LANE CENTERING LIMITATIONS

Adaptive cruise control limitations apply
to lane centering unless stated otherwise
or contradicted by a lane centering
limitation.  See

Adaptive Cruise Control

Limitations

 (page 342).

Lane Centering may not correctly operate
in any of the following conditions:
•

The lane is too narrow or wide.

•

The system does not detect at least
one lane marking or when lanes merge
or split.

•

Limited steering torque input is applied.

•

Areas under construction or new
infrastructure.

•

When modifications to the steering
system have been made.

•

When using a spare tire.

•

In high wind conditions.

Note:

The driving assistance torque is

limited and may not be sufficient for all
driving situations such as driving through
tight curves or driving through curves at high
speeds.

Note:

In exceptional conditions, such as

inclement weather or direct sunlight, the
system could deviate from the center line
or could cancel.

SWITCHING LANE CENTERING ON
AND OFF

Keep your hands on the steering wheel at
all times.

The controls are on the steering wheel.

E308131

Press the button.

The indicator appears in the instrument
cluster display. When the system is on, the
color of the indicator changes to indicate
the system status.

You can override the system at any time
by steering your vehicle.

Note:

The correct requirements must be

met before you can switch the system on.
See

Lane Centering Requirements

 (page

348).

Enabling and Disabling Lane
Centering

1.

Press

Features

 on the touchscreen.

2. Press

Driver Assistance

.

3. Press

Cruise Control

.

4. Press

Lane Centering Assist

.

LANE CENTERING ALERTS

You must keep your hands on the steering
wheel at all times.

When the system is active and detects no
steering activity for a period of time, the
system alerts you to put your hands on the
steering wheel. If you do not react to the
warnings the system cancels and slows
your vehicle down to idle speeds while
maintaining steering control. See

Lane

Centering Automatic Cancellation

(page 349).

The system also alerts you if your vehicle
crosses lane markings without detected
steering activity.

Note:

The system could detect a light grip

or touch on the steering wheel as hands-off
driving.

LANE CENTERING AUTOMATIC
CANCELLATION

When an external condition cancels the
system, and your hands are on the steering
wheel, a tone sounds and a message
appears in the instrument cluster display.

349

Adaptive Cruise Control

 (If Equipped)

When an external condition cancels the
system, and your hands are not on the
steering wheel, the system immediately
alerts you to take control of the vehicle. If
this alert is ignored, the system slows the
vehicle while maintaining steering
assistance when lane markings are
available. When no lane markings are
available, the vehicle comes to a stop.

E308130

If your vehicle starts to slow
down after system cancellation,
you must take full control of the

vehicle. To re-enable adaptive cruise
control with lane centering after
cancellation, press and release the resume
button.

Automatic cancellation can also occur if:
•

The lane becomes too wide or narrow.

•

The system cannot detect valid lane
markings.

•

Lane markings cross over one another.

•

The curve of the road is too sharp.

Note:

If your vehicle slows down due to your

inactivity twice within a key cycle, the
system disables. To reset the system, when
the vehicle is stationary, return the gear
selector to park (P) and turn the vehicle off.
Then, restart the vehicle with your foot on
the brake pedal.

LANE CENTERING MANUAL
CANCELLATION

When you perform the following actions,
adaptive cruise control with lane centering
will cancel:

•

The brake pedal is pressed.

•

Adaptive cruise control button on the
steering wheel is switched off.

The lane centering system is momentarily
suppressed when either of the following
actions are performed:

•

Turn signal indicator is latched or
tapped.

•

You steer the vehicle out of lane.

LANE CENTERING INDICATORS

E297977

Illuminates when you switch
lane centering on. The color of
the indicator changes to indicate

the system status.

Gray status indicates the system is on but
in standby mode.

Green status indicates the system is
enabled and applying steering assistance
to keep the vehicle in the center of the lane.

Amber status with an audible tone, that
then changes to gray status, indicates a
system automatic cancellation.

LANE CENTERING –
TROUBLESHOOTING

LANE CENTERING –
INFORMATION MESSAGES

Note:

Depending on your vehicle options

and instrument cluster type, some
messages can appear different or not at all.

350

Adaptive Cruise Control

 (If Equipped)

Details

Message

You must return your hands to the steering wheel and provide

steering input to cancel the message.

Keep Hands on Steering

Wheel

Lane centering is currently not available, due to conditions

that prevent the system from becoming active. To reset the

system, when the vehicle is stationary, return the gear selector

to park (P) and turn the vehicle off. Then, restart the vehicle

with your foot on the brake pedal.

Lane Centering Assist

Not Available

Adaptive cruise control with lane centering is about to cancel.

You must immediately take full control of the vehicle.

Resume Control

Adaptive cruise control with lane centering is in standby mode.

When safe to do so, you can resume adaptive cruise control

with lane centering by applying pressure on the accelerator
pedal. Alternatively, you can also re-enable adaptive cruise

control with lane centering by pressing the resume button on

the steering wheel.

Press Accelerator Pedal

to Resume

PREDICTIVE SPEED ASSIST

HOW DOES PREDICTIVE SPEED
ASSIST WORK

Predictive Speed Assist works with
adaptive cruise control and adjusts the
vehicle speed to the road geometry and to
the speed limit detected by the speed sign
recognition system. As the system
identifies curves and highway exits, the
vehicle speed temporarily decreases ahead
of and during the changing road geometry.
When passing new speed signs, the set
speed updates.  See

Predictive Speed

Assist Precautions

 (page 351).

There are limitations that affect the
accuracy of the speed sign recognition
system and its ability to determine the
current speed limit. Predictive speed assist
and its ability to determine the current
speed limit shares these limitations.  See

Speed Sign Recognition

 (page 408).

Note:

The adaptive cruise control gap

setting operates normally when the feature
is enabled.

PREDICTIVE SPEED ASSIST
PRECAUTIONS

WARNING:

You are responsible for

controlling your vehicle at all times. The
system is designed to be an aid and does
not relieve you of your responsibility to
drive with due care and attention. Failure
to follow this instruction could result in
the loss of control of your vehicle,
personal injury or death.

WARNING:

Pay close attention to

changing road conditions. You may need
to override the system by pressing the
brake or accelerator pedal if the adjusted
speed becomes higher or lower than
necessary.

351

Adaptive Cruise Control

 (If Equipped)

WARNING:

The system only

provides limited braking. Your vehicle
may not always decelerate quickly
enough to avoid a crash without driver
intervention. Apply the brakes when
necessary.

WARNING:

The system does not

activate the turn signal.

Adaptive cruise control precautions apply
to predictive speed assist unless stated
otherwise or contradicted by a predictive
speed assist precaution.  See

Adaptive

Cruise Control Precautions

 (page 341).

The system only applies limited braking.
You can override the system with the
accelerator pedal or cancel the system by
applying the brakes.

The system may adapt to various factors
such as time of day, lane width. This could
influence speed adjustments and
accelerations.

The system may adapt to various drive
modes.  See

Drive Mode Control

 (page

372). This could influence speed
adjustments and accelerations.

Note:

The system does not activate the

turn signal automatically.

PREDICTIVE SPEED ASSIST
LIMITATIONS

WARNING:

The system may not

always adjust vehicle speed in certain
road or weather conditions such as
crossing traffic, yield or stop signs, right
of way, traffic lights, speed bumps, rain,
snow, fog. You must always apply the
brake or accelerator pedal when
necessary.

