Vehicle Settings and Personalization

Fuel Gauge

The fuel gauge indicates about how much
fuel is in the fuel tank.

The arrow adjacent to the fuel pump
symbol indicates on which side of your
vehicle the fuel filler door is located.

Note:

The fuel gauge may vary slightly

when your vehicle is moving or on a slope.

Low Fuel Reminder

A low fuel level reminder displays and
sounds when the distance to empty
reaches 75 mi (120 km) to empty for
MyKey, and at 50 mi (80 km), 25 mi
(40 km), 10 mi (20 km) and 0 mi (0 km)
for all vehicle keys.

Note:

The low fuel reminder can appear at

different fuel gauge positions depending on
fuel economy conditions. This variation is
normal.

Information Bar

Displays information such as compass
direction, outside air temperature,
odometer and transmission gear selector.

Engine Coolant Temperature
Gauge

WARNING:

Do not remove the

coolant reservoir cap when the engine is
on or the cooling system is hot. Wait 10
minutes for the cooling system to cool
down. Cover the coolant reservoir cap
with a thick cloth to prevent the
possibility of scalding and slowly remove
the cap. Failure to follow this instruction
could result in personal injury.

Indicates engine coolant temperature. At
normal operating temperature, the level
indicator will be in the normal range. If the
engine coolant temperature exceeds the
normal range, stop your vehicle as soon as
safely possible, switch off the engine and
let the engine cool.

Instrument Cluster

Gauge Package

(If Equipped)

E196366

Oil Pressure Gauge

Indicates the engine oil pressure.

Vacuum or Vacuum and Boost Gauge

Indicates the vacuum or vacuum and boost
pressure in the intake.

GAUGES - VEHICLES WITH: 4.2 INCH INSTRUMENT CLUSTER
DISPLAY SCREEN

E230872

Instrument Cluster

Tachometer.

Information Display.

Speedometer.

Fuel Gauge.

Engine Coolant Temperature Gauge.

Information Display

Odometer

Located in the bottom of the information
display. Registers the accumulated
distance your vehicle has traveled.

Trip Computer

Vehicle Settings and Personalization

Fuel Gauge

The fuel gauge indicates about how much
fuel is in the fuel tank.

The arrow adjacent to the fuel pump
symbol indicates on which side of your
vehicle the fuel filler door is located.

Note:

The fuel gauge may vary slightly

when your vehicle is moving or on a slope.

Low Fuel Reminder

Note:

The low fuel reminder can appear at

different fuel gauge positions depending on
fuel economy conditions. This variation is
normal.

Information Bar

Displays information such as compass
direction, outside air temperature,
odometer and transmission gear selector.

Engine Coolant Temperature
Gauge

WARNING:

Do not remove the

Instrument Cluster

Gauge Package

(If Equipped)

E196366

Oil Pressure Gauge

Indicates the engine oil pressure.

Vacuum or Vacuum and Boost Gauge

Indicates the vacuum or vacuum and boost
pressure in the intake.

WARNING LAMPS AND
INDICATORS

The following warning lamps and
indicators alert you to a vehicle condition
that may become serious. Some lamps
illuminate when you start your vehicle to
make sure they work. If any lamps remain
on after starting your vehicle, refer to the
respective system warning lamp for further
information.

Note:

Some warning indicators appear in

the information display and operate the
same as a warning lamp but do not
illuminate when you start your vehicle.

Adaptive Cruise Control Indicator

(If Equipped)

E144524

It illuminates when you switch
the system on.

It illuminates white when the system is in
standby mode. It illuminates green when
you set the adaptive cruise speed.

Using Adaptive Cruise Control

(page 186).

Airbag Warning Lamp

E67017

If it does not illuminate when you
switch the ignition on, continues
to flash or remains on when the

engine is running, this indicates a
malfunction. Have your vehicle checked
as soon as possible.

Anti-Lock Brake System Warning
Lamp

If it illuminates when you are
driving, this indicates a
malfunction. Your vehicle

continues to have normal braking without
the anti-lock brake system function. Have
your vehicle checked as soon as possible.

Automatic Headlamp High Beam
Indicator

(If Equipped)

It illuminates when the system
automatically turns the
headlamp high beam on.

What Is Automatic High Beam

Control

(page 84).

Battery

If it illuminates while driving, it
indicates a malfunction. Switch
off all unnecessary electrical

equipment and have the system
immediately checked.

Instrument Cluster

Blind Spot Information System
Indicator

E151262

It illuminates when you switch
the system off.

Blind Spot Information

System

(page 198).

