ADAPTIVE CRUISE CONTROL –
INFORMATION MESSAGES -
VEHICLES WITH: STOP AND GO

Note:

Depending on your vehicle options

and instrument cluster type, not all
messages display or are available.

Note:

The system could abbreviate or

shorten certain messages depending upon
which cluster type you have.

Action

Message

A malfunction is preventing the adaptive cruise from engaging.

Adaptive Cruise

Malfunction

Front Sensor Not Aligned

Contact an authorized dealer to have the radar checked for

proper coverage and operation.

Conditions exist preventing the system from being available.

Adaptive Cruise Not

Available

You have a blocked radar because of poor radar visibility due
to inclement weather or ice, mud, or water in front of the radar.

You can typically clean the sensor to resolve this.

Adaptive Cruise Not

Available Sensor

Blocked See Manual

Due to the nature of radar technology, it is possible to get a

blockage warning with no actual block. This happens, for

example, when driving in sparse rural or desert environments.
A false blocked condition either self clears, or clears after you

restart your vehicle.

You have selected normal cruise control. The system does

not brake or react to traffic.

Normal Cruise Active

Adaptive Braking Off

Displays when the adaptive cruise control is going to cancel

and you must take control.

Adaptive Cruise - Driver

Resume Control

Displays when the vehicle speed is too slow to activate the

adaptive cruise control and there is no lead vehicle in range.

Adaptive Cruise Speed

Too Low to Activate

280

Adaptive Cruise Control

(If Equipped)

WHAT IS BLUECRUISE

BlueCruise keeps your vehicle centered in
the lane and offers a hands-free driving
mode in certain situations when using
adaptive cruise control.

HOW DOES BLUECRUISE
WORK

BlueCruise uses cameras to monitor your
vehicle position within a lane and applies
steering support to keep your vehicle
centered in the lane.

Using the cameras and location
information, BlueCruise allows you to
remove your hands from the steering wheel
and offers a hands-free driving mode in
certain areas.

When active, BlueCruise uses a driver
facing camera and infrared lighting to
monitor your eyes and head position to
detect if you are distracted. If the system
determines you are distracted, it alerts you
to return your eyes to the road.

E351060

Lighting area.

Camera.

Note:

When BlueCruise is active, in certain

crash or near crash-like situations, such as
an air bag deployment or hitting a road
obstacle, camera data may record through
the vehicle event data recorder. See

Event

Data

(page 27).

Note:

No data records under normal driving

conditions.

BLUECRUISE PRECAUTIONS

WARNING:

You are responsible for

keeping your eyes on the road at all
times. The system is designed to be an
aid and does not relieve you of your
responsibility to drive with due care and
attention. Failure to follow this
instruction could result in the loss of
control of your vehicle, personal injury or
death.

WARNING:

You are responsible for

controlling your vehicle at all times. The
system is designed to be an aid and does
not relieve you of your responsibility to
drive with due care and attention. Failure
to follow this instruction could result in
the loss of control of your vehicle,
personal injury or death.

WARNING:

Do not use the system

when towing a trailer. Failure to follow
this instruction could result in the loss of
control of your vehicle, personal injury or
death.

WARNING:

Obstructions to the

driver facing camera or infrared lighting
could prevent the system from properly
operating. Keep the camera and lighting
areas free from obstruction. Failure to
follow this instruction could result in the
loss of control of your vehicle, personal
injury or death.

281

BlueCruise - Vehicles With: 15 Inch Screen

(If Equipped)

WARNING:

Do not use the system

if any changes or modifications to the
steering wheel have been made. Any
changes or modifications to the steering
wheel could affect the functionality or
performance of the system. Failure to
follow this instruction could result in the
loss of control of your vehicle, personal
injury or death.

WARNING:

The system may not

function if the sensor is blocked.

WARNING:

Pay close attention to

changing road conditions such as
entering or leaving a highway, on roads
with intersections or roundabouts, roads
without visible lanes of travel, roads that
are winding, slippery, unpaved, or steep
slopes.

WARNING:

The system is not a

crash warning or avoidance system.

WARNING:

Large contrasts in

outside lighting can limit sensor
performance.

WARNING:

The system attempts

to keep your vehicle in the center of the
lane as well as maintain speed and gap
control. The system may not be able to
perform these tasks in all situations. Do
not use the system in complex or
uncertain driving conditions. Failure to
follow this instruction could result in the
loss of control of your vehicle, personal
injury or death.

