Ford Falcon. Manual - part 409

501-05-5

Interior Trim and Ornamentation

501-05-5

REMOVAL AND INSTALLATION (Continued)

2.  Lever out and remove grab handle cap, taking

7.  Remove screws from grab handle.

care not to mark surface of door trim grab handle.

8.  Disengage door trim retention clips by pulling door

3.  Remove Interior Latch Release. For additional

trim away from sheet metal (in direction of arrow),

information, refer to Door Latch Interior Release in

starting at lower edge.

this section.

NOTE: Pull along edge of trim; do not use the

grab handle.

4.  Remove 2 lower screw covering caps and screws.
5.  Remove Rear upper screw fixing.
6.  Remove Front upper screw fixing.

Item

Description

1

Front door trim

Item

Description

2

Screw

1

Front door trim

9.  When trim is loose, lift up and over lock rod

2

Interior latch release

(indicated by circle).

3

Screw

10. Disconnect electrical connectors if required and

remove door trim panel assembly.

Installation
1.  Reverse removal procedure.

Rear Door Lo Series Trim Panel

Removal
NOTE: Rear door trim with pull cup / window winder.

For rear door trim with power windows, refer to Front

Door Trim notes for removal and installation.

1.  Remove pull cup screw.
2.  Remove pull cup.
3. Remove

Window

Winder.

G11871 en

501-05-6

Interior Trim and Ornamentation

501-05-6

REMOVAL AND INSTALLATION (Continued)

4.  Remove Door Latch Interior Release handle.

Rear Quarter Trim Panel — Wagon

Removal
1.  Follow removal instructions shown in figure.

Item

Description

1

Screw

2

Ash  tray

Item

Description

3

Rear door trim - Lo Series

1

Quarter panel trim

5.  Remove 2 lower screw fixings.

2

Sunvisor check block

6.  Remove forward upper screw fixing.

3

Luggage compartment carpet

7.  Remove rear upper screw fixing.

4

Wheel arch

5

Screw

Installation
1.  Reverse removal procedure.

Quarter Trim Panel — Ute

Removal
1.  Remove the right and left hand side quarter trim

panel as shown.

Item

Description

1

Rear door trim - Lo series

2

Screw

8.  Disengage door trim retention clips by pulling door

trim away from sheet metal. Start at lower edge,

working around the edge of the door trim.

9.  Disconnect electrical connectors if required and

remove door trim panel assembly.

Installation

Item

Description

1.  Reverse removal procedure.

1

Trim panel

2

Locator plug

Installation
1.  Reverse the removal procedure.

G11871 en

501-05-7

Interior Trim and Ornamentation

501-05-7

REMOVAL AND INSTALLATION (Continued)

Loadspace Trim Panel — Ute

Liftgate Lower Trim

Removal

Removal

1.  Follow removal instructions shown in figure.

1.  Follow removal instructions shown in figure.

Item

Description

Item

Description

1

Clip fir tree

1

Liftgate lower trim

2

Cover Assy Back panel trim

2

Pull strap

3

Child restraint anchorage

3

Scrivet

4

Nut and washer Assy. M6

Installation

5

Clip

1.  Reverse removal procedure.

Installation

Liftgate Upper Trim

1.  Reverse removal procedure.

Removal

Parcel Shelf

1.  Follow removal instructions shown in figure.

Removal
1.  Carefully remove the barbed clips. (4 x No. 1 and

1 x No. 2)

2.  Lift the Package tray trim from the parcel shelf

sheet metal.

Item

Description

1

Liftgate upper trim LH

2

Liftgate upper trim RH

3

Push on clip (Type A)

4

Push on clip (Type B)

Item

Description

Installation

1

Barbed clip no. 1

1.  Reverse removal procedure.

2

Barbed clip no. 2

Installation
1.  Reverse the removal procedure.

G11857 en

501-05-8

Interior Trim and Ornamentation

501-05-8

REMOVAL AND INSTALLATION (Continued)

8.  Remove headlining via liftgate opening.

Sunvisor

Removal
1.  Remove sunvisor as shown in figure.

Item

Description

1

Headlining

2

Barbed clip

Item

Description

3

Sunvisor check block

1

Sunvisor

Installation

2

Screw

1.  Reverse removal procedure.

3

Screw

NOTE: Care should be taken when handling

Installation

headlining not to be bend unnecessarily.

1.  Reverse the removal procedure.

Headliner — Sedan

Headliner — Wagon

Removal

Removal

1.  Remove grab handles and hook.

1.  Remove grab handles and hook.

2.  Remove sunvisors and check blocks.

2.  Remove sunvisors and check blocks.

3.  Remove A,B,C and pillar interior trim parts.

3.  Remove A,B,C and D pillar interior trim parts.

4.  Remove dome light lens and body and disconnect

4.  Remove dome light lens and body and disconnect

wiring.

wiring.

5.  Remove rear courtesy light lens and body and

disconnect wiring.

6.  Remove upper sections of door and liftgate

opening weatherstrip.

7.  Remove barbed clips.

Item

Description

1

Headlining

2

Barbed clip

3

Sunvisor check block

NOTE: Avoid folding or creasing the headlining during

removal.

G11857 en
