Honda HR-V (2019 year). Instruction

Interior Lights/Interior Convenience Items

Interior Convenience Items

208

Co
ntrols

The ignition switch must be in ON

(

to use

the seat heaters.

Touch the seat heater icon.
Once - The HI setting (two indicators on)
Twice - The LO setting
Three times - The OFF setting (no indicator on)

*1: Models with the smart entry system have an ENGINE START/STOP button instead of an
ignition switch.

■

Seat Heaters

Seat Heaters

Do not use the seat heaters even in LO when the
engine is off. Under such conditions, the battery may
be weakened, making the engine difficult to start.

In the LO setting, the heater runs continuously and
does not automatically turn off.

WARNING

Heat induced burns are possible when
using seat heaters.

Persons with a diminished ability to sense
temperature (e.g., persons with diabetes,
lower-limb nerve damage, or paralysis) or
with sensitive skin should not use seat
heaters.

* Not available on all models

209

Continued

Co
ntrols

Heating and Cooling System

Using Vents, Heating and A/C

Mode Control Dial
Changes airflow.

Fan Control Dial
Adjusts the fan speed. Rotate the dial all
the way to OFF to turn everything off.

A/C Button
Press to cool the interior or dehumidify
while heating.

Temperature Control Dial
Adjusts the interior temperature.

(Recirculation) Button

Press the

button and switch the mode depending on

environmental conditions.

Recirculation mode (indicator on):
Recirculates air from the vehicle’s interior through the system.

Fresh air mode (indicator off):
Maintains outside ventilation. Keep the system in fresh air mode in
normal situations.

Dashboard
vents

Dashboard
and floor
vents

Floor vents

Floor and
defroster
vents

Defroster
vents

* Not available on all models

210

Heating and Cooling System

Using Vents, Heating and A/C

Co
ntrols

Three separate front passenger side air vents allow for different air flow rates
through the vehicle. Passengers can separately:

• Adjust each vent to optimize airflow

throughout the vehicle.

• Close individual vents to adjust passenger

comfort levels.

■

Passenger Side Vents

Adjust from side to side or up and
down

Mid

Low

High

Continued

211

Heating and Cooling System

Using Vents, Heating and A/C

Co
ntrols

The heater uses heat from the engine coolant
to warm the air.
1. Adjust the fan speed using the fan control

dial.

2. Select .
3. Adjust the temperature using the

temperature control dial.

■

To rapidly warm up the interior

1. Set the fan to the maximum speed.
2. Select .
3. Set the temperature to maximum warm.
4. Press the

button (the indicator on).

■

To dehumidify the interior

When used in combination with the heater, the air conditioning system makes the
interior warm and dry and can prevent the windows from fogging up.
1. Turn the fan on.
2. Press the A/C button to turn on the air conditioning.

■

Heating

Heating

When you select

, the mode automatically

switches to fresh air.

To rapidly warm up the interior

Change to fresh air mode as soon as the interior gets
warm enough. The windows may fog up if kept in
recirculation mode.

Heating and Cooling System

Using Vents, Heating and A/C

212

Co
ntrols

1. Adjust the fan speed using the fan control

dial.

2. Select .
3. Adjust the temperature using the

temperature control dial.

4. Press the A/C button (indicator on).

■

To rapidly cool down the interior

1. Set the fan to the maximum speed.
2. Set the temperature to maximum cool.
3. Press the

button (the indicator on).

Selecting

turns the air conditioning

system on and automatically switches the
system to fresh air mode.

■

To rapidly defrost the windows

1. Set the fan to the maximum speed.
2. Select .
3. Press the

button.

4. Set the temperature to maximum warm.

■

Cooling

To rapidly cool down the interior

If the interior is very warm, you can cool it down
more rapidly by partially opening the windows.

While in ECON mode, the system has greater
temperature fluctuations.

■

Defrosting the Windshield and Windows

Defrosting the Windshield and Windows

For your safety, make sure you have a clear view
through all the windows before driving.
Do not set the temperature near the upper or lower
limit.
When cold air hits the windshield, the outside of the
windshield may fog up.
If the side windows fog up, adjust the vents so that
the air hits the side windows.

To rapidly defrost the windows

After defrosting the windows, switch over to fresh air
mode.
If you keep the system in recirculation mode, the
windows may fog up from humidity. This impedes
visibility.

213

Continued

Co
ntrols

Climate Control System

Using Automatic Climate Control

The automatic climate control system maintains the interior temperature you select.
The system also selects the proper mix of heated or cooled air that raises or lowers
the interior temperature to your preference as quickly as possible.

Use the system when the engine is running.
1. Select the AUTO icon.
2. Adjust the interior temperature using the temperature control icons.
3. Select the

icon to cancel.

Using Automatic Climate Control

If any icons are selected while using the climate
control system in auto, the function of the icon that
was selected will take priority.
The AUTO indicator will go off, but functions
unrelated to the icon that was selected will be
controlled automatically.

To prevent cold air from blowing in from outside, the
fan may not start immediately when the AUTO icon
is selected.

If the interior is very warm, you can cool it down
more rapidly by partially opening the windows,
turning the system on auto, and setting the
temperature to low. Change the fresh air mode to
recirculation mode until the temperature cools down.

When you set the temperature to the lower or upper
limit, Lo or Hi is displayed.

You can raise or lower the temperature or fan speed
setting flicking either control icon.

