Honda HR-V (2019 year). Instruction - part 13

uu

Adjusting the Seats

u

Head Restraints

192

Co
ntrols

Head restraints can be removed for cleaning or repair.

To remove a head restraint:
Pull the restraint up as far as it will go. Then push the release button, and pull the
restraint up and out.

To reinstall a head restraint:
Insert the legs back in place, then adjust the head restraint to an appropriate height
while pressing the release button. Pull up on the restraint to make sure it is locked
in position.

■

Removing and Reinstalling the Head Restraints

1

Removing and Reinstalling the Head Restraints

To remove and install the rear outer head restraint,
recline the seat-back slightly forward as the space
between the ceiling and the seat-back is limited.

3

WARNING

Failure to reinstall, or correctly reinstall, the
head restraints can result in severe injury
during a crash.

Always replace the head restraints before
driving.

193

uu

Adjusting the Seats

u

Maintain a Proper Sitting Position

Co
ntrols

Maintain a Proper Sitting Position

After all occupants have adjusted their seats and head restraints, and put on their
seat belts, it is very important that they continue to sit upright, well back in their
seats, with their feet on the floor, until the vehicle is safely parked and the engine is
off.

Sitting improperly can increase the chance of injury during a crash. For example, if
an occupant slouches, lies down, turns sideways, sits forward, leans forward or
sideways, or puts one or both feet up, the chance of injury during a crash is greatly
increased.

In addition, an occupant who is out of position in the front seat can be seriously or
fatally injured in a crash by striking interior parts of the vehicle or being struck by an
inflating front airbag.

1

Maintain a Proper Sitting Position

3

WARNING

Sitting improperly or out of position can
result in serious injury or death in a crash.

Always sit upright, well back in the seat,
with your feet on the floor.

194

uu

Adjusting the Seats

u

Rear Seats

Co
ntrols

Rear Seats

Pull the lever on the right to change the angle
of the right half of the seat-back, and left for
the left half.

■

Adjusting the Rear Seat-Backs

Release Lever

Continued

195

uu

Adjusting the Seats

u

Rear Seats

Co
ntrols

The rear seats can be folded down separately to allow for additional storage space.

■

To fold down the seat

1. Store the center seat belt first. Insert the

latch plate into the slot on the side of the
anchor buckle.

2. Retract the seat belt into the holder on the

ceiling.

2 Seat Belt with Detachable Anchor P. 47

3. Lower the head restraint to its lowest

position.

4. Pull the release lever and fold down the

seat-back.

To return the seat to the original position, pull
up the seat-back in the upright position.

■

Folding Down the Rear Seats

1

Folding Down the Rear Seats

Make sure all items in the cargo area or items
extending to the rear seats are properly
secured. Loose items can fly forward if you have
to brake hard.

Remove any items from the rear seat cushion and
floor before you fold down the rear seat.

To lock the seat-back upright, push it backwards until
it locks.

Make sure the seat-back, head restraints and seat
cushion are securely latched back into place before
driving. Also, make sure all rear shoulder belts are
positioned in front of the seat-back, and the center
shoulder belt is re-positioned in the holding slot.

Make sure that the folded seat-back does not press
against the front passenger seat, as this can cause the
weight sensors in the front passenger seat to work
improperly.

2 Passenger Front Airbag Off Indicator P. 62

Anchor
Buckle

Latch Plate

Release Lever

uu

Adjusting the Seats

u

Rear Seats

196

Co
ntrols

Separately lift up the left and right halves of
the rear seat cushions to make room for cargo
area.

■

Lifting up the seat cushion

1. Make sure the seat belt buckles are in their

loops on the seat.

2. Pull up the rear seat cushion.
3. Fold the seat leg down while pushing the

seat cushion firmly against the seat-back to
lock it.

■

Putting the seat in the original position

1. Hold the seat cushion in the upright

position, and pull up the seat leg fully.

u

The seat cushion can abruptly fall down
once you pull up the seat leg.

2. Slowly put down the seat cushion and set

the seat leg in the floor guide.

u

A latch comes out when the leg is set
properly.

■

Folding the Rear Seat Up

1

Folding the Rear Seat Up

After you fold the seat up, or put it back in the
original position, make sure the seat is firmly secured
by rocking it forward and back.

Check if there are any items on the seat before you
pull the seat cushion up. Check if there are any
obstacles around the floor guide before you put the
seat back in the original position.

Loop

Seat Leg

Floor Guide

Latch

Seat Leg

197

uu

Adjusting the Seats

u

Armrest

Co
ntrols

Armrest

The console lid can be used as an armrest.

To adjust:
Slide the armrest to the desired position.

Pull down the armrest in the center backrest.

■

Using the Front Seat Armrest

■

Using the Rear Seat Armrest

*

* Not available on all models

198

Co
ntrols

Interior Lights/Interior Convenience Items

Interior Lights

■

ON

The interior lights come on regardless of
whether the doors are open or closed.

■

Door activated

The interior lights come on in the following
situations:
• When any doors are opened.
• You unlock the driver’s door.

• You remove the key from the ignition

switch.

• When the power mode is set to VEHICLE

OFF (LOCK).

■

OFF

The interior lights remain off regardless of
whether the doors are open or closed.

■

Interior Light Switches

1

Interior Light Switches

In the door activated position, the interior lights fade
out and go off about 30 seconds after the doors are
closed.
The lights go off after about 30 seconds in the
following situations:

•

When you unlock the driver’s door but do not open it.

