176

uu

Operating the Switches Around the Steering Wheel

u

Daytime Running Lights

Co
ntrols

Daytime Running Lights

The headlights come on slightly dimmer than normal when the following conditions
have been met:
• The ignition switch is in ON

(

w

*1

.

• The headlight switch is off, or in

.

• The headlight switch is AUTO, or in

.

• The parking brake is released.

The lights remain on even if you set the parking brake. Turning off the ignition
switch or setting the power mode to VEHICLE OFF will turn off the daytime running
lights.

The daytime running lights are off once the headlight switch is turned on, or when
the head light switch is in AUTO

*

 and it is getting darker outside.

*1: Models with the smart entry system have an ENGINE START/STOP button instead of an
ignition switch.

1

Daytime Running Lights

The daytime running lights come on dimmer when
the headlight switch is in

 than when it is in

AUTO

*

. In AUTO

*

, if the ambient brightness is dark,

the low beam headlights come on.

U.S. models

Canadian models

All models

* Not available on all models

177

uu

Operating the Switches Around the Steering Wheel

u

Wipers and Washers

Continued

Co
ntrols

Wipers and Washers

The windshield wipers and washers can be
used when the ignition switch is in ON

(

w

*1

.

■

MIST

The wipers run at high speed until you release
the lever.

■

Wiper switch (OFF, INT

*2

/AUTO

*3

, LO, HI)

Change the wiper switch setting according to
the amount of rain.

■

Adjusting wiper operation

*

Turn the adjustment ring to adjust the wiper
delay.

■

Washer

Sprays while you pull the lever toward you.
When you release the lever for more than one
second, the spray stops, the wipers sweep two
or three more times to clear the windshield,
then stop.

*1: Models with the smart entry system have an ENGINE START/STOP button instead of an
ignition switch.
*2: Models without automatic intermittent wipers.
*3: Models with automatic intermittent wipers.

■

Windshield Wiper/Washer

1

Wipers and Washers

NOTICE

Do not use the wipers when the windshield is dry.
The windshield will get scratched, or the rubber
blades will get damaged.

NOTICE

In cold weather, the blades may freeze to the
windshield.
Operating the wipers in this condition may damage
the wipers. Use the defroster to warm the
windshield, then turn the wipers on.

If the vehicle speeds up while the wipers are
operating intermittently, the length of the wipe
interval shortens.
When the vehicle speeds up, the wiper operation’s
shortest delay setting (

) and the LO setting

become the same.

Turn the washers off if no washer fluid comes out.
The pump may get damaged.

Models with intermittent time adjustment ring

All models

Pull to
use
washer.

MIST

INT

*2

/

AUTO

*3

OFF

LO: Low speed wipe

HI: High speed wipe

Intermittent Time
Adjustment Ring

*

Lower speed, fewer sweeps

Higher speed, more sweeps

* Not available on all models

uu

Operating the Switches Around the Steering Wheel

u

Wipers and Washers

178

Co
ntrols

When you push the lever down to AUTO, the
windshield wipers sweep once, and go into
the automatic mode.

The wipers operate intermittently, at low
speed, or at high speed and stops in
accordance with the amount of rainfall the
rainfall sensor detects.

■

Auto sensitivity adjustment

When in AUTO, you can also adjust the rainfall sensor sensitivity using the
adjustment ring.

Sensor sensitivity

*1: Models with the smart entry system have an ENGINE START/STOP button instead of an
ignition switch.

■

Automatic Intermittent Wipers

*

1

Wipers and Washers

If the wiper stops operating due to any obstacle such as
the build-up of snow, park the vehicle in a safe place.
Rotate the wiper switch to OFF, and turn the ignition
switch to ACCESSORY

(

q or LOCK

(

0

*1

, then

remove the obstacle.

The wiper motor may stop motor operation
temporarily to prevent an overload.
Wiper operation will return to normal within a few
minutes, once the circuit has returned to normal.

1

Automatic Intermittent Wipers

*

The rainfall sensor is in the location shown below.

NOTICE

AUTO should always be turned OFF before the
following situations in order to prevent severe
damage to the wiper system:

•

Cleaning the windshield

•

Driving through a car wash

•

No rain present

Rainfall Sensor

Adjustment Ring

Low sensitivity

High sensitivity

* Not available on all models

179

uu

Operating the Switches Around the Steering Wheel

u

Wipers and Washers

Co
ntrols

The rear wiper and washer can be used when
the ignition switch is in ON

(

w

*1

.

■

Wiper switch (OFF, INT, ON)

Change the wiper switch setting according to
the amount of rain.

■

Washer (

)

Sprays while you rotate the switch to this
position.

Hold it to activate the wiper and to spray the
washer. Once released, it stops operating
after a few more sweeps.

■

Operating in reverse

When you shift the transmission to

(

R with the windshield wiper activated, the rear

wiper operates automatically as follows even if its switch is off.

