Ford F-150 (2022 year). Manual in english

WHAT IS THE REAR
OCCUPANT ALERT SYSTEM

The rear occupant alert system monitors
vehicle conditions and notifies you to check
for rear seat occupants when you switch
the ignition off.

HOW DOES THE REAR
OCCUPANT ALERT SYSTEM
WORK

The system monitors when rear doors have
been opened and closed to indicate the
potential presence of an occupant in the
rear seat.

A message displays in the information and
entertainment display screen and an
audible warning sounds when you switch
the ignition off after any of the following
conditions have been met:
•

A rear door is opened or closed while
the ignition is on.

•

You switch the ignition on within 15
minutes of a rear door opening and
closing.

•

You switch the ignition on within 15
minutes of the alert having displayed
or sounded.

REAR OCCUPANT ALERT
SYSTEM PRECAUTIONS

WARNING:

On hot days, the

temperature inside the vehicle can rise
very quickly. Exposure of people or
animals to these high temperatures for
even a short time can cause death or
serious heat related injuries, including
brain damage. Small children are
particularly at risk.

WARNING:

Do not leave children

or pets unattended in your vehicle.
Failure to follow this instruction could
result in personal injury or death.

REAR OCCUPANT ALERT
SYSTEM LIMITATIONS

The system does not detect the presence
of objects or passengers in the rear seat.
It monitors when rear doors are opened
and closed.

Note:

It is possible to receive an alert when

there is no rear seat occupant, but alert
conditions are met.

Note:

It is possible to receive no alert when

there is an occupant in the rear seat, if alert
conditions are not met. For example, if a rear
seat occupant does not enter the vehicle
through a rear door.

Note:

The audible warning does not sound

when the front door is opened before you
switch the ignition off.

SWITCHING REAR OCCUPANT
ALERT SYSTEM ON AND OFF

Press

Settings

on the touchscreen.

2. Press

Vehicle

3. Switch

Rear Occupant Alert

on or off.

Note:

The default setting is on.

Note:

Performing a master reset causes the

system to switch on again.

Semiannual Reminder

(If Equipped)

When you switch the system off, a
message appears every six months as a
reminder that the system is off. You can
switch the system back on or leave it off.

202

Rear Occupant Alert System

(If Equipped)

REAR OCCUPANT ALERT
SYSTEM INDICATORS

E350472

Message

Check rear seats for occupants.

Displays when you switch your vehicle off
after the alert conditions are met.

The message displays for a short period of
time. Press

Close

to acknowledge and

remove the message.

Note:

Depending on your SYNC version, the

graphic may look different from what you
see here.

REAR OCCUPANT ALERT
SYSTEM AUDIBLE WARNINGS

Sounds when you switch your vehicle off
after the alert conditions are met.

The warning sounds for a short period of
time.

203

Rear Occupant Alert System

(If Equipped)

WHAT IS THE MEMORY
FUNCTION

The memory function recalls the position
of these features:

•

Driver seat.

•

Power mirrors.

•

Optional power steering column.

•

Optional power adjustable pedals.

MEMORY FUNCTION
PRECAUTIONS

WARNING:

Before activating the

memory seat, make sure that the area
immediately surrounding the seat is clear
of obstructions and that all occupants
are clear of moving parts.

WARNING:

Do not use the memory

function when your vehicle is moving.

LOCATING THE MEMORY
FUNCTION BUTTONS

E332006

The memory function buttons are on the
driver door.

SAVING A PRESET POSITION

Adjust the memory features to your
preferred position.

2. Press and hold the preferred preset

button until you hear a single tone.

A confirmation message appears in the
information display.

You can save up to three preset memory
positions at any time.

RECALLING A PRESET
POSITION

Press and release a preset button.

Note:

You can recall a preset memory

position when the ignition is off, or when you
place the transmission in park (P) or neutral
(N) if the ignition is on and the vehicle is not
moving.

Note:

Pressing any of the preset buttons or

any memory feature control during a
memory recall cancels the operation.

You can also recall a preset memory
position by:
•

Pressing the unlock button on your
remote control if you linked it to a
preset position.

•

Unlocking the intelligent driver door
handle if a linked remote control is
present.

