Disarming the system

You can disarm the system by any of the following actions:
• Unlock the doors by using the remote entry transmitter portion of

your Integrated Keyhead Transmitter.

• Unlocking the doors using the keyless entry keypad (if equipped).
• Turn ignition to the on position with a valid SecuriLock™ key.
• Press the panic control on the remote entry transmitter portion of

your IKT. This will only shut off the horn and turn lamps when the
alarm is sounding. The alarm system will still be armed.

If using a key in the driver’s door to unlock the vehicle, a chime will
sound and the message center will display TO STOP ALARM START
VEHICLE when you open the door and you will have 12 seconds to
disarm the alarm system using any of the actions above, otherwise the
alarm will trigger.

Pressing the power door unlock control within the 20 second prearmed
mode will return the vehicle to a disarmed state.

Triggering the anti-theft system

The armed system will be triggered if:
• Any door, the hood or the trunk is opened without using the door key

or the remote entry transmitter portion of your IKT.

• The ignition is turned to the 3 (on) position with an invalid

SecuriLock

威 key.

Locks and Security

113

2011 Milan (mln)
Owners Guide, 1st Printing
USA (fus)

FRONT SEATING

WARNING: Reclining the seatback can cause an occupant to
slide under the seat’s safety belt, resulting in severe personal

injuries in the event of a collision.

WARNING: Do not pile cargo higher than the seatbacks to
reduce the risk of injury in a collision or sudden stop.

WARNING: Before returning the seatback to its original
position, make sure that cargo or any objects are not trapped

behind the seatback. After returning the seatback to its original
position, pull on the seatback to ensure that it has fully latched. An
unlatched seat may become dangerous in the event of a sudden stop or
collision.

Adjustable head restraints

Your vehicle is equipped with front row outboard head restraints that are
vertically adjustable.

WARNING: To minimize the risk of neck injury in the event of a
crash, the driver and passenger occupants should not sit in

and/or operate the vehicle, until the head restraint is placed in its
proper position. The driver should never adjust the head restraint
while the vehicle is in motion.

The adjustable head restraints
consist of:
• a trimmed energy absorbing foam

and structure (1),

• two steel stems (2),
• a guide sleeve adjust/release

button (3),

• and a guide sleeve unlock/remove

button (4).

Seating and Safety Restraints

114

2011 Milan (mln)
Owners Guide, 1st Printing
USA (fus)

To adjust the head restraint, do the following:

1. Adjust the seatback to an upright driving/riding position.

2. Raise the head restraint by pulling up on the head restraint.

3. Lower the head restraint by pressing and holding the guide sleeve
adjust/release button and pushing down on the head restraint.

Properly adjust the head restraint so that the top of the head restraint is
even with the top of your head and positioned as close as possible to the
back of your head. For occupants of extremely tall stature, adjust the
head restraint to its full up position.

WARNING: The adjustable head restraint is a safety device.
Whenever possible it should be installed and properly adjusted

when the seat is occupied.

To remove the adjustable head restraint, do the following:

1. Pull up the head restraint until it reaches the highest adjustment
position.

2. Simultaneously press and hold both the adjust/release button and the
unlock/remove button, then pull up on the head restraint.

To reinstall the adjustable head restraint, do the following:

1. Insert the two stems into the guide sleeve collars.

2. Push the head restraint down until it locks.

WARNING: To minimize the risk of neck injury in the event of a
crash, head restraints must be installed properly.

Tilting head restraints (if equipped)

The front head restraints may have a tilting feature for extra comfort. To
tilt the head restraint, do the following:

1. Adjust the seatback to an upright driving/riding position.

Seating and Safety Restraints

115

2011 Milan (mln)
Owners Guide, 1st Printing
USA (fus)

2. Pivot the head restraint forward
towards your head to the desired
location.

After the head restraint reaches
the forward-most tilt position,
pivoting it forward again will then
release it to the rearward
un-tilted position.

Adjusting the front manual seat (if equipped)

WARNING: Never adjust the driver’s seat or seatback when the
vehicle is moving.

WARNING: Always drive and ride with your seatback upright
and the lap belt snug and low across the hips.

Lift handle to move seat forward or
backward.

Pull lever up to adjust seatback.

Seating and Safety Restraints

116

2011 Milan (mln)
Owners Guide, 1st Printing
USA (fus)

Using the manual lumbar support (if equipped)

The lumbar control is located on the
side of the seat cushion.

Turn to adjust lumbar support.

Adjusting the front power seat (if equipped)

WARNING: Never adjust the driver’s seat or seatback when the
vehicle is moving.

WARNING: Do not pile cargo higher than the seatbacks to
reduce the risk of injury in a collision or sudden stop.

WARNING: Always drive and ride with your seatback upright
and the lap belt snug and low across the hips.

