OVERHEAD STORAGE

OPENING THE OVERHEAD
STORAGE COMPARTMENT

E332434

Press near the rear edge of the door to
open it.

GLOVE COMPARTMENT

OPENING THE GLOVE
COMPARTMENT

E310218

Pull the latch to the left to open.

CENTER CONSOLE

OPENING THE CENTER CONSOLE

E351263

To open the center console, grab the
armrest handle and lift up. To open the
front storage compartment, grab the door
handle and slide forward.

LOCKING THE CENTER CONSOLE

You can lock the center console using the
key.

187

Storage

STARTING AND STOPPING
THE ENGINE – PRECAUTIONS

WARNING:

Extended idling at high

engine speeds can produce very high
temperatures in the engine and exhaust
system, creating the risk of fire or other
damage.

WARNING:

Do not park, idle or

drive your vehicle on dry grass or other
dry ground cover. The emission system
heats up the engine compartment and
exhaust system, creating the risk of fire.

WARNING:

Do not start the engine

in a closed garage or in other enclosed
areas. Exhaust fumes are toxic. Always
open the garage door before you start
the engine. Failure to follow this
instruction could result in personal injury
or death.

WARNING:

Do not use starting

fluid, for example ether, in the air intake
system. Such fluid could cause
immediate explosive damage to the
engine and possible personal injury.

WARNING:

Exhaust leaks may

result in entry of harmful and potentially
lethal fumes into the passenger
compartment. If you smell exhaust
fumes inside your vehicle, have your
vehicle inspected immediately. Do not
drive if you smell exhaust fumes.

The powertrain control system meets all
Canadian interference-causing equipment
standard requirements regulating the
impulse electrical field or radio noise.

Note:

If you use your vehicle regularly above

the altitude of 5,000 ft (1,524 m) and under
the temperature of -4.0°F (-20°C), it is
recommended to use the alternative engine
oil. See

Capacities and Specifications

(page 461).

If you stop your vehicle and leave the
engine idling for long periods, we
recommend that you do one of the
following:
•

Open the windows at least 1 in
(2.5 cm).

•

Set your climate control to outside air.

IGNITION SWITCH

(IF EQUIPPED)

E252522

///

Switching the Ignition Off

Turn the key to position

Switching the Ignition to
Accessory Mode

Turn the key to position

. Electrical

accessories, for example the radio, operate
without the engine running.

189

Starting and Stopping the Engine

Switching the Ignition On

Turn the key to position

. All electrical

circuits and accessories are operational
and the warning lamps and indicators
illuminate.

PUSH BUTTON IGNITION
SWITCH

(IF EQUIPPED)

E357998

Switching the Ignition Off

When the ignition is on or in accessory
mode, press the push button ignition
switch once without your foot on the brake
pedal.

Switching the Ignition to
Accessory Mode

When the ignition is off, press the push
button ignition switch once without your
foot on the brake pedal.

All electrical circuits and accessories are
operational and the warning lamps and
indicators illuminate.

Note:

Your vehicle has a battery saver

feature that shuts your vehicle off when it
detects a certain amount of battery drain,
or after approximately 30 minutes of
inactivity in accessory mode.

Note:

The system may not function if the

remote control is close to metal objects or
electronic devices, for example keys or a cell
phone.

Note:

You need a valid key inside your

vehicle to switch the ignition on and start
the engine.

STARTING THE ENGINE

STARTING A GASOLINE ENGINE -
VEHICLES WITHOUT: PUSH
BUTTON START

Before starting your vehicle, check the
following:
•

Make sure that the headlamps and
electrical accessories are off.

•

Make sure that the parking brake is on.

•

Make sure that the transmission is in
park (P).

Fully press the brake pedal.

Note:

Do not touch the accelerator pedal.

E322354

2. Turn the key to position

III

Note:

The engine may continue cranking

for up to 15 seconds or until it starts.

Note:

The engine takes longer to start at

lower temperatures. It may crank for several
seconds when very cold.

STARTING A GASOLINE ENGINE -
VEHICLES WITH: PUSH BUTTON
START

Before starting your vehicle, check the
following:
•

Make sure that the headlamps and
electrical accessories are off.

•

Make sure that the parking brake is on.

•

Make sure that the transmission is in
park (P).

Fully press the brake pedal.

Note:

Do not touch the accelerator pedal.

190

Starting and Stopping the Engine

E357998

2. Press the push button ignition switch.

Note:

The engine may continue cranking

for up to 15 seconds or until it starts.

Note:

The engine takes longer to start at

lower temperatures. It may crank for several
seconds when very cold.

RESTARTING THE ENGINE AFTER
STOPPING IT - VEHICLES WITH:
PUSH BUTTON START

The system allows you to start the engine
within 10 seconds of switching it off, even
if it does not detect a valid passive key.

Within 10 seconds of switching the engine
off, fully press the brake pedal and press
the push button ignition switch. After 10
seconds, you can no longer start the engine
if the system does not detect a valid
passive key.

When you start the engine, it remains
running until you press the push button
ignition switch, even if your vehicle does
not detect a valid passive key. If you open
and close a door when the engine is
running, the system searches for a valid
passive key.

ENGINE BLOCK HEATER

(IF

EQUIPPED)

ENGINE BLOCK HEATER
PRECAUTIONS

WARNING:

Failure to follow engine

block heater instructions could result in
property damage or serious personal
injury.

WARNING:

Do not use your heater

with ungrounded electrical systems or
two-pronged adapters. There is a risk of
electrical shock.

WARNING:

Do not fully close the

hood, or allow it to drop under its own
weight when using the engine block
heater. This could damage the power
cable and may cause an electrical short
resulting in fire, injury and property
damage.

We recommend that you do the following
for a safe and correct operation:
•

Use a 16-gauge outdoor extension cord
that is product certified by
Underwriter’s Laboratory (UL) or
Canadian Standards Association
(CSA). This extension cord must be
suitable for use outdoors, in cold
temperatures, and be clearly marked
Suitable for Use with Outdoor
Appliances. Do not use an indoor
extension cord outdoors. This could
result in an electric shock or become a
fire hazard.

•

Use as short an extension cord as
possible.

•

Do not use multiple extension cords.

191

Starting and Stopping the Engine

•

Make sure that when in operation, the
extension cord plug and engine block
heater cord plug connections are free
and clear of water. This could cause an
electric shock or fire.

•

If the engine block heater cord is under
the hood, do not remove the wiring
from its original location. Do not close
the hood on the extension wiring.

•

Park your vehicle in a clean area, clear
of combustible materials.