Using a linked remote control to recall your
memory position when the ignition is off
moves the seat and steering column to the
easy entry position.

Linking a Preset Position to Your
Remote Control or Passive Key

See

Linking or Unlinking a Personal

Profile to a Remote Control

(page 629).

204

Memory Function

(If Equipped)

WHAT IS THE GARAGE DOOR
OPENER

HomeLink Wireless Control
System

E188211

The universal garage door opener replaces
the common hand-held garage door
opener with a three-button transmitter
integrated into the driver’s sun visor.

HOW DOES THE GARAGE
DOOR OPENER WORK

The system includes two primary features,
a garage door opener and a platform for
remote activation of devices within the
home. You can program garage doors as
well as entry gate operators, security
systems, entry door locks and home or
office lighting.

Additional system information can be
found online at www.homelink.com or by
calling the toll-free help line at
1-800-355-3515.

Note:

You can program a maximum of

three devices. To change or replace any of
the three devices after it has been initially
programmed, you must first erase the
current settings. See

Clearing the Garage

Door Opener

(page 207).

GARAGE DOOR OPENER
PRECAUTIONS

WARNING:

Do not use the system

with any garage door opener that does
not have the safety stop and reverse
feature as required by U.S. Federal
Safety Standards (this includes any
garage door opener manufactured
before April 1, 1982). A garage door
opener which cannot detect an object,
signaling the door to stop and reverse,
does not meet current federal safety
standards. Using a garage door opener
without these features increases the risk
of serious injury or death.

Note:

Make sure that the garage door and

security device are free from obstruction
when you are programming. Do not program
the system with your vehicle in the garage.

Note:

Make sure you keep the original

remote control transmitter for use in other
vehicles as well as for future system
programming.

Note:

We recommend that upon the sale

or lease termination of your vehicle, you
erase the programmed function buttons for
security reasons. See

Clearing the Garage

Door Opener

(page 207).

GARAGE DOOR OPENER
LIMITATIONS

Canadian radio-frequency laws require
transmitter signals to time-out (or quit)
after several seconds – which may not be
long enough for HomeLink to pick up the
signal.

U.S. gate operators time-out in the same
manner.

205

Garage Door Opener

(If Equipped)

Note:

If programming a garage door opener

or gate operator, it is advised to unplug the
device during the “cycling” process to
prevent possible overheating.

PROGRAMMING THE GARAGE
DOOR OPENER TO YOUR
HAND-HELD TRANSMITTER

This process is to program your in-vehicle
HomeLink function button with your
hand-held transmitter.

Note:

The programming steps below

assume you will be programming HomeLink
that was not previously programmed. If your
HomeLink was previously programmed, you
may need to erase your HomeLink buttons.
See

Clearing the Garage Door Opener

(page 207).

E188212

With your vehicle parked outside of the
garage, switch your ignition to the on
position, but do not start your vehicle.

2. Press and release one of the three

HomeLink function buttons that you
would like to program.

3. Hold your hand-held garage door

transmitter 1–3 in (2–8 cm) away from
the HomeLink button you want to
program.

4. Press and hold the hand-held

transmitter button you want to
program while watching the indicator
light on HomeLink. Continue to hold
the hand-held button until the
HomeLink indicator light flashes rapidly
or is continuously on.

Note:

You may need to use a different

method if you live in Canada or have
difficulties programming your gate operator
or garage door opener. See

Programming

the Garage Door Opener to Your Gate
Opener Motor

(page 207).

5. Press and hold the HomeLink button

you programmed for two seconds, then
release. You may need to do this twice
to activate the door.

Note:

If the indicator light stays on, the

programming is complete.

Note:

If the HomeLink indicator flashes

rapidly, repeat step 5.

Note:

If your device still does not operate,

you must program your garage door. See

Programming the Garage Door Opener to
Your Garage Door Opener Motor

(page

206).

6. To program additional buttons, repeat

Steps 1 – 4.

PROGRAMMING THE GARAGE
DOOR OPENER TO YOUR
GARAGE DOOR OPENER
MOTOR

E142659

206

Garage Door Opener

(If Equipped)

Press the learn button on the garage
door opener motor, you have 30
seconds to complete the next two
steps.

