Ford Fusion (2018 year). Manual - part 25

Driver Assist

Traction Control - check enabled or uncheck disabled

Sport or Normal

Steering in D

Adaptive Steering

Sport or Normal

Steering in S

Blind Spot - check enabled or uncheck disabled

Cross Traffic Alert - check enabled or uncheck disabled

Adaptive or Normal

Cruise Control

Driver Alert or Driver Alert Display

Driver Alert

Hill Start Assist - check enabled or uncheck disabled

Alert, Aid or Both

Mode

Lane Keeping System

High, Normal or Low

Intensity

High, Normal or Low

Alert Sensitivity

Pre-Collision

Active Braking - check enabled or uncheck
disabled

Front Park Aid - check enabled or uncheck disabled

Rear Park Aid - check enabled or uncheck disabled

Tire Monitor - Hold OK to Reset

Tire Monitor

Settings

In this mode, you can configure different
driver setting choices.

Note: Some items are optional and may
not appear.

Settings

Auto Engine Off - check enabled or uncheck disabled

Vehicle

Easy Entry/Exit - check enabled or uncheck disabled

Auto Highbeam - check enabled or uncheck disabled

Lighting

Off or XX Seconds

Autolamp Delay

Daytime Lights - check enabled or uncheck disabled

Autolock - check enabled or uncheck disabled

Locks

Settings

Autounlock - check enabled or uncheck disabled

Mislock - check enabled or uncheck disabled

All Doors or Driver First

Remote Unlock

Switch Inhibit - check enabled or uncheck disabled

Autofold - check enabled or uncheck disabled

Mirrors

XXX% - Hold OK to Reset

Oil Life
Rest

Auto or Last setting

Climate Control

Remote
Start

Auto or Off

Seats or Seats and
Wheel

5, 10 or 15 minutes

Duration

System - check enabled or uncheck disabled

Seatbelts

Remote Open or Remote Close

Windows

Courtesy Wipe or Rain Sensing

Wipers

Hold OK to Create MyKey

Create
MyKey

MyKey

Always On or User Selectable

911
Assist

On or Off

Do Not
Disturb

Always On or User Selectable

Traction
Control

Choose desired speed or Off

Max
Speed

Choose desired speed or Off

Speed
Minder

Volume Limiter - check enabled or uncheck disabled

Hold OK to Clear All MyKeys

Clear
MyKeys

Settings

Miles & Gallons, l/100km or km/l

Distance

Display
Setup

Fuel Gauge or Fuel + Tach

Gauge
Display

°Fahrenheit or °Celsius

Temper-
ature

psi, kPa or bar

Tire Pres-
sure

Choose your applicable setting

Language

INFORMATION MESSAGES

Note: Depending on the vehicle options
equipped with your vehicle, not all of the
messages will display or be available.
Certain messages may be abbreviated or
shortened depending upon which cluster
type you have.

E144636

Press the OK button to acknowledge and
remove some messages from the
information display. Other messages will
be removed automatically after a short
time.

Certain messages need to be confirmed
before you can access the menus.

Active Park

Action

Message

The system requires service due to a malfunction. Have the

system checked by an authorized dealer.

Active Park Fault

Adaptive Cruise Control

Action

Message

A radar malfunction is preventing the adaptive cruise control

from engaging.  See Using Adaptive Cruise Control (page

196).

Adaptive Cruise

Malfunction

A condition exists such that the adaptive cruise cannot func-

tion properly.  See Using Adaptive Cruise Control (page

196).

Adaptive Cruise Not

Available

You have a blocked sensor due to bad weather, ice, mud or

water in front of the radar sensor. You can typically clean the
sensor to resolve.  See Using Adaptive Cruise Control (page

196).

Adaptive Cruise Not

Available Sensor

Blocked See Manual

The system has disabled the automatic braking.

Normal Cruise Active

Automatic Braking

Turned Off

A radar malfunction is preventing the adaptive cruise control

from engaging.

Front Sensor Not Aligned

The adaptive cruise has reinstated controls to the driver.

Adaptive Cruise - Driver

Resume Control

Your vehicle speed is too slow to activate the adaptive cruise.

Adaptive Cruise Speed

Too Low to Activate

The adaptive cruise is automatically adjusting the gap

distance and you need to shift the transmission into a lower

gear.

Adaptive Cruise Shift

Down

AdvanceTrac®

Action

Message

The system detects a malfunction due to a blocked sensor.

Service AdvanceTrac

The traction control has been switch on or off.

AdvanceTrac Off On
