INFORMATION MESSAGES

Note:

Depending on your vehicle options

and instrument cluster type, not all of the
messages display or are available. The
system abbreviates certain messages
depending upon which cluster type you
have.

E222314

Press the

button to acknowledge and

remove some messages from the
information display. Other messages will
be automatically removed after a short
time.

Certain messages need to be confirmed
before you can access the menus.

AWD

Action

Message

The all wheel drive system has automatically disabled itself due to

the system overheating.

AWD Temporarily

Disabled

The all wheel drive system is locking up the torque transfer clutch

to help reduce clutch temperature.

AWD Temporarily

Locked

Displays when the system automatically disables to protect itself.

This could be caused by operating your vehicle with a mini spare

tire installed, if the system detects dissimilar size tires, or if there is

an issue with another vehicle system preventing AWD operation.

The system resumes normal operation and clears this message

after you cycle the ignition on and off and drive a short distance

with the road tire re-installed or after the other vehicle system issues

are resolved.

AWD OFF

Displays after the system cools and the all wheel drive system

resumes normal function.

AWD Restored

Information Displays

Action

Message

The all wheel drive system is not properly operating and the

powertrain fault indicator illuminates. If the warning stays illumin-

ated or continues to illuminate, have the system checked as soon

as possible.

AWD Fault Service

Required

Displayed when the transfer case fluid requires service.

Change AWD

Power Transfer

Unit Lube

Displayed when the transfer case fluid has been changed and reset

to new.

AWD Power

Transfer Unit Lube

Set to New

AdvanceTrac™ and Traction Control

Action

Message

The system detects a condition that requires service. Have the

system checked as soon as possible.

Service Advan-

ceTrac

The status of the AdvanceTrac system after you switch it off.

AdvanceTrac Off

The status of the AdvanceTrac system after you switch it on.

AdvanceTrac On

The system is off while your vehicle is in 4x4 low.

AdvanceTrac OFF

in 4x4 LOW

The status of the AdvanceTrac sport mode after you switch it on.

AdvanceTrac

SPORT MODE

The status of the traction control system after you switch it off.

Traction Control

Off

The status of the traction control system after you switch it on.

Traction Control

Alarm

Action

Message

Alarm triggered due to unauthorized entry. See

Anti-Theft Alarm

(page 63).

Vehicle Alarm To

Stop Alarm, Start

Vehicle.

Information Displays

Battery and Charging System

Action

Message

The charging system needs servicing. If the warning stays on or

continues to come on, have the system checked as soon as possible.

Check Charging

System

The charging system needs servicing. If the warning stays on or

continues to come on have the system checked as soon as possible.

Charging System

Service Soon

The charging system needs servicing. Have the system checked as

soon as possible.

Charging System

Service Now

The battery management system determines that the 12V battery

is at a low state of charge. Start the engine to charge the battery

or charge the battery using an aftermarket battery charger. This

message clears once you restart your vehicle and the battery state

of charge has recovered.

Battery State of

Charge Low

The battery management system determines that the battery is at

a low state of charge. Turn the ignition off as soon as possible to

protect the battery. This message will clear once your vehicle has

been started and the battery state of charge has recovered. Turning

off unnecessary electrical loads will allow faster battery state-of-

charge recovery.

Turn Power Off To

Save Battery

Displays when the battery management system detects an

extended low-voltage condition. Various vehicle features will be

disabled to help preserve the battery. Turn off as many of the

electrical loads as soon as possible to improve system voltage. If

the system voltage has recovered, the disabled features will operate

again as normal.

Low Battery

Features Tempor-

arily Turned Off

Blind Spot Information and Cross Traffic Alert System

Action

Message

A system error has occurred. Have the system checked as soon as

possible.

Blind Spot System

Fault

The system sensors are blocked. See

Blind Spot Information

System

(page 166).

Blind Spot Not

Available Sensor

Blocked See

Manual

The system detects a vehicle and automatically applied the brakes.

