Action and Description

Menu Item

Allows you to switch the time of your start
and finish time. This setting is viewable in
12-hour mode.

AM

Weekday Finish

PM

Weekend Finish

These buttons represent the charging current assumption for the
default profile. The system uses this selection to calculate estim-
ated charge times.

240V and 120V or
32A and 10A

Touching this button erases the Default Value Charge preferences.

Clear

Touching this button stores your Default Value Charge preferences.
If you touch the back arrow button to return to the previous screen
without saving your settings, the system does not store them and
you need to enter them again.

Save

Note: Make sure you save your settings before returning to the previous screen. If you do
not touch Save the system does not store your settings.

Power Flow

E244859

B

E

H

A

F

G

C

D

I

Description

Item

Callout

This indicates which mode is active within the vehicle
system.

Power Flow

A

Action and Description

Menu Item

The system is storing
power in the high-voltage
battery.

Status: Charging HV
Battery

The vehicle is either at
rest, or sharing very little
power between the elec-
tric system parts.

Status: Idle

The vehicle is driving in
electric mode (the power
is coming from the elec-
tric motor).

Status: Electric Drive

The high-voltage battery
charging from the char-
ging station is complete.

Status: Charge Complete

Shows the direction of power flow between the
wheels and the electric motor.

Motor-to-Wheel Flow

B

Represents the electric motor. The higher the motor
power is, the larger the circle around this node. Any
time the vehicle is ready to be driven, the motor node
illuminates.

Electric Motor

C

Shows the direction of power flow between the high-
voltage battery and the electric motor. Flow toward
the motor indicates the battery is providing power to
accelerate the vehicle (discharging the battery). Flow
toward the battery indicates the electric motor is
providing power to the battery (charging the battery).

1

Battery-to-
Motor Flow

D

Appears when you plug your vehicle into the charging
station. When charging the high voltage battery from
the charging station, you can see flow from the plug
to the battery on the screen.

Plug

E

Description

Item

Callout

Includes all power usage from the low voltage
accessories such as the climate control fan, head-
lights and heated seats. The higher the power usage
is from these accessories, the larger the circle around
the node. This node illuminates anytime the vehicle
is on since there is always some low level power in
use.

2

Other

F

Includes the power usage from the high-voltage
climate control components such as the electric A/
C compressor and the electric heater. The higher the
power usage is from these components, the larger
the circle around this node.

2,3

Climate

G

Represents your high-voltage battery. A circle illumin-
ates around the node when the high-voltage battery
is receiving power from regenerative braking or engine
charging. The higher the power going into the high-
voltage battery, the larger the circle around this node.

Battery

H

Represents the power going to the wheels. The higher
the wheel power is, the larger the circle around this
node. When the engine is off, drive power displays in
blue. When the engine is on, drive power displays in
grey.

Drive

I

1

The battery-to-motor flow includes

battery power the vehicle is using for
acceleration. It does not include energy the
vehicle is using for accessories (such as air
conditioning, headlights and radio). This
screen displays accessories and climate
usage separately.

2

Accessories indicates electrical power

demands from your vehicle’s accessory
systems. Accessories use power but do not
contribute to making the vehicle move. The
power flow displays power usage from the
climate control system and other
accessories separately.

3

The climate control system may

determine A/C is necessary even when you
turn it off. In this case, you may see some
climate power when the A/C is off.

Privacy Notice for GPS Mapping with
MyFord

MyFord allows for GPS mapping when a
vehicle is registered to a MyFord Mobile
account. To remove the vehicle from the
account, thereby removing GPS mapping
ability, a Master Reset can be performed
in the vehicle.  See Settings (page 290).

Before transferring ownership of a vehicle,
owners may choose to execute a Master
Reset or Factory Reset (completed via the
MyFord Mobile website). Either method
removes the vehicle from all MyFord
Mobile accounts.

It is recommended that new owners
conduct a Master Reset upon taking
possession of the vehicle to remove it from
any existing MyFord Mobile accounts. The
new owner can activate a MyFord Mobile
account by completing registration process
on the website.

APPS

The system enables voice, steering wheel,
and touch screen control of SYNC 3
AppLink enabled smartphone apps.

Once an app is running through AppLink,
you can control main features of the app
through voice commands and steering
wheel controls.

Note: Available AppLink enabled apps will
vary by market.

Note: You must pair and connect your
smartphone via Bluetooth to SYNC 3 to
access AppLink.

Note: iPhone users need to connect the
phone to the USB port.

Note: For information on available apps,
supported smartphone devices and
troubleshooting tips please visit:

Websites

owner.ford.com

www.syncmyride.ca

www.syncmaroute.ca

Note: Make sure you have an active account
for the app that you have downloaded.
Some apps will work automatically with no
setup. Other apps will want you to configure
your personal settings and personalize your
experience by creating stations or
favorites.We recommend you do this at
home or outside of your vehicle.

Note: We encourage you to review the
smartphone app’s terms of service and
privacy policies because Ford is not
responsible for your app or its use of data.

Note: AppLink is a native SYNC system
feature. Accessing mobile apps through
AppLink is only possible when Android Auto
or Apple CarPlay are disabled. Some apps
may only be accessible in the car through
AppLink and others only through Android
Auto or Apple CarPlay. Please refer to the
Smartphone Connectivity information to
disable Android Auto or Apple CarPlay.

Note: In order to use an app with SYNC 3,
the app needs to be running in the
background of your phone. If you shut down
the app on your phone, it shuts down the
app on SYNC 3 as well.

Note: If a SYNC 3 AppLink compatible app
is not shown in the Apps Domain, make sure
the required app is running on the mobile
device.

Action and Descrip-

tion

Menu Item

SYNC 3 will search
and connect to
compatible app(s)
running on your
mobile device.

Find Mobile Apps

Enabling SYNC 3 Mobile Apps

In order to enable mobile apps, SYNC 3
requires user consent to send and receive
app authorization information and updates
using the data plan associated with the
connected device.