The road geometry and speed limit
information provided by the navigation
map data could be inaccurate or out of
date.

The system may not detect and read
speed limit signs with conditional
information, for example, when a sign is
flashing, during specific time ranges, or
when children are present.

Note:

The system does not set the vehicle

speed to speed limits shown with a
supplementary traffic sign.

Under certain conditions, the system may
not adjust the vehicle speed until after your
vehicle passes the speed limit.

Detection of road geometry operates only
where related information is available.
Road geometry information may not be
available in some areas.

SWITCHING PREDICTIVE SPEED
ASSIST MODE ON AND OFF

1.

Press

Features

 on the touchscreen.

2. Press

Driver Assistance

.

3. Press

Cruise Control

.

4. Press

Adaptive Cruise Control

.

5. Switch

Predictive Speed Assist

 on or

off.

ADJUSTING THE SET SPEED
TOLERANCE

1.

Press

Features

 on the touchscreen.

2. Press

Driver Assistance

.

3. Press

Cruise Control

.

4. Press

Adaptive Cruise Control

.

5. Switch

Predictive Speed Assist

 on.

6. Press

Tolerance

.

7.

Adjust the slider to set the tolerance.

352

Adaptive Cruise Control

 (If Equipped)

Note:

You can set tolerance for vehicle

speed adjustment based on speed sign
recognition only.

PREDICTIVE SPEED ASSIST
ALERTS

If the speed sign recognition system
detects a speed limit below the minimum
adaptive cruise control set speed, a tone
sounds and the system returns to standby
mode.

PREDICTIVE SPEED ASSIST
INDICATORS

A blue marker around the speed sign and
a blue arrow next to the set speed
indicates that the system is active.

Speed Sign Indicator

E413515

When the system detects a new speed
sign, a gray indicator appears above the
set speed while the system adjusts the
vehicle speed to the speed limit. When the
speed limit is reached, the set speed
updates and the gray indicator disappears.

Road Geometry Indicator

When the system detects a curve or
highway exit, the vehicle starts to
decelerate, and the indicator appears and
changes color.

Road Geometry Indicator Symbols

E379737

Left curve.

E379738

Right curve.

353

Adaptive Cruise Control

 (If Equipped)

PREDICTIVE SPEED ASSIST – TROUBLESHOOTING

PREDICTIVE SPEED ASSIST – INFORMATION MESSAGES

Details

Message

Navigation system based speed limit information is not

available. If the message continues to appear, have your

vehicle checked as soon as possible.

Adaptive Cruise Control

Speed Sign Recognition

Not Available

The system is going to cancel and you must take control.

Driver Resume Control

ADAPTIVE CRUISE CONTROL
– TROUBLESHOOTING

ADAPTIVE CRUISE CONTROL –
INFORMATION MESSAGES

Note:

Depending on your vehicle options

and instrument cluster type, not all
messages display or are available.

Note:

The system could abbreviate or

shorten certain messages depending upon
which cluster type you have.

Action

Message

A malfunction is preventing the adaptive cruise from engaging.

Adaptive Cruise

Malfunction

Front Sensor Not Aligned

Contact an authorized dealer to have the radar checked for

proper coverage and operation.

Conditions exist preventing the system from being available.

Adaptive Cruise Not

Available

You have a blocked radar because of poor radar visibility due
to inclement weather or ice, mud, or water in front of the radar.

You can typically clean the sensor to resolve this.

Adaptive Cruise Not

Available Sensor

Blocked See Manual

Due to the nature of radar technology, it is possible to get a

blockage warning with no actual block. This happens, for

example, when driving in sparse rural or desert environments.
A false blocked condition either self clears, or clears after you

restart your vehicle.

354

Adaptive Cruise Control

 (If Equipped)

Action

Message

You have selected normal cruise control. The system does

not brake or react to traffic.

Normal Cruise Active

Adaptive Braking Off

Displays when the adaptive cruise control is going to cancel

and you must take control.

Adaptive Cruise - Driver

Resume Control

Displays when the vehicle speed is too slow to activate the

adaptive cruise control and there is no lead vehicle in range.

Adaptive Cruise Speed

Too Low to Activate

355

Adaptive Cruise Control

 (If Equipped)

WHAT IS BLUECRUISE

BlueCruise keeps your vehicle centered in
the lane and offers a hands-free driving
mode in certain situations when using
adaptive cruise control.

HOW DOES BLUECRUISE
WORK

BlueCruise uses cameras to monitor your
vehicle position within a lane and applies
steering support to keep your vehicle
centered in the lane.

Using the cameras and location
information, BlueCruise allows you to
remove your hands from the steering wheel
and offers a hands-free driving mode in
certain areas.

When active, BlueCruise uses a driver
facing camera and infrared lighting to
monitor your eyes and head position to
detect if you are distracted. If the system
determines you are distracted, it alerts you
to return your eyes to the road.

E319812

A

A

B

Lighting area.

A

Camera.

B

Note:

When BlueCruise is active, in certain

crash or near crash-like situations, such as
an air bag deployment or hitting a road
obstacle, camera data may record through
the vehicle event data recorder.  See

Event

Data

 (page 30).

Note:

No data records under normal driving

conditions.

BLUECRUISE PRECAUTIONS

WARNING:

You are responsible for

keeping your eyes on the road at all
times. The system is designed to be an
aid and does not relieve you of your
responsibility to drive with due care and
attention. Failure to follow this
instruction could result in the loss of
control of your vehicle, personal injury or
death.

WARNING:

You are responsible for

controlling your vehicle at all times. The
system is designed to be an aid and does
not relieve you of your responsibility to
drive with due care and attention. Failure
to follow this instruction could result in
the loss of control of your vehicle,
personal injury or death.

WARNING:

Do not use the system

when towing a trailer. Failure to follow
this instruction could result in the loss of
control of your vehicle, personal injury or
death.

WARNING:

Obstructions to the

driver facing camera or infrared lighting
could prevent the system from properly
operating. Keep the camera and lighting
areas free from obstruction. Failure to
follow this instruction could result in the
loss of control of your vehicle, personal
injury or death.

356

BlueCruise

 (If Equipped)

WARNING:

Do not use the system

if any changes or modifications to the
steering wheel have been made. Any
changes or modifications to the steering
wheel could affect the functionality or
performance of the system. Failure to
follow this instruction could result in the
loss of control of your vehicle, personal
injury or death.

WARNING:

The system may not

function if the sensor is blocked.

WARNING:

Pay close attention to

changing road conditions such as
entering or leaving a highway, on roads
with intersections or roundabouts, roads
without visible lanes of travel, roads that
are winding, slippery, unpaved, or steep
slopes.

WARNING:

The system is not a

crash warning or avoidance system.

WARNING:

Large contrasts in

outside lighting can limit sensor
performance.

WARNING:

The system attempts

to keep your vehicle in the center of the
lane as well as maintain speed and gap
control. The system may not be able to
perform these tasks in all situations. Do
not use the system in complex or
uncertain driving conditions. Failure to
follow this instruction could result in the
loss of control of your vehicle, personal
injury or death.

WARNING:

Your vehicle could drift

out of the lane of travel. Always be
prepared to manually steer your vehicle.
Failure to follow this instruction could
result in the loss of control of your
vehicle, personal injury or death.