Cross Traffic Alert

Applying Brakes

Information Displays

Action

Message

The blind spot information system and cross traffic alert system

sensors are blocked. See

Cross Traffic Alert

(page 169).

Cross Traffic Not
Available Sensor

Blocked See

Manual

A system error has occurred. Have the system checked as soon as

possible.

Cross Traffic

System Fault

The system automatically turns off and displays this message when

you connect a trailer to your vehicle that does not have a trailer

blind spot system or when you switch the trailer blind spot system
off through the information display. See

Cross Traffic Alert

(page

169).

Cross Traffic Alert

Deactivated Trailer

Attached

The system automatically turns off and displays this message when

you connect a trailer to your vehicle that does not have a trailer

blind spot system or when you switch the trailer blind spot system
off through the information display. See

Blind Spot Information

System

(page 166).

Blind Spot Alert

Deactivated Trailer

Attached

Doors and Locks

Action

Message

The driver door is not completely closed.

Driver Door Ajar

The passenger door is not completely closed.

Passenger Door

Ajar

The rear left door is not completely closed.

Rear Left Door Ajar

The rear right door is not completely closed.

Rear Right Door

Ajar

The liftgate is not completely closed.

Liftgate Ajar

The hood is not completely closed.

Hood Ajar

The system has disabled the door switches.

Switches Inhibited

Security Mode

Displays when the door lock is turned on and you attempt to open

the door.

Doors Locked

Unlock Before

Opening

Information Displays

Action

Message

Indicates a driver door fault that requires manually opening the
door by the override lever. Have the system checked as soon as

possible.

Driver Door Fault

Use Inside Over-

ride Lever In Map

Pocket

Indicates a fault with the electronic door system. Have the system

checked as soon as possible.

Door Fault Service

Required

There is a system malfunction with the child locks. Have the system

checked as soon as possible.

Child Lock

Malfunction

Service Required

Indicates that the rear seat interior door release switches and power

windows are switched off, preventing rear seat occupants from

opening the doors or windows.

Child Lock ON

Indicates that the rear seat interior door release switches and power
windows are switched on, allowing the rear seat occupants to open

the doors and windows.

Child Lock OFF

The factory keypad code displays in the information display after

the system resets the keypad. See

Anti-Theft Alarm

(page 63).

Factory Keypad

Code {X X X X X}

Fuel

Action

Message

An early reminder of a low fuel condition.

Fuel Level Low

Check to make sure you properly closed the fuel fill inlet.

Check Fuel Fill

Inlet

Wait for up to 15 seconds while the fuel system depressurizes.

Fuel Door Opening

The fuel system has finished depressurizing and you can begin to

refuel.

Fuel Door Open

A reminder to close the fuel door. Failure to follow this instruction

can cause the check engine light to illuminate.

Close Fuel Door to

Avoid ""Check
Engine"" Light

There is an error in attempting to refill your vehicle.

Refuel Error See

Manual

Information Displays

Hill Start Assist

Action

Message

Hill start assist is not available. Have the system checked as soon

as possible. See

Hill Start Assist

(page 153).

Hill Start Assist

Not Available

Maintenance

Action

Message

Stop your vehicle as soon as safely possible and turn off the engine.
Check the oil level. If the warning stays on or continues to come on

with your engine running, have the system checked as soon as

possible.

Low Engine Oil

Pressure

The engine oil life is low and needs to be changed soon.

Change Engine Oil

Soon

The engine oil life is low and needs to be immediately changed.

Oil Change

Required

The brake fluid level is low and the brake system should be imme-

diately inspected. See

Brake Fluid Check

(page 228).

Brake Fluid Level

Low

The brake system needs servicing. Stop your vehicle in a safe place.

Have the system checked.

Check Brake

System

The engine coolant temperature is excessively high.

Engine Coolant

Over Temperature

The washer fluid is low and needs to be refilled.