*1: Models with the smart entry system have an ENGINE START/STOP button instead of an
ignition switch.

■

Rear Wiper/Washer

ON

INT: Intermittent

OFF

Washer

Front Wiper Position

Rear Wiper Operation

INT

*

 (Intermittent)

AUTO

*

 (Intermittent)

Intermittent

LO (Low speed wipe)
HI (High speed wipe)

Continuous

* Not available on all models

180

uu

Operating the Switches Around the Steering Wheel

u

Brightness Control

Co
ntrols

Brightness Control

When the ignition switch is in ON

(

w

*1

, you

can use the

 (select/reset) knob to adjust

instrument panel brightness.
Brighten: Turn the knob to the right.
Dim: Turn the knob to the left.

You will hear a beeper when the brightness
reaches minimum or maximum. Several
seconds after you have adjusted the
brightness, you will be returned to the
previous screen.

*1: Models with the smart entry system have an ENGINE START/STOP button instead of an
ignition switch.

1

Brightness Control

Instrument panel brightness varies, depending on
whether the exterior lights are on or off. The
instrument panel dims to reduce glare when they are
on.

To cancel the reduced instrument panel brightness
when the exterior lights are on, turn the knob to the
right until the brightness display is up to max, the
beeper sounds.

The brightness can be set differently for when the
exterior lights are on, and when they are off.

 (Select/Reset) Knob

181

uu

Operating the Switches Around the Steering Wheel

u

Brightness Control

Co
ntrols

■

Brightness level indicator

The brightness level is shown on the
information display/multi-information display
 while you are adjusting it.

Models with information display

Models with multi-information
display

182

uu

Operating the Switches Around the Steering Wheel

u

Defogger/Heated Door Mirror

*

/Heated Windshield

*

Co
ntrols

Defogger/Heated Door Mirror

*

/Heated Windshield

*

Press the rear defogger button or touch the
icon to defog the rear window and mirrors
when the ignition switch is in ON

(

w

*1

.

The rear defogger and heated door mirrors
automatically switch off after 10-30 minutes
depending on the outside temperature.
However, if the outside temperature is 32°F
(0°C) or below, they do not automatically
switch off.

*1: Models with the smart entry system have an ENGINE START/STOP button instead of an
ignition switch.

■

Rear Defogger/Heated Door Mirror

*

 Button

1

Rear Defogger/Heated Door Mirror

*

 Button

This system consumes a lot of power, so turn it off
when the window has been defogged.
Also, do not use the system for a long time while the
engine is idling. This may weaken the battery, making
it difficult to start the engine.

Models with heating and cooling system

Models with climate control system

Models with climate control system

* Not available on all models

183

uu

Operating the Switches Around the Steering Wheel

u

Defogger/Heated Door Mirror

*

/Heated Windshield

*

Co
ntrols

Press the heated windshield button to deice
the windshield when the ignition switch is
turned to ON

(

w

*1

.

The heated windshield automatically switch
off after 15 minutes.

*1: Models with the smart entry system have an ENGINE START/STOP button instead of an
ignition switch.

■

Heated Windshield Button

Canadian models

1

Heated Windshield Button

This system consumes a lot of power, so turn it off
when the window has been deiced.
Also, do not use the system for a long time while the
engine is idling. This may weaken the battery, making
it difficult to start the engine.

184

uu

Operating the Switches Around the Steering Wheel

u

Adjusting the Steering Wheel

Co
ntrols

Adjusting the Steering Wheel

The steering wheel height and distance from your body can be adjusted so that you
can comfortably grip the steering wheel in an appropriate driving posture.

1. Pull the steering wheel adjustment lever up.

u

The steering wheel adjustment lever is
under the steering column.

2. Move the steering wheel up or down, and

in or out.

u

Make sure you can see the instrument
panel gauges and indicators.

3. Push the steering wheel adjustment lever

down to lock the steering wheel in position.

u

After adjusting the position, make sure
you have securely locked the steering
wheel in place by trying to move it up,
down, in, and out.

1

Adjusting the Steering Wheel

3

WARNING

Adjusting the steering wheel position while
driving may cause you to lose control of the
vehicle and be seriously injured in a crash.

Adjust the steering wheel only when the
vehicle is stopped.

To adjust

To lock

Lever

185

Co
ntrols

Adjusting the Mirrors

Interior Rearview Mirror

Adjust the angle of the rearview mirror when you are sitting in the correct driving
position.

Flip the tab to switch the position.
The night position will help to reduce the glare
from headlights behind you when driving
after dark.

When you are driving after dark, the
automatic dimming rearview mirror reduces
the glare from headlights behind you. Press
the AUTO button to turn this function on and
off. When activated, the AUTO indicator
comes on.

■

Rearview Mirror with Day and Night Positions

*

1

Adjusting the Mirrors

Keep the inside and outside mirrors clean and
adjusted for best visibility.

Adjust the mirrors before you start driving.

