Ford Mustang (2022 year). Manual in english - page 2

Recommendations for Safety Restraints for Children

Recommended Restraint

Type

Child Size, Height, Weight, or Age

Child

Use a child restraint

(sometimes called an

infant carrier, convertible

seat, or toddler seat).

Children weighing 40 lb (18 kg) or less

(generally age four or younger).

Infants or

toddlers

Use a belt-positioning

booster seat.

Children who have outgrown or no longer

properly fit in a child restraint (generally

children who are less than 57 in (1.45 m)

tall, are greater than age four and less

than age 12, and between 40 lb (18 kg)

and 80 lb (36 kg) and upward to 100 lb

(45 kg) if recommended by your child

restraint manufacturer).

Small children

Use a vehicle seatbelt

having the lap belt snug

and low across the hips,

shoulder belt centered

across the shoulder and

chest, and seat backrest

upright.

Children who have outgrown or no longer

properly fit in a belt-positioning booster

seat (generally children who are at least

57 in (1.45 m) tall or greater than 80 lb

(36 kg) or 100 lb (45 kg) if recommended

by child restraint manufacturer).

Larger children

•

You are required by law to properly use
child restraints for infants and toddlers
in the United States, Canada and
Mexico.

•

Many states and provinces require that
small children use approved booster
seats until they reach age eight, a
height of 57 in (1.45 m) tall, or 80 lb
(36 kg). Check your local and state or
provincial laws for specific
requirements about the safety of
children in your vehicle.

•

When possible, properly restrain
children 12 years of age and under in a
rear seating position of your vehicle.
Accident statistics suggest that
children are safer when properly
restrained in the rear seating positions
than in a front seating position. See

Front Passenger Sensing System

(page 50).

•

When installing a rear facing child
restraint, adjust the vehicle seats to
avoid interference between the child
restraint and the vehicle seat in front
of the child restraint.

Child Safety

INSTALLING CHILD
RESTRAINTS - MACH 1

Rear Seat Delete

(If Equipped)

WARNING:

It is extremely

dangerous to ride in a cargo area, inside
or outside of a vehicle. In a crash, people
riding in these areas are more likely to be
seriously injured or killed. Do not allow
people to ride in any area of your vehicle
that is not equipped with seats and
seatbelts. Make sure everyone in your
vehicle is in a seat and properly using a
seatbelt. Failure to follow this warning
could result in serious personal injury or
death.

E216990

This is not a seating position. You cannot
place persons or child restraints in the rear
of the vehicle with the rear seat delete
option.

Vehicles Without Rear Seats

E216824

Once you have installed the child restraint
using the seatbelt, you can attach the top
tether strap.

Attach the tether strap only to the
appropriate tether anchor as shown. The
tether strap may not work properly if you
attach it somewhere other than the correct
tether anchor.

Perform the following to attach a child
restraint to the tether anchor.

Route the tether strap as follows.

E216991

For Recaro front seats without rear seats,
route the tether strap through the
innermost slot of the front passenger seat
backrest or route the tether strap over the
top of the seat. You may need a tether
strap extension to reach the tether anchor.

Child Safety

E338219

For standard front seats without rear seats,
route the tether strap over the top of the
seat.

If you install a child restraint and you
attach the top tether strap to the proper
top tether anchor, do not tighten the tether
strap enough to lift the child restraint off
the vehicle seat cushion when the child is
seated in it. Keep the tether strap just snug
without lifting the front of the child
restraint. Keeping the child restraint just
touching the vehicle seat gives the best
protection in a severe crash.

See the Child Safety chapter in your base
Owner's Manual for more information.

INSTALLING CHILD
RESTRAINTS - VEHICLES
WITHOUT: SVT
PERFORMANCE PACKAGE

Child Seats

E142594

Use a child restraint (sometimes called an
infant carrier, convertible seat, or toddler
seat) for infants, toddlers, or children
weighing 40 lb (18 kg) or less (generally
age four or younger).

Using Lap and Shoulder Belts

WARNING:

Do not place a

rearward facing child restraint in front of
an active airbag. Failure to follow this
instruction could result in personal injury
or death.