•

Firmly connect the engine block heater
cord and the extension cord.

•

Check the extension cord for heat
anywhere when the system has been
operating for approximately 30
minutes.

•

Unplug and properly stow the system
before starting and driving your vehicle.
The protective cover seals the
terminals of the engine block heater
cord plug when not in use.

•

Check the engine block heater system
for proper operation before winter.

HOW DOES THE ENGINE BLOCK
HEATER WORK

The engine block heater warms the engine
coolant. This allows the climate control
system to quickly respond. The equipment
includes a heater element installed in the
engine block and a wire harness. You can
connect the system to a grounded 110 volt
AC electrical source.

Note:

The engine block heater is most

effective when outdoor temperatures are
below 0°F (-18°C). We recommend the use
of engine block heater to improve engine
cold start performance.

USING THE ENGINE BLOCK
HEATER

Make sure the receptacle terminals are
clean and dry prior to use. Clean them with
a dry cloth if necessary.

The heater uses 0.4 to 1.0 kilowatt-hours
of energy per hour of use. The system does
not have a thermostat. It achieves
maximum temperature after
approximately three hours of operation.
Using the engine block heater longer than
three hours does not improve system
performance and unnecessarily uses
electricity.

STOPPING THE ENGINE

STOPPING THE ENGINE WHEN
YOUR VEHICLE IS STATIONARY -
VEHICLES WITHOUT: PUSH
BUTTON START

Shift into park (P).

2. Apply the parking brake.

3. Wait until the engine reaches idle

speed.

E322405

4. Turn the key to position

STOPPING THE ENGINE WHEN
YOUR VEHICLE IS STATIONARY -
VEHICLES WITH: PUSH BUTTON
START

Shift into park (P).

2. Apply the parking brake.

3. Wait until the engine reaches idle

speed.

192

Starting and Stopping the Engine

E357998

4. Press the push button ignition switch.

STOPPING THE ENGINE WHEN
YOUR VEHICLE IS MOVING -
VEHICLES WITHOUT: PUSH
BUTTON START

WARNING:

Switching off the

engine when your vehicle is still moving
results in a significant decrease in
braking assistance. Higher effort is
required to apply the brakes and to stop
your vehicle. A significant decrease in
steering assistance could also occur. The
steering does not lock, but higher effort
could be required to steer your vehicle.
When you switch the ignition off, some
electrical circuits, for example airbags,
also turn off. If you unintentionally switch
the ignition off, shift into neutral (N) and
restart the engine.

E322405

Turn the key to position

2. Shift into neutral and use the brakes to

bring your vehicle to a safe stop.

3. Shift into park (P).

4. Apply the parking brake.

STOPPING THE ENGINE WHEN
YOUR VEHICLE IS MOVING -
VEHICLES WITH: PUSH BUTTON
START

WARNING:

Switching off the

E357998

Press and hold the push button ignition
switch until the engine stops, or press
it three times within two seconds.

2. Shift into neutral and use the brakes to

bring your vehicle to a safe stop.

3. Shift into park (P).

4. Apply the parking brake.

AUTOMATIC ENGINE STOP

WHAT IS AUTOMATIC ENGINE
STOP

Automatic engine stop is a feature that
switches the engine off if it has been idling
for an extended period to help you save
fuel.

193

Starting and Stopping the Engine

HOW DOES AUTOMATIC ENGINE
STOP WORK

Automatic engine stop turns the engine
off. The ignition also turns off in order to
save battery power. Before the engine
shuts down, a message appears in the
information display showing a timer
counting down. If you do not intervene
within 30 seconds, the engine shuts down.
Another message appears in the
information display to inform you that the
engine has shut down in order to save fuel.
Start your vehicle as you normally do.

SWITCHING AUTOMATIC ENGINE
STOP ON AND OFF

Press

Settings

on the touchscreen.

2. Press

Vehicle Settings

3. Switch

30min Max Idle

on or off.

Note:

You cannot permanently switch off

the automatic shutdown. If you switch it off,
it turns on each time you switch the ignition
on.

OVERRIDING AUTOMATIC ENGINE
STOP

You can stop the engine shutdown, or reset
the timer, at any point before the
30-second countdown has expired by
doing any of the following:
•

Pressing the brake pedal or accelerator
pedal.

•

Pressing the

RESET

button

during the countdown.

Note:

You cannot permanently switch off

the automatic engine shutdown feature.
When you switch it off temporarily, it turns
on at the next ignition cycle.

ACCESSING THE PASSIVE KEY
BACKUP POSITION

If you are unable to start your vehicle, do
the following:

E256153

Access the backup slot.

2. With the buttons facing the front of

your vehicle, insert the passive key into
the backup slot.

3. With the key in this position, press the

brake pedal then press the push button
ignition switch to switch the ignition on
and start your vehicle.

194

Starting and Stopping the Engine

STARTING AND STOPPING
THE ENGINE –
TROUBLESHOOTING

STARTING AND STOPPING THE
ENGINE – WARNING LAMPS

Malfunction Indicator Lamp

E67028

If it illuminates when the engine
is running, the on-board
diagnostics system is detecting

a malfunction of the vehicle emission
control system.

If it flashes, engine misfire could be
occurring. Increased exhaust gas
temperatures could damage the catalytic
converter or other vehicle components.
Avoid heavy acceleration and deceleration,
and have your vehicle checked as soon as
possible.

Powertrain Warning Lamp

If it illuminates when the engine
is running, this indicates a
powertrain or four-wheel drive

fault. If it flashes when you are driving,
immediately reduce the vehicle speed.
Avoid heavy acceleration and deceleration,
and have your vehicle checked as soon as
possible.

If both lamps illuminate when the engine
is running, stop your vehicle as soon as it
is safe to do so. Continuing to drive your
vehicle could cause reduced power or the
engine to stop. Switch the ignition off and
attempt to restart the engine. Have your
vehicle checked as soon as possible.

STARTING AND STOPPING THE ENGINE – INFORMATION MESSAGES

Action

Message

Displays if you exceed the starting time limit. You cannot
attempt to start the engine for 15 minutes. If you cannot start
the engine after 15 minutes passes, have your vehicle imme-
diately checked.

Cranking Time Exceeded

Displays if you are unable to start your vehicle with a correctly
coded key. The system has detected a fault that requires
service. Have your vehicle checked as soon as possible.

Starting System Fault

Displays if the system does not detect a valid passive key.

