Ford Focus Electric (2018 year). Manual - part 69

Action and Description

Menu Item

Item

This is the status of the charging system, which includes
the charging plug, high-voltage battery and charger.

Charge Status

A

This means the vehicle is
unplugged. Charge Start and
Complete information is for the
present vehicle location.

Next Charge

This means you plugged the
vehicle in and it is ready to
charge. Typical of Value Charge
mode, the vehicle may not start
charging right away because it
is set to charge at times with
lower utility costs.

Waiting to charge

This means the high-voltage
battery is charging.

Charging

This means the vehicle is
plugged into a DC Fast Charge
station and the high voltage
battery is fast charging to 80%
state of charge. Charging slows
above 80% state of charge.

Fast Charging

This informs you that the high-
voltage battery is fully charged
and not currently scheduled for
further charging.

Charged

This alerts you that a fault is
present and is preventing the
high-voltage battery from
charging. Check the charge
plug connection, charge cord,
and charging station.

Fault

This is the estimated time of charge completion.

Complete

B

When the vehicle is in Charge
Now mode, and unplugged, the
system displays the charging
duration in hours. Once you
plug in the vehicle, the value
shows the estimated time to
finish charging.

Charge Now Duration

Action and Description

Menu Item

Item

When the vehicle is in Value
Charge mode, the system
displays the estimated charge
complete time. It is normal for
the estimated complete time
to change when charging. The
vehicle keeps charging until the
high-voltage battery is fully
charged.

Scheduled Charge
Complete Time

This is an estimate of when your vehicle is charged to
80% via DC Fast Charging.

Charge to 80%

This is an estimate of when your vehicle is charged to
100% via DC Fast Charging.

Charge to
100%

This is the scheduled start time of charging.

Start

C

When the vehicle is in Charge
Now mode, and unplugged, the
message At Plug In appears,
indicating the vehicle immedi-
ately starts charging once you
plug it in. Once you plug it in,
the system shows the actual
charge start time.

At Plug-In

When the vehicle is in Value
Charge mode, the system
displays the scheduled charge
start time (for example, 8:00
PM). Once charging starts, the
system continues to display the
actual charge start time.

Scheduled Charge Start
Time

Value Charge Profile and Mode

E231150

Action and Description

Menu Item

Item

This is the name of the presently detected Value Charge
Profile.

Value Charge
Profile

A

Action and Description

Menu Item

Item

The system detects a customer defined value charge
profile when the vehicle is within approximately 300 ft
(91.4 m) of the GPS location registered for the profile. If
the vehicle is close to more than one charge profile
location, it chooses the closest.

Displays if you have not set up
value charge profiles for
specific locations through
MyFord Mobile or if you are not
close enough to a defined
profile location.

Default Profile

Touch this button if you want your vehicle to immediately
charge when plugged in at this profile location. This
button illuminates when Charge Now is the charge mode
selected for the presently detected charge profile.

Charge Now

B

Touch this button if you want to take advantage of off-
peak electricity rates. The vehicle optimizes the charge
schedule to be complete by the next GO Time. This
button illuminates when Value Charge is the charge mode
selected for the presently detected charge profile.

Value Charge

C

Touch this button to access your Value Charge profiles
settings screen (see Value Charge Profiles later in this
section).

Edit

D