Washer Fluid Level

Low

Indicates that your vehicle is still in Transport mode. This may not

allow some features to properly operate. Have the system checked

as soon as possible.

Transport Mode

Contact Dealer

Indicates that your vehicle is still in Factory mode. This may not

allow some features to properly operate. Have the system checked

as soon as possible.

Factory Mode

Contact Dealer

Informs the driver that the powertrain needs service due to a

powertrain malfunction.

See Manual

The engine has reduced power to help reduce high engine temper-

ature.

Power Reduced to

Lower Engine

Temp

Information Displays

Action

Message

The brake system has reduced stopping power.

Brake Applied

Power Reduced

The brake system has reduced stopping power.

Brake Applied

Power Reduced

The motor electronics are overheating. Stop your vehicle as soon
as safely possible, turn off your vehicle and let it cool. If the warning
stays on or continues to come on, have your vehicle checked as
soon as possible.

Motor Coolant

Over Temperature

Park Aid

Action

Message

The system detects a fault that requires service. Have your vehicle

checked as soon as possible.

Check Front Park

Aid

The system detects a fault that requires service. Have your vehicle

checked as soon as possible.

Check Rear Park

Aid

The radar is blocked due to bad weather, ice, mud or water in front

of radar. You can typically clean the sensor to resolve. See

Rear

Parking Aid

(page 158).

Rear Park Aid Not

Available Sensor

Blocked See

Manual

The radar is blocked due to bad weather, ice, mud or water in front

of radar. You can typically clean the sensor to resolve.

Front Park Aid Not

Available Sensor

Blocked See

Manual

The radar is blocked due to bad weather, ice, mud or water in front

of radar. You can typically clean the sensor to resolve. See

Prin-

ciple of Operation

(page 158).

Park Aid Not Avail-

able Sensor

Blocked See

Manual

Displays the park aid status.

Front Park Aid On

Off

Displays the park aid status.

Rear Park Aid On

Off

Information Displays

Park Brake

Action

Message

The parking brake is set, the engine is running and you drive your

vehicle more than 3 mph (5 km/h). If the warning stays on after the

parking brake is released, have the system checked as soon as

possible.

Park Brake

Engaged

The electric parking brake is set and a manual release is attempted

without the brake pedal being pressed.

To Release: Press
Brake and Switch

The electric parking brake is set and an automatic release is

attempted but cannot be performed. Perform a manual release.

Park Brake Use

Switch to Release

The electric parking brake is set and your vehicle speed exceeds

3 mph (5 km/h). Release park brake before continued driving.

Release Park

Brake

The electric parking brake is not fully applied.

Park Brake Not

Applied

The electric parking brake is not fully released.

Park Brake Not

Released

The electric parking brake system has been put into a special mode

that is used to allow service of the rear brakes. Have the system

checked as soon as possible.

Park Brake Main-

tenance Mode

The electric park brake system has detected a condition that

requires service. Some functionality can still be available. Have the

system checked as soon as possible.

Park Brake Limited

Function Service

Required

The electric parking brake system has detected a condition that

requires service. Have the system checked as soon as possible.

Park Brake

Malfunction

Service Now

Numerous park brake applies have overheated the system. Wait 2

minutes before attempting to apply again.

Park Brake System

Overheated

Information Displays

Police Engine Idle feature

Action

Message

Displayed when the Police Engine Idle feature conditions are not

correct for proper operation.

Police Engine Idle

Not Available

Displayed when there is a fault detected in the Police Engine Idle

feature and the system is not active.

Police Engine Idle

Fault

Displayed when there is a fault detected in the Police Engine Idle

feature and the system is active.

Police Engine Idle

Fault Restart

Engine

Displayed when the Police Engine Idle feature is active.

Police Engine Idle

Active Reinsert

Key or Press

Button

Power Steering

Action

Message

The power steering system has detected a condition that requires

service. Have the system checked as soon as possible.