WARNING:

The system will not

operate if the sensor cannot track the
road lane markings.

BLUECRUISE REQUIREMENTS

BlueCruise only activates when all of the
following occur:
•

BlueCruise service plan is active. See
Ford.com
(https://www.ford.com/connectedservices/)
or the FordPass App for details.

•

Modem is enabled. See

Connecting

the Vehicle to a Mobile Network

(page 615).

•

BlueCruise is enabled in your center
display screen. See

BlueCruise

Settings

 (page 358).

•

Adaptive cruise control is on.

•

The system detects both lane
markings.

•

Your hands are on the steering wheel.

•

Your eyes are on the road.

Note:

For hands-free mode to work, your

vehicle must be on certain limited access
divided freeways.

Note:

The system may require updated

software for hands-free mode. See

Vehicle

Software Updates

 (page 650).

Note:

Without an active BlueCruise

subscription, your vehicle is still capable of
lane centering. This system requires you to
keep your hands on the steering wheel at
all times. See

Lane Centering

Requirements

 (page 348).

357

BlueCruise

 (If Equipped)

BLUECRUISE LIMITATIONS

Any of the following conditions could result
in BlueCruise not correctly operating:
•

You do not have your vehicle centered
in the lane.

•

The lane is too narrow or too wide.

•

The system does not detect at least
one lane marking or when lanes merge
or split.

•

You are applying a low amount of
steering input.

•

You are using the system in areas under
construction.

•

If you make any aftermarket
modifications to the steering system.

•

You are using a spare tire.

The driver-facing camera may not operate
correctly due to any of the following:
•

You have a pre-existing eye condition,
such as an eye misalignment, or have
had eye surgery.

•

You cover your facial features by a
mask, hat or other items.

•

The lighting conditions change
significantly.

•

You are not in the field of view of the
camera.

•

You position or tilt yourself to one side.

•

You are moving around extensively.

•

You are wearing glasses or sunglasses
that are too dark or reflective.

Note:

The system has limited steering

assistance and may not be sufficient for all
driving situations.

Note:

In exceptional conditions, such as

inclement weather or direct sunlight, the
system could deviate from the center line.

Note:

The information provided by the

navigation map data could be inaccurate or
out of date.

BLUECRUISE SETTINGS

Enabling BlueCruise

1.

Press

Features

 on the touchscreen.

2. Press

Driver Assistance

.

3. Press

Cruise Control

.

4. Press

Lane Centering with

Hands-Free

.

Enabling Activation Prompts

1.

Press

Features

 on the touchscreen.

2. Press

Driver Assistance

.

3. Press

Cruise Control

.

4. Press

Activation Prompts

.

SWITCHING BLUECRUISE ON
AND OFF

Switching BlueCruise On

The controls are on the steering wheel.

Using Activation Prompts

E144529

When the prompt appears, press
the button to switch BlueCruise
on.

The indicator appears in the instrument
cluster. When the system is on, the color
of the indicator changes to indicate the
system status.

Note:

You must enable activation prompts

in the touchscreen.

Using Steering Wheel Controls

E308131

E144529

Using the adaptive cruise control
and lane keeping buttons, make
sure both systems are active.
BlueCruise activates.

358

BlueCruise

 (If Equipped)

Switching BlueCruise Off

E308131

E144529

Press either the lane keeping or
adaptive cruise control button
when system is active or in
standby mode.

BlueCruise turns off through
each ignition cycle.

BLUECRUISE ALERTS

When BlueCruise is providing hands-on
driving or transitioning to hands-on driving
from hands-free driving and detects no
steering activity for a certain period of time,
the system alerts you with a message in
the instrument cluster to put your hands
on the steering wheel. After the first alert,
the system alerts you with a message in
the instrument cluster and an audible
warning.

When BlueCruise is providing hands-on or
hands-free driving and detects you are not
looking at the road for a certain period of
time, the system alerts you to return your
eyes to the road. Depending on where you
are looking, the alert can be a message in
the instrument cluster and an audible
warning.

If you do not react to the warnings,
BlueCruise cancels, quickly activates and
releases the brakes, and slows your vehicle
down to low speeds while maintaining
steering control.

If your vehicle slows down and you resume
control, a message appears to prompt you
to press the accelerator pedal to allow the
system to resume.

Note:

If the system detects repeated

inactivity, it disables until the next key cycle.

BLUECRUISE AUTOMATIC
CANCELLATION

When an external condition cancels
BlueCruise, for example, no lane markings
available, a tone sounds and a message
appears in the instrument cluster.

E308130

If your vehicle starts to slow
down, you must take control of
steering and press and release

the button to reactivate BlueCruise.

System cancellation can also occur if:

•

The lane becomes too narrow.

•

The system cannot detect valid lane
markings.

•

Lane markings cross.

•

Your eyes are not on the road or your
hands are not on the steering wheel.

If you have your hands on the steering
wheel and your eyes are on the road when
the feature is active and a cancellation
occurs, the system sounds a tone and
displays a cancelled graphic in the
instrument cluster.

If you are not paying attention to the road
or your hands are not on the steering wheel
and a cancellation occurs, the system
displays a message and a tone sounds until
you resume control. If you do not resume
control in time, BlueCruise quickly activates
and releases the brakes, and slows your
vehicle to low speeds while maintaining
steering control. If your vehicle slows down
and you resume control, a message
appears to prompt you to press the
accelerator pedal to allow the system to
resume.

Note:

The system disables until the vehicle

is turned off and back on if it detects
repeated inactivity.

359

BlueCruise

 (If Equipped)

BLUECRUISE INDICATORS

E297977

When on, the color of the
indicator changes to indicate the
status.

Gray indicates BlueCruise is on but inactive.

Green indicates BlueCruise is active and
applying continuous steering support.

Blue indicates BlueCruise is active and
hands-free driving mode is available.

Hands-On Driving Support
Available

E310620

The graphic in the cluster changes to a
wheel with hands on it indicating hands-on
driving mode is active.

When this indicator is present, you must
keep your hands on the steering wheel.

Hands-Free Driving Support
Available

E332864

The graphic in the cluster changes to a
wheel without hands on it indicating
hands-free driving mode is available.

When this indicator is present, you can
remove your hands from the steering
wheel.

LANE CHANGE ASSIST

HOW DOES LANE CHANGE ASSIST
WORK

E400996

Lane change assist can automatically
perform a single lane change when you
request the lane change using the turn
signal lever. This feature is available down
to 40 mph (65 km/h).

360

BlueCruise

 (If Equipped)

WARNING:

Do not use the lane

change assist system as a replacement
for using the interior and exterior mirrors
or looking over your shoulder before
changing lanes. The lane change assist
system is not a replacement for careful
driving.

1.

Make sure the lane you are requesting
is clear of traffic or obstacles.

2. Tap or latch the lever in the direction

of your planned lane change.

3. Once the lane change is complete,

move the turn signal lever back to the
middle position if necessary.

Note:

 When using lane change assist you

can tap or latch the lever.

Lane Change Suggestion

If you are approaching or have been
following a slower moving vehicle, the
system may suggest a lane change to pass
that vehicle using an available passing
lane.

LANE CHANGE ASSIST
LIMITATIONS

Lane change assist will not perform the
requested maneuver if traffic is identified
in the selected lane.

