Ford Mustang (2022 year). Manual in english

Steering System

Action

Message

The power steering system has detected a condition that requires

service. Have the system checked.

Steering Fault

Service Now

The power steering system is not working. Stop your vehicle in a

safe place. Have the system checked.

Steering Loss Stop

Safely

The power steering system has detected a condition within the

power steering system or passive entry or passive start system that

requires service. Have the system checked.

Steering Assist

Fault Service

Required

The steering lock system has detected a condition that requires

service. Have the system checked.

Steering Lock

Malfunction

Service Now

You need to turn your steering wheel when starting your vehicle to

unlock your steering column.

Steering Column

Lock Remove and

re-insert key while

turning wheel to

unlock

Suspension System

Action

Message

Displays if the adaptive damping system detects a condition that

requires service. Your vehicle speed is limited to 80 mph (130 km/h).

Have your vehicle serviced soon.

Suspension Fault

Speed Limited to

XX MPH/km/h

Tire Mobility Kit

Action

Message

This message appears when the tire sealing compound in the

Temporary Mobility Kit expires and you need to replace it. When

you replace the sealing compound you can reset any warning

messages through your settings menu. See

General Information

(page 99).

Service Tire

Mobility Kit

122

Information Displays

Tire Pressure Monitoring System

Action

Message

One or more tires on your vehicle has low tire pressure. See

Tire

Pressure Monitoring System

(page 327).

Tire Pressure Low

The tire pressure monitoring system is malfunctioning. If the warning

stays on or continues to come on, have the system checked. See

Tire Pressure Monitoring System

(page 327).

Tire Pressure

Monitor Fault

A tire pressure sensor is malfunctioning or your spare tire is in use.

See

Tire Pressure Monitoring System

(page 327). If the warning

stays on or continues to come on, have the system checked as soon

as possible.

Tire Pressure

Sensor Fault

Traction Control

Action

Message

The status of the system after you switched it off.

Traction Control

Off

The status of the system after you switched it on.

Traction Control

The system detects a spinout and turns on the hazard flashers.

Spinout Detected

Hazards Activated

Transmission

Action

Message

Have the system checked.

Transmission

Malfunction

Service Now

Have the system checked.

Transmission

Service Required

A reminder to shift into park.

Transmission Not

in Park

123

Information Displays

WHAT IS REMOTE START

The system allows you to remotely start
your vehicle and therefore to heat or cool
the interior to a predetermined
temperature.

REMOTE START LIMITATIONS

Remote start does not work under the
following conditions:

•

The alarm horn is sounding.

•

The hood is open.

•

The transmission is not in park (P).

•

The ignition is on.

•

The battery voltage is below the
minimum operating voltage.

Note:

Do not use remote start if your fuel

level is low.

ENABLING REMOTE START

Press

Settings

on the touchscreen.

2. Press

Vehicle Settings

3. Press

Remote Start Setup

4. Switch

Remote Start

on or off.

Note:

To remote start with FordPass, make

sure that the modem is enabled. See

Connecting FordPass to the Modem

(page 368).

REMOTELY STARTING THE
ENGINE

WARNING:

Do not start the engine

in a closed garage or in other enclosed
areas. Exhaust fumes are toxic. Always
open the garage door before you start
the engine. Failure to follow this
instruction could result in personal injury
or death.

To start the engine, do the following:

E138623

Press the button on the remote
control.

E138625

Within three seconds, press the
button on the remote control.

Within three seconds, press the

button again.

Note:

You can also use the FordPass app

to start the engine.

Note:

The turn signals flash twice.

Note:

The parking lamps turn on when the

engine is running.

Note:

The horn sounds if the system fails

to start.

Note:

All other vehicle systems remain off

when you have remotely started the engine.

Note:

The vehicle remains secured when

you have remotely started the engine. A
valid key must be inside your vehicle to
switch the ignition on and drive your vehicle.

EXTENDING THE REMOTE
START DURATION

To extend the engine running duration
during remote start, do the following:

E138623

Press the button on the remote
control.

124

Remote Start

(If Equipped)

E138625

Within three seconds, press the
button on the remote control.

Within three seconds, press the

button again.

Note:

You can extend the engine running

duration to a maximum of 30 minutes.

REMOTELY STOPPING THE
ENGINE

Use the FordPass App to stop the engine.

REMOTE START REMOTE
CONTROL INDICATORS

Remote Control Feedback

An LED on the remote control provides
status feedback of remote start or stop
commands.

Status

LED

Remote start

successful.

Solid green.

Remote stop

successful.

Solid red.

Request failed or

status not received.

Blinking red.

Status incomplete.