WARNING:

Properly secure

children 12 years old and under in a rear
seating position whenever possible. If
you are unable to properly secure all
children in a rear seating position,
properly secure the largest child on the
front seat. If you must use a forward
facing child restraint on the front seat,
move the seat as far back as possible.
Failure to follow these instructions could
result in personal injury or death.

Child Safety

WARNING:

Depending on where

you secure a child restraint, and
depending on the child restraint design,
you may block access to certain seatbelt
buckle assemblies and LATCH lower
anchors, rendering those features
potentially unusable. To avoid risk of
injury, make sure occupants only use
seating positions where they are able to
be properly restrained.

When installing a child restraint with
combination lap and shoulder belts:
•

Use the correct seatbelt buckle for that
seating position.

•

Insert the belt tongue into the proper
buckle until you hear a snap and feel it
latch. Make sure the tongue is securely
fastened in the buckle.

•

Keep the buckle release button
pointing up and away from the child
restraint, with the tongue between the
child restraint and the release button,
to prevent accidental unbuckling.

•

Place the vehicle seat in the upright
position before you install the child
restraint.

•

Put the seatbelt in the automatic
locking mode. See Step 5. This vehicle
does not require the use of a locking
clip.

Perform the following steps when
installing the child restraint with
combination lap and shoulder belts:

Note:

Although the child restraint

illustrated is a forward facing child restraint,
the steps are the same for installing a rear
facing child restraint.

E142528

Position the child restraint in a seat
with a combination lap and shoulder
belt.

E142529

2. Pull down on the shoulder belt and

then grasp the shoulder belt and lap
belt together.

E142530

Child Safety

3. While holding the shoulder and lap belt

portions together, route the tongue
through the child restraint according
to the child restraint manufacturer's
instructions. Make sure that you have
not twisted the belt webbing.

E142531

4. Insert the belt tongue into the proper

buckle (the buckle closest to the
direction the tongue is coming from)
for that seating position until you hear
a snap and feel the latch engage. Make
sure the tongue is latched securely by
pulling on it.

E142875

5. To put the retractor in the automatic

locking mode, grasp the shoulder
portion of the belt and pull downward
until all of the belt is pulled out.

Note:

The automatic locking mode is

available on the front passenger and rear
seats. This vehicle does not require the use
of a locking clip.

6. Allow the belt to retract to remove

slack. The belt will click as it retracts
to indicate it is in the automatic locking
mode.

Try to pull the belt out of the retractor
to make sure the retractor is in the
automatic locking mode. You should
not be able to pull more belt out. If the
retractor does not lock, unbuckle the
belt and repeat Steps 5 and 6.

E142533

8. Remove remaining slack from the belt.

Force the seat down with extra weight,
for example, by pressing down or
kneeling on the child restraint while
pulling up on the shoulder belt in order
to force slack from the belt. This is
necessary to remove the remaining
slack that exists once you add the extra
weight of the child to the child restraint.
It also helps to achieve the proper
snugness of the child restraint to your
vehicle. Sometimes, a slight lean
toward the buckle will additionally help
to remove remaining slack from the
belt.

9. If the child restraint has a tether strap,

attach it.

Child Safety

E142534

10.

Before placing the child in the seat,
forcibly move the seat forward and
back to make sure the seat is securely
held in place. To check this, grab the
seat at the belt path and attempt to
move it side to side and forward and
back. There should be no more than
1 in (2.5 cm) of movement for proper
installation.

We recommend checking with a NHTSA
Certified Child Passenger Safety
Technician to make certain the child
restraint is properly installed. In Canada,
check with Transport Canada for referral
to a Child Car Seat Clinic.

Using Lower Anchors and Tethers
for CHildren (LATCH)

WARNING:

Do not attach two child

safety restraints to the same anchor. In
a crash, one anchor may not be strong
enough to hold two child safety restraint
attachments and may break, causing
serious injury or death.