2. Return to your vehicle.

E188212

3. Press and hold one of the three

HomeLink function buttons you want
to program for two seconds, then
release. Repeat this step. Depending
on your brand of garage door opener,
you may need to repeat this sequence
a third time.

PROGRAMMING THE GARAGE
DOOR OPENER TO YOUR GATE
OPENER MOTOR

Gate Operator / Canadian
Programming

Canadian radio-frequency laws require
transmitter signals to “time-out” (or quit)
after several seconds of transmission –
which may not be long enough for
HomeLink to pick up the signal during
programming. Similar to this Canadian law,
some U.S. gate operators “time-out” in the
same manner.

Note:

If programming a garage door opener

or gate operator, it is advised to unplug the
device during the “cycling” process to
prevent possible overheating.

Press and release, every two seconds,
your hand-held transmitter until the
HomeLink indicator light changes to a
rapidly blinking or continuously on light.

2. Release the hand-held transmitter

button.

3. Press and hold the HomeLink function

button you want to program for two
seconds, then release. You may need
to do this twice to activate the door.

Note:

If the indicator light stays on, the

programming is complete.

Note:

If the HomeLink indicator flashes

rapidly, repeat Step 3.

Note:

If your device still does not operate,

you must program your garage door. See

Programming the Garage Door Opener to
Your Garage Door Opener Motor

(page

206).

4. To program additional buttons, repeat

Steps 1 – 4.

CLEARING THE GARAGE DOOR
OPENER

E188213

Press and hold the outer two function
buttons simultaneously for
approximately 10 seconds until the
indicator light above the buttons
flashes rapidly.

207

Garage Door Opener

(If Equipped)

2. When the indicator light flashes,

release the buttons.

Note:

You cannot erase individual buttons.

REPROGRAMMING THE
GARAGE DOOR OPENER

To program a device to a previously trained
button, follow these steps:

Press and hold the desired button. Do
NOT release the button.

2. The indicator light begins to flash after

20 seconds. Without releasing the
button, follow programming steps.

GARAGE DOOR OPENER
RADIO FREQUENCIES

FCC and RSS-210 Industry Canada
Compliance

WARNING:

Changes or

modifications not expressively approved
by the party responsible for compliance
could void the user's authority to operate
the equipment. The term "IC:" before the
radio certification number only signifies
that Industry Canada technical
specifications were met.

This device complies with Part 15 of the
FCC Rules and with RSS-210 of Industry
Canada. Operation is subject to the
following two conditions: (1) this device
may not cause harmful interference, and
(2) this device must accept any
interference received, including
interference that could cause undesired
operation.

This equipment complies with FCC
radiation exposure limits set forth for an
uncontrolled environment. End Users must
follow the specific operating instructions
for satisfying RF exposure compliance. This
transmitter must be at least 8 in (20 cm)
from the user and must not be co-located
or operating in conjunction with any other
antenna or transmitter.

208

Garage Door Opener

(If Equipped)

LOCATING THE USB PORTS

Data Transfer USB Ports

The USB ports could be in the following
locations:

•

On the lower instrument panel below
the climate control.

•

Inside the center console.

Note:

These USB ports can also charge

devices.

Note:

Not all USB ports in your vehicle have

data transfer capabilities.

Note:

We recommend using only USB-IF

certified cables and adapters. Non-certified
cables and adapters may not work.

Charge Only USB Ports

The USB ports could be in the following
locations:

•

On the lower instrument panel.

•

On the upper instrument panel.

•

Inside the media bin.

•

Inside the center console.

•

On the rear of the center console.

•

In the cargo area.

LOCATING THE USB PORTS -
RAPTOR

Data Transfer USB Ports

The USB Ports could be in the following
locations:

•

Inside the media bin.

•

Inside the center console.

Note:

These USB ports can also charge

devices.

Note:

Not all USB ports in your vehicle have

data transfer capabilities.

Note:

We recommend using only USB-IF

certified cables and adapters. Non-certified
cables and adapters may not work.

Charge Only USB Ports

The USB ports could be in the following
locations:

•

On the lower instrument panel.

•

On the upper instrument panel.

•

Inside the media bin.

•

Inside the center console.

•

On the rear of the center console.

•

In the cargo area.