No Key Detected

195

Starting and Stopping the Engine

STARTING AND STOPPING THE
ENGINE – FREQUENTLY ASKED
QUESTIONS - VEHICLES
WITHOUT: PUSH BUTTON START

Why is the engine idle speed high
when I am starting the engine?

•

The speed at which the engine idles
immediately after starting is optimized
to minimize vehicle emissions and
maximize cabin comfort and fuel
economy.

Why does the engine not crank?

•

You can only attempt to start the
engine for a limited amount of time
before the starting system temporarily
disables. If you exceed the starting time
limit, a message may appear and you
cannot attempt to start the engine for
at least 15 minutes.

Why do I experience different

driving characteristics?

•

If you disconnect the battery, your
vehicle may exhibit some unusual
driving characteristics for
approximately 5 mi (8 km) after you
reconnect it. This is because the engine
management system must realign
itself with the engine. You can
disregard any unusual driving
characteristics during this period.

Why can I not start the engine?

If you cannot start the engine after 3
attempts, wait 10 seconds and do the
following:

Fully press the brake pedal or the
clutch pedal.

Note:

Make sure that the parking brake is

applied.

Note:

Make sure that the transmission is in

park (P) or neutral (N).

2. Fully press the accelerator pedal and

hold it there.

E322354

3. Turn the key to position

III

and wait

until the engine stops cranking.

4. Release the accelerator pedal.
5. Turn the key to position

III

STARTING AND STOPPING THE
ENGINE – FREQUENTLY ASKED
QUESTIONS - VEHICLES WITH:
PUSH BUTTON START

Why is the engine speed high when
I am starting the engine?

•

The speed at which the engine idles
immediately after starting is optimized
to minimize vehicle emissions and
maximize cabin comfort and fuel
economy.

Why does the engine not crank?

•

196

Starting and Stopping the Engine

Why do I experience different
driving characteristics?

•

If you disconnect the battery, your
vehicle may exhibit some unusual
driving characteristics for
approximately 5.0 mi (8 km) after you
reconnect it. This is because the engine
management system must realign
itself with the engine. You can
disregard any unusual driving
characteristics during this period.

Why can I not start the engine?

If you cannot start the engine after 3
attempts, wait 10 seconds and do the
following:

Fully press the brake pedal or the
clutch pedal.

Note:

Make sure that the parking brake is

applied.

Note:

Make sure that the transmission is in

park (P) or neutral (N).

2. Fully press the accelerator pedal and

hold it there.

3. Press the push button ignition switch.

Note:

The engine cranks for a short period

of time and then it stops.

4. Release the accelerator pedal.

E357998

5. Press the push button ignition switch.

Why does the system not detect a
passive key?

•

If the system does not detect a passive
key and you are unable to start the
engine, insert the passive key into the
backup position and press the push
button ignition switch to start the
engine. See

Accessing the Passive

Key Backup Position

(page 194).

197

Starting and Stopping the Engine

WHAT IS AUTO-START-STOP

The system is designed to help reduce fuel
consumption and CO

emissions by

stopping the engine when it is idling, for
example at traffic lights.

AUTO-START-STOP
PRECAUTIONS

WARNING:

Apply the parking

brake, shift into park (P), switch the
ignition off and remove the key before
you leave your vehicle. Failure to follow
this instruction could result in personal
injury or death.

WARNING:

Apply the parking

brake, shift into park (P), switch the
ignition off and remove the key before
you open the hood or have any service
or repair work completed. If you do not
switch the ignition off, the engine could
restart at any time. Failure to follow this
instruction could result in personal injury
or death.

SWITCHING AUTO-START-
STOP ON AND OFF

The system turns on when you switch the
ignition on.

E121377

Press the button to switch the
system off.

Note:

OFF

illuminates in the switch.

Note:

Deactivating the system using the

button lasts only one key cycle.

Press the button again to switch the
system back on.

Note:

The system turns off if it detects a

malfunction. If the system malfunctions,
have your vehicle checked as soon as
possible.

STOPPING THE ENGINE

Stop your vehicle, keep your foot on the
brake pedal and the transmission in drive
(D).

RESTARTING THE ENGINE

Release the brake pedal or press the
accelerator pedal.

A message appears in the instrument
cluster display if the system requires you
to take action.

AUTO-START-STOP
INDICATORS

WARNING:

The system may

require the engine to automatically
restart when the auto-start-stop
indicator illuminates green or flashes
amber. Failure to follow this instruction
could result in personal injury.

E121377

The Auto-Start-Stop indicator
illuminates green when the
engine stops. It flashes amber

and a message appears when you need to
take action.

E146361

The Auto-Start-Stop indicator
illuminates gray with a
strikethrough when the system

is not available.

Note:

You can display the reason why the

system is not available in the information
display.

198

Auto-Start-Stop

(If Equipped)

AUTO-START-STOP –
TROUBLESHOOTING

AUTO-START-STOP –
INFORMATION MESSAGES

A message appears in the instrument
cluster display if the system requires you
to take action.

Action

Condition

Message

Press the brake pedal to
restart the engine.

The system needs to restart
the engine but requires your
confirmation.

Auto StartStop Press Brake
to Start Engine

Press the brake pedal or the
accelerator pedal to restart
the engine.

The system needs to restart
the engine but requires your
confirmation.

Auto StartStop Press a
Pedal to Start Engine

199

Auto-Start-Stop

(If Equipped)

AUTO-START-STOP –
FREQUENTLY ASKED QUESTIONS

Why does the engine not always
stop when I expect it to?

The system is designed to work in a way
that complements other vehicle systems,
allowing them to operate at optimum
performance.

The system does not stop the engine if:
•

The driver door is open.

•

Your vehicle is at high altitude.

•

The heated windshield is on.

•

The engine is warming up.

•

The outside temperature is too low or
too high.

•

The battery charge is low.

•

The battery temperature is outside the
optimal operating range.

•

The engine is required to run to
maintain interior climate and reduce
fogging.

Why does the engine sometimes
restart when I do not expect it to?

The system is designed to work in a way
that complements other vehicle systems,
allowing them to operate at optimum
performance.

The system restarts the engine if:
•

You switch the heated windshield on.

•

You switch maximum defrost on.

•

Your vehicle starts to roll downhill in
neutral.

•

The engine is required to run to
maintain adequate brake system
assistance.

•

The engine is required to run to
maintain interior climate and reduce
fogging.

Can I permanently switch the
system off?

No. The system plays an important role in
reducing the fuel consumption and the CO

emissions.

Will the frequent engine starts
cause parts to wear out?

Your vehicle has an enhanced battery and
starter motor that are designed for the
increased number of engine starts.

