Geely FC. Manual part - 82
Windshield/bodywork glass/wing mirror--Rear ventilation window
figure.
A: 40mm
B: 8mm
17. Assemble rear ventilation window inboard sealed
tape [68000105]
Stick sealed tape with double faced adhesive tape on both
sides.
18. Assemble rear ventilation window assembly
[68000103]
(a) Put rear ventilation window at the right position.
(b) Inspect the contacting part of rear ventilation window brim
whether it is flat.
(c) Mark signal between bodywork and glass.
(d) Disassemble rear ventilation window
(e) Use blade to remove coarseness area.
Note: leave agglutinant as much as possible on the
bodywork.
(f) Use duster cloth with cleaner to clean the agglutinant on
the cutting surface.
Clues on: When all the agglutinant has been removed
completely, clean the bodywork.
(g) Use brush to daub M priming paint on the contacting part
of bodywork.
Notes:
z
Dry M priming paint for three minutes.
z
Do not daub M priming paint on the agglutinant.
z
Opened M priming paint can not use for the next
time.
(h) Use brush or sponge to daub G priming paint on the front
windscreen brim and contacting interface.
(i) When daub other areas beside regulations, use clean duster
325
Bond
Bond
