413-07-5 Clock 413-07-5

DIAGNOSIS AND TESTING (Continued)

Test Step

Result / Action to Take

VOLTAGE CHECK

Disconnect Clock.

Yes

Replace Clock.

Connect multimeter to pin ?? of Clock wiring connector and measure
voltage while varying IC illumination control switches.

Go to B1

Does the voltage vary?

PINPOINT TEST B : CLOCK NOT WORKING

Test Step

Result / Action to Take

CORRECT CONNECTION

Remove Clock from Instrument panel.

Yes

Continue.

Is the connector fully engaged ?

Engage connector and check functionality. Go to
B2 if still not functioning.

VOLTAGE CHECK

Disconnect Clock.

Yes

Replace clock.

Set multi meter to measure 12 volts and connect multimeter across
pins.

For (Y-B) and (B-LG) wires of Clock wiring connector and measure

Check wire integrity.

voltage.

Is 12 volts present.

PINPOINT TEST C : CLOCK LOSING / GAINING TIME

Test Step

Result / Action to Take

VOLTAGE CHECK

Yes

Continue.

Is battery voltage above 12 volts?

Refer batter service.

CLOCK CONDITION

Yes

Replace clock.

Does clock loose / gain more than five seconds every 24 hours?

Clock functioning correctly.

G86737 en

413-07-6 Clock 413-07-6

REMOVAL AND INSTALLATION

Clock

Removal
1. To remove the analogue clock, gently slide a flat

blade item ( eg. large screw driver) into the rear

margin, closest to the windscreen, and pry the

clock panel upwards to disengage the two clips.

2. Rotate this end up to disengage the interlocking

fingers attaching the clock panel to the air register

panel.

3. Disconnect the electrical connector.
Installation
1. To install the clock, first make the electrical

connection.

2. Ensure clock functions and illumination varies.
3. Ensure all interlocking fingers are aligned and

rotate the clock panel down wards to drive the

panel home and engage the two clips.

G73350 en

413-08-1

Interior Command Centre

413-08-1

SECTION : 413-08 Interior Command Centre

VEHICLE APPLICATION : 2003.0 BA Falcon
CONTENTS

PAGE

DESCRIPTION AND OPERATION

Interior Command Centre .....................................................................................................413-08-2

ICC Handling and Storage ....................................................................................................413-08-2

DIAGNOSIS AND TESTING

Interior Command Centre .....................................................................................................413-08-4

Principles

Operation

.............................................................................................................413-08-4

Inspection and Verification ...................................................................................................413-08-6

Symptom

Chart

....................................................................................................................413-08-9

Service

Procedures

............................................................................................................413-08-11

REMOVAL AND INSTALLATION

Interior Command Centre (ICC) ...........................................................................................413-08-19

Service Body Computer (BEM) ...........................................................................................413-08-23

Service Remote Key Receiver (RKR) .................................................................................413-08-25

Service Air Register ............................................................................................................413-08-25

Cabin Temperature Sensor ..................................................................................................413-08-26

413-08-2

Interior Command Centre

413-08-2

DESCRIPTION AND OPERATION

2. Warranty is void if ICC is dropped, handled

Interior Command Centre

roughly or treated outside of these guidelines.

The Interior Command Centre includes audio, climate 3. The ICC must not to be tilted beyond 90 degrees

control and auxiliary controls (i.e.. Door locks,

from upright. At no stage can the ICC be shocked

courtesy lamps, interior lamps) displayed in a

or excessively vibrated. Such action may damage

centralised area. System status is displayed on a

the Audio mechanism. Warranty will be void if

screen built into the instrument panel.

these conditions are not met.

The Interior Command Centre screen is

4. The ICC contains many delicate mechanical and

monochromatic for low series screens. High series

electrical components. Special care must be

vehicles receive a colour screen. Vehicles with

taken. The following are important :

Sat-Nav optioned also receive a colour screen.

1. DO NOT scratch the Class A appearance

Features of each screen are highlighted below:

surfaces.

1. LCD for low series:

2. DO NOT apply excess pressure to the screen

Monochromatic

surface at any time.

Uses preset symbols to display information

3. DO NOT apply force in excess of 10 kg to any

appearance surface of the ICC.

2. TFT for high series:

4. DO NOT touch the pins of the Self-aligning

Full colour

connector at the rear of the Audio Module.

Reconfigurable screen settings

5. DO NOT touch the Cabin Temperature

Video input for Sat-Nav, as well as preset

Sensor (refer illustration).

screens

6. DO NOT apply pressure to any of the

The Interior Command Centre consists of the

switches, knobs or buttons exceeding 5 kg.

following base components:

7. AVOID all contact with dirt, dust, metal flakes,

Audio features:

metal shavings.

LCD screen

5. The ICC is sensitive to Electro Static Discharge.

Loud button

Avoid all contact with static electricity and all

Tuning/Track select

precautions must be undertaken to ensure

adequate grounding of the repair technician and

Auto store

the ICC Module outside of the vehicle

CD eject button

environment to avoid ESD damage.

CD mode button

6. Avoid all contact with any liquids : soft drinks,

Mode select button

water, hot drinks, alcohol, etc. ICC electronic

Audio On/Off/Volume button

components will be damaged by any contact with

liquids.

FM/AM select buttons

7. ICC is not to be disassembled except for

HVAC features:

recognised service items. The only recognised

A/C on/off

service items are the Body Computer (BEM), Air

Automatic Climate Control On/Off

These individual components are to be removed

Driver/Passenger temp settings

in tact as required, according to the Service

Front windscreen demist

Manual requirements. Components are not to be

Air distribution modes

tampered with or else component warranty is

Fresh/Recirc air inlet

voided.

Blower fan speed

8. ICC storage temperature is never to exceed the

range -30

°C to +85°C.

Ambient temperature display

9. Adhesive labels cannot be used on CD’s as they

Rear demist (heated backlight)

can peel off and damage internal mechanisms.

Door lock

The use of a disc that deviates from above

Dome lamp

industrial standards, use of soiled, scratched,

For further information regarding the function of each

dented, cracked, or warped discs and use of

button, please refer to the Owners Guide.

pirated discs, etc. will void a warranty claim.

Sumitomo will not accept a warranty claim if any

ICC Handling and Storage

part of the audio unit or ICC has been damaged

by the use of an "unsupported" disc.

1. ICC must be handled appropriately. Grab points

are shown in illustrations.

G73346 en
