Vehicles With Front Fog Lamps

E231828

Press repeatedly or press and hold until
you reach the desired level.

Vehicles Without Front Fog Lamps

A

B

E165366

Press repeatedly or press and
hold to dim.

A

Press repeatedly or press and
hold to brighten.

B

DAYTIME RUNNING LAMPS

WARNING

The daytime running lamps system
does not activate the rear lamps and
may not provide adequate lighting

during low visibility driving conditions.
Make sure you switch the headlamps on,
as appropriate, during all low visibility
conditions. Failure to do so may result in a
crash.

Type One - Conventional (Non-
Configurable)

The daytime running lamps turn on when:
1.

Switching the ignition on.

2. The transmission is not in park (P) for

vehicles with automatic transmissions,
or releasing the parking brake for
vehicles with manual transmissions.

3. The lighting control is in the off, parking

lamp or autolamps positions.

4. The headlamps are off.

Type Two - Configurable

Switch the daytime running lamps on or
off using the information display.  See
Information Displays (page 114).

The daytime running lamps turn on when:
1.

The lamps are on in the information
display.

2. Switching the ignition on.
3. The transmission is not in park (P) for

vehicles with automatic transmissions,
or releasing the parking brake for
vehicles with manual transmissions.

4. The lighting control is in the autolamps

position.

5. The headlamps are off.

The other lighting control switch positions
do not turn on the daytime running lamps.

If the daytime running lamps are off in the
information display, the lamps stay off in
all switch positions.

AUTOMATIC HIGH BEAM
CONTROL

 (If Equipped)

WARNING

The system does not relieve you of
your responsibility to drive with due
care and attention. You may need to

override the system if it does not turn the
high beams on or off.

The system turns on high beams if it is dark
enough and no other traffic is present. If it
detects an approaching vehicle’s
headlamps or tail lamps, or street lighting
ahead, the system turns off high beams
before they can distract other road users.
Low beams remain on.

Note: The system may not operate properly
if the sensor is blocked. Keep the windshield
free from obstruction or damage.

Note: The system may not operate properly
in cold or inclement conditions. You can
switch on the high beams by overriding the
system.

Note: If the system detects a blockage, for
example bird droppings, bug splatter, snow
or ice, the system goes into low beam mode
until you clear the blockage. A message may
appear in the information display if the
camera is blocked.

Note: Using much larger tires or equipping
vehicle accessories such as snowplows can
modify your vehicle's ride height and
degrade automatic high beam control
performance.

A camera sensor, centrally mounted
behind the windshield of your vehicle,
continuously monitors conditions to turn
the high beams on and off.

Once the system is active, the high beams
turn on if:
•

The ambient light level is low enough.

•

There is no traffic in front of your
vehicle.

•

The vehicle speed is greater than
approximately 32 mph (51 km/h).

The high beams turn off if:
•

The ambient light level is high enough
that high beams are not required.

•

The system detects an approaching
vehicle's headlamps or tail lamps.

•

The vehicle speed falls below
approximately 27 mph (44 km/h).

•

The system detects severe rain, snow
or fog.

•

The camera is blocked.

Switching the System On and Off

Switch the system on using the information
display.  See Information Displays (page
114).

E142451

Switch the lighting control to the
autolamps position.  See Autolamps
(page 90).

Overriding the System

When you switch on the high beams,
pushing or pulling the stalk provides a
temporary override to low beam.

Automatic High Beam Indicator

 (If

Equipped)

The indicator lamp illuminates
to confirm when the system is
ready to assist.

FRONT FOG LAMPS

 (If Equipped)

E142453

Press the control to switch the fog lamps
on or off.

You can switch the fog lamps on when the
lighting control is in any position except
Off and the high beams are not on.

DIRECTION INDICATORS

E163272

•

To operate the left direction indicator,
push the lever down until it stops.

•

To operate the right direction indicator,
push the lever up until it stops.

Note: Tap the lever up or down to make the
direction indicators flash three times.

SPOT LAMPS

 (If Equipped)

The spot lamps are on the forward-facing
side of the exterior mirrors. Switch on the
spot lamps by pressing the buttons above
the lighting control with the parking lamps
on.

E176842

When switching on the spot lamps, the
area in front of and to the side of your
vehicle illuminates.

Adjust the aim of the spot lamps by
moving the position of the exterior mirrors.

For manual folding mirrors, adjust the aim
of the lamps by folding the exterior mirrors
into or away from the windows. For
power-folding mirrors, use the switch on
the driver-side door.

Note: The spot lamps turn off when you
reach a speed of 6 mph (10 km/h).

Cargo and Trailer Hookup Lamps

(If Equipped)

The cargo lamps are in the central high
mounted stop lamp, and to either side of
the cargo box.

The trailer hookup lamp is on the tailgate
next to the handle.

E189587

Pressing the button in the
lighting control panel or the
button in the cargo box near the

lamp turns on both of these lamps.

E190880

If you switch on the cargo lamps, the cargo
and trailer hitch area illuminate.

Note: The cargo and trailer hookup lamps
turn off when you reach a speed of 3 mph
(5 km/h). They also turn off after 10
minutes, fading gradually to off.

INTERIOR LAMPS

The lamps turn on under the following
conditions:
•

You open any door.

•

You press a remote control button.

Front Interior Lamps

Note: The front interior lamp switches are
on the overhead console. The exact location
of each button on the overhead console
depends upon your vehicle features.

Note: Press the button to switch the door
function off when you open any door. When
the door function is off and you open a door,
the courtesy and door lamps stay off. The
indicator lamp lights amber when the door
function is off.

Note:  Press the button again to switch the
door function back on. When the door
function is on and you open a door, the
courtesy and door lamps turn on. The
indicator lamp lights blue when the door
function is on.
