5. Select an intensity setting.

AID MODE

WHAT IS AID MODE

Aid mode provides temporary steering
assistance toward the center of the lane.

HOW DOES AID MODE WORK

E165516

The lane keeping system aids you when
an unintentional lane departure occurs.
The system provides a small steering input
to move the vehicle towards the center of
the lane.

ALERT AND AID MODE

WHAT IS ALERT AND AID MODE

Alert and aid mode uses multiple features
to keep you in your lane. The system first
provides a small steering input to bring
your vehicle back towards the center of
the lane. If your vehicle moves too far out
of the center of the lane the system alerts
you with vibration in the steering wheel.

HOW DOES ALERT AND AID MODE
WORK

E165517

Alert.

Aid.

The lane keeping system detects a lane
departure and provides aid when the
vehicles enters

and applies the

additional alert warning if

is entered.

LANE KEEPING SYSTEM
INDICATORS - VEHICLES
WITH: 8 INCH SCREEN

E355748

If you switch the lane keeping system on,
a graphic with lane markings appears in
the information display.

296

Lane Keeping System

When you switch the system off, the lane
marking graphics do not display.

Note:

The overhead vehicle graphic may

still display if adaptive cruise control is
enabled.

While the lane keeping system is on, the
color of the lane markings change to
indicate the system status.

Red

Yellow

Green

Gray

Indicates that the

system is providing

or has just provided
a lane keeping alert

warning.

Indicates that the

system is providing

or has just provided

a lane keeping aid

intervention.

Indicates that the

system is available

or ready to provide a

warning or interven-

tion on the indicated

side.

Indicates that the

system is tempor-

arily unavailable to

provide a warning or

intervention on the

indicated side.

297

Lane Keeping System

LANE KEEPING SYSTEM
INDICATORS - VEHICLES
WITH: 12.3 INCH SCREEN

E356730

If you switch the lane keeping system on,
a graphic with lane markings appears in
the information display.

When you switch the system off, the lane
marking graphics do not display.

Note:

The overhead vehicle graphic may

still display if adaptive cruise control is
enabled.

While the lane keeping system is on, the
color of the lane markings change to
indicate the system status.

Red

Yellow

Green

Gray

Indicates that the

system is providing

or has just provided
a lane keeping alert

warning.

Indicates that the

system is providing

or has just provided

a lane keeping aid

intervention.

Indicates that the

system is available

or ready to provide a

warning or interven-

tion on the indicated

side.

Indicates that the

system is tempor-

arily unavailable to

provide a warning or

intervention on the

indicated side.

BLIND SPOT ASSIST

WHAT IS BLIND SPOT ASSIST

Blind spot assist is an extension of the lane
keeping system.

It may help you identify adjacent vehicles
during a lane change.

Blind spot assist provides a blind spot
warning and steering assistance to help
during lane changes.

HOW DOES BLIND SPOT ASSIST
WORK

E334922

Activate and deactivate the
system using the lane keeping
system button on the steering

wheel.

During lane changes, the design of the
blind spot assist feature detects vehicles
in, or approaching, your blind spot and
provides a warning, plus steering
assistance to direct your vehicle back into
your lane.

298

Lane Keeping System

When active, this system functions with or
without the use of direction indicators and
hazard flashers.

You must keep your hands on the steering
wheel at all times.

BLIND SPOT ASSIST LIMITATIONS

All system limitations present in the basic
lane keeping system also apply to blind
spot assist.

Blind spot assist does not function under
the following conditions:

•

The system does not detect lane
markings.

•

One or both rear radar sensors become
blocked or faulty.

•

You attach a trailer with a wiring
connection to your vehicle.

Note:

Bike, cargo racks and attaching a

trailer could cause false alerts due to
obstruction of the sensor. We recommend
switching the feature off when using a bike,
cargo rack or when not using our trailer
wiring.

Blind spot assist may have difficulty
detecting hazards under the following
conditions:

•

If a vehicle is approaching in an
adjacent lane at a relative speed much
higher than your vehicle.

•

Bad weather conditions are present
that obstruct the sensors.

BLIND SPOT ASSIST INDICATORS

E310089

299

Lane Keeping System

The lane keeping aid warning lamp or
yellow lane marking in your instrument
cluster indicate blind spot assist activation.
In addition, the blind spot information

system alert indicator flashes on the
exterior mirror on the same side as the
detection. See

Blind Spot Information

System

(page 305).

Blind Spot Assist Information Messages

Details

Message

Displays if you attach a trailer to your vehicle.

