Trip 1 & 2

All Values

•

All Values — shows all trip values (Trip
Timer, Trip Odometer and Average
Fuel).

•

Trip Odometer — Shows your
accumulated trip distance.

•

Average Fuel — Shows your average
fuel economy for a given trip.

•

Trip Timer— The timer stops when you
turn your vehicle off and restarts when
you restart your vehicle.

Note: You can reset your trip information
by pressing and holding the OK button on
the left hand steering wheel controls.

Fuel Economy

Use the left or right arrow buttons to
choose the desired fuel economy display.

Fuel Economy

Instant Fuel Economy - Hold OK to Reset

Fuel History

•

Inst Fuel Economy - shows a visual
graph of your instantaneous fuel
economy, average fuel economy and
distance to empty.

•

Fuel History - shows a bar chart of your
fuel history from the past 30 min,
average fuel economy and distance to
empty.

Note: You can reset your average fuel
economy by pressing and holding the OK
button on the left hand steering wheel
controls.

Driver Assist

In this mode, you can configure different
driver setting choices.

Note: Some items are optional and may
not appear.

Driver Assist

Traction Control

Intelligent 4WD with Terrain Management System

Intelligent 4WD

Blindspot

Cross Traffic

Adaptive or Normal

Cruise Control

Driver Alert

Driver Assist

Hill Start Assist

Alert, Aid or Alert + Aid

Mode

Lane Keeping Sys

High, Normal or Low

Intensity

High, Normal or Low

Alert Sensitivity

Pre-Collision

Rear Park Aid

Tire Pressure

Trailer Sway

Settings

In this mode, you can configure different
driver setting choices.

Note: Some items are optional and may
not appear.

Settings

All Sensors

Alarm

Vehicle

Perimeter Sensing

Ask on Exit

Normal or Towing

DTE Calcula-
tion

Information

Chimes

Easy Entry/Exit

Auto Engine Off

Auto Highbeam

Lighting

Off or XX Seconds

Autolamp Delay

Daytime Lights

Autolock

Locks

Autounlock

Relock

All Doors or Driver's Door

Remote Unlock

Settings

Switch Inhibit

Autofold

Mirror

XXX% - Hold OK to Reset

Oil Life

Enable Switch or Disable Switch

Power Lift-
gate

Auto or Last Settings

Climate Control

Remote
Start

Auto or Off

Front Seats &
Wheel

5, 10 or 15 minutes

Duration

System

Remote Open

Windows

Courtesy Wipe

Wipers

Rain Sensing

MyKeys Qty

Mykey
Status

MyKey

MyKey Odometer
Admin Key Qty

Hold OK to Create MyKey

Create
MyKey

Always On or User Selectable

911 Assist

On or Off

Do Not
Disturb

Always On or User Selectable

Traction
Control

Choose desired speed or off

Max Speed

Speed
Minder

Volume Limiter

Hold OK to Clear All MyKeys

Clear
MyKeys

Miles & Gallons, L/100 km or km/L

Distance
Unit

Display

Settings

°Fahrenheit or °Celsius

Temper-
ature Unit

psi, kPa or bar

Tire Pres-
sure

Choose your applicable setting

Language

Speedo in km/h

Note: Some MyKey items only appear if a
MyKey is set.

INFORMATION MESSAGES

Note: Depending on the vehicle options
equipped with your vehicle, not all of the
messages will display or be available.
Certain messages may display abbreviated
or shortened depending upon which cluster
type you have.

Press the OK button to acknowledge and
remove some messages from the
information display. Other messages
delete automatically after a short time.

You need to confirm certain messages
before you can access the menus.

4WD

Action

Message

The four wheel drive system has automatically disabled itself

due to the system overheating.

4WD Temporarily

Disabled

The four wheel drive system has automatically disabled itself
due to the system overheating or you are using the spare tire.

4WD Off

The four wheel drive system resumes normal function and

clears this message after driving a short distance with the

road tire re-installed or after the system cools.

4WD Restored