WARNING:

Depending on where

WARNING:

The center of the rear

seat is not designed as a seating position
and is not equipped with seatbelts. The
LATCH anchors were not designed to be
used with a child restraint in the center
position and there is no tether anchor
available at the center. Do not attempt
to use the center as a seating position
as this will increase the risk of injury or
death in the event of a crash.

The LATCH system has three vehicle
anchor points: two lower anchors where
the seat backrest and seat cushion meet
(called the seat bight) and one top tether
anchor behind that seating position.

LATCH compatible child restraints have
two rigid or webbing mounted
attachments that connect to the two lower
anchors at the LATCH equipped seating
positions in your vehicle. This type of
attachment method eliminates the need
to use seatbelts to attach the child
restraint. However, you can still use the
seatbelt to attach the child restraint. For
forward-facing child restraints, you must
also attach the top tether strap to the
proper top tether anchor, if a top tether
strap has been provided with your child
restraint.

Child Safety

E316614

Your vehicle has LATCH lower anchors for
child restraint installation at the seating
positions marked with the child restraint
symbol.

E187773

The LATCH anchors are at the rear section
of the rear seat between the cushion and
seat backrest below the symbols as
shown. Follow the child restraint
manufacturer's instructions to properly
install a child restraint with LATCH
attachments. Follow the instructions on
attaching child restraints with tether
straps.

Only attach LATCH lower attachments of
the child restraint to the anchors shown.

Combining Seatbelt and LATCH Lower
Anchors for Attaching Child Restraints

When used in combination, you can attach
either the seatbelt or the LATCH lower
anchors first, provided a proper installation
is achieved. Attach the tether strap
afterward, if included with the child
restraint.

Using Tether Straps

E141128

Many forward-facing child
restraints include a tether strap
which extends from the back of

the child restraint and hooks to an
anchoring point called the top tether
anchor. Tether straps are available as an
accessory for many older child restraints.

Contact the manufacturer of your child
restraint for information about ordering a
tether strap, or to obtain a longer tether
strap if the tether strap on your child
restraint does not reach the appropriate
top tether anchor in your vehicle.

Once you install the child restraint using
either the seatbelt, the lower anchors of
the LATCH system, or both, you can attach
the top tether strap.

The tether strap anchors in your vehicle
are in the following positions (shown from
top view):

Child Safety

E316620

Perform the following steps to install a
child restraint with tether anchors:

For coupe:

Note:

If you install a child restraint with rigid

LATCH attachments, do not tighten the
tether strap enough to lift the child restraint
off your vehicle seat cushion when the child
is seated in it. Keep the tether strap just snug
without lifting the front of the child restraint.
Keeping the child restraint just touching your
vehicle seat gives the best protection in a
severe crash.

Route the tether strap over the top of
the seat backrest.

E174400

2. Locate the correct anchor for the

selected seating position.

3. Open the tether anchor cover.

E174401

4. Clip the tether strap to the anchor as

shown.

5. Tighten the child restraint tether strap

according to the manufacturer's
instructions. If your child restraint
system has a tether strap, and the child
restraint manufacturer recommends
its use, we also recommend its use.

If you have not properly anchored the child
restraint, the risk of a child being injured in
a crash greatly increases.

For vehicles with a convertible top:

Note:

For easier access, attach the tether

with the convertible top up.

Route the child restraint tether strap
over the top of the seat backrest.

Child Safety

E185416

2. Access the tether anchors behind the

seat backrest.

3. Remove the tether anchor cap.

4. Clip the tether strap to the anchor.

5. Tighten the child restraint tether strap

according to the manufacturer’s
instructions.

If you have not properly anchored the child
restraint, the risk of a child being injured in
a crash greatly increases.

If your child restraint system has a tether
strap, and the child restraint manufacturer
recommends its use, we also recommend
its use.

INSTALLING CHILD
RESTRAINTS - VEHICLES
WITH: SVT PERFORMANCE
PACKAGE

Rear Seat Delete

(If Equipped)

WARNING:

It is extremely

E216990

This is not a seating position. You cannot
place persons or child restraints in the rear
of the vehicle with the rear seat delete
option.

Child Safety

Vehicles Without Rear Seats

E216824

Once you have installed the child restraint
using the seatbelt, you can attach the top
tether strap.