Models without SYNC icon

Dashboard
vents

Dashboard
and floor
vents

Floor vents Floor and

defroster
vents

Temperature Control
Icons

AUTO Icon

Mode Control Icon

Fan Control Icons

(On/Off) Icon

(Recirculation) Icon

A/C (Air Conditioning) Icon

(Fresh Air) Icon

* Not available on all models

Climate Control System

Using Automatic Climate Control

214

Co
ntrols

Use the system when the engine is running.
1. Select the AUTO icon.
2. Adjust the interior temperature using the driver side temperature control icons.
3. Select the

icon to cancel.

Using Automatic Climate Control

Selecting the

icon switches the climate control

system between on and off. When turned on, the
system returns to your last selection.

While in ECON mode, the system has greater
temperature fluctuations.

Models with SYNC icon

Dashboard
vents

Dashboard
and floor
vents

Floor vents Floor and

defroster
vents

Driver Side
Temperature Control
Icons

AUTO Icon

Mode Control Icon

Passenger Side
Temperature
Control Icons

(On/Off) Icon

(Recirculation) Icon

A/C (Air Conditioning) Icon

SYNC Icon

215

Climate Control System

Using Automatic Climate Control

Continued

Co
ntrols

■

Switching between the recirculation and fresh air modes

Select the

(recirculation) or

(fresh air) icon to switch the mode

depending on environmental conditions.

Recirculation mode (indicator on): Recirculates air from the vehicle’s interior

through the system.

Fresh air mode (indicator on): Maintains outside ventilation. Keep the system

in fresh air mode in normal situations.

Select the

(recirculation) icon to switch the mode depending on

environmental conditions.
Recirculation mode (indicator on): Recirculates air from the vehicle’s interior through
the system.
Fresh air mode (indicator off): Maintains outside ventilation. Keep the system in
fresh air mode in normal situations.

Models without SYNC icon

Models with SYNC icon

Climate Control System

Using Automatic Climate Control

216

Co
ntrols

Select the

icon to turn the air conditioning

system on and automatically switch the
system to fresh air mode.

Select the

icon again to turn off, the

system returns to the previous settings.

■

Defrosting the Windshield and Windows

Defrosting the Windshield and Windows

For your safety, make sure you have a clear view
through all the windows before driving.

Do not set the temperature near the upper or lower
limit.
When cold air hits the windshield, the outside of the
windshield may fog up.

If the side windows fog up, adjust the vents so that
the air hits the side windows.

Models without SYNC icon

Models with SYNC icon

Continued

217

Climate Control System

Using Automatic Climate Control

Co
ntrols

■

To rapidly defrost the windows

1. Select the

icon.

2. Select the

icon.

To rapidly defrost the windows

After defrosting the windows, switch over to fresh air
mode. If you keep the system in recirculation mode,
the windows may fog up from humidity. This
impedes visibility.

Models without SYNC icon

Models with SYNC icon

Climate Control System

Using Automatic Climate Control

218

Co
ntrols

You hear the beep when operating the climate control system on the touch screen.
This can be turned on and off.

To turn off the beep:
1. Turn the ignition switch to ON

(

2. Touch the

of the temperature control

icon five times while pressing and holding
the .

3. Release the

, after -- blinks five times

and OF is displayed.

*1: Models with the smart entry system have an ENGINE START/STOP button instead of an
ignition switch.

■

Turning On and Off the Touch Screen Beep

Turning On and Off the Touch Screen Beep

If you touch any other icons during this procedure,
the setting may fail. In this case, once you turn the
ignition switch to OFF

(

, then follow this

procedure again.

Models without SYNC icon

Models with SYNC icon

219

Climate Control System

Using Automatic Climate Control

Continued

Co
ntrols

To turn on the beep:
1. Turn the ignition switch to ON

(

2. Touch the

of the temperature control

icon five times while pressing and holding
the .

3. Release the

, after OF blinks five times

and -- is displayed.

*1: Models with the smart entry system have an ENGINE START/STOP button instead of an
ignition switch.

Models without SYNC icon

Models with SYNC icon

Climate Control System

Using Automatic Climate Control

220

Co
ntrols

You can set the level of sensitivity of the touch control panel to high, normal, or low.

1. Turn the ignition switch to ON

(

2. Press and hold the AUTO icon, then press

any of the following icons five times to set
the level.

•

: High (Hi)

Previous setting blinks five times and Hi
will be displayed in the temperature
display area.

•

: Normal (--)

Previous setting blinks five times and --
will be displayed in the temperature
display area.

•

: Low (Lo)

Previous setting blinks five times and Lo
will be displayed in the temperature
display area.

3. Release the AUTO icon.

*1: Models with the smart entry system have an
ENGINE START/STOP button instead of an ignition
switch.
*2: Default setting

■

Touch Panel Sensitivity Setting

Touch Panel Sensitivity Setting

If you touch any other icons during this procedure,
the setting may fail. In this case, once you turn the
ignition switch to LOCK

(

, then follow this

procedure again.

Temperature display area

Models without SYNC icon

Models with SYNC icon

221

Climate Control System

Using Automatic Climate Control

Co
ntrols

You can set the temperature synchronously for the driver side and the passenger
side in synchronization mode.
1. Select the SYNC icon.

The system switches to synchronization mode.

2. Adjust the temperature using the driver’s side temperature control icon.

Select the SYNC icon to return to dual mode.

■

Synchronization Mode

Synchronization Mode

When the system is in dual mode, the driver side
temperature and the passenger side temperature can
be set separately.

SYNC Icon

Driver Side
Temperature
Control Icon

Passenger Side
Temperature
Control Icon

* Not available on all models

222

Climate Control System

Automatic Climate Control Sensors

Co
ntrols

Automatic Climate Control Sensors

The automatic climate control system is
equipped with sensors. Do not cover or spill
any liquid on them.

Sensor

Honda HR-V (2019 year). Instruction - part 14