200

Auto-Start-Stop

(If Equipped)

FUEL AND REFUELING
PRECAUTIONS

WARNING:

Fuels can cause serious

injury or death if misused or mishandled.

WARNING:

Fuel may contain

benzene, which is a cancer-causing
agent.

WARNING:

Read and follow all the

instructions on the pump island.

WARNING:

When refueling always

shut the engine off and never allow
sparks or open flames near the fuel tank
filler valve. Never smoke or use a cell
phone while refueling. Fuel vapor is
extremely hazardous under certain
conditions. Avoid inhaling excess fumes.

Follow these guidelines when refueling:
•

Extinguish all smoking materials and
any open flames before refueling your
vehicle.

•

Switch the engine off before refueling.

•

Automotive fuels can be harmful or
fatal if swallowed. Fuel is highly toxic
and if swallowed can cause death or
permanent injury. If fuel is swallowed
immediately call a physician, even if no
symptoms are immediately apparent.
The toxic effects of fuel may not be
apparent for hours.

•

Avoid inhaling fuel vapors. Inhaling fuel
vapor can lead to eye and respiratory
tract irritation. In severe cases,
excessive or prolonged breathing of
fuel vapor can cause serious illness and
permanent injury.

•

Avoid getting fuel in your eyes. If you
splash fuel in your eyes, immediately
remove contact lenses, if worn, flush
with water for 15 minutes and seek
medical attention. Failure to seek
proper medical attention could lead to
permanent injury.

•

Fuels can be harmful if absorbed
through the skin. If you splash fuel on
your skin, clothing or both, promptly
remove contaminated clothing and
thoroughly wash your skin with soap
and water. Repeated or prolonged skin
contact causes skin irritation.

•

Be particularly careful if you are taking
Antabuse or other forms of Disulfiram
for the treatment of alcoholism.
Breathing fuel vapors could cause an
adverse reaction, serious personal
injury or sickness. Immediately call a
physician if you experience any adverse
reactions.

FUEL QUALITY

SELECTING THE CORRECT FUEL

E161513

Your vehicle operates on regular unleaded
gasoline with a minimum pump (R+M)/2
octane rating of 87.

Some fuel stations, particularly those in
high altitude areas, offer fuels posted as
regular unleaded gasoline with an octane
rating below 87. The use of these fuels
could result in engine damage that will not
be covered by the vehicle Warranty.

201

Fuel and Refueling

For best overall vehicle and engine
performance, premium fuel with an octane
rating of 91 or higher is recommended. The
performance gained by using premium fuel
is most noticeable in hot weather as well
as other conditions, for example when
towing a trailer. See

Towing a Trailer

(page 352).

Do not be concerned if the engine
sometimes knocks lightly. However, if the
engine knocks heavily while using fuel with
the recommended octane rating, contact
an authorized dealer to prevent any engine
damage.

We recommend Top Tier detergent
gasolines, where available to help minimize
engine deposits and maintain optimal
vehicle and engine performance.

For additional information, visit

www.toptiergas.com

Note:

Use of any fuel for which the vehicle

was not designed can impair the emission
control system, cause loss of vehicle
performance, and cause damage to the
engine which may not be covered by the
vehicle Warranty.

Do not use:
•

Diesel fuel.

•

Fuels containing kerosene or paraffin.

•

Fuel containing more than 15% ethanol
or E85 fuel.

•

Fuels containing methanol.

•

Fuels containing metallic-based
additives, including manganese-based
compounds.

•

Fuels containing the octane booster
additive, methylcyclopentadienyl
manganese tricarbonyl (MMT).

•

Leaded fuel, using leaded fuel is
prohibited by law.

The use of fuels with metallic compounds
such as methylcyclopentadienyl
manganese tricarbonyl, which is a
manganese-based fuel additive, will impair
engine performance and affect the
emission control system.

LOCATING THE FUEL FILLER
FUNNEL

The fuel filler funnel is under the luggage
compartment floor covering.

RUNNING OUT OF FUEL

FILLING A PORTABLE FUEL
CONTAINER

WARNING:

Flow of fuel through a

fuel pump nozzle can produce static
electricity. This can cause a fire if you are
filling an ungrounded fuel container.

Use the following guidelines to avoid
electrostatic charge build-up, which can
produce a spark, when filling an
ungrounded fuel container:
•

Only use an approved fuel container to
transfer fuel to your vehicle. Place the
container on the ground when filling it.

•

Do not fill a fuel container when it is
inside your vehicle (including the cargo
area).

•

Keep the fuel pump nozzle in contact
with the fuel container when filling it.

•

Do not use a device that holds the fuel
pump nozzle lever in the fill position.

202

Fuel and Refueling

ADDING FUEL FROM A PORTABLE
FUEL CONTAINER

WARNING:

Do not insert the nozzle

of a fuel container or an aftermarket
funnel into the fuel filler neck. This may
damage the fuel system filler neck or its
seal and cause fuel to run onto the
ground.

WARNING:

Do not pry open the

fuel tank filler valve. This could damage
the fuel system. Failure to follow this
instruction could result in fire, personal
injury or death.

WARNING:

Do not dispose of fuel

in the household refuse or the public
sewage system. Use an authorized waste
disposal facility.

When refueling the vehicle fuel tank from
a fuel container, use the fuel filler funnel
included with your vehicle. See

Locating

the Fuel Filler Funnel

(page 202).

Note:

Do not use aftermarket funnels as

they may not work with the capless fuel
system and can damage it.

When refueling the vehicle fuel tank from
a fuel container, do the following:

Fully open the fuel filler door.

E157452

2. Fully insert the fuel filler funnel into the

fuel filler inlet.

3. Add fuel to your vehicle from the fuel

container.

4. Remove the fuel filler funnel.

5. Fully close the fuel filler door.

6. Clean the fuel filler funnel and place it

back in your vehicle or correctly dispose
of it.

Note:

If your vehicle runs out of fuel add a

minimum of 1.3 gal (5 L) of fuel to restart
the engine.

Note:

You may need to switch the ignition

from off to on several times after refueling
to allow the fuel system to pump the fuel
from the tank to the engine. When
restarting, cranking time takes a few
seconds longer than normal.

Note:

Extra funnels can be purchased from

an authorized dealer if you choose to
dispose of the funnel.

203

Fuel and Refueling

REFUELING

REFUELING SYSTEM OVERVIEW

E267248

Fuel filler door.

Fuel filler inlet.

Fuel tank filler pipe.

