Driver Assist

Front Park Aid - check enabled or uncheck disabled

Rear Park Aid - check enabled or uncheck disabled

Tire Pressure

Tire Monitor

1

Type 2

Settings

Auto Engine Off - check enabled or uncheck disabled

Vehicle

Easy Entry/Exit - check enabled or uncheck disabled

Off or XX Seconds

Autolamp delay

Lighting

Autolock - check enabled or uncheck disabled

Locks

Autounlock - check enabled or uncheck disabled

Mislock - check enabled or uncheck disabled

All Doors or Driver's Door

Remote Unlock

Switches inhibit - check enabled or uncheck disabled

oil Life XXX% - Hold OK to Reset

Oil Life
Rest

Auto or Last Settings

Climate Control

Remote
Start

Automatic or Off

Driver Seat or Seats
and Wheel

5, 10 or 15 minutes

Duration

System - check enabled or uncheck disabled

Remote Open or Remote Close

Windows

Courtesy Wipe or Rain Sensing

Wipers

Hold OK to Create MyKey

Create
MyKey

MyKey

Always On or User Selectable

911
Assist

On or Off

Do Not
Disturb

Settings

Always On or User Selectable

Traction
Control

Choose desired speed or Off

Max
Speed

Choose desired speed or Off

Speed
Minder

Volume Limiter - check enabled or uncheck disabled

Hold OK to Clear All MyKeys

Clear
MyKeys

Miles & Gallons, L/100km or km/L

Distance

Display
Setup

Fahrenheit (°F) or Celsius (°C)

Temper-
ature

psi, kPa or bar

Tire Pres-
sure

Choose your applicable setting

Language

1

 Type 2

Information Display Controls
(Type 3)

E144638

•

Press the up and down arrow buttons
to scroll through and highlight the
options within a menu.

•

Press the right arrow button to enter a
sub-menu.

•

Press the left arrow button to exit a
menu.

•

Press and hold the left arrow button at
any time to return to the main menu
display (escape button).

•

Press the OK button to choose and
confirm settings or messages.

Main menu

From the main menu bar on the left side
of the information display, you can choose
from the following categories:

•

Display Mode

•

Trip 1 & 2

•

Fuel Economy

•

Driver Assist

•

Settings

Scroll up or down to highlight one of the
categories, then press the right arrow key
or OK to enter into that category. Press the
left arrow key as needed to exit back to the
main menu.

Display Mode

Use the up/down arrow buttons to choose
between the following display options.

Option 6

Option 5

Option 4

Option 3

Option 2

Option 1

Display mode

-

-

-

-

X

X

XXX mi (km) to
empty

X

X

X

X

X

X

Fuel gauge

-

-

X

X

-

-

Round tachometer

X

X

-

-

X

-

Vertical tachometer

-

-

X

-

-

-

Engine coolant
temp gauge

-

X

-

-

-

-

Tire Pressure

X

-

-

-

-

-

Speedometer

Intelligent AWD - AWD Gauge

•

XXX mi (km) to empty - Shows the approximate distance the vehicle will travel.

•

Fuel gauge - Indicates approximately how much fuel is left in the fuel tank. The fuel
gauge may vary slightly when the vehicle is in motion or on a grade. When the fuel
level becomes low, the level indicator will change to amber. When the fuel level
becomes critically low, the level indicator will change to red. Note: When a MyKey®
is in use, low fuel warnings will display earlier. The fuel icon and arrow indicates which
side of the vehicle the fuel filler door is located.

•

Round tachometer - Indicates the engine speed in revolutions per minute. Driving with
your tachometer pointer continuously at the top of the scale may damage the engine.
During SelectShift Automatic™ transmission (SST) use, the currently selected gear
will appear in the display.

•

Engine coolant temperature gauge - Indicates engine coolant temperature. At normal
operating temperature, the level indicator will be in the normal range. If the engine
coolant temperature exceeds the normal range, stop the vehicle as soon as safely
possible, switch off the engine and let the engine cool.

•

Tire Pressure - Shows the tire pressure of each wheel on your vehicle.

•

Speedometer - Shows the speed your vehicle is traveling.

Trip 1 & 2

You can access the menu using the
information display control.

Note: Some options may appear slightly
different or not at all if the items are
optional.

Trip 1 and 2

All Values

All Values — shows all trip values (Trip Timer, Odometer and Average Fuel).

•

Trip Odometer — Shows your accumulated trip distance.

•

Trip Timer— The timer stops when you turn your vehicle off and restarts when you
restart your vehicle.

•

Average Fuel — Shows your average fuel economy for a given trip.

Note: You can reset your trip information by pressing and holding the OK button on the left
hand steering wheel controls.

Fuel Economy

Use the left and right arrow buttons to
choose the desired fuel economy display.

Fuel Economy

Instant Fuel Economy - Hold OK to Reset

Fuel History

Average Speed - Hold OK to Reset

Auto StartStop

•

Inst Fuel Economy - Shows a visual graph of your instantaneous fuel economy, average
fuel economy and distance to empty.

•

Fuel History - Shows a bar chart of your fuel history from the past 30 min, average
fuel economy and distance to empty.

•

Average Speed - Shows your vehicles average speed since the function was last reset.

•

Auto StartStop - Available Auto Start-Stop messaging will provide details about what
is happening with your system.  See Information Messages (page 105).

Note: You can reset your average fuel economy by pressing and holding the OK button on
the left hand steering wheel controls.

Driver Assist

In this mode, you can configure different
driver setting choices.

Note: Some items are optional and may
not appear.