WARNING:

Your vehicle could drift

out of the lane of travel. Always be
prepared to manually steer your vehicle.
Failure to follow this instruction could
result in the loss of control of your
vehicle, personal injury or death.

WARNING:

The system will not

operate if the sensor cannot track the
road lane markings.

BLUECRUISE REQUIREMENTS

BlueCruise only activates when all of the
following occur:
•

BlueCruise is enabled in your
information and entertainment screen.
See

BlueCruise Settings

(page 283).

•

Adaptive cruise control is on.

•

The system detects both lane
markings.

•

Your hands are on the steering wheel.

•

Your eyes are on the road.

Note:

For hands-free mode to work, your

vehicle must be on certain limited access
divided freeways.

Note:

The system may require updated

software for hands-free mode. See

Vehicle

System Updates

(page 520).

BLUECRUISE LIMITATIONS

Any of the following conditions could result
in BlueCruise not correctly operating:
•

You do not have your vehicle centered
in the lane.

•

The lane is too narrow or too wide.

•

The system does not detect at least
one lane marking or when lanes merge
or split.

•

You are applying a low amount of
steering input.

•

You are using the system in areas under
construction.

•

If you make any aftermarket
modifications to the steering system.

•

You are using a spare tire.

282

BlueCruise - Vehicles With: 15 Inch Screen

(If Equipped)

The driver-facing camera may not operate
correctly due to any of the following:
•

You have a pre-existing eye condition,
such as an eye misalignment, or have
had eye surgery.

•

You cover your facial features by a
mask, hat or other items.

•

The lighting conditions change
significantly.

•

You are not in the field of view of the
camera.

•

You position or tilt yourself to one side.

•

You are moving around extensively.

•

You are wearing glasses or sunglasses
that are too dark or reflective.

Note:

The system has limited steering

assistance and may not be sufficient for all
driving situations.

Note:

In exceptional conditions, such as

inclement weather or direct sunlight, the
system could deviate from the center line.

Note:

The information provided by the

navigation map data could be inaccurate or
out of date.

BLUECRUISE SETTINGS

Enabling BlueCruise

Access the vehicle drawer on the
touchscreen.

2. Press

SETTINGS

3. Press

Driver Assistance

4. Press

Cruise Control

5. Press

Lane Centering with

Hands-Free

Enabling Activation Prompts

Access the vehicle drawer on the
touchscreen.

2. Press

SETTINGS

3. Press

Driver Assistance

4. Press

Cruise Control

5. Press

Activation Prompts

SWITCHING BLUECRUISE ON
AND OFF

Switching BlueCruise On

The controls are on the steering wheel.

Using Activation Prompts

E144529

When the prompt appears, press
the button to switch BlueCruise
on.

The indicator appears in the instrument
cluster. When the system is on, the color
of the indicator changes to indicate the
system status.

Note:

You must enable activation prompts

in the touchscreen.

Using Steering Wheel Controls

E308131

E144529

Using the adaptive cruise control
and lateral support buttons,
ensure both systems are active.
BlueCruise activates.

Switching BlueCruise Off

E308131

E144529

Press either the lateral support
or adaptive cruise control button
when system is active or in
standby mode.

BlueCruise turns off through
each ignition cycle.

283

BlueCruise - Vehicles With: 15 Inch Screen

(If Equipped)

BLUECRUISE ALERTS

When BlueCruise is providing hands-on
driving or transitioning to hands-on driving
from hands-free driving and detects no
steering activity for a certain period of time,
the system alerts you with a message in
the instrument cluster to put your hands
on the steering wheel. After the first alert,
the system alerts you with a message in
the instrument cluster and an audible
warning.

When BlueCruise is providing hands-on or
hands-free driving and detects you are not
looking at the road for a certain period of
time, the system alerts you to return your
eyes to the road. Depending on where you
are looking, the alert can be a message in
the instrument cluster and an audible
warning.

If you do not react to the warnings,
BlueCruise cancels, quickly activates and
releases the brakes, and slows your vehicle
down to low speeds while maintaining
steering control.

If your vehicle slows down and you resume
control, a message appears to prompt you
to press the accelerator pedal to allow the
system to resume.

Note:

If the system detects repeated

inactivity, it disables until the next key cycle.

BLUECRUISE AUTOMATIC
CANCELLATION

When an external condition cancels
BlueCruise, for example, no lane markings
available, a tone sounds and a message
appears in the instrument cluster.

E308130

If your vehicle starts to slow
down, you must take control of
steering and press and release

the button to reactivate BlueCruise.