•

When you remove the key from the ignition switch
but do not open a door.

•

When you set the power mode to VEHICLE OFF
(LOCK) but do not open a door.

You can change the interior lights dimming time.

2 Customized Features P. 122

The interior lights go off immediately in the following
situations:

•

When you lock the driver’s door.

•

When you turn the ignition switch to ON

(

w

*1

.

•

When you close the driver’s door with the key in
the ignition switch.

•

When you close the driver’s door in ACCESSORY
mode.

*1: Models with the smart entry system have an ENGINE
START/STOP button instead of an ignition switch.

Models without smart entry system

Models with smart entry system

Models with multi-information display

Models without smart entry system

Models with smart entry system

On

Off

Door Activated Position

Front

*

Rear

Door Activated Position

Off

Models without smart entry system

Models with smart entry system

* Not available on all models

199

uu

Interior Lights/Interior Convenience Items

u

Interior Lights

Co
ntrols

The map lights can be turned on and off by
pressing the lenses.

■

ON

The light comes on when you open the
tailgate, and goes off when closed.

■

OFF

The light stays off with or without opening the
tailgate.

■

Map Lights

1

Interior Light Switches

To avoid draining the battery, do not leave the
interior light on for an extended length of time when
the engine is off.

If you leave any of the doors open in VEHICLE OFF
(LOCK) mode, or without the key in the ignition
switch, the interior lights go off after about 15
minutes.

1

Map Lights

When the front interior light switch is in the door
activated position and any door is open, the map
light will not go off when you press the lens.

Models with moonroof

Models with moonroof

Models without moonroof

■

Cargo Area Light

On

Off

200

uu

Interior Lights/Interior Convenience Items

u

Interior Convenience Items

Co
ntrols

Interior Convenience Items

Pull the handle to open the glove box.

Pull the handle to open the console
compartment.

■

Glove Box

1

Glove Box

3

WARNING

An open glove box can cause serious injury
to your passenger in a crash, even if the
passenger is wearing the seat belt.

Always keep the glove box closed while
driving.

■

Console Compartment

Continued

201

uu

Interior Lights/Interior Convenience Items

u

Interior Convenience Items

Co
ntrols

■

Front seat beverage holders

■

Center console beverage holders

To put a short-size beverage: Push down
the bottom plate.

To put a tall-size beverage: Pull up the
bottom plate.

■

Beverage Holders

1

Beverage Holders

NOTICE

Spilled liquids can damage the upholstery, carpeting,
and electrical components in the interior.

Be careful when you are using the beverage holders.
Hot liquid can scald you.

Front Door

Center Console

Bottom plate

202

uu

Interior Lights/Interior Convenience Items

u

Interior Convenience Items

Co
ntrols

■

Rear seat beverage holders

Rear Door

At the Back of the Center Console

203

uu

Interior Lights/Interior Convenience Items

u

Interior Convenience Items

Continued

Co
ntrols

Pull up the cargo area floor lid.

■

Cargo Floor Box

Cargo Floor Box

2WD models

AWD models

Cargo Floor Box

uu

Interior Lights/Interior Convenience Items

u

Interior Convenience Items

204

Co
ntrols

The accessory power socket can be used when the ignition switch is in ACCESSORY

(

q or ON

(

w

*1

.

■

Accessory power socket (console panel)

Open the cover to use it.

■

Accessory power socket (rearward of
center console)

Open the cover to use it.

*1: Models with the smart entry system have an ENGINE START/STOP button instead of an
ignition switch.

■

Accessory Power Sockets

1

Accessory Power Sockets

NOTICE

Do not insert an automotive type cigarette lighter
element.
This can overheat the power socket.

Each accessory power socket is designed to supply
power for 12 volt DC accessories that are rated 180
watts (15 amps) or less.

To prevent battery drain, only use the power socket
with the engine running.

When both sockets are being used, the combined
power rating of the accessories should not exceed
180 watts (15 amps).

Cover

Continued

205

uu

Interior Lights/Interior Convenience Items

u

Interior Convenience Items

Co
ntrols

■

Accessory power socket (cargo area)

Open the cover to use it.

There is a coat hook on the rear left grab
handle. Pull it down to use it.

Canadian models

■

Coat Hook

1

Coat Hook

The coat hook is not designed for large or heavy
items.

206

uu

Interior Lights/Interior Convenience Items

u

Interior Convenience Items

Co
ntrols

The tie-down anchors on the cargo area floor
can be used to install a net for securing items.

■

Tie-down Anchors

Front Anchors

Rear Anchors

Continued

207

uu

Interior Lights/Interior Convenience Items

u

Interior Convenience Items

Co
ntrols

The cargo cover can be used to conceal your
items and protect them from direct sunlight.

■

To remove:

Pull out the cargo cover rearwards and
remove it.

■

To fold:

The cargo cover is collapsible.
1. Take the opposite sides, fold the cover

halfway, then twist into opposite ways.

2. Curl to narrow the cover as shown.

■

Cargo Cover

Canadian models

1

Cargo Cover

Do not let anyone access items in the cargo area
while driving. Loose items can cause injury if you have
to brake hard.

Do not stack objects higher than the top of the seat
in the cargo area. They could block your view and be
thrown about the vehicle during a sudden stop.

To prevent cargo cover damage, do not:

•

Place items on the cargo cover.

•

Put weight on the cargo cover.

When reinstalling the cargo cover, put the tagged
side first.

Tag