WARNING: Reclining the seatback can cause an occupant to
slide under the seat’s safety belt, resulting in severe personal

injuries in the event of a collision.

WARNING: Sitting improperly out of position or with the seat
back reclined too far can take off weight from the seat cushion

and affect the decision of the front passenger sensing system, resulting
in serious injury or death in a crash. Always sit upright against your
seatback, with your feet on the floor.

Seating and Safety Restraints

117

2011 Milan (mln)
Owners Guide, 1st Printing
USA (fus)

WARNING: To reduce the risk of possible serious injury: Do not
hang objects off seat back or stow objects in the seatback map

pocket (if equipped) when a child is in the front passenger seat. Do
not place objects underneath the front passenger seat or between the
seat and the center console (if equipped). Check the “passenger airbag
off” or “pass airbag off” indicator lamp for proper airbag status. Refer
to Front passenger sensing system in the Airbag supplemental
restraint system (SRS) section for additional details. Failure to follow
these instructions may interfere with the front passenger seat sensing
system.

The control is located on the outboard side of the seat cushion.

Move the control in the direction of
the arrows to raise or lower the
front portion of the seat cushion.

Move the control in the direction of
the arrows to raise or lower the rear
portion of the seat cushion.

Press the control in the direction of
the arrows to move the seat
forward, backward, up or down.

Seating and Safety Restraints

118

2011 Milan (mln)
Owners Guide, 1st Printing
USA (fus)

Power recline (if equipped)

Press the control to recline the
seatback forward or rearward.

Using the power lumbar support (if equipped)

The power lumbar control is located on the outboard side of the driver’s
seat.

Press one side of the control to
adjust firmness.

Press the other side of the control
to adjust softness.

Heated seats (if equipped)

WARNING: Persons who are unable to feel pain to the skin
because of advanced age, chronic illness, diabetes, spinal cord

injury, medication, alcohol use, exhaustion, or other physical
conditions, must exercise care when using the seat heater. The seat
heater may cause burns even at low temperatures, especially if used
for long periods of time. Do not place anything on the seat that
insulates against heat, such as a blanket or cushion, because this may
cause the seat heater to overheat. Do not puncture the seat with pins,
needles, or other pointed objects because this may damage the heating
element which may cause the seat heater to overheat. An overheated
seat may cause serious personal injury.

Seating and Safety Restraints

119

2011 Milan (mln)
Owners Guide, 1st Printing
USA (fus)

Note: Do not do the following:
• Place heavy objects on the seat
• Operate the seat heater if water or any other liquid is spilled on the

seat. Allow the seat to dry thoroughly.

The heated seats will only function when the ignition is in the on
position.

To operate the heated seats:

DATC systems
• Press the control located on the

climate control system panel once
to activate high heat.

• Press twice to activate low heat.
• Press a third time to deactivate.
The indicator light on the control will illuminate when activated. For low
heat, one light will be lit; for high heat, both lights will be lit.

Navigation based systems
• Press the control located on the

climate control system panel once
to activate high heat.

• Press twice to activate low heat.
• Press a third time to deactivate.

REAR SEATS

Second-row adjustable head restraints

Your vehicle is equipped with outboard and center head restraints that
are vertically adjustable.

WARNING: To minimize the risk of neck injury in the event of a
crash, the driver and passenger occupants should not sit in

and/or operate the vehicle, until the head restraint is placed in its
proper position. The driver should never adjust the head restraint
while the vehicle is in motion.

Seating and Safety Restraints

120

2011 Milan (mln)
Owners Guide, 1st Printing
USA (fus)

Outboard head restraints

The outboard adjustable head
restraints consist of:
• a trimmed energy absorbing foam

and structure (1),

• two steel stems (2),
• a guide sleeve adjust/release

button (3),

• and a guide sleeve unlock/remove

button (4).

To adjust the outboard head restraints, do the following:

1. Raise the head restraint by pulling up on the head restraint.

2. Lower the head restraint by pressing and holding the guide sleeve
adjust/release button and pushing down on the head restraint.

WARNING: The adjustable head restraint is a safety device.
Whenever possible it should be installed and properly adjusted

when the seat is occupied.

To remove the outboard head restraints, do the following:

1. Pull up the head restraint until it reaches the highest adjustment
position.

2. Simultaneously press and hold both the adjust release button and the
unlock/remove button, then pull the head restraint upward. (You may
have to fold the seat slightly in order to pull the headrest out.)

3. Store the head restraint in a secure location, such as the trunk of the
vehicle.

To reinstall the outboard head restraints, do the following:

1. Insert the two stems into the guide sleeve collars.

2. Push the head restraint down until it locks.

Properly adjust the head restraint so that the top of the head restraint is
even with the top of your head and positioned as close as possible to the

Seating and Safety Restraints

121

2011 Milan (mln)
Owners Guide, 1st Printing
USA (fus)

back of your head. For occupants of extremely tall stature, adjust the
head restraint to its full up position.

