Ford Falcon. Manual - part 410

501-05-9

Interior Trim and Ornamentation

501-05-9

REMOVAL AND INSTALLATION (Continued)

Installation

2.  Undo spare wheel board tie down and remove

spare wheel cover.(Refer removal of spare wheel

1.  Reverse removal procedure.

cover in this section.)

Headliner — Ute

Removal
1.  Remove A,B,C pillar interior trim parts.
2.  Remove sunvisors and check blocks.
3.  Remove grab handles and hook.
4.  Locate interior light wiring connector at base of

"A" pillar trim and disconnect.

5.  Remove barbed clips.
6.  Remove headlining via door opening.

3.  Remove 3 fir tree clips from front of cover lower

back.

Item

Description

1

Panel assy. roof trim

Installation
1.  Reverse removal procedure.

NOTE: Care should be taken when handling

Item

Description

headlining not to bend unnecessarily.

1

Fir tree clip

4.  Remove cover lower back with an upwards

Luggage Compartment Cover Lower

motion.

Back

NOTE: Be careful not to damage hooks located

on both the LH and RH extremities.

Removal
1. Lift

carpet.

Installation
1.  Reverse removal procedure.

G11864 en

501-05-10

Interior Trim and Ornamentation

501-05-10

REMOVAL AND INSTALLATION (Continued)

2.  Fold carpet from underneath seat backs into the

Luggage Compartment Quarter Trims

luggage compartment.

Removal

3. Remove

carpet.

1.  Remove 2 fir tree clips on luggage compartment

side.
NOTE: On high series vehicles that have luggage

net fitted, luggage net hook will be removed

instead of a fir tree.

Installation
1.  Reverse removal procedure.

Spare Wheel Board

Removal

Item

Description

1.  Fold carpet back.

1

Quarter trim

2

Fir tree clip

3

Fir tree clip

4

Plug

2.  Lower seat back in cabin. (Refer to Section

501-10.)

3.  Loosen package tray trim at front edge.
4.  Remove 2 fir tree clips located behind seat back.

2.  Undo spare wheel tie down.

Installation
1.  Reverse removal procedure.

Luggage Compartment Load Floor

Carpet

Item

Description

Removal

1

Strap

1.  Lower seat back in cabin. (Refer to Section

501-10.)

2

Cover

G11864 en

501-05-11

Interior Trim and Ornamentation

501-05-11

REMOVAL AND INSTALLATION (Continued)

Item

Description

Installation

3

Spare wheel

1.  Reverse removal procedure.

3.  Remove spare wheel board.

Decklid Trim

Installation

Removal

1.  Reverse removal procedure.

Short Wheel Base

Package Tray Insulator

1.  Remove 14 fir tree clips.

Removal

2.  Slide trim off decklid latch.

1.  Remove both LH and RH quarter trims.(Refer

removal of quarter trim in this section.)

2.  Remove package tray trim. (Refer to removal of

Parcel Shelf in this section.)

3.  Remove 2 fir tree clips located on front edge of

package tray insulator behind seat backs.

Item

Description

1

Decklid trim - SWB

2

Fir tree clips

Long Wheel Base

1.  Remove 13 fir tree clips.

Item

Description

2. Remove

pulldown

handle.

1

Package tray insulator

2

Fir tree clip

4.  Remove clips on rear edge of package tray

insulator.

Item

Description

1

Decklid trim - LWB

2

Fir tree clips

3

Pull down handle

Item

Description

3.  Slide decklid trim off decklid latch.

1

Package tray insulator

Installation

2

Plastic snap clip

1.  Reverse removal procedure.

5.  Bend part through the middle and slide through

pass through into luggage compartment.

G11869 en

501-05-12

Interior Trim and Ornamentation

501-05-12

REMOVAL AND INSTALLATION (Continued)

Front Door Watershield

Front Inner Scuff Plate (RH)

Removal

Removal

1.  Remove watershield as shown in figure.

1.  Remove plug from front of plate (dash panel side).

2.  Remove plug from door side.

Item

Description

1

Pull through hole in watershield

2

Front door trim watershield

Installation
1.  Reverse removal procedure.

Rear Door Watershield

Removal
1.  Remove watershield as shown in figure.

3.  Pull scuff plate towards centre of vehicle.

Installation
1.  Reverse removal procedure.

Installation
1.  Reverse removal procedure.

G11869 en