REFUELING YOUR VEHICLE

WARNING:

When refueling always

WARNING:

Fuel vapor burns

violently and a fuel fire can cause severe
injuries.

WARNING:

The fuel system may

be under pressure. If you hear a hissing
sound near the fuel filler inlet, do not
refuel until the sound stops. Otherwise,
fuel may spray out, which could cause
serious personal injury.

WARNING:

Keep children away

from the fuel pump. Never let children
pump fuel.

WARNING:

Do not pry open the

fuel tank filler valve. This could damage
the fuel system. Failure to follow this
instruction could result in fire, personal
injury or death.

WARNING:

Stay outside your

vehicle and do not leave the fuel pump
unattended when refueling your vehicle.

WARNING:

Do not remove the fuel

pump nozzle from its fully inserted
position when refueling.

WARNING:

Stop refueling when

the fuel pump nozzle automatically
shuts off for the first time. Failure to
follow this will fill the expansion space
in the fuel tank and could lead to fuel
overflowing.

WARNING:

Do not overfill the fuel

tank. The pressure in an overfilled tank
may cause leakage and lead to fuel spray
and fire.

WARNING:

Wait at least five

seconds before removing the fuel pump
nozzle to allow any residual fuel to drain
into the fuel tank.

Fully open the fuel filler door.

2. Select the correct fuel pump nozzle for

your vehicle.

204

Fuel and Refueling

E139202

3. Insert the fuel pump nozzle up to the

first notch. Keep the fuel pump nozzle
resting on the fuel tank filler pipe.

E327438

4. Hold the fuel pump nozzle in position

A when refueling. Holding the fuel
pump nozzle in position B can affect
the flow of fuel and shut off the fuel
pump nozzle before the fuel tank is full.

E119081

5. When the pump shuts off, wait five

seconds, then raise the fuel pump
nozzle and slowly remove it.

6. Fully close the fuel filler door.

Note:

Do not attempt to start the engine

if you have filled the fuel tank with incorrect
fuel. Incorrect fuel use could cause damage
not covered by the vehicle Warranty. Have
your vehicle immediately checked.

FUEL TANK CAPACITY

Advertised Capacity

The advertised capacity is the maximum
amount of fuel that you can add to the fuel
tank after running out of fuel. Included in
the advertised capacity is an empty
reserve. The empty reserve is an
unspecified amount of fuel that remains
in the fuel tank when the fuel gauge
indicates empty.

Note:

The amount of fuel in the empty

reserve varies and should not be relied upon
to increase driving range.

FUEL AND REFUELING –
TROUBLESHOOTING

FUEL AND REFUELING –
WARNING LAMPS

If it illuminates when you are
driving, refuel as soon as
possible.

205

Fuel and Refueling

FUEL AND REFUELING –
INFORMATION MESSAGES

Refueling System Warning

If the fuel tank filler valve does not fully
close, a message could appear in the
instrument cluster display.

Message

Check Fuel Fill Inlet

If the message appears, do the following:

Stop your vehicle as soon as it is safe
to do so and switch the engine off.

2. Shift into park (P) or neutral (N).

3. Apply the parking brake.

4. Fully open the fuel filler door.

5. Check the fuel tank filler valve for any

debris that may be restricting its
movement.

6. Remove any debris from the fuel tank

filler valve.

Fully insert a fuel pump nozzle or the
fuel filler funnel provided with your
vehicle into the fuel filler pipe. See

Locating the Fuel Filler Funnel

(page 202). This action should dislodge
any debris that may be preventing the
fuel tank filler valve from fully closing.

8. Remove the fuel pump nozzle or fuel

filler funnel from the fuel filler pipe.

9. Fully close the fuel filler door.

Note:

The message may not immediately

reset. If the message continues to appear
and a warning lamp illuminates, have your
vehicle checked as soon as possible.

206

Fuel and Refueling

WHAT IS THE CATALYTIC
CONVERTER

The catalytic converter is part of your
vehicle's emissions system and filters
harmful pollutants from the exhaust gas.

CATALYTIC CONVERTER
PRECAUTIONS

WARNING:

Do not park, idle or

drive your vehicle on dry grass or other
dry ground cover. The emission system
heats up the engine compartment and
exhaust system, creating the risk of fire.

WARNING:

The normal operating

temperature of the exhaust system is
very high. Never work around or attempt
to repair any part of the exhaust system
until it has cooled. Use special care when
working around the catalytic converter.
The catalytic converter heats up to a very
high temperature after only a short
period of engine operation and stays hot
after the engine is switched off.

WARNING:

Exhaust leaks may

To avoid damaging the catalytic converter:
•

Do not crank the engine for more than
10 seconds at a time.

•

Do not run the engine with a spark plug
lead disconnected.

•

Do not push-start or tow-start your
vehicle. Use booster cables. See

Jump

Starting the Vehicle

(page 389).

•

Use the correct fuel. See

Fuel and

Refueling

(page 201).

•

Do not switch the ignition off when your
vehicle is moving.

•

Avoid running out of fuel.

•

Have the items listed in scheduled
maintenance information performed
according to the specified schedule.

Note:

Do not make any unauthorized

changes to your vehicle or engine. By law,
vehicle owners and anyone who
manufactures, repairs, or services a fleet of
vehicles are not permitted to intentionally
remove an emission control device or
prevent it from working.

CATALYTIC CONVERTER –
TROUBLESHOOTING

CATALYTIC CONVERTER –
WARNING LAMPS

Your vehicle has an on-board diagnostics
system that monitors the emission control
system. If any of the following warning
lamps illuminate, this may indicate that
the on-board diagnostics system has
detected an emission control system
malfunction.

E103308

E67021

E67028

Continuing to drive your vehicle may cause
reduced power or the engine to stop.
Failure to respond to a warning lamp may
cause damage that your vehicle Warranty
may not cover. Have your vehicle checked
as soon as possible.

207

Catalytic Converter

AUTOMATIC TRANSMISSION
PRECAUTIONS

WARNING:

Apply the parking

brake, shift into park (P), switch the
vehicle off and remove the key or remote
control before you leave your vehicle.
Failure to follow this instruction could
result in personal injury or death.

WARNING:

When your vehicle is

stationary, keep the brake pedal fully
pressed when shifting gears. Failure to
follow this instruction could result in
personal injury, death or property
damage.

WARNING:

Do not apply the brake

pedal and accelerator pedal
simultaneously. Applying both pedals
simultaneously for more than a few
seconds limits vehicle performance,
which may result in difficulty maintaining
speed in traffic and could lead to serious
injury.

