Ford Fiesta (2011 year). Manual - part 29

4. NOTE: If the safety belt webbing retracts further

than the safety belt webbing stop, a new safety
belt retractor must be installed.

General Equipment: Webbing Retainer

E51474

200

mm

1

2

5. Torque: 35 Nm

E105814

6. Torque: 35 Nm

E105815

7.

G1090220en

501-10-

32

Seating

501-10-

32

DISASSEMBLY AND ASSEMBLY

201

E105816

1

2

8.

E105817

1

2

G1090220en

501-10-

33

Seating

501-10-

33

DISASSEMBLY AND ASSEMBLY

201

9.

Torque: 23 Nm

1.
2. Torque: 23 Nm

Torque: 40 Nm

3.

E108814

x2

x2

1

3

2

Assembly

10. To install, reverse the removal procedure.

11. General Equipment: Hog Ring Plier

V4001063

G1090220en

501-10-

34

Seating

501-10-

34

DISASSEMBLY AND ASSEMBLY

201