Blind Spot Assist Not
Available Trailer
Attached

Displays if the blind spot information system sensors are
blocked.

Blind Spot Assist Not
Available Side Sensor
Blocked

The system has detected a fault that requires service. Have
your vehicle checked as soon as possible.

Blind Spot Assist System
fault

Lost communication with the trailer module. Blind Spot Assist
is suppressed until the failure is fixed.

Trailer Brake Module
Fault

Lost communication with the trailer module. Blind Spot Assist
is suppressed until the failure is fixed.

Trailer Lighting Module
Fault See Manual

Front Camera Fault. Blind Spot Assist is suppressed until the
failure is fixed.

Front Camera Fault
Service Required

See

Blind Spot Information System

(page 305).

BLIND SPOT ASSIST WITH
TRAILER COVERAGE

WHAT IS BLIND SPOT ASSIST
WITH TRAILER COVERAGE

Blind spot assist with trailer coverage is an
extension of the lane keeping system.

It may help you identify adjacent vehicles
during a lane change.

Blind spot assist provides a blind spot
warning and steering assistance to help
during lane changes.

When attaching a trailer, ensure you have
properly set up the trailer coverage
settings. See

Blind Spot Information

System With Trailer Coverage

(page

307).

HOW DOES BLIND SPOT ASSIST
WITH TRAILER COVERAGE WORK

E334922

Activate and deactivate the
system using the lane keeping
system button on the steering

wheel.

300

Lane Keeping System

If a supported trailer is connected, the
function is reduced to only detecting
vehicles on both sides of your vehicle and
trailer, extending rearward from the
exterior mirrors to the end of your trailer.
See

Blind Spot Information System

With Trailer Coverage

(page 307).

When active, this system functions with or
without the use of direction indicators and
hazard flashers.

You must keep your hands on the steering
wheel at all times.

BLIND SPOT ASSIST WITH
TRAILER COVERAGE
LIMITATIONS

All system limitations present in the basic
lane keeping system also apply to blind
spot assist.

Blind spot assist does not function under
the following conditions:

•

The system does not detect lane
markings.

•

One or both rear radar sensors become
blocked or faulty.

•

You have not configured the attached
trailer correctly in the trailer tow menus
or an unsupported trailer has been
attached. Only certain trailer shapes
and dimensions are supported. See

Blind Spot Information System
With Trailer Coverage Limitations

(page 307).

Note:

Blind spot assist with trailer coverage

could have reduced performance if you
attach a trailer to your vehicle.

Blind spot assist may have difficulty
detecting hazards under the following
conditions:

•

If a vehicle is approaching in an
adjacent lane at a relative speed much
higher than your vehicle.

•

Bad weather conditions are present
that obstruct the sensors.

•

Attaching bike or cargo racks could
cause false alerts due to obstruction
of the sensor.

BLIND SPOT ASSIST WITH
TRAILER COVERAGE INDICATORS

E310089

The lane keeping aid warning lamp or
yellow lane marking in your instrument
cluster indicate blind spot assist activation.
In addition, the blind spot information
system alert indicator flashes on the
exterior mirror on the same side as the
detection. See

Blind Spot Information

System

(page 305).

301

Lane Keeping System

Blind Spot Assist Information Messages

Action

Message

Displays if you attach a trailer to your vehicle with the blind
spot information system switched off or you have not
configured the trailer.

Blind Spot Assist Not
Available Trailer
Attached

Displays if you have blocked blind spot information system
sensors.

Blind Spot Assist Not
Available Side Sensor
Blocked

The system has detected a fault that requires service. Have
your vehicle checked as soon as possible.

Blind Spot Assist System
fault

Lost communication with the trailer module. Blind Spot Assist
is suppressed until the failure is fixed.

Trailer Brake Module
Fault

Lost communication with the trailer module. Blind Spot Assist
is suppressed until the failure is fixed.

Trailer Lighting Module
Fault See Manual

Front Camera Fault. Blind Spot Assist is suppressed until the
failure is fixed.

Front Camera Fault
Service Required

LANE KEEPING SYSTEM – TROUBLESHOOTING

LANE KEEPING SYSTEM – INFORMATION MESSAGES

Action

Message

The system has malfunctioned. Have your

vehicle checked as soon as possible.

Lane Keeping Sys. Malfunction Service

Required

The system has detected a condition that

has caused the system to be temporarily

unavailable.

Front Camera Temporarily Not Available

The system has detected a condition that

requires you to clean the windshield in order

for it to operate properly.