AUTOMATIC TRANSMISSION
POSITIONS

PARK (P)

WARNING:

Shift into park (P) only

when your vehicle is stationary.

In park (P) power is not transmitted to the
driven wheels.

Note:

A tone sounds if you attempt to exit

your vehicle without the vehicle in park (P).

Note:

Your vehicle may not shift out of park

(P) if the 12 V battery has run out of charge.

Note:

Your vehicle may not shift out of park

(P) if a fuse is blown.

Note:

Your vehicle may not shift out of park

(P) unless the key or remote control is inside
your vehicle.

Note:

The electronic parking brake could

apply when you power your vehicle on with
the selector in park (P).

Note:

The electronic parking brake could

apply if you shift to park (P) without fully
pressing the brake pedal.

Note:

The electronic parking brake could

apply if you shift to park (P) on a slope.

Note:

Do not manually release the parking

brake when the selector is in park (P). See

Automatically Releasing the Electric
Parking Brake

(page 228).

Note:

Your vehicle could shift into park (P)

if you attempt to exit your vehicle without
the vehicle in park (P). See

How Does

Temporary Neutral Mode Work

(page 212).

Note:

A tone could sound when you select

park (P).

REVERSE (R)

WARNING:

Shift into reverse (R)

only when your vehicle is stationary.

In reverse (R) power is transmitted to the
driven wheels.

NEUTRAL (N)

WARNING:

In neutral (N) your

vehicle is free to roll.

In neutral (N) power is not transmitted to
the driven wheels.

208

Automatic Transmission

DRIVE (D)

In drive (D) power is transmitted to the
driven wheels.

MANUAL (M)

In manual (M) you can select a specific
gear. See

Manually Shifting Gears

(page

210).

Note:

We recommend using this mode for

driving on hilly or mountainous roads or
when towing a trailer. See

Towing a Trailer

(page 352).

SHIFTING YOUR VEHICLE INTO
GEAR

Console Shifter

The selector is on the center console.

E252861

Press and hold the brake pedal.

2. Rotate the outer ring to select a

position.

Note:

The position illuminates on the

selector.

Note:

Your vehicle cannot shift from drive

(D) to park (P) with a clockwise rotation.
Your vehicle cannot shift from park (P) to
drive (D) with a counter clockwise rotation.

3. Press the low (L) or manual (M) or

sport (S) button when your vehicle is
in drive (D) to enter or exit mode.

Column Shifter

(If Equipped)

The selector is on the steering column.

E327267

Press and hold the brake pedal.

2. Move the lever to select a position.

3. Press the manual (M) button when

your vehicle is in drive (D) to enter or
exit mode.

AUTOMATIC TRANSMISSION
POSITION INDICATORS

The instrument cluster displays the current
position.

E317778

Note:

The position could illuminate on the

transmission selector.

209

Automatic Transmission

AUTOMATIC TRANSMISSION
AUDIBLE WARNINGS

Transmission Not In Park (P)
Audible Warning

Sounds if you open the driver door before
shifting into park (P).

MANUALLY SHIFTING GEARS

SHIFTING USING THE BUTTONS
ON THE SELECTOR LEVER

The instrument cluster displays the current
gear. The current gear flashes when your
vehicle cannot shift into the requested
gear. Your vehicle will not shift if the
requested gear raises or lowers the engine
speed beyond the limit.

Your vehicle could shift when you fully
press the accelerator or brake pedal.

Note:

Prolonged driving with high engine

speed could cause vehicle damage not
covered by vehicle warranty.

Note:

Drive modes could affect when the

vehicle shifts into the requested gear.

E327267

Manually Shifting Gears in Drive
(D)

(If Equipped)

Use this feature to temporarily change
gear.

Note:

We recommend using this feature for

engine braking or driving on hilly or
mountainous roads.

•

Press any button to switch the feature
on.

•

Press the upper (+) button to upshift.

•

Press the lower (-) button to
downshift.

•

Hold the (+) button for a few seconds
to switch the feature off.

Note:

The feature switches off after a short

period of time if neither button is pressed.

Progressive Range Selection in
Drive (D)

Use this feature to prevent your vehicle
from automatically shifting to high gears.
The instrument cluster displays the current
gear and the highest gear available.

Note:

Your vehicle automatically shifts

within the gear range you select.

Note:

We recommend using this feature for

engine braking, driving on hilly or
mountainous roads, or when towing a trailer.
See

Towing a Trailer

(page 352).

•

Press the lower (-) button to switch
the feature on.

•

Press the lower (-) button to disable
the next highest gear.

•

Hold the upper (+) button for a few
seconds to switch the feature off.

Manually Shifting Gears in Manual
(M)

Use this feature to select a specific gear.

210

Automatic Transmission

Note:

We recommend using this feature for

engine braking, driving on hilly or
mountainous roads, or when towing a trailer.
See

Towing a Trailer

(page 352).

•

Press any button to switch the feature
on.

•

Press the upper (+) button to upshift.

•

Press the lower (-) button to
downshift.

•

Shift to drive (D) to switch the feature
off.

SHIFTING USING THE BUTTONS
ON THE ROTARY SHIFTER

Your vehicle could shift when you fully
press the accelerator or brake pedal.

Note:

Prolonged driving with high engine

speed could cause vehicle damage not
covered by vehicle warranty.

Note:

Drive modes could affect when the

vehicle shifts into the requested gear.

E252861

Manually Shifting Gears in Drive
(D)

(If Equipped)

Use this feature to temporarily change
gear.

Note:

We recommend using this feature for

engine braking or driving on hilly or
mountainous roads.

•

Press any button to switch the feature
on.

•

Press the (+) button to upshift.

•

Press the (-) button to downshift.

•

Hold the (+) button for a few seconds
to switch the feature off.

Note:

The feature switches off after a short

period of time if neither button is pressed.

Progressive Range Selection in
Drive (D)

Use this feature to prevent your vehicle
from automatically shifting to high gears.
The instrument cluster displays the current
gear and the highest gear available.

211

Automatic Transmission

Note:

Your vehicle automatically shifts

within the gear range you select.

Note:

We recommend using this feature for

engine braking, driving on hilly or
mountainous roads, or when towing a trailer.
See

Towing a Trailer

(page 352).

•

Press the lower (-) button to switch
the feature on.

•

Press the lower (-) button to disable
the next highest gear.

•

Hold the upper (+) button for a few
seconds to switch the feature off.

Manually Shifting Gears in Manual
(M)

Use this feature to select a specific gear.