Blinking green.

REMOTE START SETTINGS

SWITCHING CLIMATE CONTROL
AUTO MODE ON AND OFF

Using the information display controls
on the steering wheel, select

Settings

2. Select

Vehicle

3. Select

Remote Start

4. Select

Climate Control

5. Switch

Auto

on or off.

Note:

If you switch the auto mode on, the

system attempts to heat or cool the interior
to 72°F (22°C).

Note:

When you switch the ignition on, the

climate control system returns to the last
used settings.

Note:

The heated windshield, heated rear

window, heated mirrors, heated seats and
heated steering wheel could turn on in cold
weather.

SWITCHING CLIMATE CONTROL
LAST SETTINGS ON AND OFF

Using the information display controls
on the steering wheel, select

Settings

2. Select

Vehicle

3. Select

Remote Start

4. Select

Climate Control

5. Switch

Last Settings

on or off.

Note:

If you switch the last settings on, the

system remembers the last used settings.

SWITCHING THE HEATED SEAT
SETTINGS ON AND OFF

Using the information display controls
on the steering wheel, select

Settings

2. Select

Vehicle

3. Select

Remote Start

4. Select

Front Seats

5. Select

Auto

Off

Note:

If you switch the heated seat settings

on, the heated seats turn on during cold
weather.

Note:

You cannot adjust the heated seat

settings when you have remotely started
the engine.

125

Remote Start

(If Equipped)

SWITCHING THE HEATED
STEERING WHEEL SETTINGS ON
AND OFF

Using the information display controls
on the steering wheel, select

Settings

2. Select

Vehicle

3. Select

Remote Start

4. Select

Front Seats & Wheel

5. Select

Auto

Off

Note:

If you switch the heated steering

wheel settings on, the heated steering wheel
turns on during cold weather.

Note:

You cannot adjust the heated

steering wheel settings when you have
remotely started the engine.

SETTING THE REMOTE START
DURATION

You can set a duration for the vehicle to
run.

Note:

Wait a few seconds before remotely

starting the engine after the engine stops
running.

Using the information display controls
on the steering wheel, select

Settings

2. Select

Vehicle

3. Select

Remote Start

4. Select

Duration

126

Remote Start

(If Equipped)

MANUAL CLIMATE CONTROL

(IF EQUIPPED)

E287201

Note:

Depending on your vehicle option

package, the controls may look different
from what you see here.

Directing the Airflow

Press and release the button to
direct airflow to the windshield
air vents and de-mister.

E244097

Press and release the button to
direct airflow to the instrument
panel air vents.

Press and release the button to
direct airflow to the footwell air
vents.

You can direct air through the windshield
and footwell air vents or the instrument
panel and footwell air vents at the same
time.

Setting the Blower Motor Speed

E265389

Turn the control to adjust the volume of
air circulated in the vehicle.

Setting the Temperature

E244106

Turn the control to set the temperature.

Switching the Air Conditioning On
and Off

Press and release the button.

127

Climate Control

Use air conditioning with recirculated air
to improve cooling performance and
efficiency.

Note:

In certain conditions such as

maximum defrost, the air conditioning
compressor may continue to operate even
though you switch off the air conditioning.

Switching the Climate Control On
and Off

Press and release the button.

Switching Maximum Air
Conditioning On and Off

Turn the temperature control
counterclockwise to the lowest
setting.

Note:

Recirculated air flows through the

instrument panel air vents, air conditioning
turns on and the blower motor adjusts to
the highest speed.

Switching Maximum Defrost On
and Off

Turn the temperature control
clockwise to the highest setting.

Note:

Air flows through the windshield air

vents, and the blower motor adjusts to the
highest speed.

You can also use this setting to defog and
clear the windshield of a thin covering of
ice. The heated rear window also turns on
when you select maximum defrost.

Note:

To prevent window fogging, you

cannot select recirculated air when
maximum defrost is on.

Switching Recirculated Air On and
Off

Press and release the button to
switch between outside air and
recirculated air.

The air currently in the passenger
compartment recirculates. This may
reduce the time needed to cool the interior,
when used with A/C, and reduce unwanted
odors from entering your vehicle.

Note:

Recirculated air may turn off, or

prevent you from switching on, in all air flow
modes except MAX A/C to reduce the risk
of fogging. Recirculation may also turn on
and off in various air distribution control
combinations during hot weather to improve
cooling efficiency.

AUTOMATIC CLIMATE
CONTROL

(IF EQUIPPED)

E287205

Note:

Depending on your vehicle option

package, the controls may look different
from what you see here.

Note:

You can switch temperature units

between Fahrenheit and Celsius.