Steering Fault

Service Now

The power steering system is not working. Stop your vehicle in a

safe place. Have the system checked as soon as possible.

Steering Loss Stop

Safely

The power steering system has detected a condition within the

power steering system or passive entry or passive start system that

requires service. Have the system checked as soon as possible.

Steering Assist

Fault Service

Required

The steering lock system has detected a condition that requires

service. Have the system checked as soon as possible.

Steering Lock

Malfunction

Service Now

Information Displays

Pre-Collision Assist

Action

Message

You have a blocked sensor due to inclement weather, ice, mud or
water in front of the radar sensor. You can typically clean the sensor
to resolve.

Pre-Collision

Assist Not Avail-

able Sensor

Blocked

A fault with the system has occurred. Have the system checked as
soon as possible.

Pre-Collision

Assist Not Avail-

able

Seats

Action

Message

Objects are by the passenger seat. After you move the objects away
from the seat, if the warning stays on or continues to come on, have

the system checked as soon as possible.

Occupant Sensor

BLOCKED Remove

Objects Near

Passenger Seat

Starting System

Action

Message

Displays when starting your vehicle as a reminder to apply the brake.

To START Press

Brake

Displays when the starter has exceeded its cranking time in

attempting to start your vehicle.

Cranking Time

Exceeded

Displays when the starter is attempting to start your vehicle.

Engine Start

Pending Please

Wait

Displays when the pending start has been cancelled.

Pending Start

Cancelled

Your vehicle is ready to drive.

Ready to Drive

Information Displays

Tire Pressure Monitoring System

Action

Message

One or more tires on your vehicle have low tire pressure. See

Tire

Pressure Monitoring System

(page 260).

Tire Pressure Low

The tire pressure monitoring system is malfunctioning. If the warning
stays on or continues to come on, have the system checked as soon

as possible. See

Tire Pressure Monitoring System

(page 260).

Tire Pressure

Monitor Fault

A tire pressure sensor is malfunctioning, or your spare tire is in use.

For more information on how the system operates under these

conditions, See

Tire Pressure Monitoring System

(page 260). If

the warning stays on or continues to come on, have the system

checked as soon as possible.

Tire Pressure

Sensor Fault

Trailer

Action

Message

A correct trailer connection is sensed during

a given ignition cycle.

Trailer Connected

A trailer connection becomes either inten-

tionally or unintentionally disconnected and

has been sensed during a given ignition

cycle.

Trailer Disconnected

The trailer sway control has detected trailer

sway.

Trailer Sway Reduce Speed

There are certain faults in your vehicle

wiring and trailer wiring/brake system. See

Towing a Trailer

(page 183).

Trailer Wiring Fault

There is a fault with your trailer turn lamp.

Check your lamp.

Trailer Left Turn Lamps Fault Check Lamps

There is a fault with your trailer turn lamp.

Check your lamp.

Trailer Right Turn Lamps Fault Check

Lamps

There is a fault with your trailer battery.

See

Towing a Trailer

(page 183).

Trailer Battery Not Charging See Manual

There is a fault with your vehicle trailer

lighting module. See

Towing a Trailer

(page 183).

Trailer Lighting Module Fault See Manual

Information Displays

Transmission

Action

Message

You switched the engine off and shift select lever is in any position

other than park (P).

Shift to Park

Transmission is too cold. Wait for it to warm up before you drive.

Transmission

Warming Up

Please Wait

Displays when the brake pedal needs to be depressed.

Press Brake Pedal

The transmission is overheating and needs to cool. Stop in a safe

place as soon as possible.

Transmission Over

Temperature Stop

Safely

Have the system checked as soon as possible.

Transmission

Service Required

The transmission is overheating and needs to cool. Stop in a safe

place as soon as possible.

Transmission Too

Hot Press Brake

The transmission has limited functionality. Have the system

checked as soon as possible.

