Trip/Fuel

E176095

Use the arrow buttons to choose
between the following trip and
fuel options.

Trip/Fuel

Trip 1 or 2

Fuel Economy

Fuel History

Average Speed

Select Your Setting

Navigation/Compass

Auto StartStop

Trip 1 or 2
•

Trip Timer - Registers the time of individual journeys.

•

DTE - Shows the approximate distance your vehicle can travel before running out of
fuel.

•

Odometer - Registers the distance of individual journeys.

•

Avg - Shows the average fuel economy for a given trip.

Fuel Economy - Shows your instantaneous fuel usage as a bar graph and average fuel
economy.

Fuel History - Shows your fuel usage based on time. The graph is updated each minute
with the fuel economy that you achieved during 30 minutes of driving.

Average Speed - Shows the average speed your vehicle travels.

Navigation/Compass - Shows navigation turn by turn or compass direction when a route
is not set.

Auto StartStop - Shows the current status of the Auto StartStop system.

Note: Press and hold OK to reset the currently displayed information.

Truck Info

E163181

In this mode, off-road
information depicted with
graphics are available.

Note: Use the arrow buttons to choose between the following display options.

Truck Info

Choose your applicable setting.

Gauge
View

Tire Pressure

Digital Speedometer

Diesel Exhaust Fluid Status

Diesel Exhaust Filter Status

Engine Information

Transmission Temperature

•

Gauge View - Shows the turbo boost or transmission temp value.

•

Tire Pressure - Shows the tire pressure.  See Tire Pressure Monitoring System
(page 395).

•

Digital Speedometer - Shows a digital display of your vehicle speed.

•

Diesel Exhaust Fluid Status - Shows diesel exhaust fluid status on demand screen.

•

Diesel Exhaust Filter Status - Shows exhaust filter on demand screen.

•

Engine Information - Shows engine information.

•

Transmission Temperature - Shows the transmission temperature of your vehicle.

Towing

E176096

Use the arrow buttons to choose
between the following towing
options.

Note: Once you select a trailer, it remains active until you set it as no longer active. An active
trailer still accumulates miles even after you physically disconnect it from your vehicle.

Towing

% Grade, steering angle, gain and output display

Towing
Status

Trailer Name, Accumulated Miles, Pro Trailer Backup Assist Status and
Trailer BLIS Status - Press OK for Trailer Options

Towing
Informa-
tion

Running, Brake and Turn Signal Light Status or No Trailer Detected

Trailer
Light
Status

Towing

Trailer Sway Control

Trailer
Setup

Select trailer

Change Trailer Settings

Add Trailer

Conventional

Connec-
tion Check-
list

Fifth Wheel

Gooseneck

Off Road

E176097

Use the arrow buttons to choose
between the following off road
options.

Off Road

Pitch, Steering Angle, Roll, Elocker and 4X4

Power Distribution

Settings

E176098

Use the arrow buttons to
configure different driver setting
choices.

Settings

Auto Regen

Cross Traffic Alert

Driver Alert

Rear Park Aid

Trailer Blind Spot

Alert Sensitivity

Pre-Collision

Distance Indication

Settings

Active Braking

Pre-Collision

Choose your applicable setting.

Cruise
Control

Choose your applicable setting.

DTE Calcula-
tion

Choose your applicable setting.

Gauge Selec-
tion

Mode

Lane
Keeping
System

Alert Intensity

Vehicle

Advanced
Settings

MyKey

Display Setup

INFORMATION MESSAGES

Note:  Depending on your vehicle options
and instrument cluster type, not all of the
messages will display or be available.  The
information display may abbreviate or
shorten certain messages.

E184451

Press the OK button to acknowledge and
remove some messages from the
information display. The information
display will automatically remove other
messages after a short time.

You need to confirm certain messages
before you can access the menus.