System cancellation can also occur if:

•

The lane becomes too narrow.

•

The system cannot detect valid lane
markings.

•

Lane markings cross.

•

Your eyes are not on the road or your
hands are not the on steering wheel.

If you have your hands on the steering
wheel and your eyes are on the road when
the feature is active and a cancellation
occurs, the system sounds a tone and
displays a cancelled graphic in the
instrument cluster.

If you are not paying attention to the road
or your hands are not on the steering wheel
and a cancellation occurs, the system
displays a message and a tone sounds until
you resume control. If you do not resume
control in time, BlueCruise quickly activates
and releases the brakes, and slows your
vehicle to low speeds while maintaining
steering control. If your vehicle slows down
and you resume control, a message
appears to prompt you to press the
accelerator pedal to allow the system to
resume.

Note:

The system disables until the vehicle

is turned off and back on if it detects
repeated inactivity.

BLUECRUISE INDICATORS

E297977

When on, the color of the
indicator changes to indicate the
status.

Gray indicates BlueCruise is on but inactive.

Green indicates BlueCruise is active and
applying continuous steering support.

Blue indicates BlueCruise is active and
hands-free driving mode is available.

284

BlueCruise - Vehicles With: 15 Inch Screen

(If Equipped)

Hands-On Driving Support
Available

E333236

When this indicator is present, you must
keep your hands on the steering wheel.

Hands-Free Driving Support
Available

E333232

A graphic in the instrument cluster of a
steering wheel without hands indicates the
hands-free driving mode is available.

When this indicator is present, you can
remove your hands from the steering
wheel.

BLUECRUISE –
TROUBLESHOOTING

BLUECRUISE – INFORMATION
MESSAGES

Depending on your vehicle options and
instrument cluster type, not all messages
display or are available.

Details

Message

Make sure you return your hands to the

steering wheel and provide steering input.

Keep Hands on Steering Wheel

The system is going to cancel and you must

take control.

Resume Control

Return your attention to the road.

Watch the Road

285

BlueCruise - Vehicles With: 15 Inch Screen

(If Equipped)

Details

Message

Conditions exist preventing the system from

being available. If the message continues

to display, have the system checked as

soon as possible.

BlueCruise not available

Press the accelerator pedal and follow the

prompts.

Press Accelerator Pedal to Resume

Make sure your facial features are visible

and in the field of view of the driver facing

camera.

Driver monitor camera cannot detect face

See manual

Make sure your hands, arms or other objects

are not obscuring the camera.

Driver monitor camera is blocked See

manual

Conditions exist preventing the system from

being available. If the message continues

to display, have the system checked as

soon as possible.

Driver monitor camera fault See manual

BlueCruise is active, keep your attention on

the road.

BlueCruise On Watch the road Be prepared

to resume control

The system is in standby mode, press the

button on the steering wheel to activate.

BlueCruise available Press {ICON} to

activate

Note:

The instrument cluster display may

abbreviate or shorten certain messages.

286

BlueCruise - Vehicles With: 15 Inch Screen

(If Equipped)

WHAT IS DRIVE MODE
CONTROL

Your vehicle has various drive modes that
you can select for different driving
conditions. Depending on the drive mode
that you select, the system adjusts various
vehicle settings.

HOW DOES DRIVE MODE
CONTROL WORK

Drive mode control adjusts your vehicle
configuration for each mode you select.

Changing the drive mode adjusts the
steering effort and feel of the steering
system.

The stability and traction control assist
your vehicle control in adverse conditions
or high-performance driving.

Throttle control enhances the powertrain
response, transmission controls become
optimized with shift schedules, and
four-wheel drive settings are optimized
and tuned to each mode.

Changing the drive mode can engage or
disengage the electronic locking
differentials.

Changing the drive mode changes the
four-wheel drive mode to the default
setting for the selected drive mode.

Note:

The system has diagnostic checks

that continuously monitor the system for
proper operation. If a mode is unavailable
due to a system fault, the drive mode
system defaults to normal. When the
system defaults to normal, the driveline
settings remain the same as prior to the
system fault.

Note:

The system reverts to the normal

mode each time you start your vehicle. At
startup the system also displays a prompt
on the instrument cluster display that gives
you the option to return to the previously
selected drive mode during the last ignition
cycle. If you select yes, the system returns
to the last selected drive mode and the
default driveline settings associated with
that mode. If you select no, the system
remains in normal mode and the driveline
settings remain the same as selected in the
prior ignition cycle. If you do not select yes
or no, the system stays in normal mode and
the driveline settings remain the same as
selected in the prior ignition cycle.

