Ford Super Duty (2018 year). Manual - part 23

Type One

E199032

C

C

A

B

Door function.

A.

All lamps on.

B.

Map lamps.

C.

Type Two

E192153

D

D

C

A

B

All lamps on.

A.

Door function.

B.

All lamps off.

C.

Map lamps.

D.

Type Three

E201073

A

D

C

B

Map lamp.

A.

Door function.

B.

All lamps off.

C.

Map lamp.

D.

E187342

All lamps on.

A.

Door function.

B.

Rear Interior Lamps

 (If Equipped)

Type One

E182517

Individual lamp.

A.

Individual lamp.

B.

Type Two

E187343

Type Three

E187345

Press the button to switch the lamps on
or off.

AMBIENT LIGHTING

 (If Equipped)

Adjust the ambient lighting using the
touchscreen. See your SYNC information.

POWER WINDOWS

 (If Equipped)

WARNINGS

Do not leave children unattended in
your vehicle and do not let them play
with the power windows. They may

seriously injure themselves.

When closing the power windows,
you should verify they are free of
obstructions and make sure that

children and pets are not in the proximity
of the window openings.

E176215

Press the control to open the window.

Lift the control to close the window.

Note: You may hear a pulsing noise when
just one of the windows is open. Lower the
opposite window slightly to reduce this
noise.

One-Touch Up or Down

 (If Equipped)

Press or lift the switch fully and release it.
Press or lift it again to stop the window.

Note: The window may disable for up to
five minutes if you cycle it up and down
repeatedly. This helps prevent damage to
the motor. Normal operation will resume
once the motor cools.

Restoring the One-Touch Up Function

You may lose the one-touch function if the
vehicle battery is low.

To reset the function after the battery
recharges:

1.

Pull the switch all the way up.

2. Hold the switch until the glass stops

and continue to hold for two seconds.

3. Press the switch down and operate the

window to the full down position.
One-touch up will now be functional.

Note: Perform one-touch up re-calibration
with the door closed. Calibrating with the
door open will cause the window to
continuously bounce back.

Bounce-Back

 (If Equipped)

The window will automatically stop and
reverse some distance if it detects an
obstacle while closing.

Overriding the Bounce-Back Feature

WARNING

When you override the bounce-back
feature the window will not reverse
if it detects an obstacle. Take care

when closing the windows to avoid
personal injury or damage to your vehicle.

Pull up the window switch and hold within
two seconds of the window reaching the
bounce-back position. The window will
travel up with no bounce-back protection.
The window will stop if you release the
switch before the window closes fully.