SWITCHING LANE CHANGE
ASSIST ON AND OFF

1.

Press

Features

 on the touchscreen.

2. Press

Driver Assistance

.

3. Press

Cruise Control

.

4. Press

Lane Change Assist

 to toggle

the system on and off.

LANE CHANGE ASSIST
CANCELLATION

To cancel lane change assist, manually
steer your vehicle or return the turn signal
lever to the middle position.

361

BlueCruise

 (If Equipped)

LANE CHANGE ASSIST – TROUBLESHOOTING

LANE CHANGE ASSIST – INFORMATION MESSAGES

Details

Message

The lane you have selected to enter has a

vehicle or obstacle.

Lane is busy

A lane is not recognized or available to

perform the requested maneuver.

No lane detected

The driver has manually overridden the lane

change.

Driver canceled

The requested lane change is being

performed.

Changing lanes

If desired, press the turn signal lever in the

direction indicated by the lane change
suggestion to initiate the lane change.

Lane change suggested

Note:

The instrument cluster display may

abbreviate or shorten certain messages.

IN-LANE REPOSITIONING

HOW DOES IN-LANE
REPOSITIONING WORK

BlueCruise with in-lane repositioning uses
the vehicle's front and corner radar sensors
together with the front windshield camera
sensor to operate.

Using these sensors, the system
automatically adjusts your vehicle’s
position in the lane based on the current
driving situation.

Note:

In-lane repositioning is active only

when BlueCruise is enabled while traveling
on divided highways and when any of the
following occur:

•

Passing or being passed by adjacent
lane vehicles in close proximity.

•

In a curve.

•

Driving in outer lanes.

Note:

In certain situations, the vehicle may

bias without showing the indicators.

Note:

Keep the front of your vehicle free of

dirt, metal badges or objects. Vehicle front
protectors, aftermarket lights, additional
paint or plastic coatings could also degrade
sensor performance.

Note:

The radar sensor has a limited field

of view. It may not detect vehicles at all or
detect a vehicle later than expected in some
situations.

SWITCHING IN-LANE
REPOSITIONING ON AND OFF

1.

Press

Features

 on the touchscreen.

2. Press

Driver Assistance

.

3. Press

Cruise Control

.

362

BlueCruise

 (If Equipped)

4. Press

Adaptive Cruise Control

.

5. Press

Lane Centering with

Hands-Free

.

6. Press In-Lane Repositioning to toggle

the system on or off.

IN-LANE REPOSITIONING
INDICATORS

E400993

Biased towards right-hand side of the lane.

E400994

Biased towards left-hand side of the lane.

BLUECRUISE –
TROUBLESHOOTING

BLUECRUISE – INFORMATION
MESSAGES

Depending on your vehicle options and
instrument cluster type, not all messages
display or are available.

Details

Message

Make sure you return your hands to the

steering wheel and provide steering input.

Keep Hands on Steering Wheel

The system is going to cancel and you must

take control.

Resume Control

Return your attention to the road.

Watch the Road

Conditions exist preventing the system from

being available. If the message continues

to display, have the system checked as

soon as possible.

BlueCruise not available

Press the accelerator pedal and follow the

prompts.

Press Accelerator Pedal to Resume

363

BlueCruise

 (If Equipped)

Details

Message

Make sure your facial features are visible

and in the field of view of the driver facing

camera.

Driver monitor camera cannot detect face

See manual

Make sure your hands, arms or other objects

are not obscuring the camera.

Driver monitor camera is blocked See

manual

Conditions exist preventing the system from

being available. If the message continues

to display, have the system checked as

soon as possible.

Driver monitor camera fault See manual

BlueCruise is active, keep your attention on

the road.

BlueCruise On Watch the road Be prepared

to resume control

The system is in standby mode, press the

button on the steering wheel to activate.

BlueCruise available Press {ICON} to

activate

Note:

The instrument cluster display may

abbreviate or shorten certain messages.

364

BlueCruise

 (If Equipped)

WHAT IS DRIVE MODE
CONTROL

This feature connects multiple vehicle
systems through a single interface,
providing you with enhanced vehicle
control and driving dynamics for different
driving scenarios, terrains, weather, or
various road conditions.

HOW DOES DRIVE MODE
CONTROL WORK

When a drive mode is selected it alters
various electrical and mechanical systems
within the vehicle to a predetermined
configuration. The systems altered and
features available will depend on which
mode is selected.

Note:

: The electronic locking differential is

available and automatically engages in
some drive modes.  See

Electronic Locking

Differential

 (page 283).

Note:

Off-Road drive modes automatically

disable the Brake Over Accelerator system
to allow for two-footed driving in off-road
environments.  See

Brake Over Accelerator

(page 290).

Note:

Your vehicle reverts to normal mode

each time you start it. If you shut your
vehicle off in a drive mode other than
normal mode, at startup the instrument
cluster screen displays a pop-up asking if
you would like to return to your last used
drive mode. If you select yes to the pop-up,
your vehicle returns to the last selected drive
mode and the default four-wheel driveline
setting associated with that drive mode. If
you select no, your vehicle remains in normal
mode and the default four-wheel driveline
setting associated with that drive mode. If
you do not select yes or no, the pop-up
message times out, your vehicle remains in
normal mode, and the four-wheel driveline
setting remains in its last used setting.

SELECTING A DRIVE MODE

E308146

Rotate the controller located on the center
console. Rotate the drive mode controller
once to activate the drive mode selection
menu in the display. Rotate the controller
a second time to select and engage the
drive mode.

Note:

Button icons vary depending on the

vehicle’s configuration.

DRIVE MODES

ECO - 4X4

E295413

This mode decreases
accelerator pedal
responsiveness to soften driver

inputs and encourage efficient driving.

Depending on your vehicle’s options,
adaptive cruise control is slower to return
to the set speed and auto start-stop
engages more often. The system
decreases air conditioning output to
conserve energy when set to auto mode.

365

Drive Mode Control - Excluding: Raptor

Use this mode for fuel efficient driving
which allows for an extended vehicle
range.

Note:

Two-wheel drive high (2H) is the

default four-wheel drive mode. Four-wheel
drive low (4L) is not available.

Note:

The electronic locking differential is

available below 25 mph (40 km/h).  See

Switching the Electronic Locking
Differential On and Off

 (page 284).

ECO - 4X2

E295413

This mode decreases
accelerator pedal
responsiveness to soften driver

inputs and encourage efficient driving.

Depending on your vehicle’s options,
adaptive cruise control is slower to return
to the set speed and auto start- stop
engages more often. The system
decreases air conditioning output to
conserve energy when set to Auto Mode.

Use this mode for fuel efficient driving
which allows for an extended driving range.

Note:

The electronic locking differential is

available below 25 mph (40 km/h).  See

Switching the Electronic Locking
Differential On and Off

 (page 284).

NORMAL - 4X4

E225310

This mode adjusts all systems
to their base settings and
balances vehicle performance

for all around drivability. Each time you
switch your vehicle off it defaults to this
mode.

Use this mode for everyday driving, such
as city and highway routes or commuting.

Note:

Two-wheel drive high (2H) is the

default four-wheel drive mode. All
four-wheel drive modes are selectable when
in normal mode.

Note:

The electronic locking differential is

available below 25 mph (40 km/h).  See

Switching the Electronic Locking
Differential On and Off

 (page 284).

