Ford Ranger EV (2001 year). Manual - part 34

206-04-4

Rear Disc Brake

REMOVAL AND INSTALLATION (Continued)

4. Remove the caliper.

1 Remove the bolts.
2 Remove the caliper.

5. Inspect the caliper for leaks and replace if

necessary.

6. Remove and clean the caliper slide pins. After

cleaning, lubricate with Silicone Brake Caliper
Grease D7AZ-19A331-A meeting Ford
specification ESE-M1C171-A.

Installation

1. To install, reverse the removal procedure.

•

After installation, bleed the brake system to
remove any air that has become trapped in
the system. Refer to Section 206-00 of the
1998 Ranger Workshop Manual.

206-04-5

Rear Disc Brake

REMOVAL AND INSTALLATION (Continued)

Rear Disc Brakes —Rotor

Removal

WARNING: Brake fluid contains polyglycol

ethers and polyglycols. Avoid contact with eyes.
Wash hands thoroughly after handling. If brake
fluid contacts eyes, flush eyes with running water
for 15 minutes. Get medical attention if irritation
persists if taken internally, drink water and
induce vomiting. Get medical attention
immediately.

CAUTION: Brake fluid is harmful to

painted and plastic surfaces If brake fluid is
spilled onto a painted or plastic surface,
immediately wash it with water.

1. Raise and support the vehicle. Refer to

Section

100-02

2. Remove the rear wheel.

1 Remove the center cap.
2 Remove the lug nuts.
3 Remove the wheel.