Transmission

Limited Function

See Manual

A reminder to shift into park. In addition, this message is typical

after reconnecting or recharging the battery until you cycle the

ignition to the on mode. See

Changing the 12V Battery

(page

229).

Transmission Not

in Park

Displays when there is a system fault and the park brake needs to

be depressed before exiting your vehicle. Have the system checked

as soon as possible.

SHIFT SYS FAULT

Confirm Park

Brake Apply Before

Exiting the Vehicle

Have the system checked as soon as possible.

SHIFT SYS FAULT

Service Required

Displays when there is a system fault while your vehicle is shifting

to park. Have the system checked as soon as possible.

SHIFT SYS FAULT

Vehicle is Shifting

to Park

Displays when there is a system fault while your vehicle is shifting

to reverse. Have the system checked as soon as possible.

SHIFT SYS FAULT

Reverse Unavail-

able Service

Required

Information Displays

Action

Message

Have the system checked as soon as possible.

SHIFT SYS FAULT

Drive Unavailable

Select S for Drive

Service Required

Have the system checked as soon as possible.

SHIFT SYS FAULT

Neutral Unavail-

able Service

Required

Have the system checked as soon as possible.

SHIFT SYS FAULT
Sport Unavailable

Service Required

Displays when an invalid gear has been selected.

Invalid Gear Selec-

tion

Displays when the brake pedal needs to be depressed to enable

the transmission to shift from park.

Depress Brake to

Shift from Park

Reminder to switch off the ignition while in neutral tow.

Neutral Tow

Engaged Turn Igni-
tion Off for Towing

Displays when neutral hold is active and you want to exit neutral

tow.

Neutral Tow

Engaged Depress

Brake and Select

Park to Exit

Neutral Tow

Reminder to remove park brake while in neutral tow.

Neutral Tow

Remove Park

Brake for Towing

Displays when the neutral tow is off.

Neutral Tow

Disengaged

Displays when neutral tow is on.

Neutral Tow

Enabled Leave

Transmission in

Neutral

Information Displays

AUTOMATIC CLIMATE
CONTROL

E286486

Note:

Depending on your vehicle option

package, the controls may look different
from what you see here.

Note:

You can switch temperature units

between Fahrenheit and Celsius.

Note:

For Hybrid Electric Vehicle (HEV) and

Plug-In Hybrid Electric Vehicle (PHEV)
vehicles, the air conditioning compressor
may run, and you may feel airflow when the
climate control is off to provide cooling to
the battery.

Directing the Airflow

Press and release the button to
direct airflow to the windshield
air vents and de-mister.

E244097

Press and release the button to
direct airflow to the instrument
panel air vents.

Press and release the button to
direct airflow to the footwell air
vents.

You can direct air through any combination
of these air vents.

Setting the Blower Motor Speed

Press and release

to adjust

the volume of air circulated in
the vehicle.

Setting the Temperature

E266187

E266186

Press the buttons on the left-hand side of
the climate control to set the left-hand
temperature.

Note:

This control also adjusts the

right-hand side temperature when you
switch off dual zone mode.

Press the buttons on the right-hand side
of the climate control to set the right-hand
temperature.

Switching Auto Mode On and Off

Press and release the button to
switch on automatic operation.
Repeatedly press the button to

adjust auto mode.

The system adjusts the blower motor
speed, air distribution, air conditioning
operation, and outside or recirculated air
to reach and maintain the temperature you
have set.

Under high humidity conditions, the system
adjusts the blower motor speed, air
distribution and air conditioning operation
to reduce window fogging.

Note:

The system starts at the previous

setting when you switch on

AUTO

mode.

Note:

You can also switch off dual zone

mode by pressing and holding the button
for more than two seconds.

100

Climate Control

Auto Mode Indicator Status

Description

Auto Mode Indicator

Status

One indicator illumin-
ated.