Attach the tether strap only to the
appropriate tether anchor as shown. The
tether strap may not work properly if you
attach it somewhere other than the correct
tether anchor.

Perform the following to attach a child
restraint to the tether anchor.

Route the tether strap as follows.

E216991

For coupe without rear seats, route the
tether strap through the inboard slot of the
front passenger seat backrest or route the
tether strap over the top of the seat. You
may need a tether strap extension to reach
the tether anchor.

See the Child Safety chapter in your base
Owner's Manual for more information.

BOOSTER SEATS

WARNING:

Do not put the shoulder

section of the seatbelt or allow the child
to put the shoulder section of the
seatbelt under their arm or behind their
back. Failure to follow this instruction
could reduce the effectiveness of the
seatbelt and increase the risk of injury or
death in a crash.

Use a belt-positioning booster seat for
children who have outgrown or no longer
properly fit in a child safety restraint
(generally children who are less than 57 in
(1.45 m) tall, are greater than age 4 and
less than age 12, and between 40 lb (18 kg)
and 80 lb (36 kg) and upward to 100 lb
(45 kg) if recommended by your child
restraint manufacturer). Many state and
provincial laws require that children use
approved booster seats until they reach
age eight, a height of 57 in (1.45 m) tall, or
80 lb (36 kg).

Booster seats should be used until you can
answer YES to ALL of these questions
when seated without a booster seat:

Child Safety

E142595

•

Can the child sit all the way back
against their vehicle seat backrest with
knees bent comfortably at the edge of
the seat cushion?

•

Can the child sit without slouching?

•

Does the lap belt rest low across the
hips?

•

Is the shoulder belt centered on the
shoulder and chest?

•

Can the child stay seated like this for
the whole trip?

Always use booster seats in conjunction
with your vehicle lap and shoulder belt.

Types of Booster Seats

E68924

•

Backless booster seats

If your backless booster seat has a
removable shield, remove the shield. If a
vehicle seating position has a low seat
backrest or no head restraint, a backless
booster seat may place your child's head
(as measured at the tops of the ears)
above the top of the seat. In this case,
move the backless booster to another
seating position with a higher seat backrest
or head restraint and lap and shoulder
belts, or consider using a high back booster
seat.

E70710

•

High back booster seats

If, with a backless booster seat, you cannot
find a seating position that adequately
supports your child's head, a high back
booster seat would be a better choice.

Children and booster seats vary in size and
shape. Choose a booster that keeps the
lap belt low and snug across the hips,
never up across the stomach, and lets you
adjust the shoulder belt to cross the chest
and rest snugly near the center of the
shoulder. The following drawings compare
the ideal fit (center) to a shoulder belt
uncomfortably close to the neck and a
shoulder belt that could slip off the
shoulder. The drawings also show how the
lap belt should be low and snug across the
child's hips.

Child Safety

E142596

E142597

If the booster seat slides on the vehicle
seat upon which it is being used, placing a
rubberized mesh sold as shelf or carpet
liner under the booster seat may improve
this condition. Do not introduce any item
thicker than this under the booster seat.
Check with the booster seat
manufacturer's instructions.

CHILD RESTRAINT
POSITIONING

WARNING:

Do not place a

rearward facing child restraint in front of
an active airbag. Failure to follow this
instruction could result in personal injury
or death.

WARNING:

Properly secure

WARNING:

Always carefully follow

the instructions and warnings provided
by the manufacturer of any child
restraint to determine if the restraint
device is appropriate for your child's size,
height, weight, or age. Follow the child
restraint manufacturer's instructions and

Child Safety

warnings provided for installation and
use in conjunction with the instructions
and warnings provided by your vehicle
manufacturer. A safety seat that is
improperly installed or utilized, is
inappropriate for your child's height, age,
or weight or does not properly fit the
child may increase the risk of serious
injury or death.

WARNING:

Do not allow a

passenger to hold a child on their lap
when your vehicle is moving. Failure to
follow this instruction could result in
personal injury or death in the event of a
sudden stop or crash.