Brake System Warning Lamp

WARNING:

Driving your vehicle

with the warning lamp on is dangerous.
A significant decrease in braking
performance may occur. It may take you
longer to stop your vehicle. Have your
vehicle checked as soon as possible.
Driving extended distances with the
parking brake engaged can cause brake
failure and the risk of personal injury.

Note:

Indicators vary depending on region.

This lamp is a dual function lamp and
illuminates when:

•

You apply the parking brake with the
ignition on.

•

Your vehicle has a brake fault or low
brake fluid level, regardless of parking
brake position.

E270480

If the lamp illuminates when you
are moving, you may have the
parking brake applied. Make sure
the parking brake is off. Have
your vehicle checked as soon as
possible if the lamp continues to

illuminate.

Cruise Control Indicator

E71340

It illuminates when you switch
the system on.

Switching Cruise Control

On and Off

(page 185).

Direction Indicator

It illuminates when you switch
on the left or right direction
indicator or the hazard warning

flasher. Flashes during operation. An
increase in the rate of flashing warns of a
failed indicator bulb.

Door Ajar Warning Lamp

Displays when the ignition is on
and any door is not completely
closed.

Engine Coolant Temperature
Warning Lamp

If it illuminates when your vehicle
is moving, this indicates that the
engine is overheating. Stop your

vehicle as soon as it is safe to do so and
switch the engine off. Have your vehicle
checked as soon as possible.

Fasten Seatbelt Warning Lamp

E71880

It illuminates and a chime
sounds until you fasten the
seatbelts.

Front Fog Lamp Indicator

(If Equipped)

It illuminates when you switch
the front fog lamps on.

Headlamp High Beam Indicator

It illuminates when you switch
the high beam headlamps on. It
flashes when you use the

headlamp flasher.

Instrument Cluster

Hood Ajar

E159324

It illuminates when the ignition
is on and you do not have the
hood completely closed.

Lane Keeping System Lamp

E144813

Illuminates when the system
activates.

Launch Control

E234583

Illuminates when this feature is
ready, including both slip control
and engine RPM hold.

E255688

Illuminates when only engine
RPM hold is active. See

Track

Use

(page 279).

Low Beam Malfunction

E181350

Lights when there is a
malfunction with the low beam
headlamp bulb.

Low Fuel Level Warning Lamp

If it illuminates when you are
driving, refuel as soon as
possible.

Low Tire Pressure Warning Lamp

Illuminates when your tire
pressure is low. If the lamp
remains on with the engine

running or when driving, check your tire
pressure as soon as possible.

It also illuminates momentarily when you
switch the ignition on to confirm the lamp
is functional. If it does not illuminate when
you switch the ignition on, or begins to
flash at any time, have the system checked
as soon as possible.

Low Washer Fluid Level Warning
Lamp

E132353

Illuminates when the washer
fluid is low.

Oil Pressure Warning Lamp

Illuminates when you switch the
ignition on.

If it illuminates when the engine

is running this indicates a malfunction.
Stop your vehicle as soon as it is safe to
do so and switch the engine off. Check the
engine oil level. If the oil level is sufficient,
this indicates a system malfunction. Have
your vehicle checked as soon as possible.

Engine Oil Check

(page 263).

Parking Lamps

Illuminate when you switch the
parking lamps on.

Powertrain Fault

Illuminates when the system
detects a powertrain fault. Have
your vehicle checked as soon as

possible.

Service Engine Soon

If it illuminates when the engine
is running this indicates a
malfunction. The On Board

Diagnostics system has detected a
malfunction of the vehicle emission control
system.

If it flashes, engine misfire may be
occurring. Increased exhaust gas
temperatures could damage the catalytic
converter or other vehicle components.
Drive in a moderate fashion (avoid heavy
acceleration and deceleration) and have
your vehicle immediately serviced.

Instrument Cluster

It illuminates when you switch the ignition
on prior to engine start to check the bulb
and to indicate whether your vehicle is
ready for Inspection and Maintenance
(I/M) testing.

Normally, it illuminates until the engine
cranks and automatically turns off if no
malfunctions are present. However, if after
15 seconds it flashes eight times, this
indicates that your vehicle is not ready for
Inspection and Maintenance (I/M) testing.

Catalytic Converter

(page 161).

Shift Indicator

(If Equipped)

Illuminates to inform you that
shifting to a higher gear as
indicated may give better fuel
economy and lower CO2

emissions. It does not illuminate during
periods of high acceleration, braking or
when you press the clutch pedal.

Stability Control and Traction
Control Indicator

E138639

Flashes during operation.

If it does not illuminate when you
switch the ignition on, or remains

on when the engine is running, this
indicates a malfunction. Have your vehicle
checked as soon as possible.