Note:

You can control some of the climate

features through the touchscreen.

Setting the Blower Motor Speed

Press and release + or - to adjust
the volume of air circulated in
the vehicle.

128

Climate Control

Setting the Temperature

Press the toggle button on the left-hand
side of the climate control upward or
downward to set the left-hand
temperature.

Note:

This control also adjusts the

right-hand side temperature when you
switch off dual zone mode.

Press the toggle button on the right-hand
side of the climate control upward or
downward to set the right-hand
temperature.

Switching Auto Mode On and Off

Press and release the button to
switch on automatic operation,
then set the temperature.

The system adjusts the blower motor
speed, air distribution, air conditioning
operation, and outside or recirculated air
to reach and maintain the temperature you
have set.

Note:

You can also switch off dual zone

mode by pressing and holding the button
for more than two seconds.

Switching the Air Conditioning On
and Off

Press and release the button.

Use air conditioning with recirculated air
to improve cooling performance and
efficiency.

Note:

In certain conditions, such as

maximum defrost, the air conditioning
compressor could continue to operate even
after you switch off the air conditioning.

Switching the Climate Control On
and Off

Press and release the button.

Switching Defrost On and Off

Press and release the button to
distribute air through the
windshield air vents and

de-mister.

You can also use this setting to defog and
clear the windshield of a thin covering of
ice.

Switching Maximum Air
Conditioning On and Off

Press and release the button for
maximum cooling.

Recirculated air flows through the
instrument panel air vents, air conditioning
turns on and the blower motor adjusts to
the highest speed.

Switching Maximum Defrost On
and Off

Press and release the button for
maximum defrosting.

Air flows through the windshield air vents,
and the blower motor adjusts to the
highest speed.

You can also use this setting to defog and
clear the windshield of a thin covering of
ice.

Note:

To prevent window fogging, you

cannot select recirculated air when
maximum defrost is on.

Note:

The heated rear window also turns

on when you select maximum defrost.

129

Climate Control

Switching Recirculated Air On and
Off

Press and release the button to
switch between outside air and
recirculated air.

The air currently in the passenger
compartment recirculates. This may
reduce the time needed to cool the interior
when used with A/C, and reduce unwanted
odors from entering your vehicle.

Note:

Recirculated air may turn off

automatically, or prevent you from switching
on in all air flow modes except MAX A/C to
reduce the risk of fogging. Recirculation may
also turn on and off automatically in various
air distribution control combinations to
improve heating or cooling efficiency.

HINTS ON CONTROLLING THE
INTERIOR CLIMATE -
VEHICLES WITH: MANUAL
TEMPERATURE CONTROL

General Hints

Note:

Prolonged use of recirculated air may

cause the windows to fog up.

Note:

You may feel a small amount of air

from the footwell air vents regardless of the
air distribution setting.

Note:

To reduce humidity build-up inside

your vehicle, do not drive with the system
switched off or with recirculated air always
switched on.

Note:

Do not place objects under the front

seats as this may interfere with the airflow
to the rear seats.

Note:

Remove any snow, ice or leaves from

the air intake area at the base of the
windshield.

Note:

To improve the time to reach a

comfortable temperature in hot weather,
drive with the windows open until you feel
cold air through the air vents.

Quickly Heating the Interior

Adjust the blower motor speed to the
highest speed setting.

2. Adjust the temperature control to the

highest setting.

3. Direct air to the footwell air vents.

Recommended Settings for
Heating

Adjust the blower motor speed to the
center setting.

2. Adjust the temperature control to the

midway point of the hot settings.

3. Direct air to the footwell air vents.

Quickly Cooling the Interior

Switch

MAX A/C

on.

2. Drive with the windows open for a short

period of time.

Recommended Settings for
Cooling

Adjust the blower motor speed to the
center setting.

2. Adjust the temperature control to the

midway point of the cold settings.

3. Direct air to the instrument panel air

vents.

Vehicle Stationary for Extended
Periods During Extreme High
Ambient Temperatures

Apply the parking brake.

2. Place your vehicle in park (P) or neutral

(N).

3. Switch

MAX A/C

on.

130

Climate Control

4. Adjust the blower motor speed to the

lowest speed setting.

Defogging the Side Windows in
Cold Weather

Direct air to the instrument panel and
windshield air vents.

2. Press and release

A/C

3. Adjust the temperature control to the

setting you prefer.

4. Adjust the blower motor speed to the

highest setting.

5. Direct air toward the side windows.

6. Close the instrument panel air vents.

HINTS ON CONTROLLING THE
INTERIOR CLIMATE -
VEHICLES WITH: AUTOMATIC
TEMPERATURE CONTROL

General Hints

Note:

Prolonged use of recirculated air may

cause the windows to fog up.