NORMAL - 4X2

E225310

This mode adjusts all systems
to their base settings and
balances vehicle performance

for all around drivability. Each time you
switch your vehicle off it defaults to this
mode.

Use this mode for everyday driving, such
as city and highway routes or commuting.

Note:

The electronic locking differential is

available below 25 mph (40 km/h).  See

Switching the Electronic Locking
Differential On and Off

 (page 284).

OFF-ROAD - 4X4

E359277

This mode lowers accelerator
pedal responsiveness and delays
transmission upshifts for

improved vehicle control in low speed
off-road environments. Traction and
stability controls allow the wheels to spin
to maintain vehicle momentum and clear
debris from the tires for improved traction.

Depending on your vehicle’s options, the
system inhibits auto start stop and
engages the rear electronic locking
differential.

Use this mode for driving through mud,
sand, and rough, uneven off-road terrains.

Note:

Four-wheel drive high (4H) is the

default four-wheel drive mode. Depending
on your vehicle options, four-wheel drive
auto (4A) or two-wheel drive high (2H) is
not available.

366

Drive Mode Control - Excluding: Raptor

Note:

The electronic locking differential

engages when you select this mode at any
speed, and you can disengage it at any time
using the button.  See

Switching the

Electronic Locking Differential On and
Off

 (page 284).

Note:

This mode is for Off-Road use only.

Do not use this mode when driving on
pavement. Depending on the four-wheel
drive mode selection, this could cause
driveline bind up and damage the system.
See

Four-Wheel Drive

 (page 273).

SLIPPERY - 4X4, VEHICLES WITH:
2-SPEED TORQUE ON DEMAND

E295414

This mode lowers accelerator
pedal responsiveness, adjusts
transmission shift points, and

optimizes traction and stability controls to
help mitigate wheel spin and maintain
vehicle control in slick driving conditions.

Depending on your vehicle’s options, this
feature adjusts all-wheel drive control to
provide optimum traction for slippery
surfaces.

Use this mode for less than ideal road
conditions such as snow and ice covered
roads or for firm surfaces that are covered
with loose or slippery materials.

Note:

Four-wheel drive auto (4A) is the

default four-wheel drive mode. Two-wheel
drive high (2H) is not available.

Note:

The electronic locking differential is

available below 25 mph (40 km/h).  See

Switching the Electronic Locking
Differential On and Off

 (page 284).

Note:

Do not use this mode when driving

on dry pavement. This could cause driveline
bind up and damage the system depending
on the four-wheel drive mode you select.
See

Four-Wheel Drive

 (page 273).

SLIPPERY - 4X4, VEHICLES WITH:
ELECTRONIC SHIFT-ON-THE-FLY

E295414

This mode lowers accelerator
pedal responsiveness, adjusts
transmission shift points, and

optimizes traction and stability controls to
help mitigate wheel spin and maintain
vehicle control in slick driving conditions.

Depending on your vehicle’s options, this
feature adjusts all-wheel drive control to
provide optimum traction for slippery
surfaces.

Use this mode for less than ideal road
conditions such as snow and ice covered
roads or for firm surfaces that are covered
with loose or slippery materials.

Note:

Four-wheel drive high (4H) is the

default four-wheel drive mode. All
four-wheel drive modes are selectable.

Note:

The electronic locking differential is

available below 25 mph (40 km/h).  See

Switching the Electronic Locking
Differential On and Off

 (page 284).

Note:

Do not use this mode when driving

on dry pavement. This could cause driveline
bind up and damage the system depending
on the four-wheel drive mode you select.
See

Four-Wheel Drive

 (page 273).

SLIPPERY - 4X2

E295414

This mode lowers accelerator
pedal responsiveness, adjusts
transmission shift points, and

optimizes traction and stability controls to
help mitigate wheel spin and maintain
vehicle control in slick driving conditions.

Depending on your vehicle’s options, this
feature adjusts all-wheel drive control to
provide optimum traction for slippery
surfaces.

367

Drive Mode Control - Excluding: Raptor

Use this mode for less than ideal road
conditions such as snow and ice covered
roads or for firm surfaces that are covered
with loose or slippery materials.

Note:

The electronic locking differential is

available below 25 mph (40 km/h).  See

Switching the Electronic Locking
Differential On and Off

 (page 284).

SPORT - 4X4, VEHICLES WITH: 2-
SPEED TORQUE ON DEMAND

E246593

This mode increases accelerator
pedal responsiveness and holds
the transmission in lower gears

longer for enhanced acceleration. The
system switches the chassis controls to
their sport settings.

Depending on your vehicle’s options, this
feature sets the exhaust to a louder tone,
inhibits auto-start stop, increases steering
torque buildup, and it adjusts the
suspension for enhanced driver
connectivity and responsive driving
dynamics.

Use this mode for a sportier and engaging
driving experience.

Note:

Four-wheel drive auto (4A) is the

default four-wheel drive mode. Four-wheel
drive low (4L) is not available.

Note:

The electronic locking differential is

available below 25 mph (40 km/h).  See

Switching the Electronic Locking
Differential On and Off

 (page 284).

SPORT - 4X4, VEHICLES WITH:
ELECTRONIC SHIFT-ON-THE-FLY

E246593

This mode increases accelerator
pedal responsiveness and holds
the transmission in lower gears

longer for enhanced acceleration. The
system switches the chassis controls to
their sport settings.

Depending on your vehicle’s options, this
feature sets the exhaust sound to a louder
tone, inhibits auto-start stop, increases
steering torque buildup, and it adjusts the
suspension for enhanced driver
connectivity and responsive driving
dynamics.

Use this mode for a sportier and engaging
driving experience.

Note:

Two-wheel drive high (2H) is the

default four-wheel drive mode. Four-wheel
drive low (4L) is not available.

Note:

The electronic locking differential is

available below 25 mph (40 km/h).  See

Switching the Electronic Locking
Differential On and Off

 (page 284).

SPORT - 4X2

E246593

This mode increases accelerator
pedal responsiveness and holds
the transmission in lower gears

longer for enhanced acceleration. The
system switches the chassis controls to
their sport settings.

Depending on your vehicle’s options, the
system increases the tone of the exhaust,
increases steering effort, and adjusts the
suspension for enhanced driver
connectivity and responsive driving
dynamics.

Use this mode for a sportier and engaging
driving experience.

Note:

The electronic locking differential is

available below 25 mph (40 km/h). See

Switching the Electronic Locking
Differential On and Off

 (page 284).

368

Drive Mode Control - Excluding: Raptor

TOW/HAUL - 4X4

E246592

For improved vehicle operation
when towing a trailer or hauling
a heavy load. This mode moves

upshifts to higher engine speeds to reduce
the frequency of transmission shifting. It
also provides downshift engine braking to
assist in maintaining vehicle speed when
descending a slope.

Depending on your vehicle’s options, the
system enhances steering response to
assist in controlling the vehicle when
towing or hauling and auto-start stop is
inhibited.

Note:

All four-wheel drive modes are

selectable. This mode does not default to
a certain four-wheel drive mode and
maintains the previous selection.

Note:

The electronic locking differential is

available below 25 mph (40 km/h).  See

Switching the Electronic Locking
Differential On and Off

 (page 284).

