ENGINE SPECIFICATIONS - 3.5L ECOBOOST™

Specification

Measurement

213

Cubic inches

1-4-2-5-3-6

Firing order

Coil on plug

Ignition system

.030-.033 in. (0.75 - 0.85 mm)

Spark plug gap

10.5:1

Compression ratio

Drivebelt Routing

E167467

ENGINE SPECIFICATIONS - 5.0L MODULAR - V8

Specification

Measurement

307

Cubic inches

1-3-7-2-6-5-4-8

Firing order

Coil on plug, coil near plug

Ignition system

.049-.053 in. (1.25 - 1.35 mm)

Spark plug gap

12:1

Compression ratio

Drivebelt Routing

E249450

MOTORCRAFT PARTS - 2.7L ECOBOOST™

Part Number

Component

FA-1883

Air filter element.

FL-2062

Oil filter.

BAGM-48H6-760

Battery.

BAGM-94RH7-800

(King Ranch, Lariat and Premium)

SP-542

Spark plugs.

WW-2242

Windshield wiper blade.

FP-79

Cabin air filter.

For scheduled maintenance, we
recommend Motorcraft® replacement
parts available at your Ford dealer or at
fordparts.com. These parts meet or exceed
Ford Motor Company’s specifications and
are engineered for your vehicle. Use of
other parts may impact vehicle
performance, emissions and durability.
Your warranty may be void for any damage
related to use of other parts.

If a Motorcraft® oil filter is not available,
use an oil filter that meets industry
performance specification
SAE/USCAR-36.

For spark plug replacement, contact an
authorized dealer.  Replace the spark plugs
at the appropriate intervals.  See
Scheduled Maintenance (page 554).

MOTORCRAFT PARTS - 3.0L DURATORQ-TDCI - V6

Part Number

Component

-

Air filter element.

-

Oil filter.

-

Battery.

-

-

Glow plugs.

WW-2242

Windshield wiper blade.

FP-79

Cabin air filter.

For scheduled maintenance, we
recommend Motorcraft® replacement
parts available at your Ford dealer or at
fordparts.com. These parts meet or exceed
Ford Motor Company’s specifications and
are engineered for your vehicle. Use of
other parts may impact vehicle
performance, emissions and durability.
Your warranty may be void for any damage
related to use of other parts.

If a Motorcraft® oil filter is not available,
use an oil filter that meets industry
performance specification
SAE/USCAR-36.

For glow plug replacement, contact an
authorized dealer.  Replace the spark plugs
at the appropriate intervals.  See
Scheduled Maintenance (page 554).

MOTORCRAFT PARTS - 3.3L DURATEC - V6

Part Number

Component

FA-1883

Air filter element.

FL-500-S

Oil filter.

BAGM-48H6-760

Battery.

BAGM-94RH7-800

(King Ranch, Lariat and Premium)

SP-520

Spark plugs.

WW-2242

Windshield wiper blade.

FP-79

Cabin air filter.

For scheduled maintenance, we
recommend Motorcraft® replacement
parts available at your Ford dealer or at
fordparts.com. These parts meet or exceed
Ford Motor Company’s specifications and
are engineered for your vehicle. Use of
other parts may impact vehicle
performance, emissions and durability.
Your warranty may be void for any damage

related to use of other parts.

If a Motorcraft® oil filter is not available,
use an oil filter that meets industry
performance specification
SAE/USCAR-36.

For spark plug replacement, contact an
authorized dealer.  Replace the spark plugs
at the appropriate intervals.  See
Scheduled Maintenance (page 554).

MOTORCRAFT PARTS - 3.5L ECOBOOST™

Part Number

Component

FA-1883

Air filter element.

FL-500-S

Oil filter.

BAGM-48H6-760

Battery.

BAGM-94RH7-800

(King Ranch, Lariat and Premium)

SP-534

Spark plugs.

WW-2242

Windshield wiper blade.

FP-79

Cabin air filter.

For scheduled maintenance, we
recommend Motorcraft® replacement
parts available at your Ford dealer or at
fordparts.com. These parts meet or exceed
Ford Motor Company’s specifications and
are engineered for your vehicle. Use of
other parts may impact vehicle
performance, emissions and durability.
Your warranty may be void for any damage
related to use of other parts.

If a Motorcraft® oil filter is not available,
use an oil filter that meets industry
performance specification
SAE/USCAR-36.

For spark plug replacement, contact an
authorized dealer.  Replace the spark plugs
at the appropriate intervals.  See
Scheduled Maintenance (page 554).
