415-03-4 Speakers 415-03-4

REMOVAL AND INSTALLATION

Speakers — Door Mounted

Speaker — Package Tray Subwoofer

Removal and Installation

Removal and Installation

1.  Remove the front door trim panel. For additional

1.  Remove the package tray trim panel. For

information refer to Section 501-05.

additional information refer to Section 501-05.

Item

Description

Item

Description

1

Door trim panel

1

Package tray

2

Speaker

2

Screw

3

Body sheetmetal

2.  Remove the speaker retaining screws.

4

Speaker

3.  Remove the speaker and disconnect the electrical

connector.

5

Foam gasket

4.  To install, reverse the procedure

2.  Remove the foam gasket located on top of the

speaker.

Speakers — Package Tray

3.  Remove the speaker retaining screws.

Removal and Installation

4.  Remove the speaker and disconnect the electrical

connector.

1.  Remove the package tray trim panel. For

additional information refer to Section 501-05.

5.  To install, reverse the procedure

Speaker — Tweeter A-pillar

Removal and Installation
1.  Remove the A-pillar trim. For additional

information refer to Section 501-05.

Item

Description

1

Package tray

2

Speaker

2.  Remove the speaker retaining screws.
3.  Remove the speaker and disconnect the electrical

Item

Description

connector.

1

A-Pillar trim panel

4.  To install, reverse the procedure

2

Dashboard

G43922 en

415-03-5 Speakers 415-03-5

REMOVAL AND INSTALLATION (Continued)

Item

Description

Speaker — Ute Rear Quarter Panel

3

Rivet

Removal and Installation

4

Tweeter

1.  Remove the quarter trim panel. For additional

5

Body sheetmetal

information refer to Section 501-05.

2.  Remove the rivet attaching the tweeter bracket to

the sheetmetal .

3.  Remove the speaker and disconnect the electrical

connector.

4.  To install, reverse the procedure

Speaker — Wagon Rear Quarter Panel

Removal and Installation
1.  Remove the C pillar to quarter panel trim. For

additional information refer to Section 501-05.

Item

Description

1

Quarter trim panel

2

Screw

3

Body sheetmetal

4

Speaker

2.  Remove the speaker retaining screws.
3.  Remove the speaker and disconnect the electrical

connector .

4.  To install, reverse the procedure

Item

Description

1

Screw

2

Electrical connector

3

Body sheetmetal

4

Speaker

2.  Remove the speaker retaining screws.
3.  Remove the speaker and disconnect the electrical

connector.

4.  To install, reverse the procedure

G43926 en

417-01-1 Exterior

Lighting 417-01-1

SECTION : 417-01 Exterior Lighting

VEHICLE APPLICATION : 2003.0 BA Falcon
CONTENTS

PAGE

SPECIFICATIONS

 Specifications  .........................................................................................................................417-01-3

DESCRIPTION AND OPERATION

 Exterior Lighting  .....................................................................................................................417-01-4

  Twilight Sensor/Sun Load Sensor  ........................................................................................417-01-4

DIAGNOSIS AND TESTING

 Headlamps  .............................................................................................................................417-01-5

  Connector Circuit Reference  ................................................................................................417-01-5

  Inspection and Verification  ...................................................................................................417-01-8

 Symptom

Chart



....................................................................................................................417-01-8

 Pinpoint

Tests



......................................................................................................................417-01-9

  Turn Signal and Hazard Lamps  ...........................................................................................417-01-15

  Connector Circuit Reference  ..............................................................................................417-01-15

  Inspection and Verification  .................................................................................................417-01-20

 Symptom

Chart



..................................................................................................................417-01-20

 Pinpoint

Tests



....................................................................................................................417-01-20

  Stop  Lamps  ..........................................................................................................................417-01-23

  Connector Circuit Reference  ..............................................................................................417-01-23

  Inspection and Verification  .................................................................................................417-01-27

 Symptom

Chart



..................................................................................................................417-01-27

 Pinpoint

Tests



....................................................................................................................417-01-27

 Fog Lamps  ...........................................................................................................................417-01-30

  Connector Circuit Reference  ..............................................................................................417-01-30

  Inspection and Verification  .................................................................................................417-01-31

 Symptom

Chart



..................................................................................................................417-01-32

 Pinpoint

Tests



....................................................................................................................417-01-32

  Parking, Rear and License Lamps  .......................................................................................417-01-34

  Connector Circuit Reference  ..............................................................................................417-01-34

  Inspection and Verification  .................................................................................................417-01-39

 Symptom

Chart



..................................................................................................................417-01-39

 Pinpoint

Tests



....................................................................................................................417-01-40

 Reverse Lamps  ....................................................................................................................417-01-42

  Connector Circuit Reference  ..............................................................................................417-01-42

  Inspection and Verification  .................................................................................................417-01-45

 Symptom

Chart



..................................................................................................................417-01-45

 Pinpoint

Tests



....................................................................................................................417-01-45

GENERAL PROCEDURES

 Headlamp Adjustment  ..........................................................................................................417-01-48

REMOVAL AND INSTALLATION

 Headlamp Assembly  ............................................................................................................417-01-52

  Headlamp Bulb — High Beam H7  .......................................................................................417-01-52

  Headlamp Bulb — Low Beam H4  ........................................................................................417-01-52

 Turn Signal Bulb  ..................................................................................................................417-01-53

01/2003 2003.0 BA Falcon

417-01-2 Exterior

Lighting 417-01-2

(Continued)

 Parklamp Bulb  ......................................................................................................................417-01-53

 Auxiliary Lamp  .....................................................................................................................417-01-53

 Auxiliary Lamp Bulb  .............................................................................................................417-01-53

  Fog  Lamp  .............................................................................................................................417-01-54

 Fog Lamp Bulb  .....................................................................................................................417-01-54

  Tail Lamp Assembly — Sedan  ............................................................................................417-01-54

  Tail Lamp Assembly — Wagon  ...........................................................................................417-01-55

  Tail Lamp, Reverse Lamp and Rear Indicator Bulb — Sedan And Wagon .........................417-01-55

  Tail Lamp Assembly — Style Side Box  ...............................................................................417-01-55

  Rear Light Bulbs Replacement — Style Side Box  ...............................................................417-01-56

  Reverse Light Replacement — Style Side Box  ...................................................................417-01-56

  Tail Lamp Assembly — Tray  ................................................................................................417-01-56

  Rear Light Bulbs Replacement — Cable/Chassis and Tray  ................................................417-01-57

  Licence Plate Lamp Assembly  .............................................................................................417-01-57

  Licence Plate Bulb  ...............................................................................................................417-01-58

  Rear Licence Plate Lamp Replacement — Style Side Box  .................................................417-01-58

  Rear Licence Plate Lamp Replacement — Chassis/Cab and Tray  .....................................417-01-58

 Side Indicator Lamps  ...........................................................................................................417-01-58

  High Mount Stop Lamp — Sedan (Except LWB)  .................................................................417-01-59

  High Mount Stop Lamp — XR Series Sedan   ......................................................................417-01-59

  High Mount Stop Lamp Bulb — Wagon  ...............................................................................417-01-59

  High Mount Stop Lamp — LWB  ...........................................................................................417-01-60

  Twilight Sensor/Sun Load Sensor ........................................................................................417-01-60