Note:

You may feel a small amount of air

from the footwell air vents regardless of the
air distribution setting.

Note:

To reduce humidity build-up inside

your vehicle, do not drive with the system
switched off or with recirculated air always
switched on.

Note:

Do not place objects under the front

seats as this may interfere with the airflow
to the rear seats.

Note:

Remove any snow, ice or leaves from

the air intake area at the base of the
windshield.

Note:

To improve the time to reach a

comfortable temperature in hot weather,
drive with the windows open until you feel
cold air through the air vents.

Automatic Climate Control

Note:

Adjusting the settings when your

vehicle interior is extremely hot or cold is
not necessary. Automatic mode is best
recommended to maintain set temperature.

Note:

The system adjusts to heat or cool

the interior to the temperature you select
as quickly as possible.

Note:

For the system to function efficiently,

the instrument panel and side air vents
should be fully open.

Note:

If you select

AUTO

during cold

outside temperatures, the system directs
air flow to the windshield and side window
air vents. In addition, the blower motor may
run at a slower speed until the engine warms
up.

Note:

If you select

AUTO

during hot

temperatures and the inside of the vehicle
is hot, the system uses recirculated air to
maximize interior cooling. Blower motor
speed may also reduce until the air cools.

Quickly Heating the Interior

Press and release

AUTO

2. Adjust the temperature function to the

setting you prefer.

Recommended Settings for
Heating

Press and release

AUTO

2. Adjust the temperature function to the

setting you prefer. Use 72°F (22°C) as
a starting point, then adjust the setting
as necessary.

Quickly Cooling the Interior

Press and release

MAX A/C

Recommended Settings for
Cooling

Press and release

AUTO

131

Climate Control

2. Adjust the temperature function to the

setting you prefer. Use 72°F (22°C) as
a starting point, then adjust the setting
as necessary.

Defogging the Side Windows in
Cold Weather

Press and release defrost or maximum
defrost.

2. Adjust the temperature control to the

setting you prefer. Use 72°F (22°C) as
a starting point, then adjust the setting
as necessary.

HEATED REAR WINDOW

E184884

Press the button to clear the rear
window of thin ice and fog. The
heated rear window turns off

after a short period of time.

Note:

Do not use harsh chemicals, razor

blades or other sharp objects to clean or
remove decals from the inside of the heated
rear window. The vehicle warranty may not
cover damage to the heated rear window
grid lines.

HEATED EXTERIOR MIRRORS

(IF EQUIPPED)

When you switch the heated rear window
on, the heated exterior mirrors turn on.

Note:

Do not remove ice from the mirrors

with a scraper or adjust the mirror glass
when it is frozen in place.

Note:

Do not clean the mirror housing or

glass with harsh abrasives, fuel or other
petroleum-based cleaning products. The
vehicle warranty may not cover damage
caused to the mirror housing or glass.

132

Climate Control

WHAT IS THE CABIN AIR
FILTER

The cabin air filter improves the quality of
air in your vehicle by trapping dust, pollen
and other particles.

LOCATING THE CABIN AIR
FILTER

The cabin air filter is behind the glovebox.

Note:

The filter access door is above the

passenger footwell under the instrument
panel.

REPLACING THE CABIN AIR
FILTER

Replace the filter at regular intervals. See

Scheduled Maintenance

(page 449).

Note:

Make sure you have a cabin air filter

installed at all times. This prevents foreign
objects from entering the system. Running
the system without a filter in place could
result in degradation or damage to the
system.

Note:

Using an aftermarket cabin air filter

could reduce cabin air filtration and climate
control performance.

133

Interior Air Quality

SITTING IN THE CORRECT
POSITION

WARNING:

Sitting improperly, out

of position or with the seatback reclined
too far can take weight off the seat
cushion and affect the decision of the
passenger sensing system, resulting in
serious injury or death in the event of a
crash. Always sit upright against your
seat back, with your feet on the floor.

WARNING:

Do not recline the seat

backrest too far as this can cause the
occupant to slide under the seatbelt,
resulting in personal injury in the event
of a crash.

WARNING:

Do not place objects

higher than the top of the seat backrest.
Failure to follow this instruction could
result in personal injury or death in the
event of a sudden stop or crash.

E68595

When you use them properly, the seat,
head restraint, seatbelt and airbags will
provide optimum protection in the event
of a crash.

We recommend that you follow these
guidelines:
•

Sit in an upright position with the base
of your spine as far back as possible.