Front Camera Low Visibility Clean Screen

The system has malfunctioned. Have your

vehicle checked as soon as possible.

Front Camera Malfunction Service Required

The system requests that you keep your

hands on the steering wheel.

Keep Hands on Steering Wheel

302

Lane Keeping System

LANE KEEPING SYSTEM – FREQUENTLY ASKED QUESTIONS

Why is the feature not available (lane markings are gray) when I can see the lane markings

on the road?

Your vehicle speed is less than 40 mph (65 km/h).

The sun is shining directly into the camera lens.

A quick intentional lane change has occurred.

Your vehicle stays too close to the lane markings for an extended interval of time.

Driving at high speeds in curves.

The last alert warning or aid intervention occurred a short time ago.

Ambiguous lane markings, for example, in construction zones.

Rapid transition from light to dark, or from dark to light.

Sudden offset in lane markings.

ABS or AdvanceTrac™ is active.

There is a camera blockage due to dirt, grime, fog, frost or water on the windshield.

You are driving too close to the vehicle in front of you.

Transitioning between no lane markings to lane markings, or vice versa.

There is standing water on the road.

Faint lane markings, for example, partial yellow lane markings on concrete roads.

Lane width is too narrow or too wide.

You have not calibrated the camera after a windshield replacement.

Driving on tight or on uneven roads.

303

Lane Keeping System

WHAT IS BLIND SPOT
INFORMATION SYSTEM

Blind spot information system detects
vehicles that may have entered the blind
spot zone.

HOW DOES BLIND SPOT
INFORMATION SYSTEM WORK

Blind spot information system uses
sensors on both sides of your vehicle,
detecting rearward from the exterior
mirrors to approximately 13 ft (4 m)
beyond the rear bumper. The detection
area extends to approximately 59 ft (18 m)
beyond the rear bumper when the vehicle
speed is greater than 30 mph (48 km/h)
to alert you of faster approaching vehicles.

E255695

BLIND SPOT INFORMATION
SYSTEM PRECAUTIONS

WARNING:

Do not use the blind

spot information system as a
replacement for using the interior and
exterior mirrors or looking over your
shoulder before changing lanes. The
blind spot information system is not a
replacement for careful driving.

WARNING:

The system may not

operate properly during severe weather
conditions, for example snow, ice, heavy
rain and spray. Always drive with due
care and attention. Failure to take care
may result in a crash.

Note:

Blind spot information system does

not prevent contact with other vehicles. It
does not detect parked vehicles,
pedestrians, animals or other infrastructure.

BLIND SPOT INFORMATION
SYSTEM LIMITATIONS

Blind spot information system does not
operate in park (P) or reverse (R).

The system may not alert you if a vehicle
quickly passes through the detection zone.

BLIND SPOT INFORMATION
SYSTEM REQUIREMENTS

Blind spot information system turns on
when all the following occur:
•

You start your vehicle.

•

You shift into drive (D).

•

The vehicle speed is greater than
6 mph (10 km/h).

SWITCHING BLIND SPOT
INFORMATION SYSTEM ON
AND OFF - VEHICLES WITH:
12.3 INCH SCREEN

To switch blind spot information system
on or off, use the touchscreen:

Press

Features

on the touchscreen.

2. Press

Driver Assistance

3. Press

Blind Spot Information System

305

Blind Spot Information System

4. Switch the feature on or off.

When you switch blind spot information
system off, a warning lamp illuminates and
a message displays. When you switch the
system on or off, the alert indicators flash
twice.

Note:

The system remembers the last

setting when you start your vehicle.

To permanently switch the system off,
contact an authorized dealer.

SWITCHING BLIND SPOT
INFORMATION SYSTEM ON
AND OFF - VEHICLES WITH: 15
INCH SCREEN

To switch blind spot information system
on or off, use the touchscreen:

Access the vehicle drawer.

2. Press

SETTINGS

3. Press

Driver Assistance

4. Switch

Blind Spot Information

System

on or off.

When you switch blind spot information
system off, a warning lamp illuminates and
a message displays. When you switch the
system on or off, the alert indicators flash
twice.

Note:

The system remembers the last

setting when you start your vehicle.

To permanently switch the system off,
contact an authorized dealer.

LOCATING THE BLIND SPOT
INFORMATION SYSTEM
SENSORS

E205199

The sensors are behind the rear fascia on
both sides of your vehicle.

Note:

Keep the sensors free from snow, ice

and large accumulations of dirt.