2 Front Seats P. 187

Tab

Daytime
Position

Night Position

Up

Down

■

Automatic Dimming Rearview Mirror

*

1

Automatic Dimming Rearview Mirror

*

The auto dimming function cancels when the shift
position is in

(

R.

Sensor

Auto Button

Indicator

* Not available on all models

186

uu

Adjusting the Mirrors

u

Power Door Mirrors

Co
ntrols

Power Door Mirrors

You can adjust the door mirrors when the
ignition switch is in ON

(

w

*1

.

■

Mirror position adjustment

L/R selector switch: Select the left or right
mirror. After adjusting the mirror, return the
switch to the center position.
Mirror position adjustment switch: Press
the switch left, right, up, or down to move the
mirror.

*1: Models with the smart entry system have an ENGINE START/STOP button instead of an
ignition switch.

Selector Switch

Adjustment Switch

187

Continued

Co
ntrols

Adjusting the Seats

Front Seats

Adjust the driver’s seat as far back as possible
while allowing you to maintain full control of
the vehicle. You should be able to sit upright,
well back in the seat and be able to
adequately press the pedals without leaning
forward, and grip the steering wheel
comfortably. The passenger’s seat should be
adjusted in a similar manner, so that it is as far
back from the front airbag in the dashboard
as possible.

■

Adjusting the driver’s power seat

*

1

Adjusting the Seats

The National Highway Traffic Safety Administration
and Transport Canada recommend that drivers allow
at least 10 inches (25 cm) between the center of the
steering wheel and the chest.

Always make seat adjustments before driving.

3

WARNING

Sitting too close to a front airbag can result
in serious injury or death if the front
airbags inflate.

Always sit as far back from the front
airbags as possible while maintaining
control of the vehicle.

Move back.

Allow sufficient
space.

■

Adjusting the Seat Positions

1

Adjusting the Seat Positions

Once a seat is adjusted correctly, rock it back and
forth to make sure it is locked in position.

Horizontal
Position
Adjustment

Height
Adjustment
(Driver’s seat
only)

Seat-back
Angle
Adjustment

* Not available on all models

188

uu

Adjusting the Seats

u

Front Seats

Co
ntrols

■

Adjusting the front manual seat(s)

*

Horizontal Position
Adjustment
Pull up on the bar to move the
seat, then release the bar.

Driver’s seat is shown.

Seat-back Angle Adjustment
Pull up the lever to change the
angle.

Height Adjustment
(Driver side only)
Pull up or push down the lever
to raise or lower the seat.

* Not available on all models

189

uu

Adjusting the Seats

u

Front Seats

Co
ntrols

Adjust the driver’s seat-back to a comfortable,
upright position, leaving ample space
between your chest and the airbag cover in
the center of the steering wheel.

The front seat passenger should also adjust
their seat-back to a comfortable, upright
position.

Reclining a seat-back so that the shoulder part of the belt no longer rests against the
occupant’s chest reduces the protective capability of the belt. It also increases the
chance of sliding under the belt in a crash and being seriously injured. The farther a
seat-back is reclined, the greater the risk of injury.

■

Adjusting the Seat-Backs

1

Adjusting the Seat-Backs

Do not put a cushion, or other object, between the
seat-back and your back.
Doing so may interfere with proper seat belt or airbag
operation.

If you cannot get far enough away from the steering
wheel and still reach the controls, we recommend
that you investigate whether some type of adaptive
equipment may help.

3

WARNING

Reclining the seat-back too far can result in
serious injury or death in a crash.

Adjust the seat-back to an upright position,
and sit well back in the seat.

190

uu

Adjusting the Seats

u

Head Restraints

Co
ntrols

Head Restraints

Your vehicle is equipped with head restraints in all seating positions.

Head restraints are most effective for
protection against whiplash and other rear-
impact crash injuries when the center of the
back of the occupant’s head rests against the
center of the restraint. The tops of the
occupant’s ears should be level with the
center height of the restraint.

To raise the head restraint:
Pull it upward.
To lower the head restraint:
Push it down while pressing the release
button.

■

Adjusting the front head restraint positions

1

Adjusting the front head restraint positions

In order for the head restraint system to work
properly:

•

Do not hang any items on the head restraints, or
from the restraint legs.

•

Do not place any objects between an occupant and
the seat-back.

•

Install each restraint in its proper location.

3

WARNING

Improperly positioning head restraints
reduces their effectiveness and increases
the likelihood of serious injury in a crash.

Make sure head restraints are in place and
positioned properly before driving.

Position head in the center
of the head restraint.

191

uu

Adjusting the Seats

u

Head Restraints

Continued

Co
ntrols

A passenger sitting in a back seating position
should adjust the height of their head restraint
to an appropriate position before the vehicle
begins moving.
To raise the head restraint:
Pull it upward.
To lower the head restraint:
Push it down while pressing the release
button.

■

Changing the Rear Seat Head Restraint Positions

Outer

Center