WARNING: To minimize the risk of neck injury in the event of a
crash, head restraints must be installed properly.

Center head restraint

The center head restraint consists
of:
• a trimmed energy absorbing foam

and structure (1),

• two steel stems (2),
• a guide sleeve adjust/release

button (3),

• and a guide sleeve with a pin hole

for removing the head restraint
(4).

To adjust the head restraint, do the following:

1. Raise the head restraint by pulling up on the head restraint.

2. Lower the head restraint by pressing and holding the guide sleeve
adjust/release button and pushing down on the head restraint.

WARNING: The adjustable head restraint is a safety device.
Whenever possible it should be installed and properly adjusted

when the seat is occupied.

Seating and Safety Restraints

122

2011 Milan (mln)
Owners Guide, 1st Printing
USA (fus)

To remove the center head restraint, do the following:

1. Pull up the head restraint until it reaches the highest adjustment
position.

2. Insert and push a tool, such as a large paper clip, into the pin hole
located on the side of the guide sleeve and press the adjust/release
button, then pull the head restraint upward.

3. Store the head restraint in a secure location, such as the trunk of the
vehicle.

To reinstall the center head restraint, do the following:

1. Insert the two stems into the guide sleeve collars.

2. Push the head restraint down until it locks.

WARNING: To minimize the risk of neck injury in the event of a
crash, head restraints must be installed properly.

Split-folding rear seatbacks

One or both rear seatbacks can be folded down to provide additional
cargo space.

To lower the seatback(s), pull the
release handle(s) located inside the
trunk.

Seating and Safety Restraints

123

2011 Milan (mln)
Owners Guide, 1st Printing
USA (fus)

Fold the seatback(s) down.

Note: If the front seats interfere
with folding the seatbacks, you will
need to remove the rear seat head
restraints. To remove the rear seat
head restraints, see removal
instructions under Second-row
adjustable head restraints in this
chapter.

WARNING: Before returning the seatback to its original
position, make sure that cargo or any objects are not trapped

Make sure that the safety belt for the rear center passenger is properly
routed over the rear seatback.

Seating and Safety Restraints

124

2011 Milan (mln)
Owners Guide, 1st Printing
USA (fus)

Seat-mounted cup holders and armrest storage compartment

To access the cup holders, fold the
armrest down.

WARNING: Use only soft cups in the cup holder. Hard objects
can injure you in a collision.

SAFETY RESTRAINTS

Personal Safety System™

The Personal Safety System provides an improved overall level of frontal
crash protection to front seat occupants and is designed to help further
reduce the risk of airbag-related injuries. The system is able to analyze
different occupant conditions and crash severity before activating the
appropriate safety devices to help better protect a range of occupants in
a variety of frontal crash situations.

Your vehicle’s Personal Safety System consists of:
• Driver and passenger dual-stage airbag supplemental restraints.
• Front outboard safety belts with pretensioners, energy management

retractors (first row only), and safety belt usage sensors.

• Driver’s seat position sensor.
• Front passenger sensing system
• “Passenger airbag off” or “pass airbag off” indicator lamp
• Front crash severity sensor.
• Restraints Control Module (RCM) with impact and safing sensors.
• Restraint system warning light and back-up tone.
• The electrical wiring for the airbags, crash sensor(s), safety belt

pretensioners, front safety belt usage sensors, driver seat position
sensor, front passenger sensing system, and indicator lights.

Seating and Safety Restraints

125

2011 Milan (mln)
Owners Guide, 1st Printing
USA (fus)

How does the Personal Safety System work?

The Personal Safety System can adapt the deployment strategy of your
vehicle’s safety devices according to crash severity and occupant
conditions. A collection of crash and occupant sensors provides
information to the Restraints Control Module (RCM). During a crash, the
RCM may activate the safety belt pretensioners and/or either one or both
stages of the dual-stage airbag supplemental restraints based on crash
severity and occupant conditions.

The fact that the pretensioners or airbags did not activate for both front
seat occupants in a collision does not mean that something is wrong with
the system. Rather, it means the Personal Safety System determined the
accident conditions (crash severity, belt usage, etc.) were not
appropriate to activate these safety devices. Front airbags are designed
to activate only in frontal and near-frontal collisions (not rollovers, side
impacts or rear impacts) unless the collision causes sufficient
longitudinal deceleration. The pretensioners are designed to activate in
frontal and near-frontal collisions, and in side collisions.