TOW/HAUL - 4X2

E246592

For improved vehicle operation
when towing a trailer or hauling
a heavy load. This mode moves

upshifts to higher engine speeds to reduce
the frequency of transmission shifting. It
also provides downshift engine braking to
assist in maintaining vehicle speed when
descending a slope.

Depending on your vehicle’s options, the
system enhances steering response to
assist in controlling the vehicle when
towing or hauling and auto-start stop is
inhibited.

Note:

The electronic locking differential is

available below 25 mph (40 km/h).  See

Switching the Electronic Locking
Differential On and Off

 (page 284).

TRAIL - 4X2

E295419

This mode lowers accelerator
pedal responsiveness and delays
transmission up-shifts for

improved vehicle control in low speed
off-road environments. The system
optimizes the traction and stability
controls for improved traction and to help
maintain forward momentum through
loose deformable terrains.

Depending on your vehicle's options, the
system disables auto-start-stop and
optimizes the all-wheel drive system for
enhanced traction.

Use this mode for driving on two-track
trails, loose gravel and mixed uneven
terrain.

Note:

The brake over accelerator system is

on in this mode.  See

Brake Over

Accelerator

 (page 290).

Note:

The electronic locking differential is

available below 25 mph (40 km/h).  See

Switching the Electronic Locking
Differential On and Off

 (page 284).

DRIVE MODE CONTROL –
TROUBLESHOOTING

DRIVE MODE CONTROL –
WARNING LAMPS

E130458

Some drive modes reduce
traction and stability control
performance and the indicator

illuminates in the instrument cluster.

Note:

The system has diagnostic checks

that continuously monitor the system for
proper operation. If a mode is unavailable
due to a system fault, the drive mode
system defaults to normal. When the
system defaults to normal, the driveline
settings remain the same as prior to the
system fault.

369

Drive Mode Control - Excluding: Raptor

DRIVE MODE CONTROL – INFORMATION MESSAGES

Details

Message

You have selected a four-wheel drive mode

that is not available in the current drive

mode. Select an available four-wheel drive

mode.

Selected 4x4 Mode Not Available in Current

Drive Mode

370

Drive Mode Control - Excluding: Raptor

DRIVE MODE CONTROL –
FREQUENTLY ASKED QUESTIONS

Why did the system default to
normal mode?

•

If a mode is unavailable due to a
system fault, it defaults to normal
mode and the driveline settings remain
the same as prior to the system fault.

Can I switch drive modes while I
am driving?

•

In most instances, you can switch drive
modes while you are driving (if you
maintain attention on the road), or
while the vehicle is stationary.
However, you should not switch the
vehicle into a drive mode intended for
off-road or track use while driving on
paved, public roads. For example, while
driving on a paved highway, it would
be acceptable to switch from normal
mode to eco mode, but not to off-road
mode.

How long does it take for the
vehicle to switch modes after I
make a selection?

•

After switching modes, the new drive
mode will activate within several
seconds, if all the appropriate
pre-conditions are met.

How should I decide which drive
mode to use?

•

Selecting a drive mode usually
depends on the driving experience you
would like to have, and the driving
conditions. For example, if you want to
have a more exciting on-road driving
experience, you could switch into sport
mode. If you find yourself driving on
slick roads, you could switch into
slippery mode.

Will drive modes impact my
vehicle’s fuel consumption?

•

Drive modes can have an impact on
your vehicle’s fuel consumption. In
addition to the active mode, your
driving style will also affect the fuel
consumption.

371

Drive Mode Control - Excluding: Raptor

WHAT IS DRIVE MODE
CONTROL

This feature connects multiple vehicle
systems through a single interface,
providing you with enhanced vehicle
control and driving dynamics for different
driving scenarios, terrains, weather, or
various road conditions.

HOW DOES DRIVE MODE
CONTROL WORK

When a drive mode is selected it alters
various electrical and mechanical systems
within the vehicle to a predetermined
configuration. The systems altered and
features available will depend on which
mode is selected.

Note:

: The electronic locking differential is

available and automatically engages in
some drive modes.  See

Electronic Locking

Differential

 (page 283).

Note:

Off-Road drive modes automatically

disable the Brake Over Accelerator system
to allow for two-footed driving in off-road
environments.  See

Brake Over Accelerator

(page 290).

Note:

Your vehicle reverts to normal mode

each time you start it. If you shut your
vehicle off in a drive mode other than
normal mode, at startup the instrument
cluster screen displays a pop-up asking if
you would like to return to your last used
drive mode. If you select yes to the pop-up,
your vehicle returns to the last selected drive
mode and the default four-wheel driveline
setting associated with that drive mode. If
you select no, your vehicle remains in normal
mode and the default four-wheel driveline
setting associated with that drive mode. If
you do not select yes or no, the pop-up
message times out, your vehicle remains in
normal mode, and the four-wheel driveline
setting remains in its last used setting.

SELECTING A DRIVE MODE

E416808

Rotate the controller located on the center
console. Rotate the drive mode controller
once to activate the drive mode selection
menu in the display. Rotate the controller
a second time to select and engage the
drive mode.

Note:

Button icons vary depending on the

vehicle’s configuration.

Selecting a Steering Mode

E347142

To change the steering feel,
press the button on the steering
wheel. The first press displays a

pop-up message in the instrument cluster
display for the selected mode and
subsequent presses changes the selected
mode.

Modes:
•

Normal – Developed to complement
vehicle response during daily driving.

•

Sport – Slightly less assist and
damping for improved steering feel
during spirited driving.

372

Drive Mode Control - Raptor

•

Comfort – Slightly more assist for
driver preference and daily driving ease.

•

Off-road – Similar assist to Normal
with added damping for improved
control during off-road driving.

After selecting the desired setting, you may
feel a soft feedback bump in the steering
wheel when the changeover occurs.

Note:

If you disconnect or remove the

battery, the steering system defaults to
normal.

Selecting a Suspension Mode

E347107

To change the suspension feel,
press the button on the steering
wheel. The first press displays a

pop-up message in the instrument cluster
display for the selected mode and
subsequent presses changes the selected
mode.

Modes:
•

Normal – Default factory setting.

•

Sport – Slightly stiffer suspension with
emphasis on handling and control.

•

Off-road – Maximizes shock
performance in extreme off-road
environments.

Selecting an Exhaust Mode

E375920

To change the exhaust sound,
press the button on the steering
wheel. The first press displays a

pop-up message in the instrument cluster
display for the selected mode and
subsequent presses changes the selected
mode.

Modes:
•

Normal – Default setting provides a
balance of comfort and feedback.

•

Sport – Slightly louder than normal for
spirited driving.

•

Baja – Loudest setting for off-road use
only. Maximum exhaust noise under all
driving conditions.

•

Quiet – Quietest setting for maximum
comfort under all driving conditions.

Quiet Start

Quiet start allows you to schedule when
the exhaust mode turns on the quiet
setting. The time window can be from 1 to
24 hours.

Enabling and disabling quiet start:

1.

Press Settings on the touchscreen.

2. Press Vehicle Settings.

3. Press Quiet Start.

4. Press Quiet Start.

5. Press Settings.

Setting quiet time:

1.

Press Settings on the touchscreen.

2. Press Vehicle Settings.

3. Press Quiet Start.

4. Press Set Quiet Time.

5. Set your desired start and end times.

MyMode

E359278

You can use MyMode to create
one custom vehicle
configuration based on the

current state of your vehicle.