PLAYING MEDIA USING THE
USB PORT

WARNING:

Driving while distracted

can result in loss of vehicle control, crash
and injury. We strongly recommend that
you use extreme caution when using any
device that may take your focus off the
road. Your primary responsibility is the
safe operation of your vehicle. We
recommend against the use of any
hand-held device while driving and
encourage the use of voice-operated
systems when possible. Make sure you
are aware of all applicable local laws
that may affect the use of electronic
devices while driving.

209

USB Ports

Connect your device to the USB port.

E100027

Press the audio button on the
feature bar.

Select

Sources

Select the USB option.

Press the button to play a track.
Press the button again to pause
the track.

Press the button to skip to the
next track.

Press and hold the button to fast

forward through the track.

Press the button once to return
to the beginning of a track.
Repeatedly press the button to

return to previous tracks.

Press and hold the button to fast rewind.

CHARGING A DEVICE

Connect your device to the USB port.

Data Transfer USB Ports

You can charge your device through the
data transfer USB port when SYNC is on.

Charge Only USB Ports

You can charge your device through the
charge only USB port when the vehicle is
in accessory mode or when the vehicle is
running.

210

USB Ports

WHAT IS THE POWER OUTLET

The vehicle functions as a portable
generator and can power devices that
require up to the rating listed on power
outlet label.

POWER OUTLET
PRECAUTIONS - VEHICLES
WITH: 2KW

WARNING:

Do not start the engine

in a closed garage or in other enclosed
areas. Exhaust fumes are toxic. Always
open the garage door before you start
the engine. Failure to follow this
instruction could result in personal injury
or death.

WARNING:

Exhaust leaks may

result in entry of harmful and potentially
lethal fumes into the passenger
compartment. If you smell exhaust
fumes inside your vehicle, have your
vehicle inspected immediately. Do not
drive if you smell exhaust fumes.

WARNING:

Do not connect any

vehicle power outlets to any premises.
This can create a backfeed to utility lines.
Failure to follow this instruction could
result in property damage, fire, electrical
shock or death.

WARNING:

The vehicle's engine

runs while the generator is switched on.
Running engines emit carbon monoxide.
Only use the generator when the vehicle
is outdoors. Failure to follow this
instruction could result in personal injury
or death.

Note:

Automatic engine stop is disabled

and the gasoline engine will continue to idle
when the outlet is switched on.

Note:

We recommend using UL approved

devices for use with the power outlet.

Note:

Unplug electrical devices from the

power outlet when they are not switched
on.

Note:

Make sure there is no damage to the

outlets before driving your vehicle.

Note:

Make sure that objects are not

blocking the inverter inlet and exhaust near
the rear underseat storage compartment.

Note:

The climate control system may turn

on and power may be limited during extreme
hot or cold temperatures to optimize the
performance of the system.

Note:

When the outlet is switched on and

the vehicle is in Park (P) the engine turns
off 30 minutes after the low fuel warning is
displayed. After the vehicle is turned off,
generator mode only operates while driving
or until the vehicle is refueled.

211

Power Outlet - Vehicles With: Pickup Bed Power Generator

Outlet

Grounding Types

Grounding Type

Vehicle Type

Neutral floating: The neutral of the inverter

generator is isolated from system ground.

Gas

Neutral bonded: The neutral of the inverter

generator is bonded to system ground.

Connecting loads that also have neutral
bonded to ground will cause the ground

fault detection to trip.

HEV

Note:

If additional grounding measures are

required, consult with a qualified electrician.

POWER OUTLET
PRECAUTIONS - VEHICLES
WITH: 2.4KW/7.2KW

WARNING:

Do not start the engine

WARNING:

Exhaust leaks may

WARNING:

Do not connect any

vehicle power outlets to any premises,
including buildings or recreational
vehicles. This can create a backfeed to
utility lines. Failure to follow this
instruction could result in damage to the
vehicle, fire, electrical shock or death.

WARNING:

The vehicle's engine

Note:

The gasoline engine may start and

stop to provide power when the outlet is
switched on.

Note:

We recommend using UL approved

devices for use with the power outlet.

Note:

Unplug electrical devices from the

power outlet when they are not switched
on.