SELECTING A DRIVE MODE

E308146

Rotate the drive mode control on the
center console to select or change a drive
mode.

Note:

Button icons vary depending on the

vehicle.

287

Drive Mode Control

DRIVE MODES

ECO - 4X4

E295413

For efficient driving. This mode
helps deliver maximum fuel
efficiency and helps to increase

driving range.

Two-wheel drive high is the default
four-wheel drive mode. Four-wheel drive
low is not available in eco mode.

The electronic locking differential is
available below 25 mph (40 km/h). See

Locking and Unlocking the Electronic
Limited-Slip Differential

(page 217).

ECO - 4X2

E295413

For efficient driving. This mode
helps deliver maximum fuel
efficiency and helps to increase

driving range.

The electronic locking differential is
available below 25 mph (40 km/h). See

Locking and Unlocking the Electronic
Limited-Slip Differential

(page 217).

MUD/RUTS - 4X4

(If Equipped)

E296606

For off-road driving. This mode
enhances vehicle performance
to traverse muddy, rutted or

uneven terrains.

Four-wheel drive high is the default
four-wheel drive mode. Four-wheel drive
low is selectable in mud/rut mode.

The electronic locking differential engages
when you select this mode at any speed,
and you can disengage it at any time using
the button. See

Locking and Unlocking

the Electronic Limited-Slip Differential

(page 217).

Note:

Do not use this mode when driving

on pavement or packed snow. This could
cause driveline bind up and damage the
system depending on the four-wheel drive
mode selection. See

Four-Wheel Drive

(page 209).

NORMAL - 4X4

E225310

For everyday driving. This mode
is the perfect balance of
excitement, comfort and

convenience. This is the default mode after
each ignition cycle.

Two-wheel drive high is the default
four-wheel drive mode. All four-wheel drive
modes are selectable when in normal
mode.

The electronic locking differential is
available below 25 mph (40 km/h). See

Locking and Unlocking the Electronic
Limited-Slip Differential

(page 217).

NORMAL - 4X2

E225310

For everyday driving. This mode
is the perfect balance of
excitement, comfort and

convenience. This is the default mode after
each ignition cycle.

The electronic locking differential is
available below 25 mph (40 km/h). See

Locking and Unlocking the Electronic
Limited-Slip Differential

(page 217).

SAND - 4X4

(If Equipped)

E332185

For more spirited off-road
driving. Sand mode is for
off-road driving on soft, dry sand

or deep conditions. Lower gears hold
longer in sand mode to maintain
momentum in soft conditions. Sand mode
engages the four-wheel drive lock, which
you can switch off using the drive mode

288

Drive Mode Control

controller. Sand mode optimizes braking
for off-road conditions, allowing quick path
corrections and minimized stopping
distance when on deformable surfaces.
The engine sound enhances when in sand
mode.

The rear differential lock feature is
available in sand mode. When enabled it
is engaged below 30 mph (48 km/h).

Note:

Using sand mode on dry, hard

surfaces could produce some vibration,
driveline bind up, potential excessive tire
wear and vehicle wear.

Note:

Do not use on firm, slippery surfaces,

such as paved roads covered with snow or
ice or driving on packed snow. For slippery,
firm surfaces use slippery mode.

SLIPPERY - 4X4

E295414

For less than ideal road
conditions such as snow or ice
covered roads. Use this mode for

crossing terrain where loose or slippery
materials cover a firm surface. Slippery
mode lowers throttle response and
optimizes shifting for slippery surfaces.

Four-wheel drive auto is the default
four-wheel drive mode. Two-wheel drive
high is not available in slippery mode.

The electronic locking differential is
available below 25 mph (40 km/h). See

Locking and Unlocking the Electronic
Limited-Slip Differential

(page 217).

Note:

Do not use this mode when driving

on dry pavement. This could cause driveline
bind up and damage the system depending
on the four-wheel drive mode selection.
See

Four-Wheel Drive

(page 209).

SLIPPERY - 4X2

E295414

For less than ideal road
conditions such as snow or ice
covered roads. Use this mode for

crossing terrain where loose or slippery
materials cover a firm surface. Slippery
mode lowers throttle response and
optimizes shifting for slippery surfaces.

The electronic locking differential is
available below 25 mph (40 km/h). See

Locking and Unlocking the Electronic
Limited-Slip Differential

(page 217).

