Ford Galaxy / Ford S-MAX. Manual - part 132
Engine - 2.0L EcoBoost SCTi
(149kW/203PS) - MI4 - Specifications
S-MAX/Galaxy 2006.5 (02/2006-)
Engine Data
Engine Oil
Engine Oil Capacity
Lubricants, Fluids, Sealers and Adhesives
Oil Pressure
Valve Clearance
Cylinder Head
Description
Engine code
TNBA
Firing order
1-4-3-2
Emission level
Stage V
Bore
87.5 mm
Stroke
83.1 mm
Cubic capacity
1999 cm³
Compression ratio
10 : 1
Power output at 6000 rpm
149 kW (203 PS)
Maximum torque at 1750 - 4000 rpm
300 Nm
Maximum engine speed (intermittent)
6800
Maximum engine speed (continous)
6500
Idle speed
760
Number of main bearings
5
Camshaft drive
Chain
Oil consumption
0.5 l/1000 Km
Viscosity / ambient temperature
Type
Specification
Recommended engine oil
SAE 5W-30 / below -20°C to over+40°C
Ford Formula E
WSS-M2C913-C
Alternative engine oils (for topping up only)
SAE 10W-40 / below -20°C to over +40°C
Ford Formula XR+
ACEA A3/B3
SAE 5W-40 / below -20°C to over +40°C
Ford Formula S/SD
ACEA A3/B3
Description
Liters
Service fill including filter
5.4
Service fill including filter
5.1
Spezifikationen
Sealant, oil pan contact surface to crankshaft rear seal retainer, oil pan to
cylinder block, oil pan to front cover, engine front cover to cylinder block/ oil
pan
WSE-M4G323-
A4
Oil pressure switch and engine front cover blanking plug sealant
WSK-M2G349-
A7
Description
Bar
Minimum oil pressure at 800 - 850 rpm (normal operating temperature)
1.0
Minimum oil pressure at 4000 rpm (normal operating temperature)
3.2 - 4.5
Description
mm
Valve clearance (engine cold), intake
0.19 - 0.31
Valve clearance (engine cold), exhaust
0.29 - 0.41
Description
mm