Note:

Do not cover the sensors with bumper

stickers, repair compound or other objects.

Note:

Bike and cargo racks could cause

false alerts due to obstruction of the sensor.
We recommend switching the feature off
when using a bike or cargo rack.

Note:

Blocked sensors may affect system

accuracy.

If the sensors become blocked, a message
appears in the instrument cluster display.
See

Blind Spot Information System –

Information Messages

(page 309). The

alert indicators illuminate but the system
does not alert you.

306

Blind Spot Information System

BLIND SPOT INFORMATION
SYSTEM WITH TRAILER
COVERAGE

WHAT IS BLIND SPOT
INFORMATION SYSTEM WITH
TRAILER COVERAGE

E225007

Blind spot information system detects
vehicles that may have entered the blind
spot zone. The detection area is on both
sides your vehicle and trailer, extending
rearward from the exterior mirrors to the
end of your trailer.

BLIND SPOT INFORMATION
SYSTEM WITH TRAILER
COVERAGE LIMITATIONS

Trailer coverage only supports
conventional trailers. The system turns off
if you select a fifth wheel trailer type.

Make sure the trailer width is less than or
equal to 8.5 ft (2.6 m) and the length is
less than 33 ft (10.1 m). If you input values
higher, the system turns off.

Some trailers could cause a slight change
in system performance:
•

Large box trailers could cause false
alerts to occur when driving next to
infrastructures or near parked cars. A
false alert could also occur while
making a 90-degree turn.

•

Trailers that have a width greater than
8.5 ft (2.6 m) at the front and have a
total length greater than 20 ft (6 m)
could cause delayed alerts when a
vehicle is passing at high speeds.

•

Box trailers that have a width greater
than 8.5 ft (2.6 m) at the front could
cause early alerts when you pass a
vehicle.

•

Clam shell or v-nose box trailers with
a width greater than 8.5 ft (2.6 m) at
the front could cause delayed alerts
when a vehicle traveling the same
speed as your vehicle merges lanes.

SETTING A TRAILER LENGTH

E225008

Trailer length.

Trailer width.

Trailer hitch ball.

You can set-up a trailer to work with the
blind spot information system through the
touchscreen. When setting up a trailer, a
sequence of screens appear asking for
trailer information.

Select type of trailer screen -
conventional, fifth wheel or gooseneck.

307

Blind Spot Information System

Note:

The system only supports

conventional trailers.

2. Do you want to set up blind spot with

trailer screen? If no, the system turns
off. If yes, the menu goes to the next
screen.

3. Is the width less than 9 ft (2.7 m) and

length less than 33 ft (10.1 m)? If no,
the system turns off. If yes, the menu
goes to the next screen.

4. Trailer width measurement. Measure

the width at the front of the trailer. It is
not measured at the widest point of
the trailer. The maximum width at the
front of the trailer the system can
support is 8.5 ft (2.6 m).

Note:

You do not need to enter an exact

trailer width measurement. You only need
to confirm that the width of the trailer is less
than 9 ft (2.7 m).

5. Trailer length measurement. The trailer

length is the distance between the
trailer hitch ball and the rear of the
trailer. The maximum length that the
system can support is 33 ft (10.1 m).

6. Enter the length of trailer. The default

setting is 18 ft (5.5 m). Toggling up or
down using the menu buttons
increases or decreases the
measurement by 3 ft (1 m). Select a
length that is equal to or within 3 ft
(1 m) of the actual measured length.
For example, if the actual measure
length is 25 ft (7.5 m), toggle the length
in the menu to 27 ft (8.2 m). The
system setup saves when you enter the
length of the trailer.

Note:

If the trailer is a bike rack or cargo

rack with electrical lighting, enter a length
of 3 ft (1 m). Cross traffic alert remains on
for trailers with a length of 3 ft (1 m) or less.

Note:

The system requires proper

measurement and measure entry to function
properly.

SELECTING A TRAILER

When you connect a trailer to your vehicle,
the trailer set up menu appears in the
touchscreen. This menu allows you to set
up a new trailer or choose from a
previously set up trailer. A warning
message appears and the system turns off
if you do not choose or add a new trailer.

Note:

The warning message may not

appear until your vehicle reaches 22 mph
(35 km/h).

BLIND SPOT INFORMATION
SYSTEM INDICATORS

E309137

E249861

When blind spot information
system detects a vehicle, an
alert indicator illuminates in the

exterior mirror on the side the approaching
vehicle is coming from. If you turn the turn
signal on for that side of your vehicle, the
alert indicator flashes.