Note:

Do not use this mode when driving

on dry pavement. This could cause driveline
bind up and damage the system depending
on the four-wheel drive mode selection.
See

Four-Wheel Drive

(page 209).

SPORT - 4X4

E246593

For sporty driving with improved
performance handling and
response. This mode increases

accelerator pedal response and provides
a sportier steering feel. The powertrain
system holds onto lower gears longer,
helping your vehicle accelerate faster.

Four-wheel drive auto is the default
four-wheel drive mode. Four-wheel drive
low is not available in sport mode.

The system tunes the steering and
suspension to provide a more connected
and spirited driving experience.

The electronic locking differential is
available below 25 mph (40 km/h). See

Locking and Unlocking the Electronic
Limited-Slip Differential

(page 217).

289

Drive Mode Control

SPORT - 4X2

E246593

For sporty driving with improved
performance handling and
response. This mode increases

accelerator pedal response and provides
a sportier steering feel. The powertrain
system holds onto lower gears longer,
helping your vehicle accelerate faster.

The system tunes the steering and
suspension to provide a more connected
and spirited driving experience.

The electronic locking differential is
available below 25 mph (40 km/h). See

Locking and Unlocking the Electronic
Limited-Slip Differential

(page 217).

TOW/HAUL - 4X4

E246592

For improved transmission
operation when towing a trailer
or a heavy load. This mode

moves upshifts to higher engine speeds to
reduce the frequency of transmission
shifting. This mode also provides engine
braking in all forward gears, which slows
your vehicle and assists you in controlling
your vehicle when descending a slope. The
amount of downshift braking provided
varies based on the amount you press the
brake pedal.

All four-wheel drive modes are selectable
in tow/haul mode. This mode does not
default to a certain four-wheel drive mode
and maintains the previous selection.

The system tunes the steering and
suspension to enhance driving comfort
when towing or carrying heavy loads.

The electronic locking differential is
available below 25 mph (40 km/h). See

Locking and Unlocking the Electronic
Limited-Slip Differential

(page 217).

TOW/HAUL - 4X2

E246592

For improved transmission
operation when towing a trailer
or a heavy load. This mode

The system tunes the steering and
suspension to enhance driving comfort
when towing or carrying heavy loads.

The electronic locking differential is
available below 25 mph (40 km/h). See

Locking and Unlocking the Electronic
Limited-Slip Differential

(page 217).

TRAIL - 4X2

(If Equipped)

E295419

Trail mode is for off-road driving
on muddy, rutted, soft or uneven
terrain. This mode lowers

throttle response to increase wheel spin
to keep the tires clear and to prevent
getting stuck.

The electronic locking differential is
available below 25 mph (40 km/h). See

Locking and Unlocking the Electronic
Limited-Slip Differential

(page 217).

290

Drive Mode Control

DRIVE MODE CONTROL –
TROUBLESHOOTING

DRIVE MODE CONTROL –
WARNING LAMPS

E130458

Some drive modes reduce
traction and stability control
performance and the indicator

illuminates in the instrument cluster.

DRIVE MODE CONTROL – INFORMATION MESSAGES

Action

Message

You have selected a four-wheel drive mode

that is not available in the current drive

mode. Select an available four-wheel drive

mode.

Selected 4x4 Mode Not Available in Current

Drive Mode

291

Drive Mode Control

WHAT IS THE LANE KEEPING
SYSTEM

The lane keeping system alerts you by
providing temporary steering assistance
or steering wheel vibration when it detects
an unintended lane departure.

HOW DOES THE LANE
KEEPING SYSTEM WORK

The lane keeping system uses a forward
looking camera mounted on the windshield
to monitor vehicle movement within the
travel lane.

When the camera detects a drift out of the
travel lane, the lane keeping system alerts
the driver by vibrating the steering wheel,
or aids the driver by providing a small
steering input to move the vehicle back
into the travel lane.

The driver can select one of three modes:

•

Alert (If Equipped)

•

Aid

•

Alert + Aid

LANE KEEPING SYSTEM
PRECAUTIONS

WARNING:

You are responsible for

WARNING:

The system will not

operate if the sensor cannot track the
road lane markings.

WARNING:

The sensor may

incorrectly track lane markings as other
structures or objects. This can result in
a false or missed warning.

WARNING:

In cold and severe

weather conditions the system may not
function. Rain, snow and spray can all
limit sensor performance.

WARNING:

The system may not

operate properly if the sensor is blocked.
Keep the windshield free from
obstruction.

WARNING:

If damage occurs in the

immediate area surrounding the sensor,
have your vehicle checked as soon as
possible.