Note:

We recommend using this feature for

engine braking, driving on hilly or
mountainous roads, or when towing a trailer.
See

Towing a Trailer

(page 352).

•

Shift to manual (M) to switch the
feature on.

•

Press the upper (+) button to upshift.

•

Press the lower (-) button to
downshift.

•

Shift to drive (D) to switch the feature
off.

TEMPORARY NEUTRAL MODE

HOW DOES TEMPORARY
NEUTRAL MODE WORK

Use this mode to keep your vehicle in
neutral (N), for a limited time, when you
exit your vehicle or switch your vehicle off.
For example, if you exit your vehicle before
an automatic car wash.

Note:

You do not need to use this mode at

an automatic car wash if you stay in your
vehicle with power on.

Note:

Do not tow your vehicle in this mode.

Note:

Automatic return to park (P) is

delayed when your vehicle is in this mode.
See

How Does Automatic Return to Park

(P) Work

(page 213).

TEMPORARY NEUTRAL MODE
LIMITATIONS

Your vehicle could shift to park (P) after
30 minutes, or when the vehicle battery
charge level is low. Prolonged use of this
mode can cause the 12 V battery to run out
of charge.

This mode could be unavailable if your
vehicle is below operating temperature.
Warm up your vehicle and attempt the
procedure again.

Do not tow your vehicle in this mode.
Failure to follow these instructions could
result in vehicle damage not covered by
the vehicle warranty.

ENTERING TEMPORARY
NEUTRAL MODE

Bring your vehicle to a complete stop.

2. Press and hold the brake pedal.

3. Power your vehicle on.

4. Shift into neutral (N).

Note:

An instructional message appears.

5. Press the manual (M) button.

Note:

A confirmation message appears

when your vehicle enters the mode.

6. Release the brake pedal.

Note:

Your vehicle is free to roll.

Switch your vehicle off.

Note:

Do not tow your vehicle in this mode.

Note:

The neutral (N) indicator on the

transmission selector may flash in this
mode.

212

Automatic Transmission

EXITING TEMPORARY NEUTRAL
MODE

Press the brake pedal.

2. Shift into park (P), or power your

vehicle on and shift into drive (D) or
reverse (R).

AUTOMATIC RETURN TO
PARK (P)

HOW DOES AUTOMATIC RETURN

TO PARK (P) WORK

Your vehicle shifts into park (P) if you
attempt to exit your vehicle without the
vehicle in park (P).

Your vehicle shifts into park (P) when your
vehicle is stationary and any of the
following occur:
•

You switch the vehicle off.

•

You open the driver door with the driver
seatbelt unfastened.

•

You unfasten the driver seatbelt when
the driver door is open.

Note:

Do not use automatic return to park

(P) when your vehicle is moving, except in
an emergency. See

Starting and Stopping

the Engine

(page 189).

AUTOMATIC RETURN TO PARK
(P) LIMITATIONS

Automatic return to park (P) may not work
if any of the following occur:

•

The driver door ajar sensor is
malfunctioning.

•

The driver seatbelt sensor is
malfunctioning.

See an authorized dealer if any of the
following occur:

•

Seatbelt indicator illuminates or tone
sounds with the driver seatbelt
fastened.

•

Door ajar indicator does not illuminate
with the driver door open.

•

Door ajar indicator illuminates with the
driver door closed.

•

Transmission not in park message
appears, with the driver door closed,
after you shift out of park (P).

213

Automatic Transmission

HOW DOES FOUR-WHEEL
DRIVE WORK

Using the 1-Speed Automatic Four-
Wheel Drive System

The 1-speed automatic four-wheel drive
system utilizes an electronically controlled
on-demand 1-speed transfer case. This
system monitors various vehicle sensory
inputs to provide an increased level of
performance. This system offers the driver
two-wheel drive high, four-wheel drive
auto and four-wheel drive high as available
modes of operation via the selectable drive
mode switch. When you select four-wheel
drive auto the system continuously varies
power to the front wheels for optimum
performance for all on-road conditions.
When you select four-wheel drive high the
system provides power to the front and
rear wheels for use in off-road or slippery
conditions such as deep snow, sand or
mud. There is further information on driving
in unique driving conditions. See

Driving

Hints

(page 383).

Using the 2-Speed Automatic
Four-Wheel Drive System

(If Equipped)

The 2-speed automatic four-wheel drive
system utilizes an electronically controlled
on-demand 2-speed transfer case. This
system monitors various vehicle sensory
inputs to provide an increased level of
performance. This system offers the driver
two-wheel drive high, four-wheel drive
auto, four-wheel drive high, and four-wheel
drive low as available modes of operation.
When you select four-wheel drive auto the
system continuously varies power to the
front wheels for optimum performance for
all on-road conditions. When you select
either four-wheel drive high or four-wheel
drive low with the appropriate drive modes,
the four-wheel drive system provides
electronically locked power to the front
and rear wheels for use in off-road or

slippery conditions such as deep snow,
sand or mud. Selecting four-wheel drive
low also provides additional gearing for
increased torque multiplication for
conditions like deep sand, snow, steep
slopes, or pulling heavy objects. See

Selecting a Four-Wheel Drive Mode

(page 215). Additionally, the system is
capable of recreational flat towing by
putting the transfer case into neutral (N).
See

Recreationally Towing Your

Vehicle

(page 394).

There is further information on driving in
unique driving conditions. See

Driving

Hints

(page 383).

FOUR-WHEEL DRIVE
PRECAUTIONS

WARNING:

Vehicles with a higher

center of gravity (utility and four-wheel
drive vehicles) handle differently than
vehicles with a lower center of gravity
(passenger cars). Avoid sharp turns,
excessive speed and abrupt steering in
these vehicles. Failure to drive cautiously
increases the risk of losing control of your
vehicle, vehicle rollover, personal injury
and death.

WARNING:

Do not become

overconfident in the ability of four-wheel
drive vehicles. Although a four-wheel
drive vehicle may accelerate better than
a two-wheel drive vehicle in low traction
situations, it won't stop any faster than
two-wheel drive vehicles. Always drive
at a safe speed.

Truck and utility vehicles can differ from
some other vehicles. Your vehicle could be
higher to allow it to travel over rough
terrain without getting stuck or damaging
underbody components. The differences
that make your vehicle so versatile also

214

Four-Wheel Drive

(If Equipped)

make it handle differently than an ordinary
passenger car. Always maintain steering
wheel control, especially in rough terrain.
Since sudden changes in terrain can result
in abrupt steering wheel motion, make sure
you grip the steering wheel from the
outside. Do not grip the spokes. Drive
cautiously to avoid vehicle damage from
concealed objects such as rocks and
stumps. Drive slower in strong crosswinds
which can affect the normal steering
characteristics of your vehicle. Be
extremely careful when driving on
pavement made slippery by loose sand,
water, gravel, snow or ice.