Driver and passenger dual-stage airbag supplemental restraints

The dual-stage airbags offer the capability to tailor the level of airbag
inflation energy. A lower, less forceful energy level is provided for more
common, moderate-severity impacts. A higher energy level is used for
the most severe impacts. Refer to Airbag supplemental restraint
system (SRS) section in this chapter.

Front crash severity sensor

The front crash severity sensor enhances the ability to detect the
severity of an impact. Positioned up front, it provides valuable
information early in the crash event on the severity of the impact. This
allows your Personal Safety System to distinguish between different
levels of crash severity and modify the deployment strategy of the
dual-stage airbags and safety belt pretensioners.

Driver’s seat position sensor

The driver’s seat position sensor allows your Personal Safety System to
tailor the deployment level of the driver dual-stage airbag based on seat
position. The system is designed to help protect smaller drivers sitting
close to the driver airbag by providing a lower airbag output level.

Front passenger sensing system

For airbags to do their job they must inflate with great force, and this
force can pose a potentially deadly risk to occupants that are very close

Seating and Safety Restraints

126

2011 Milan (mln)
Owners Guide, 1st Printing
USA (fus)

to the airbag when it begins to inflate. For some occupants, this occurs
because they are initially sitting very close to the airbag. For other
occupants, this occurs when the occupant is not properly restrained by
safety belts or child safety seats and they move forward during pre-crash
braking. The most effective way to reduce the risk of unnecessary
injuries is to make sure all occupants are properly restrained. Accident
statistics suggest that children are much safer when properly restrained
in the rear seating positions than in the front.

WARNING: Air bags can kill or injure a child in a child seat.
NEVER place a rear-facing child seat in front of an active air

bag. If you must use a forward-facing child seat in the front seat, move
the seat all the way back.

WARNING: When possible, all children 12 years old and under
should be properly restrained in a rear seating position.

The front passenger sensing system can automatically turn off the front
passenger airbag and passenger seat-mounted side airbag. The system is
designed to help protect small (child size) occupants from frontal airbag
deployments when they are seated or restrained in the front passenger
seat contrary to proper child-seating or restraint usage
recommendations. Even with this technology, parents are STRONGLY
encouraged to always properly restrain children in the rear seat. The
sensor also turns off the passenger front airbag and passenger
seat-mounted side airbag when the passenger seat is empty and the
safety belt is unbuckled, or when a child or a small person occupies the
front passenger seat and the safety belt is unbuckled.

Front safety belt usage sensors

The front safety belt usage sensors detect whether or not the driver and
front outboard passenger safety belts are fastened. This information
allows your Personal Safety System to tailor the airbag deployment and
safety belt pretensioner activation depending upon safety belt usage.

Front safety belt pretensioners

The safety belt pretensioners at the front outboard seating positions are
designed to tighten the safety belts firmly against the occupant’s body
during frontal collisions and in side collisions when the side curtains and
side airbags are activated. This helps increase the effectiveness of the
safety belts. In frontal collisions, the safety belt pretensioners can be
activated alone or, if the collision is of sufficient severity, together with
the front airbags.

Seating and Safety Restraints

127

2011 Milan (mln)
Owners Guide, 1st Printing
USA (fus)

Front safety belt energy management retractors

The front outboard safety belt energy management retractors allow
webbing to be pulled out of the retractor in a gradual and controlled
manner in response to the occupant’s forward momentum. This helps
reduce the risk of force-related injuries to the occupant’s chest by
limiting the load on the occupant. Refer to Energy management
feature- front outboard section in this chapter.

Determining if the Personal Safety System is operational

The Personal Safety System uses a warning light in the instrument
cluster or a back-up tone to indicate the condition of the system. Refer
to the Warning lights and chimes section in the Instrument Cluster
chapter. Routine maintenance of the Personal Safety System is not
required.

The Restraints Control Module (RCM) monitors its own internal circuits
and the circuits for the airbag supplemental restraints, crash sensor(s),
safety belt pretensioners, front safety belt buckle sensors, driver seat
position sensor, and front passenger sensing system. In addition, the
RCM also monitors the restraints warning light in the instrument cluster.
A difficulty with the system is indicated by one or more of the following.
• The warning light will either flash or stay lit.
• The warning light will not illuminate immediately after ignition is

turned on.

• A series of five beeps will be heard. The tone pattern will repeat

periodically until the problem and warning light are repaired.

If any of these things happen, even intermittently, have the Personal
Safety System serviced at an authorized dealer immediately. Unless
serviced, the system may not function properly in the event of a
collision.

Safety belt precautions

WARNING: Always drive and ride with your seatback upright
and the lap belt snug and low across the hips.

WARNING: To reduce the risk of injury, make sure children sit
where they can be properly restrained.

Seating and Safety Restraints

128

2011 Milan (mln)
Owners Guide, 1st Printing
USA (fus)

Content .. 6 7 8 9 ..