308

Blind Spot Information System

BLIND SPOT INFORMATION SYSTEM – TROUBLESHOOTING

BLIND SPOT INFORMATION SYSTEM – INFORMATION MESSAGES

Action

Message

A fault with the system has occurred. Have

your vehicle checked as soon as possible.

Blind Spot System Fault

Something is blocking the sensors. Clean

the sensors.

Blind Spot Not Available Sensor Blocked

See Manual

The system automatically turns off and

displays this message when you connect a

trailer to the vehicle that does not have a

trailer blind spot system or when you switch
the trailer blind spot system off through the

touchscreen.

Blind Spot Alert Deactivated Trailer

Attached

309

Blind Spot Information System

WHAT IS CROSS TRAFFIC
ALERT

The system alerts you of vehicles
approaching from the sides behind your
vehicle when you shift into reverse (R).

HOW DOES CROSS TRAFFIC
ALERT WORK

Cross traffic alert detects vehicles that
approach at a speed between 4–37 mph
(6–60 km/h). Coverage decreases when
the sensors are partially, mostly or fully
obstructed.

E142440

The sensor on the left-hand side is only
partially obstructed and zone coverage on
the right-hand side is maximized.

E142441

Zone coverage also decreases when
parking at narrow angles. The sensor on
the left-hand side is mostly obstructed and
zone coverage on that side is severely
reduced.

Note:

Slowly reversing helps increase the

coverage area and effectiveness.

CROSS TRAFFIC ALERT
PRECAUTIONS

WARNING:

Do not use the cross

traffic alert system as a replacement for
using the interior and exterior mirrors or
looking over your shoulder before
reversing out of a parking space. The
cross traffic alert system is not a
replacement for careful driving.

WARNING:

The system may not

operate properly during severe weather
conditions, for example snow, ice, heavy
rain and spray. Always drive with due
care and attention. Failure to take care
may result in a crash.

CROSS TRAFFIC ALERT
LIMITATIONS

The system may not correctly operate
when any of the following occur:
•

Something is blocking the sensors.

•

Adjacently parked vehicles or objects
are obstructing the sensors.

•

Vehicles approach at speeds less than
4 mph (6 km/h) or greater than 37 mph
(60 km/h).

•

Your vehicle speed is greater than
7 mph (12 km/h).

•

You reverse out of an angled parking
space.

310

Cross Traffic Alert

Cross Traffic Alert Limitations
with a Trailer Attached

The system remains on when you attach
a trailer in vehicles with blind spot
information system with trailer tow under
the following conditions:
•

You connect a trailer.

•

The trailer is a bike rack or cargo rack
with a maximum length of 3 ft (1 m).

•

You set the trailer length to 3 ft (1 m)
in the instrument cluster display.

Note:

The system may not correctly operate

when towing a trailer. For vehicles with an
approved trailer tow module and tow bar,
the system turns off when you attach a
trailer. For vehicles with an aftermarket
trailer tow module or tow bar, we
recommend that you switch the system off
when you attach a trailer.

SWITCHING CROSS TRAFFIC
ALERT ON AND OFF -
VEHICLES WITH: 12.3 INCH
SCREEN

To switch cross traffic alert on or off use
the touchscreen.

Press

Features

on the touchscreen.

2. Press

Driver Assistance

3. Switch

Cross Traffic Alert

on or off.

Note:

The system switches on every time

you switch the ignition on. To permanently
switch the system off, contact an authorized
dealer.

SWITCHING CROSS TRAFFIC
ALERT ON AND OFF -
VEHICLES WITH: 15 INCH
SCREEN

To switch cross traffic alert on or off use
the touchscreen:

Access the vehicle drawer.

2. Press

SETTINGS

3. Press

Driver Assistance

4. Switch

Cross Traffic Alert

on or off.

When you switch the system on or off, the
alert indicators flash twice.

Note:

The system turns on every time you

start your vehicle. To permanently switch
the system off, contact an authorized
dealer.

LOCATING THE CROSS
TRAFFIC ALERT SENSORS

E205199

The sensors are behind the rear fascia on
both sides of your vehicle.

Note:

Keep the sensors free from snow, ice

and large accumulations of dirt.

Note:

Do not cover the sensors with bumper

stickers, repair compound or other objects.

Note:

Blocked sensors may affect system

accuracy.

311

Cross Traffic Alert

Ford Expedition (2022 year). Manual in english - page 18