Note:

The climate control system may turn

on and power may be limited during extreme
hot or cold temperatures to optimize the
performance of the system.

Note:

When the outlet is switched on and

212

Power Outlet - Vehicles With: Pickup Bed Power Generator

Outlet

Grounding Types

Grounding Type

Vehicle Type

Neutral floating: The neutral of the inverter

generator is isolated from system ground.

Gas

Neutral bonded: The neutral of the inverter

generator is bonded to system ground.

Connecting loads that also have neutral
bonded to ground will cause the ground

fault detection to trip.

HEV

Note:

If additional grounding measures are

required, consult with a qualified electrician.

LOCATING THE POWER
OUTLETS

E335065

The power outlets are behind covers on
the left side of the bed.

POWER OUTLET INDICATORS
- VEHICLES WITH: 2KW

Power Outlet Status Indicator

The power outlet indicator illuminates to
let you know the status of the system.

Description

Indicator Status

The power point is

working and the

vehicle is on.

The power point is

off or the vehicle is

off.

Off

The power point is

in fault mode.

Flashing

Generator Mode Power Indicator

E335469

213

Power Outlet - Vehicles With: Pickup Bed Power Generator

Outlet

The generator mode power indicator
displays the currently used power and total
available power level on the touchscreen.
When Generator Mode is switched off the
indicator displays a reduced available
power level. When generator mode is
switched on the indicator displays the full
available power.

Note:

Ensure plugged in devices do not

exceed the available power displayed on
the generator mode power indicator.

Note:

Maximum power may be reduced

when the vehicle is in drive (D).

POWER OUTLET INDICATORS
- VEHICLES WITH: 2.4KW/
7.2KW

Power Outlet Status Indicator

The power outlet indicator illuminates to
let you know the status of the system.

Description

Indicator Status

The power point is

working and the

vehicle is on.

The power point is
off and the vehicle

is off.

Off

The power point is

in fault mode.

Flashing

Generator Mode Power Indicator

E335469

Note:

Additional indicators may be

available based on vehicle configuration.

Note:

Ensure plugged in devices do not

exceed the available power displayed on
the generator mode power indicator.

WHAT IS UTILITY IDLE MODE -
VEHICLES WITH: FLIP KEY

Utility Idle mode allows you to remove the
key from the ignition and keep the vehicle
and bed power point running.

SWITCHING UTILITY IDLE ON
AND OFF - VEHICLES WITH:
FLIP KEY

Switching Utility Idle On

Start the vehicle. See

Starting and

Stopping the Engine

(page 231).

214

Power Outlet - Vehicles With: Pickup Bed Power Generator

Outlet

2. Press the Features button on the

touchscreen.

3. Press the Pro Power Onboard button.

4. Press the Generator Mode button to

switch the power outlet to the rating
listed on the power outlet label.

5. Press the Utility Idle button.

6. Turn the key to position

Remove the key from the ignition.

Switching Utility Idle Off using the
Key

Insert the key into the ignition.

2. Turn the key to position

III

Switching Utility Idle off using the
Information and Entertainment
Display Screen

Use the controls on the touchscreen to
switch off the vehicle.

WHAT IS GENERATOR MODE

Generator Mode uses the vehicle engine
to increase power to the bed power outlets
up to the rating listed on the power outlet
label.

SWITCHING GENERATOR
MODE ON AND OFF

Using the Information and
Entertainment Display Screen

Switch the vehicle on. See

Starting

and Stopping the Engine

(page 231).

2. Press the Features button on the

touchscreen.

3. Press the Pro Power Onboard button.

4. Press the Generator Mode button to

switch the power outlet to the full
rating listed on the power outlet label.

Using the Instrument Panel

E311311

Press the button to switch
between off, Convenience Mode,
and Generator Mode.

Using the Bed Control

E337175

Press the button to switch Generator Mode
on and off.

RESETTING GROUND FAULT
DETECTION

After disconnecting all electrical loads the
ground fault can be reset using the
switches on the power point, on the
instrument panel or on the touchscreen.

Use the controls on the touchscreen to test
the ground fault detection circuit.

215

Power Outlet - Vehicles With: Pickup Bed Power Generator

Outlet

Ford F-150 (2022 year). Manual in english - page 12