Note:

The system automatically turns off

if there is a malfunction.

Using Stability Control

(page 177).

Using Traction Control

(page 175).

Stability Control and Traction
Control Off Warning Lamp

E130458

Illuminates when you switch the
system off.

Trunk Ajar

E159323

Illuminates when the ignition is
on and you do not have the trunk
completely closed.

AUDIBLE WARNINGS AND
INDICATORS

Keyless Warning Alert

The horn sounds twice when you exit your
vehicle with the passive key and your
vehicle is in ON, indicating your vehicle is
still on. The horn also sounds twice when
you exit your vehicle and attempt to lock
the doors manually when the passive key
is still in the vehicle. The doors will not lock
if the passive key remains in the vehicle.

Headlamps On Warning Tone

Sounds when you remove the key from the
vehicle and you have left the headlamps
or parking lamps on.

Parking Brake On Warning Tone

Sounds when you have left the parking
brake on and drive your vehicle. If the
warning tone remains on after you release
the parking brake, have the system
checked by your authorized dealer
immediately.

Transmission Not in Park

Sounds when the gear selector is in any
position other than park (P), and you
switch the vehicle ignition off or to the
accessory position. If the door is ajar, the
tone is continuous. Once you close the
door, the tone continues for a period of
time.

Instrument Cluster

Direction Indicator Left On

Sounds when the direction indicator does
not disengage after 2.0 mi (3.2 km) of
driving.

Beltminder Warning

Sounds when the system detects an
unfastened seatbelt in an occupied seat
and your vehicle is moving.

Instrument Cluster

GENERAL INFORMATION -
MACH 1

WARNING:

Driving while distracted

can result in loss of vehicle control, crash
and injury. We strongly recommend that
you use extreme caution when using any
device that may take your focus off the
road. Your primary responsibility is the
safe operation of your vehicle. We
recommend against the use of any
hand-held device while driving and
encourage the use of voice-operated
systems when possible. Make sure you
are aware of all applicable local laws
that may affect the use of electronic
devices while driving.

Note:

Some items could appear slightly

different or not at all if the features are
optional.

Information Display Controls

E249038

Back button.

Arrow up.

Voice control button.

Arrow down.

Pony button.

Audio button.

Phone buttons.

Settings button.

Navigation button.

•

Press one of the quick action menu
buttons to enter a menu.

•

Toggle

(B)

and

(D)

to scroll through

and highlight the options within a
menu.

Information Displays

•

Press the

button.

•

Press

(A)

to exit a menu.

•

Press the open menu's quick action
menu button at any time to close the
menu.

•

Press the

button to choose and

confirm settings or messages.

Settings

Trip/Fuel Info

Auto Engine Off

Driver
Assist

Blindspot

Pre-Collision Assist

Cross Traffic Alert

Cruise Control

Driver Alert

Hill Start Assist

Rear Park Aid

Lane Keeping System

Tire Monitor

Wipers

Speedometer MPH

Speedometer km/h

Vehicle

Advanced
Settings

MyKey

Display Setup

100

Information Displays

Pony

WARNING:

Track Apps™

is for

track use only. Remember that even
advanced technology cannot defy the
laws of physics. It is always possible to
lose control of a vehicle due to

inappropriate driver input for the
conditions. Aggressive driving on any
road condition can cause you to lose
control of your vehicle increasing the risk
of personal injury or property damage.

Track Apps™ provides a suite of options
to record and optimize your track
performances. See

Track Use

(page 279).

Pony

Show Status

MyMode

MyMode must be configured and saved before selection enabled.

Add
MyMode

Choose your applicable setting.

Exhaust
Mode

Quiet Start

Acceleration Timer

Track Apps

Brake Performance

Line Lock

Lap Timer

Start Option

Shift Point

Perform-
ance Shift
Indicator

Shift Tone

Shift Light Mode

Launch Control

Launch
Control

RPM

Rev Match

Show Gauges

Gauges

Configure MyGauges

Primary Color

MyColor

Secondary Color

Ambient Light

101

Information Displays

Pony

Create MyColor

Change with Drive Mode

Cluster
Appear-
ance

Normal

Sport

Track

Track Use

(page 279).

Note:

Quiet start allows you to schedule when the exhaust mode turns on the quiet setting.

The time window can be from 1 to 24 hours.

Note:

Depending on your vehicle

configuration, some features such as
Exhaust Mode and Line Lock may be if
equipped.

Note:

The menu options for Performance

Shift Indicator, Launch Control, and Rev
Match are for manual transmissions only.

Phone

Audio

Navigation

(If Equipped)