•

Do not recline the seat backrest so that
your torso is more than 30 degrees
from the upright position.

•

Adjust the head restraint so that the
top of it is level with the top of your
head and as far forward as possible.
Make sure that you remain
comfortable.

•

Keep sufficient distance between
yourself and the steering wheel. We
recommend a minimum of 10 in
(25 cm) between your breastbone and
the airbag cover.

•

Hold the steering wheel with your arms
slightly bent.

•

Bend your legs slightly so that you can
press the pedals fully.

•

Position the shoulder strap of the
seatbelt over the center of your
shoulder and position the lap strap
tightly across your hips.

Make sure that your driving position is
comfortable and that you can maintain full
control of your vehicle.

HEAD RESTRAINTS

WARNING:

Fully adjust the head

restraint before you operate your vehicle.
This will help minimize the risk of neck
injury in the event of a crash. Do not
adjust the head restraint when your
vehicle is moving.

134

Seats

WARNING:

The adjustable head

restraint is a safety device. Whenever
possible it should be installed and
properly adjusted when the seat is
occupied. Failure to adjust the head
restraint properly could reduce its
effectiveness during certain impacts.

WARNING:

Install the head

restraint properly to help minimize the
risk of neck injury in the event of a crash.

Note:

Adjust the seatback to an upright

driving position before adjusting the head
restraint. Adjust the head restraint so that
the top of it is level with the top of your head
and as far forward as possible. Make sure
that you remain comfortable. If you are
extremely tall, adjust the head restraint to
its highest position.

Front seat head restraints (if
equipped)

E138642

The head restraints consist of:

An energy absorbing head
restraint.

Two steel stems.

Guide sleeve adjust and release
button.

Guide sleeve unlock and remove
button.

Adjusting the Head Restraint

Raising the Head Restraint

Pull the head restraint up.

Lowering the Head Restraint

Press and hold button C.

2. Push the head restraint down.

Removing the Head Restraint

Pull the head restraint up until it
reaches its highest position.

2. Press and hold buttons C and D.
3. Pull the head restraint up.

Installing the Head Restraint

Align the steel stems into the guide sleeves
and push the head restraint down until in
locks.

Front Seat Non-Adjustable Head
Restraints

(If Equipped)

E174407

The non-adjustable head restraints consist
of a trimmed foam covering over the upper
structure of the seatback.

Properly adjust the seatback to an upright
driving or riding position, so that the head
restraint is positioned as close as possible
to the back of your head.

135

Seats

Tilting Head Restraints

(If Equipped)

The front head restraints tilt for extra
comfort. To tilt the head restraint, do the
following:

E144727

Adjust the seatback to an upright
driving or riding position.

2. Pivot the head restraint forward toward

your head to the desired position.

After the head restraint reaches the
forward-most tilt position, pivoting it
forward again will then release it to the
rearward, un-tilted position.

MANUAL SEATS

WARNING:

Do not adjust the driver

seat or seat backrest when your vehicle
is moving. This may result in sudden seat
movement, causing the loss of control
of your vehicle.

WARNING:

Make sure the seat fully

locks into place by rocking it backward
and forward.

WARNING:

Reclining the seatback

can cause an occupant to slide under the
seat's seatbelt, resulting in severe
personal injuries in the event of a crash.

WARNING:

Do not place cargo or

any objects behind the seatback before
returning it to the original position.

The front seats may consist of:

E174553

A bar to move the seat backward
and forward.

A lever to adjust the height of the
seat.

A lever to adjust the angle of the
seat backrest.

136

Seats

POWER SEATS

(IF EQUIPPED)

WARNING:

Do not adjust the driver

seat when your vehicle is moving.

WARNING:

Do not place cargo or

any objects behind the seatback before
returning it to the original position.

Driver Side

E187770

Passenger Side

E285698

The power seat control is on the outermost
side of the seat. Move the control in the
direction of the arrows to raise or lower the
seat cushion or to move the seat forward,
backward, up or down.

Power Lumbar

(If Equipped)

The power lumbar control is on the side of
the driver seat.

E187771

Press one side of the control to increase
lower back firmness. Press the other side
of the control to decrease lower back
firmness.

MEMORY FUNCTION

(IF EQUIPPED)

WARNING:

Before activating the

memory seat, make sure that the area
immediately surrounding the seat is clear
of obstructions and that all occupants
are clear of moving parts.

WARNING:

Do not use the memory

function when your vehicle is moving.

The memory function recalls the position
of these features.

•

Driver seat.

•

MyColor settings.

•

Power mirrors.

The memory control is on the driver door.

137

Seats

Ford Mustang (2022 year). Manual in english - page 8
