Ford Galaxy / Ford S-MAX. Manual - part 31
Description
Shock absorber and spring assembly
Wheel knuckle
Wheel hub
Heat shield
Lower arm
Stabilizer bar
Front subframe
Vibration damper (if equipped)
Stabilizer bar clamp and bushing assembly
Stabilizer bar link
Shock absorber wiring harness
Item 1 : Shock absorber and spring assembly
Continuous damping control shock absorbers provide dynamic front suspension. A
continuous damping control shock absorber creates a damping force which depends on the
velocity of the vehicle and an electrical current applied to the continuous damping control
shock absorber. The electronic stability program (ESP) sensors, acceleration sensors and
displacement sensors provide information to the dynamic suspension electronic control unit
(ECU), which detects the state of heave, roll, pitch, cornering and acceleration of the
vehicle. The ECU then calculates the best damping characteristics for each wheel within 2
ms. The ECU sends an individual electrical current to each shock absorber to control the
amount of damping required.
Item
1
2
3
4
5
6
7
8
9
10
11
Part Number
-
-
-
-
-
-
-
-
-
-
-
