Parking Brake On Warning Chime

Sounds when you have left the parking
brake on and drive your vehicle. If the
warning chime remains on after you have
released the parking brake, have your
vehicle checked by an authorized dealer
immediately.

Automatic Transmission Warning
Chime

Sounds when you have not moved the
transmission selector lever to park. A
message will be shown in the display.

GENERAL INFORMATION

WARNING

Driving while distracted can result in
loss of vehicle control, crash and
injury. We strongly recommend that

you use extreme caution when using any
device that may take your focus off the
road. Your primary responsibility is the safe
operation of your vehicle. We recommend
against the use of any hand-held device
while driving and encourage the use of
voice-operated systems when possible.
Make sure you are aware of all applicable
local laws that may affect the use of
electronic devices while driving.

Information Display Controls

E138659

Use the information display controls on
the steering wheel to adjust various system
settings on your vehicle.  The information
display shows the system settings.

•

Press the up or down arrow buttons to
scroll through and highlight the options
within a menu.

•

Press the right arrow button to enter a
submenu.

•

Press the left arrow button to exit a
submenu.

•

Press the OK button to choose and
confirm settings or messages.

Menu Structure

Note: Some menus may show features as
used in different models, so may appear
different to you on your vehicle.

Trip 1 and 2

1

Distance to E

Trip Odometer

Trip Timer

Anticipation

Ford EcoMode

Average Fuel

Speed

Trip 1 and 2

1

Ford EcoMode

Average Speed

Outside Temp.

Instantaneous Fuel

All values

Distance to E

Trip Odometer

Average Fuel

1

 See Trip Computer (page 86).

Information

MyKey

MyKey Info

System Check

Settings

Traction Ctrl

Driver Assist

Blindspot

Cross traffic alrt

Hill Start Assist

Rain Light

Lighting

DRL

Hdlamp Delay

Navigation info

Display

Choose your applicable setting.

Language

Choose your applicable setting.

Distance

Choose your applicable setting.

Temperature

Information

Chimes

Settings

Warning

Display

Compass

Convenience

Calibrate

Set Zone

Create MyKey

Create MyKey

MyKey

Always On

Traction Ctrl

User selectable

Always On

911 Assist

User selectable

Choose your applicable setting.

Max Speed

Choose your applicable setting.

Speed Warning

Volume Limiter

Always On

Do Not Disturb

User selectable

Clear MyKey

Clear MyKeys

CLOCK

Type 1

To adjust the clock, switch the ignition on
and press buttons H or M on the
information and entertainment display as
necessary.

Type 2

Note: Use the information display to adjust
the clock.  See General Information (page
84).

TRIP COMPUTER

Resetting the Trip Computer

Press and hold OK on the current screen
to reset the respective trip, distance, time
and average fuel information.

Trip Odometer

Registers the distance traveled of
individual journeys.

Distance to Empty

Indicates the approximate distance your
vehicle will travel on the fuel remaining in
the tank. Changes in driving pattern may
cause the value to vary.
