Estimated Charge Time Limits

E231151

Action and Description

Menu Item

Item

This shows you the battery's current charge displayed
as a percentage. A reading of 100% means the battery
has a full charge. A reading of 0% indicates the battery
has no plug-in energy left.

Battery

A

240V / High Power or 32A / HI is the estimated
minimum charging time from the present high-voltage
battery level to full charge (100%). This represents the
shortest amount of time you should expect the high-
voltage battery to recharge under ideal conditions. Ideal
conditions include a 240V charging station and a
minimum 30A service, or a 230V charging station and a
32A service, and high-voltage battery at a moderate
temperature.

To Fully Charge

B

Action and Description

Menu Item

Item

Note: Some charging stations use lower voltage (208V),
which result in longer charge times.

120V / Low Power or 10A / LO is the estimated
maximum charging time from the present high-voltage
battery level to full charge (100%). This represents the
longest amount of time you should expect the high-
voltage battery to recharge under normal conditions.
Normal conditions include a 120V convenience cord and
12A service, or a 230V convenience cord and 10A service.

Note: These charging times are only estimates. It is normal for your actual charge duration
to be longer.

Note: Charging may take longer when the AC line voltage is low and may indicate your
electrical source is not meeting certain requirements.  See Charging the High Voltage
Battery (page 110).

GO Time Schedule

You can access the GO Time Schedule by
selecting the edit option under MY GO
Time on the Charge Setting screen.

Action and Description

Menu Item

This turns on the GO Time schedule.

On

This turns off the GO Time schedule. This also turns off the cabin
conditioning function. Use this mode to prevent using energy for
cabin preconditioning when you leave your vehicle plugged in and
do not plan to use it for a while, such as when on vacation.

Off

Note: If you choose to perform Value Charging with the schedule
off, the vehicle schedules charging to finish at the lowest cost
within 24 hours of plugging the vehicle in.

This displays the GO Time day-of-week and time. The blue high-
lighted GO Time is the present GO Time, which the vehicle is using
for charge scheduling and cabin conditioning. You can schedule
two GO Time events per day for each day of the week.

GO Time 1

Action and Description

Menu Item

Allows you to edit the GO Time and
cabin conditioning temperature.

My GO Times

Indicates that you can add a GO
Time to this slot.

--:--

GO Time 2

Note: If you set GO Time 2 to occur before GO Time 1, or if you
set GO Time 1 to occur after an existing GO Time 2, the GO Times
will automatically sort themselves and be displayed in the correct
order.

GO Time and Cabin Conditioning

This screen allows you to enter or change
the GO Time and cabin conditioning
temperature.

Press any GO Time on the Schedule screen
to enter the editing screen for that GO
Time.

Action and Description

Menu Item

These change the hours and minutes of your GO Time. The
minutes change in increments of five. You can also switch the
settings for AM and PM by touching those buttons.

Time (+ and -)

These switch the setting for your selected cabin conditioning
temperature for this GO Time event. You can select from four
settings:

Cabin Conditioning
(+ and -)

Off

85°F (29.5°C)

72°F (22°C)

65°F (18.5°C)

Note: Cabin conditioning can perform differently depending on
if you plug into a low current convenience cord or a high current
charging station. The power available for conditioning is limited
to the charging station power available.
Note:  Your vehicle may not always reach the set cabin temper-
ature due to charging and ambient temperature conditions. This
is normal operation.

Touching this button erases the GO Time and cabin conditioning
temperature.

Clear

Touching this button stores the GO Time and temperature
settings.

Save

Note: If you select a GO Time, but choose Off for the temperature setting, the vehicle
schedules charging to be complete by your GO Time and does not condition the cabin.

Note: Make sure you save your settings before returning to the previous screen. If you do
not touch Save, the system will not automatically store the settings.

Value Charge Profiles

You can access the Value Charge Profile

screen by selecting the edit option in the
bottom right hand corner of the Charge
Settings screen.

Action and Description

Menu Item

This displays the charging mode and off-peak times for your
Default Value Charge profile. The system displays off-peak times
for weekdays; the remaining hours of the day are considered peak
time. The system displays similar off-peak times for weekend
days.

Default

If you want your vehicle to immediately
charge when you plug it in at this profile
location.

Charge Now

If you want to take advantage of off-peak
electricity rates. The vehicle optimizes the
charge schedule to be complete by the next
GO Time.

Value Charge

To access your Default Value Charge Profile
settings screen (see Default Value Charge
Profile later in this section).

Edit

Once you create profile names, this section displays the Value
Charge Profile names and current Charge Mode for specific loca-
tions. You can set up and edit these profiles using the MyFord
Mobile internet application. You can program up to nine unique
charge profiles.

Customer Defined
Value Charge
Profiles

Default Value Charge Profile

You can access your Default Value Charge
Profile by selecting the edit option on the
Value Charge Profiles screen.

Action and Description

Menu Item

Set the Weekday times and Weekend times by pressing the
Weekday and Weekend buttons.

Weekday

Weekend

This displays the start and finish of off-peak charge times, which
you can modify, using the following:

Weekday Start

Allows you to switch the hours of your start
and finish times.

+ and -

Weekend Start