•

The blower motor speed is reduced.
•

Use this setting to minimize the amount of noise from
the blower motor.

•

This setting increases the time taken to cool the
interior.

Two indicators illumin-
ated.

•

The blower motor speed is moderate.

Three indicators illumin-
ated.

•

The blower motor speed is increased.
•

Use this setting to reduce the time taken to cool the
interior.

•

This setting increases the amount of noise from the
blower motor.

Smart Zone - Hybrid Electric Vehicle
(HEV), Plug-In Hybrid Electric Vehicle
(PHEV)

If there is not an occupant in the front
passenger seat, the climate control system
may default to single zone to improve fuel
economy, if you were previously in dual
zone operation. When this occurs, dual
zone turns off and the passenger set point
changes to match the driver set point.

Adjust the passenger set point normally to
use dual zone operation without a
passenger present. The system remains in
dual zone operation until you switch the
vehicle off.

You can disable or re-enable the Smart
Zone feature by pressing and holding

AUTO

for more than four seconds. Both

set point displays begin flashing to signify
when the feature disables. The system
returns to previous state after you release

AUTO

Switching the Air Conditioning On
and Off

Press and release the button.

Use air conditioning with recirculated air
to improve cooling performance and
efficiency.

Note:

In certain conditions, such as

maximum defrost, the air conditioning
compressor may continue to operate even
though you switch off the air conditioning.

Note:

The

A/C

LED light may turn on and

off based on the temperature setting or the
current conditions.

Switching the Climate Control On
and Off

Press and release the button.

101

Climate Control

Switching Maximum Air
Conditioning On and Off

Press and release the button for
maximum cooling.

The driver and passenger temperatures
are set to LO, recirculated air flows through
the instrument panel air vents, air
conditioning turns on and the blower motor
adjusts to the highest speed.

Switching Maximum Defrost On
and Off

Press and release the button for
maximum defrosting.

The driver and passenger temperatures
are set to HI, air flows through the
windshield air vents, and the blower motor
adjusts to the highest speed.

Note:

Depending on your region, air

conditioning turns on.

You can also use this setting to defog and
clear the windshield of a thin covering of
ice.

Note:

To prevent window fogging, you

cannot select recirculated air when
maximum defrost is on.

Note:

The heated rear window also turns

on when you select maximum defrost.

Switching Recirculated Air On and
Off

Press and release the button to
switch between outside air and
recirculated air.

The air currently in the passenger
compartment recirculates. This may
reduce the time needed to cool the interior,
when used with

A/C

, and reduce unwanted

odors from entering your vehicle.

Note:

Recirculated air may turn off, or

prevent you from switching on, in all air flow
modes except

MAX A/C

to reduce the risk

of fogging. Recirculation may also turn on
and off in various air distribution control
combinations during hot weather to improve
cooling efficiency.

HINTS ON CONTROLLING THE
INTERIOR CLIMATE

General Hints

Note:

Prolonged use of recirculated air may

cause the windows to fog up.

Note:

You may feel a small amount of air

from the footwell air vents regardless of the
air distribution setting.

Note:

To reduce humidity build-up inside

your vehicle, do not drive with the system
switched off or with recirculated air always
switched on.

Note:

Do not place objects under the front

seats as this may interfere with the airflow
to the rear seats.

Note:

Remove any snow, ice or leaves from

the air intake area at the base of the
windshield.

Note:

To improve the time to reach a

comfortable temperature in hot weather,
drive with the windows open until you feel
cold air through the air vents.

Automatic Climate Control

Note:

Adjusting the settings when your

vehicle interior is extremely hot or cold is
not necessary. Automatic mode is best
recommended to maintain set temperature.

Note:

The system adjusts to heat or cool

the interior to the temperature you select
as quickly as possible.

Note:

For the system to function efficiently,

the instrument panel and side air vents
should be fully open.

102

Climate Control

Content .. 4 5 6 7 ..