When you have your vehicle configured to
your desired settings, you can press and
hold the button for a few seconds to save
as MyMode.

Double-pressing the button activates your
saved MyMode.

You can check the saved MyMode settings
with a single press of the button.

373

Drive Mode Control - Raptor

You can save the following settings as
MyMode:
•

Drive mode.

•

Steering mode.

•

Suspension mode.

•

Exhaust mode.

•

Four-wheel drive mode.

•

Stop and start on or off.

•

Rear electronic locking differential on
or off.

Note:

MyMode can only be set with

configurations that are available for each
drive mode.  See

Drive Modes

 (page 374).

Note:

You can save or view MyMode at any

time, regardless of your vehicle's speed or
transmission selection, as long as your
vehicle is running and it meets system
conditions.

Note:

When activating MyMode, your

vehicle must meet all preconditions for the
drive mode and various settings before it
activates. A message appears if it does not
meet system conditions.

DRIVE MODES

BAJA

E225314

This mode increases accelerator
pedal responsiveness, optimizes
transmission shifting response,

and activates the anti-lag system all for
quicker power delivery. The system places
the stability controls in their baja settings
for optimum vehicle control in loose sandy
conditions.

This feature places the steering and
suspension in their off-road settings for
enhanced vehicle dynamics in high speed
off-roading.

Additionally, active exhaust is set to the
baja setting for a louder and more
aggressive tone.

Use this mode for maximized high speed
performance in off-road environments.

Note:

Four-wheel drive high (4H) is the

default four-wheel drive mode. Four-wheel
drive auto is not available.

Note:

Off-road is the default steering and

suspension modes. All steering and
suspension modes are available. Baja is the
default exhaust mode. All exhaust modes
are available.

Note:

The electronic locking differential is

available at all speeds in four-wheel drive.
See

Switching the Electronic Locking

Differential On and Off

 (page 286).

Note:

This mode is for Off-Road use only.

Do not use this mode when driving on
pavement. This could cause driveline bind
up and damage the system depending on
the four-wheel drive mode selection.  See

Four-Wheel Drive

 (page 273).

NORMAL

E347003

This mode adjusts all systems
to their base settings and
balances vehicle performance

for all around drivability. Each time you
switch your vehicle off it defaults to this
mode.

Use this mode for everyday driving, such
as city and highway routes or commuting.

Note:

Two-wheel drive high (2H) is the

default four-wheel drive mode. All
four-wheel drive modes are selectable when
in normal mode.

Note:

The electronic locking differential is

available below 25 mph (40 km/h).  See

Switching the Electronic Locking
Differential On and Off

 (page 284).

374

Drive Mode Control - Raptor

Note:

Normal is the default steering,

suspension, and exhaust modes. Off-road
steering mode is not available. All
suspension and exhaust modes are
available.

OFF-ROAD

E347001

This mode lowers accelerator
pedal responsiveness and delays
transmission upshifts for

improved vehicle control in low speed
off-road environments. Traction and
stability controls allow the wheels to spin
to maintain vehicle momentum and clear
debris from the tires for improved traction.

The system inhibits auto start stop and
engages the rear electronic locking
differential.

Use this mode for driving through mud,
sand, and rough, uneven off-road terrains.

Note:

Four-wheel drive high (4H) is the

default four-wheel drive mode.

Note:

The electronic locking differential

engages when you select this mode at any
speed, and you can disengage it at any time
using the button.  See

Switching the

Electronic Locking Differential On and
Off

 (page 284).

Note:

Comfort is the default steering mode.

All steering modes are available. Off-road
is the default suspension mode. All
suspension modes are available. Sport is
the default exhaust mode. All exhaust
modes are available.

Note:

This mode is for Off-Road use only.

Do not use this mode when driving on
pavement. Depending on the four-wheel
drive mode selection, this could cause
driveline bind up and damage the system.
See

Four-Wheel Drive

 (page 273).

ROCK CRAWL

E347002

This mode lowers accelerator
pedal responsiveness and holds
the transmission in lower gears

to enhance vehicle control for low speed
rock crawling. The system switches the
traction and stability controls to their rock
crawl settings.

This feature inhibits auto start stop and
engages the rear electronic locking
differential.

Use this mode when crossing aggressive
terrain including rocks, mountain trails, and
boulders.

Note:

Four-wheel drive low (4L) is the only

four-wheel drive mode available.

Note:

The electronic locking differential is

available below 25 mph (40 km/h).  See

Switching the Electronic Locking
Differential On and Off

 (page 284).

Note:

Comfort is the default steering mode.

All steering modes are available. Off-road
is the default suspension mode. All
suspension modes are available. Normal is
the default exhaust mode. All exhaust
modes are available.

Note:

This mode is for Off-Road use only.

Do not use this mode when driving on
pavement. This could cause driveline bind
up and damage the system depending on
the four-wheel drive mode you select.  See

Four-Wheel Drive

 (page 273).

SLIPPERY

E347004

This mode lowers accelerator
pedal responsiveness, adjusts
transmission shift points, and

optimizes traction and stability controls to
help mitigate wheel spin and maintain
vehicle control in slick driving conditions.

This feature adjusts four-wheel drive
control to provide optimum traction for
slippery surfaces.

375

Drive Mode Control - Raptor

Use this mode for less than ideal road
conditions such as snow and ice covered
roads or for firm surfaces that are covered
with loose or slippery materials.

Note:

Four-wheel drive auto (4A) is the

default four-wheel drive mode. Two-wheel
drive high (2H) is not available.

Note:

The electronic locking differential is

available below 25 mph (40 km/h).  See

Switching the Electronic Locking
Differential On and Off

 (page 284).

Note:

Normal is the default steering,

suspension, and exhaust modes. Off-road
steering mode is not available. All
suspension and exhaust modes are
available.

Note:

Do not use this mode when driving

on dry pavement. This could cause driveline
bind up and damage the system depending
on the four-wheel drive mode you select.
See

Four-Wheel Drive

 (page 273).

SPORT - 3.5L

E246593

This mode increases accelerator
pedal responsiveness and holds
the transmission in lower gears

longer for enhanced acceleration. The
system switches the chassis controls to
their sport settings.

This feature sets the exhaust to a louder
tone, inhibits auto-start stop, increases
steering torque buildup, and it adjusts the
suspension for enhanced driver
connectivity and responsive driving
dynamics.

Use this mode for a sportier and engaging
driving experience.

Note:

Two-wheel drive auto (2H) is the

default four-wheel drive mode. Four-wheel
drive low (4L) is not available.

Note:

The electronic locking differential is

available below 25 mph (40 km/h).  See

Switching the Electronic Locking
Differential On and Off

 (page 284).

Note:

Sport is the default steering,

suspension, and exhaust modes. Off-road
steering mode is not available. All
suspension and exhaust modes are
available.

SPORT - 5.2L

E246593

This mode increases accelerator
pedal responsiveness and holds
the transmission in lower gears

longer for enhanced acceleration. The
system switches the chassis controls to
their sport settings.

This feature sets the exhaust sound to a
louder tone, inhibits auto-start stop,
increases steering torque buildup, and it
adjusts the suspension for enhanced driver
connectivity and responsive driving
dynamics.

