Settings

All Sensors

Alarm

Vehicle

Perimeter Sensing

Ask on Exit

Auto Engine Off

Information

Chimes

Normal or Towing

DTE calcula-
tion

Easy Entry/Exit

Auto Highbeam

Lighting

Off or XX Seconds

Hdlamp Delay

Daytime Lights

Autolock

Locks

Autounlock

Relock

All Doors or Driver's Door

Remote Unlock

Switches inhibit

Autofold

Power
Mirror

Remaining Life XXX% - Hold OK to Reset

Oil Life
Reset

Enable Switch or Disable Switch

Power Lift-
gate

Auto or Last Settings

Climate Control

Remote
Start

Automatic or Off

Seats or Seats and
Wheel

5, 10 or 15 minutes

Duration

System

Remote Open

Windows

Settings

Courtesy Wipe

Wipers

Rain sensing

MyKey Qty

MyKey
Status

MyKey

MyKey Odo
Admin Key Qty

Hold OK to Create MyKey

Create
MyKey

Always On or User Selectable

911 Assist

On or Off

Do Not
Disturb

Always On or User Selectable

Traction
Ctrl

Choose desired speed or off

Max Speed

Volume Limiter

Hold OK to Clear All MyKeys

Clear
MyKeys

Miles & Gallons, L/100 km or km/L

Distance

Display

Fahrenheit (°F) or Celsius (°C)

Temper-
ature

psi, kPa or bar

Tire Pres-
sure

Choose your applicable setting

Language

Note: Some MyKey items only appear if a
MyKey is set.

Information Display Controls
(Type 2)

•

Press the up and down arrow buttons
to scroll through and highlight the
options within a menu.

•

Press the right arrow button to enter a
sub-menu.

•

Press the left arrow button to exit a
menu.

•

Press and hold the left arrow button at
any time to return to the main menu
display (escape button).

•

Press the OK button to choose and
confirm settings or messages.

Main Menu

From the main menu bar on the left side
of the information display, you can choose
from the following categories:

•

Display Mode.

•

Trip 1 & 2.

•

Fuel Economy.

•

Driver Assist.

•

Settings.

Scroll up or down to highlight one of the
categories and then press the right arrow
key or OK to enter into that category. Press
the left arrow key as needed to exit back
to the main menu.

Display Mode

Use the up or down arrow buttons to
choose between the following display
options.

Display Mode

Option 4

*

Option 3

Option 2

Option 1

*

Display Mode

-

-

X

X

XXX mi (km) to

empty

X

X

-

-

Round tacho-

meter

-

-

X

-

Vertical tacho-

meter

Display Mode

Tire pressure on demand screen

Digital speedometer - XXX MPH - Press OK for km/h

Intelligent 4WD - 4WD Gauge with Terrain Management System

*

Vehicles with Intelligent 4WD only. You can choose to have only the fuel gauge show in

this mode. Refer to Display > Gauge Display found in the table under the Settings section
later in this chapter.

XXX mi (km) to empty

Shows approximate fuel level before the
fuel tank reaches empty. The value is
dynamic and can change (raise or lower)
depending on driving style.

Fuel gauge

Switch the ignition on. The fuel gauge
indicates approximately how much fuel is
in the fuel tank. The arrow next to the fuel
pump symbol shows the fuel filler door
side of your vehicle. When the fuel level
becomes low, the level indicator changes
to amber. When the fuel level becomes
critically low, the level indicator changes
to red.

Note: The fuel gauge level may vary slightly
when your vehicle is moving or when driving
on a slope.

Note: When a MyKey is in use, low fuel
warnings display earlier.

Bar or Round tachometer

Indicates the engine speed in revolutions
per minute. Driving with your tachometer
pointer continuously at the top of the scale
may damage the engine. During SelectShift
Automatic™ transmission (SST) use, the
currently selected gear appears in the
display.

Engine coolant temperature gauge

Indicates engine coolant temperature. At
normal operating temperature, the level
indicator is in the normal range. If the
engine coolant temperature exceeds the
normal range, stop your vehicle as soon as
safely possible, switch off the engine and
let the engine cool.

Intelligent 4WD (if equipped)

Displays power distribution between the
front and rear wheels. More power to either
the front or rear wheels displays by more
area filled in. Intelligent 4WD also displays
the currently selected terrain management
mode.

Trip 1 & 2

You can access the menu using the
information display control.

Note: Some options may appear slightly
different or not at all if the items are
optional.
