Ford Transit (2018 year). Manual - part 58

BRAKE FLUID CHECK

WARNINGS

Do not use any fluid other than the
recommended brake fluid as this will
reduce brake efficiency. Use of

incorrect fluid could result in the loss of
vehicle control, serious personal injury or
death.

Only use brake fluid from a sealed
container. Contamination with dirt,
water, petroleum products or other

materials may result in brake system
damage or failure. Failure to adhere to this
warning could result in the loss of vehicle
control, serious personal injury or death.

Do not allow the fluid to touch your
skin or eyes. If this happens, rinse the
affected areas immediately with

plenty of water and contact your physician.

A fluid level between the MAX and
MIN lines is within the normal
operating range and there is no need

to add fluid. A fluid level not in the normal
operating range could compromise the
performance of the system. Have your
vehicle checked immediately.

To avoid fluid contamination, the reservoir
cap must remain in place and fully tight,
unless you are adding fluid.

Only use fluid that meets Ford
specifications.  See Capacities and
Specifications (page 299).

POWER STEERING FLUID
CHECK

WARNING

Do not allow the fluid to touch your
skin or eyes. This could cause serious
personal injury. Rinse the affected

areas immediately with plenty of water
and consult a physician.

If the power steering fluid level is not
between the MAX and MIN marks, add
power steering fluid that meets the correct
specification.  See Capacities and
Specifications (page 310).

Adding Power Steering Fluid

1.

Remove the filler cap.

2. Add power steering fluid to the MAX

mark. Do not overfill.

3. Replace the filler cap. Turn it until you

feel a strong resistance.

WASHER FLUID CHECK

Note: The reservoir supplies the front and
rear washer systems.

When adding fluid, use a mixture of washer
fluid and water to help prevent freezing in
cold weather and improve the cleaning
capability. We recommend that you use
only high quality washer fluid.

For information on fluid dilution, refer to
the product instructions.

DRAINING THE FUEL FILTER
WATER TRAP - 3.2L POWER
STROKE DIESEL

WARNING

Do not dispose of fuel in the
household refuse or the public
sewage system. Use an authorized

waste disposal facility.

Your vehicle is fitted with a diesel fuel
conditioner module located behind the fuel
tank.

A warning lamp will illuminate
and a message will be displayed
when approximately 3.38 fl oz

(100 ml) of water accumulates in the
module. If you allow the water level to
exceed this level, the water may pass
through to the engine and may cause fuel
injection equipment damage.

Note: To drain the fuel filter water trap,
access the underside of your vehicle.

E177378

2

1

1.

Attach a tube to the drain plug and
place the end of the tube into a
suitable container.

2. Loosen the drain plug by turning

counterclockwise one to two turns and
allow the water to drain.

Note: The drain plug will rise when opening.

3. Tighten the drain plug by turning

clockwise until you feel a strong
resistance.

Note: The drain plug will lower when
closing.

When you start the engine the water in fuel
indicator lamp turns off after a short period
of time.

Changing the Fuel Filter

Note: To drain the fuel filter, access the
underside of your vehicle.

1.

Drain the fuel from the filter housing.

E184430

2

3

2. Disconnect the electrical connector.

3. Rotate the housing counterclockwise

to the unlock position.

4. Remove the housing and filter.

5. Replace the housing seal and lubricate.

6. Insert the new filter into housing and

refit aligning the arrows in the unlock
position.

E184789

7

7.

Rotate the housing clockwise aligning
the arrows in the lock position.

8. Purge air from the system.

Note: Only add fuel that meets the Ford
specification.  See Fuel and Refueling
(page 126).

Purging Air From the Fuel System

1.

Switch the ignition on for at least 30
seconds then switch the ignition off.

2. Repeat this process six times.

3. Start the engine and maintain engine

speed at 1500 RPM.

4. Wait 20 seconds.

5. If the engine is running smoothly,

reduce the engine speed to idle.

6. Check for leaks.

7.

Switch the ignition off.

If the Engine Does Not Start or Runs
Rough

E177379

1

1.

Remove the Schrader valve cap.

2. Attach suitable tool with a tube to the

Schrader valve and place the end of
the tube into a suitable container.

3. Open the Schrader valve.

4. Switch the ignition on until a steady

stream of fuel can be seen coming out
of the tube.

5. Switch the ignition off.

6. Remove the tool from the Schrader

valve.

7.

Refit the Schrader valve cap.

8. Switch the ignition on for at least 30

seconds then switch the ignition off.

9. Repeat this process three times.

10.

Start the engine.

FUEL FILTER - GASOLINE

Your vehicle is equipped with a lifetime
fuel filter that is integrated with the fuel
tank. Regular maintenance or replacement
is not needed.

CHANGING THE 12V BATTERY

Removing the Battery

WARNINGS

You must replace your vehicle
battery with one of exactly the same
specification.

Make sure the battery box is correctly
sealed.

Your vehicle battery is heavy; take
care when lifting and removing.

Note: If you have power seats and the
battery has no charge, jump-start your
vehicle to move the seat.  See Jump
Starting the Vehicle (page 191).

Note: Where applicable you must
reprogram the audio system using the
keycode.

The battery is located inside your vehicle
under the driver seat.

E152526

1

1.

Fully raise the driver seat and slide the
seat fully forward. Remove the cover
trim by pulling up the tabs with your
fingers.