WARNING:

Do not use pillows,

books or towels to boost your child's
height. Failure to follow this instruction
could result in personal injury or death.

WARNING:

Properly secure child

restraints or booster seats when they are
not in use. They could become projectiles
in a sudden stop or crash. Failure to
follow this instruction could result in
personal injury or death.

WARNING:

Do not put the shoulder

WARNING:

Do not leave children

or pets unattended in your vehicle.
Failure to follow this instruction could
result in personal injury or death.

Child Safety

Recommendations for Attaching Child Safety Restraints for Children

Use Any Attachment Method as Indicated Below by X

Combined

Weight of

Child and

Child

Restraint

Type

Seatbelt

Only

Seatbelt

and LATCH

(Lower

Anchors

and Top

Tether

Anchor)

Seatbelt

and Top

Tether

Anchor

LATCH

(Lower

Anchors

Only)

LATCH

(Lower

Anchors

and Top

Tether

Anchor)

Up to 65 lb

(29.5 kg)

Rear facing

child

restraint

Over 65 lb

(29.5 kg)

Rear facing

child

restraint

Up to 65 lb

(29.5 kg)

Forward

facing

child

restraint

Over 65 lb

(29.5 kg)

Forward

facing

child

restraint

Note:

The child restraint must rest tightly

against the vehicle seat upon which it is
installed. It may be necessary to lift or
remove the head restraint. See

Seats

(page

134).

Child Safety

PRINCIPLE OF OPERATION

WARNING:

Always drive and ride

with your seatback upright and the lap
belt snug and low across the hips.

WARNING:

Children must always

be properly restrained.

WARNING:

Never let a passenger

hold a child on his or her lap while the
vehicle is moving. The passenger cannot
protect the child from injury in a crash.

WARNING:

All occupants of your

vehicle, including the driver, should
always properly wear their seatbelts,
even when an airbag supplemental
restraint system is provided. Failure to
properly wear your seatbelt could
seriously increase the risk of injury or
death.

WARNING:

It is extremely

WARNING:

In a rollover crash, an

unbelted person is significantly more
likely to die than a person wearing a
seatbelt.

WARNING:

Each seating position

in your vehicle has a specific seatbelt
assembly made up of one buckle and
one tongue designed to be used as a pair.
Use the shoulder belt on the outside
shoulder only. Never wear the shoulder
belt under the arm. Never use a single
seatbelt for more than one person.

WARNING:

Airbags can kill or injure

a child in a child restraint. Properly
restrain children 12 and under in the rear
seat whenever possible.

WARNING:

Seatbelts and seats

may be hot in a vehicle that is in the
sunshine. The hot seatbelts or seats may
burn a small child. Check seat covers and
buckles before you place a child
anywhere near them.

WARNING:

The center of the rear

All seating positions in your vehicle have
lap and shoulder seatbelts. All occupants
of the vehicle should always properly wear
their seatbelts, even when an airbag
supplemental restraint system is provided.

The seatbelt system consists of:
•

Lap and shoulder seatbelts.

•

Seatbelt pretensioner at the front
outboard seating positions.

•

Belt tension sensor at the front
outboard passenger seating position.

Seatbelts

E71880

· Seatbelt warning light and
chime.

E67017

· Crash sensors and monitoring
system with readiness indicator.

The seatbelt pretensioners at the front
seating positions are designed to tighten
the seatbelts when activated. In frontal
and near-frontal crashes, the seatbelt
pretensioners may be activated alone or,
if the crash is of sufficient severity, together
with the front airbags. The pretensioners
may also activate in side impacts and
rollovers.

FASTENING THE SEATBELTS

The front outboard and rear safety
restraints in the vehicle are combination
lap and shoulder belts.

A web guide is included on the outboard
side of the front seats. Depending on
occupant size and seating position, you
may need to route the belt through the
guide for a proper fit. If the seatbelt does
not route across the middle of the
shoulder, route the belt through the web
guide.

Convertible

E175860

Coupe

E175859

Recaro

E175163

Recaro SVT

E216814

Seatbelts

Content .. 1 2 3 ..