Note:

Do not use four-wheel drive high or

four-wheel drive low mode on dry, hard
surfaced roads. Doing so can produce
excessive noise, increase tire wear and can
damage drive components.

FOUR-WHEEL DRIVE
LIMITATIONS

Operating Four-Wheel Drive with
a Spare or Mismatched Tires

(If

Equipped)

On four-wheel drive vehicles, the size of
the spare tire can affect the four-wheel
drive system. If there is a significant
difference between the size of the spare
tire and the remaining tires, you could have
limited four-wheel drive functionality.
When driving with the full-size dissimilar
spare wheel and tire assembly, we
recommend that you do not:

•

Exceed 50 mph (80 km/h) with a
four-wheel drive mode turned on.

•

Use a four-wheel drive mode on dry
pavement.

Driving with the full-size dissimilar spare
wheel and tire assembly can limit
four-wheel drive functionality. You can
experience the following:

•

Additional noise from the transfer case
or other drive components.

Use of a dissimilar spare wheel and tire
assembly can lead to impairment of the
following:

•

Comfort and noise.

•

Winter weather driving capability.

•

Wet driving capability.

•

Four-wheel drive capability.

Note:

Your vehicle could have a front air

dam that can become damaged, due to
reduced ground clearance, when taking your
vehicle off-road. You can remove this air
dam by removing the eight bolts that secure
it.

Note:

Your vehicle could have side steps

that can become damaged, due to reduced
ground clearance, when taking your vehicle
off-road. Remove side steps before driving
your vehicle off-road.

SELECTING A FOUR-WHEEL
DRIVE MODE

E357409

215

Four-Wheel Drive

(If Equipped)

E357408

Depending on the variant, the four-wheel
drive mode control is either in the
instrument panel or the center console.

To select a four-wheel drive mode, press
the four-wheel drive mode control button
of the desired mode. You can select
two-wheel drive high (2H), four-wheel
drive auto (4A) or four-wheel drive high
(4H) at a stop or while driving. Once the
shift is complete, the information display
shows the selected four-wheel drive mode.
While shifts are in progress, the lights on
the four-wheel drive control switch flashes
until your vehicle achieves the desired shift.

Note:

When shifting to and from four-wheel

drive, the information display shows the
shifting in progress message indicating that
the system is in the process of making a
shift.

Note:

Do not perform this operation if the

rear wheels are slipping or while applying
the accelerator pedal.

If the system detects a fault, a warning
message appears in the information
display. See

Four-Wheel Drive –

Information Messages

(page 219).

Shifting to or from Four-Wheel
Drive Low (4L)

(If Equipped)

To select or exit four-wheel drive low (4L):

Bring your vehicle to a speed of 3 mph
(5 km/h) or less.

2. Place the transmission in neutral (N)

3. Press the desired four-wheel drive

button on the four-wheel drive mode
control switch.

The information display shows a message
indicating a four-wheel drive shift is in
progress. If any of the above shift
conditions are not present, the shift does
not occur and the information display
shows information guiding the driver
through the proper shifting procedures. If
there is a transfer case tooth blockage, a
message displays in the information
display. To alleviate this condition, place
the transmission in a forward gear, move
your vehicle forward approximately 5 ft
(1.5 m), and shift the transmission back to
neutral (N) to allow the transfer case to
complete the range shift.

Note:

You could hear some noise as the

system shifts or engages which is normal.

If the system detects a fault, a warning
message appears in the information
display. See

Four-Wheel Drive –

Information Messages

(page 219).

FOUR-WHEEL DRIVE MODES

TWO-WHEEL DRIVE HIGH

Two-wheel drive high is for general
on-road driving. Power is sent to the rear
wheels only.

Note:

Two-wheel drive high can turn on or

off based on Drive Mode selection See

Drive

Mode Control

(page 297).

216

Four-Wheel Drive

(If Equipped)

FOUR-WHEEL DRIVE AUTO

Four-wheel drive auto provides
electronically controlled four-wheel drive
power to both the front and rear wheels,
as required, for increased traction in varying
on-road conditions. The four-wheel drive
auto tuning varies based on selected Drive
Mode. See

Selecting a Drive Mode

(page

297).

Note:

Four-wheel drive auto can turn on or

off automatically based on Drive Mode
selection. See

Selecting a Drive Mode

(page 297).

FOUR-WHEEL DRIVE HIGH

(If Equipped)

Four-wheel drive high provides
electronically locked four-wheel drive
power to both the front and rear wheels
for use in off-road or winter conditions
such as deep snow, sand or mud. This
mode is not for use on dry pavement.

Note:

Four-wheel drive high can turn on or

off automatically based on Drive Mode
selection. See

Selecting a Drive Mode

(page 297).

FOUR-WHEEL DRIVE LOW

(If Equipped)

Four-wheel drive low provides
electronically locked four-wheel drive
power to both the front and rear wheels
for use on low traction surfaces, but does
so with additional gearing for increased
torque multiplication. This mode is only for
off-road conditions such as deep sand,
steep slopes, or pulling heavy objects.

Note:

Four-wheel drive low can turn on or

off automatically based on drive mode
selection. See

Selecting a Drive Mode

(page 297).

FOUR-WHEEL DRIVE
INDICATORS

Two-wheel Drive High

E181778

Momentarily illuminates when
you select two-wheel drive high.

Four-wheel Drive Auto

E181781

Continuously illuminates when
you select four-wheel drive auto.

Four-wheel Drive High

(If Equipped)

E181779

Continuously illuminates when
you select four-wheel drive high.

Four-wheel Drive Low

(If Equipped)

E181780

Continuously illuminates when
you select four-wheel drive low.

FOUR-WHEEL DRIVE DRIVING
HINTS

DRIVING IN SAND

When driving over sand, try to keep all four
wheels on the most solid area of the trail.
Avoid reducing the tire pressures but shift
to a lower gear and drive steadily through
the terrain. Apply the accelerator slowly
and avoid excessive wheel slip.

When driving at slow speeds in deep sand
under high outside temperatures, use a low
gear when possible. Low gear operation
can maximize the engine and transmission
cooling capability.

217

Four-Wheel Drive

(If Equipped)

Ford Expedition (2024 year). Manual in english - page 6
