Reading Lamps

Vehicles with Interior Sensors

2

2

1

E72786

1.

Carefully remove the lamp.

2. Turn the bulb holder counterclockwise

and remove it.

E73939

3

3. Remove the bulb.

Vehicles without Interior Sensors

E99453

2

3

1

1.

Carefully remove the lamp.

2. Turn the bulb holder counterclockwise

and remove it.

3. Remove the bulb.

Sun Visor Mirror Lamp

E72785

1.

Carefully remove the lamp.

2. Remove the bulb.

BULB SPECIFICATION CHART

Exterior Lamps

Power (Watt)

Specification

Lamp

5

168

Front side marker lamp.

5

W5W

Front I.D. lamp.

55

H11

Headlamp low beam and Daytime
running lamp.

60

9005

Headlamp high beam.

21

3457NAK

Front direction indicator.

5

W5W

Side direction indicator.

5

W5W

Front clearance lamp (Exterior mirror).

26/6

3057K

Brake, rear and direction indicator
lamp.

5

168

Rear clearance lamp.

26

3057K

Reversing lamp.

5

W5W

License plate lamp.

Note: If your vehicle is fitted with LED lamps these are not serviceable items, see an
authorized dealer if they fail.

Interior Lamps

Power (watt)

Specification

Lamp

6

W6W

Front interior lamp.

6

Festoon

Front interior lamp. Vehicles with
category 1 alarm.

6

W6W

Map lamp.

10

211 Festoon

Side door entrance lamp.

10

211 Festoon

Luggage compartment lamp.

Note: If your vehicle is fitted with LED lamps these are not serviceable items, see an
authorized dealer if they fail.

CHANGING THE ENGINE AIR
FILTER - 3.2L POWER STROKE
DIESEL

WARNING

To reduce the risk of vehicle damage
and personal burn injuries, do not
start your engine with the air cleaner

removed and do not remove it while the
engine is running.

Note: Failure to use the correct air filter
element may result in severe engine
damage. The vehicle warranty may be void
for any damage to the engine if the correct
air filter element is not used.

Note: After operating the vehicle up to
200 mi (320 km) in heavy snowfall, we
recommend that you open the hood at the
earliest opportunity and clear the snow and
ice from air filter housing. Do not remove the
foam filter.

E177563

The foam filter must be in place
at all times.

Only use the specified air filter. See
Capacities and Specifications (page
299).

Change the air filter element and foam
filler at the proper interval. See Scheduled
Maintenance (page 454).

E174609

1

2

3

1.

Disconnect the mass air flow sensor
electrical connector and cable from
the air filter cover.

2. Clean the area around the air tube to

air filter cover connection to prevent
debris from entering the system and
then loosen the bolt on the air tube
clamp so the clamp is no longer snug
to the air tube. It is not necessary to
completely remove the clamp. Pull the
air tube off from the air filter cover.

3. Release the clamps that secures the

air filter cover to the air filter housing.

E177562

3

5

4. Carefully lift the air filter housing cover.

Remove the air filter element from the
air filter housing.

5. Install a new air filter element. Make

sure that the groove seal on the
pleated paper filter traps both sides of
the vertical partition of the air box.

6. Replace the air filter housing. Engage

the clamps that secure the air filter
housing cover to the air filter housing.
Be careful not to crimp the filter
element edges between the air filter
housing and cover. Make sure that the
tabs on the edge are correctly aligned
into the slots.

7.

Slip the air tube onto the air filter cover
and snugly tighten the bolt on the air
tube clamp, but do not overtighten.

8. Reconnect the mass air flow sensor

electrical connector to the outlet tube.
Make sure the locking tab on the
connector is in the locked position.

CHANGING THE ENGINE AIR
FILTER - 3.5L ECOBOOST™

WARNING

To reduce the risk of vehicle damage
and personal burn injuries, do not
start your engine with the air cleaner

removed and do not remove it while the
engine is running.

Note:  Failure to use the correct air filter
element may result in severe engine
damage.  The vehicle Warranty may be void
for any damage to the engine if the correct
air filter element is not used.

Only use the specified air filter. See
Capacities and Specifications (page
299).

Change the air filter element at the proper
interval. See Scheduled Maintenance
(page 454).

E174607

1

2

3

1.

Disconnect the intake air temperature
sensor electrical connector and cable
from the air filter cover.

2. Clean the area around the air tube to

air filter cover connection to prevent
debris from entering the system and
then loosen the bolt on the air tube
clamp so the clamp is no longer snug
to the air tube. It is not necessary to
completely remove the clamp. Pull the
air tube off from the air filter cover.

3. Release the clamps that secure the air

filter cover to the air filter housing.

E174669

4. Carefully lift the air filter housing cover.

Remove the air filter element from the
air filter housing.

5. Install a new air filter element.
