Ford F-150 (2018 year). Manual - part 28

Display Mode

Note: Use the arrow buttons to choose between the following display options.

Display Mode

Distance to Empty

DEF Status

Exhaust Filter Status

Tire Pressure

Digital Speedometer - Press OK for km/h

Engine Information

Transmission Temp.

•

Distance to Empty - Shows the approximate distance your vehicle can travel before
running out of fuel.

•

DEF Status - Shows DEF status on demand screen.

•

Exhaust Filter Status - Shows exhaust filter on demand screen.

•

Tire Pressure - Shows the tire pressure.  See Tire Pressure Monitoring System
(page 395).

•

Engine Information - Shows engine hours and engine idle hours. Hold OK to Reset

•

Transmission Temp.- Shows the transmission temperature of your vehicle.

Trip/Fuel

Note: Use the arrow buttons to choose between the following trip and fuel options.

Trip/Fuel

Trip 1 or 2

Fuel Economy

Fuel History

Select Your Setting

Compass

Trip/Fuel

Average Speed

Auto StartStop

Trip 1 or 2
•

Trip Timer - Registers the time of individual journeys.

•

DTE - Shows the approximate distance your vehicle can travel before running out of
fuel.

•

Odometer - Registers the distance of individual journeys.

•

Avg - Shows the average fuel economy for a given trip.

Fuel Economy - Shows your instantaneous fuel usage as a bar graph and average fuel
economy.

Fuel History - Shows your fuel usage based on time. The graph is updated each minute
with the fuel economy that you achieved during 30 minutes of driving.

Average Speed - Shows the average speed your vehicle travels.

Auto StartStop - Shows the current status of the Auto StartStop system.

Note: Press and hold OK to reset the currently displayed information.

Towing

Note: Use the arrow buttons to configure different towing setting choices.

Note: Once you select a trailer, it remains active until you set it as no longer active. An active
trailer still accumulates miles even after you physically disconnect it from your vehicle.

Towing

Trailer Connection Status

Trailer Status

BLIS with Trailer Ready/Not Available/Not Setup/Off

Pro Trailer Backup Assist: Ready or Not Setup or Not Calibrated

Active Trailer Name or Default Trailer

Accumulated Trailer Miles

Trailer Brake Gain

Output

Trailer Sway Control

Trailer
Options

Select Trailer

Change Trailer Settings

Towing

Add Trailer

Conventional

Connection
Checklist

Fifth Wheel

Gooseneck

Off Road

Note: Use the arrow buttons to configure different off road choices.

Off Road

Pitch, Steering Angle and Roll

Power Distribution

Settings

Settings

Auto Regen

Blind Spot

Cross Traffic Alert

Choose your applicable setting.

DTE Calcula-
tion

Rear Park Aid

Trailer Blind Spot

Vehicle

Advanced
Settings

MyKey

Display Setup

Information Display Controls
(Type 3)

 (If Equipped)

E176093

•

Press the up and down arrow buttons
to scroll through and highlight the
options within a menu.

•

Press the right arrow button to enter a
sub-menu.

•

Press the left arrow button to exit a
menu.

•

Press the OK button to choose and
confirm a setting or messages.

Main menu

You can access the menus using the
information display control.

E176094

My View

E176095

Trip/Fuel

E163181

Truck Info

E176096

Towing

E176097

Off Road

E176098

Settings

My View

E176094

Use the arrow buttons to choose
between the following My View
options.

MyView

Trip 1

Fuel Economy

Tire Pressure

Off Road Status

Add/Remove Screens

Configure MyView

Reorder Screens