Use this mode for a sportier and engaging
driving experience.

Note:

Four-wheel drive auto (4A) is the

default four-wheel drive mode. Four-wheel
drive low (4L) is not available.

Note:

The electronic locking differential is

available below 25 mph (40 km/h).  See

Switching the Electronic Locking
Differential On and Off

 (page 284).

Note:

Sport is the default steering,

suspension, and exhaust modes. Off-road
steering mode is not available. All
suspension and exhaust modes are
available.

376

Drive Mode Control - Raptor

TOW/HAUL

E347108

For improved vehicle operation
when towing a trailer or hauling
a heavy load. This mode moves

upshifts to higher engine speeds to reduce
the frequency of transmission shifting. It
also provides downshift engine braking to
assist in maintaining vehicle speed when
descending a slope.

The system enhances steering response
to assist in controlling the vehicle when
towing or hauling and auto-start stop is
inhibited.

Note:

All four-wheel drive modes are

selectable. This mode does not default to
a certain four-wheel drive mode and
maintains the previous selection.

Note:

The electronic locking differential is

available below 25 mph (40 km/h).  See

Switching the Electronic Locking
Differential On and Off

 (page 284).

Note:

Normal is the default steering and

exhaust modes. Off-road steering mode is
not available. All exhaust modes are
available. Sport is the default suspension
mode. Normal suspension mode is available.
Off-road suspension mode is not available.

DRIVE MODE CONTROL –
TROUBLESHOOTING

DRIVE MODE CONTROL –
WARNING LAMPS

E130458

Some drive modes reduce
traction and stability control
performance and the indicator

illuminates in the instrument cluster.

Note:

The system has diagnostic checks

that continuously monitor the system for
proper operation. If a mode is unavailable
due to a system fault, the drive mode
system defaults to normal. When the
system defaults to normal, the driveline
settings remain the same as prior to the
system fault.

DRIVE MODE CONTROL – INFORMATION MESSAGES

Details

Message

You have selected a four-wheel drive mode

that is not available in the current drive

mode. Select an available four-wheel drive

mode.

Selected 4x4 Mode Not Available in Current

Drive Mode

377

Drive Mode Control - Raptor

DRIVE MODE CONTROL –
FREQUENTLY ASKED QUESTIONS

Why did the system default to
normal mode?

•

If a mode is unavailable due to a
system fault, it defaults to normal
mode and the driveline settings remain
the same as prior to the system fault.

Can I switch drive modes while I
am driving?

•

In most instances, you can switch drive
modes while you are driving (if you
maintain attention on the road), or
while the vehicle is stationary.
However, you should not switch the
vehicle into a drive mode intended for
off-road or track use while driving on
paved, public roads. For example, while
driving on a paved highway, it would
be acceptable to switch from normal
mode to eco mode, but not to off-road
mode.

How long does it take for the
vehicle to switch modes after I
make a selection?

•

After switching modes, the new drive
mode will activate within several
seconds, if all the appropriate
pre-conditions are met.

How should I decide which drive
mode to use?

•

Selecting a drive mode usually
depends on the driving experience you
would like to have, and the driving
conditions. For example, if you want to
have a more exciting on-road driving
experience, you could switch into sport
mode. If you find yourself driving on
slick roads, you could switch into
slippery mode.

Will drive modes impact my
vehicle’s fuel consumption?

•

Drive modes can have an impact on
your vehicle’s fuel consumption. In
addition to the active mode, your
driving style will also affect the fuel
consumption.

378

Drive Mode Control - Raptor

WHAT IS THE LANE KEEPING
SYSTEM

The lane keeping system alerts you by
providing temporary steering assistance
or steering wheel vibration when it detects
an unintended lane departure.

HOW DOES THE LANE
KEEPING SYSTEM WORK

The lane keeping system uses a forward
looking camera mounted on the windshield
to monitor vehicle movement within the
lane of travel.

When the camera detects a drift out of the
lane of travel, the lane keeping system
alerts the driver by vibrating the steering
wheel, or aids the driver by providing a
small steering input to move the vehicle
back into the lane of travel.

The driver can select one of three modes:

•

Alert

•

Aid

•

Alert + Aid

LANE KEEPING SYSTEM
PRECAUTIONS

WARNING:

You are responsible for

controlling your vehicle at all times. The
system is designed to be an aid and does
not relieve you of your responsibility to
drive with due care and attention. Failure
to follow this instruction could result in
the loss of control of your vehicle,
personal injury or death.

WARNING:

The system will not

operate if the sensor cannot track the
road lane markings.

WARNING:

The sensor may

incorrectly track lane markings as other
structures or objects. This can result in
a false or missed warning.

WARNING:

In cold and severe

weather conditions the system may not
function. Rain, snow and spray can all
limit sensor performance.

WARNING:

The system may not

operate properly if the sensor is blocked.
Keep the windshield free from
obstruction.

WARNING:

If damage occurs in the

immediate area surrounding the sensor,
have your vehicle checked as soon as
possible.

WARNING:

The system may not

correctly operate if your vehicle is fitted
with a suspension kit not approved by
us.

WARNING:

Large contrasts in

outside lighting can limit sensor
performance.

LANE KEEPING SYSTEM
LIMITATIONS

The lane keeping system only operates
when the vehicle speed is greater than
40 mph (64 km/h).

The system works when the camera can
detect at least one lane marking or the
edge of the road.

379

Lane Keeping System

Note:

When you select Aid or Alert and Aid

mode and the system detects no steering
activity for a short period of time, the system
alerts you to put your hands on the steering
wheel. The system may detect a light grip
or touch on the steering wheel as hands-off
driving.

The lane keeping system may not correctly
operate in any of the following conditions:
•

The lane keeping system does not
detect at least one lane marking.

•

You switch the turn signal on.

•

You apply direct steering, accelerate
fast or brake hard.

•

The vehicle speed is less than 40 mph
(64 km/h).

•

The anti-lock brake, stability control or
traction control system activates.

•

The lane is too narrow.

•

Something is obscuring the camera or
it is unable to detect the lane markings
due to environment, traffic or vehicle
conditions.

•

Entering or exiting a tight curve when
driving at high speeds.

The lane keeping system may not correct
lane positioning in any of the following
conditions:
•

High winds.

•

Uneven road surfaces.

•

Heavy or uneven loads.

•

Incorrect tire pressure.

SWITCHING THE LANE
KEEPING SYSTEM ON AND
OFF

E334922

To activate the lane keeping
system, press the button on the
steering wheel.

To deactivate the lane keeping system,
press the button again.

Note:

When switching the system on or off

a message appears in the instrument cluster
display to show the status.

Note:

The system stores the on or off

setting until manually changed.

SWITCHING THE LANE
KEEPING SYSTEM MODE

The lane keeping system has different
settings that you can view or adjust using
the touchscreen.

The system stores the last known selection
for each setting.

To change the lane keeping system mode,
use the touchscreen:

1.

Press

Features

 on the touchscreen.

2. Press

Driver Assistance

.

3. Press

Lane-Keeping System

.

4. Press

Lane-Keeping Mode

.

5. Select a mode.

Note:

The system remembers the last

setting when you start your vehicle.

ALERT MODE

WHAT IS ALERT MODE

Alert mode vibrates the steering wheel
when it detects an unintended lane
departure.

380

Lane Keeping System