WARNING:

The system may not

correctly operate if your vehicle is fitted
with a suspension kit not approved by
us.

WARNING:

Large contrasts in

outside lighting can limit sensor
performance.

LANE KEEPING SYSTEM
LIMITATIONS

The lane keeping system only operates
when the vehicle speed is greater than
40 mph (64 km/h).

The system works when the camera can
detect at least one lane marking.

Note:

When you select Aid or Alert and Aid

mode and the system detects no steering
activity for a short period of time, the system
alerts you to put your hands on the steering
wheel. The system may detect a light grip
or touch on the steering wheel as hands-off
driving.

293

Lane Keeping System

The lane keeping system may not correctly
operate in any of the following conditions:
•

The lane keeping system does not
detect at least one lane marking.

•

You switch the turn signal on.

•

You apply direct steering, accelerate
fast or brake hard.

•

The vehicle speed is less than 40 mph
(64 km/h).

•

The anti-lock brake, stability control or
traction control system activates.

•

The lane is too narrow.

•

Something is obscuring the camera or
it is unable to detect the lane markings
due to environment, traffic or vehicle
conditions.

•

Entering or exiting a tight curve when
driving at high speeds.

The lane keeping system may not correct
lane positioning in any of the following
conditions:
•

High winds.

•

Uneven road surfaces.

•

Heavy or uneven loads.

•

Incorrect tire pressure.

SWITCHING THE LANE
KEEPING SYSTEM ON AND
OFF

E334922

To activate the lane keeping
system, press the button on the
steering wheel.

To deactivate the lane keeping system,
press the button again.

Note:

When switching the system on or off

a message appears in the information and
entertainment display to show the status.

Note:

The system stores the on or off

setting until manually changed, unless it
detects a MyKey™. If the system detects a
MyKey™, it defaults to the last setting for
that MyKey™.

Note:

If the system detects a MyKey™,

pressing the button does not affect the on
or off status of the system. You can only
change the mode and intensity settings.

SWITCHING THE LANE
KEEPING SYSTEM MODE -
VEHICLES WITH: 12.3 INCH
SCREEN

The lane keeping system has different
settings that you can view or adjust using
the information display.

The system stores the last known selection
for each of these settings. You do not need
to readjust your settings each time you
switch on the system.

To change the lane keeping system mode,
use the touchscreen:

Press

Features

on the touchscreen.

2. Press

Driver Assistance

3. Press

Lane-Keeping System

4. Press

Lane-Keeping Mode

5. Select a mode.

Note:

The system remembers the last

setting when you start your vehicle. If the
system detects a MyKey™, it defaults to the
last setting for that MyKey™.

294

Lane Keeping System

SWITCHING THE LANE
KEEPING SYSTEM MODE -
VEHICLES WITH: 15 INCH
SCREEN

The lane keeping system has different
settings that you can view or adjust using
the information display.

•

Alert (If Equipped)

•

Aid

•

Alert and Aid

The system permanently stores the last
known selection for each setting.

To change the lane keeping system mode,
access the vehicle drawer on the
touchscreen:

Press

SETTINGS

2. Press

Driver Assistance

3. Press

Lane-Keeping System

4. Press

Lane-Keeping Mode

5. Select a setting.

Note:

The system remembers the last

setting when you start your vehicle.

ALERT MODE

WHAT IS ALERT MODE

Alert mode vibrates the steering wheel
when it detects an unintended lane
departure.

HOW DOES ALERT MODE WORK

E165515

When in alert mode, the lane keeping
system alerts you by vibrating the steering
wheel. The intensity of the vibration is set
through the lane keeping system menu.

ADJUSTING THE STEERING
WHEEL VIBRATION INTENSITY -
VEHICLES WITH: 12.3 INCH
SCREEN

To change the steering wheel vibration
intensity, use the touchscreen:

Press

Features

on the touchscreen.

2. Press

Driver Assistance

3. Press

Lane-Keeping System

4. Press

Lane-Keeping Intensity

5. Select an intensity setting.

ADJUSTING THE STEERING
WHEEL VIBRATION INTENSITY -
VEHICLES WITH: 15 INCH SCREEN

To change the steering wheel vibration
intensity, access the vehicle drawer on the
touchscreen:

Press

SETTINGS

2. Press

Driver Assistance

3. Press

Lane-Keeping System

4. Press

Lane-Keeping Intensity

295

Lane Keeping System

Ford Expedition (2022 year). Manual in english - page 17
