Ford Explorer (2018 year). Manual - part 27

Trip 1 & 2

All Values

•

All Values — shows all trip values (Trip
Timer, Trip Odometer and Average
Fuel).

•

Trip Odometer — Shows your
accumulated trip distance.

•

Average Fuel — Shows your average
fuel economy for a given trip.

•

Trip Timer— The timer stops when you
turn your vehicle off and restarts when
you restart your vehicle.

Note: You can reset your trip information
by pressing and holding the OK button on
the left hand steering wheel controls.

Fuel Economy

Use the left or right arrow buttons to
choose the desired fuel economy display.

Fuel Economy

Inst Fuel Economy - Hold OK to Reset

Fuel History

•

Inst Fuel Economy - shows a visual
graph of your instantaneous fuel
economy, average fuel economy and
distance to empty.

•

Fuel History - shows a bar chart of your
fuel history from the past 30 min,
average fuel economy and distance to
empty.

Note: You can reset your average fuel
economy by pressing and holding the OK
button on the left hand steering wheel
controls.

Driver Assist

In this mode, you can configure different
driver setting choices.

Note: Some items are optional and may
not appear.

Driver Assist

Traction Control

Blindspot

Cross Traffic Alert

Adaptive or Normal

Cruise Control

Driver Alert

Hill Start Assist

Driver Assist

Alert Only, Aid Only or

Both

Mode

Lane Keeping Sys

High, Normal or Low

Intensity

High, Normal or Low

Alert Sensitivity

Pre-Collision

Rear Park Aid

Trailer Sway

Settings

In this mode, you can configure different
driver setting choices.

Note: Some items are optional and may
not appear.

Settings

All Sensors Active

Alarm

Vehicle

Perimeter Sensing

Ask on Exit

Auto Engine Off

Normal or Towing

DTE Calcula-
tion

Easy Entry/Exit

On or Off

Auto Highbeam

Lighting

Off or XX Seconds

Autolamp Delay

Daytime Lights

Autolock

Locks

Autounlock

Relock

All Doors or Driver's Door

Remote Unlock

Switch Inhibit

Autofold

Mirrors

Settings

XXX% - Hold OK to Reset

Oil Life
Reset

Enable Switch or Disable Switch

Power Lift-
gate

Auto or Last Settings

Climate Control

Remote
Start

Auto or Off

Seats or Seats and
Wheel

5, 10 or 15 minutes

Duration

System

Remote Open

Windows

Courtesy Wipe

Wipers

Rain Sensing

MyKeys Qty

MyKey

MyKey

MyKey Odometer
Admin Key Qty

Hold OK to Create MyKey

Create
MyKey

Always On or User Selectable

911 Assist

Do Not
Disturb

Traction
Control

Choose desired speed or off

Max Speed

Speed
Minder

Volume Limiter

Hold OK to Clear All MyKeys

Clear
MyKeys

Miles & Gallons, L/100km or Km/L

Distance

Display Setup

°Fahrenheit or °Celsius

Temper-
ature

Settings

Fuel Gauge or Fuel + Tach

Gauge
Display

psi, kPa or bar

Tire Pres-
sure

Choose your applicable setting

Language

Note: Some MyKey items only appear if a
MyKey is set.

Information Display Controls
(Type 3)

•

Press and hold the left arrow button at
any time to return to the main menu
display (escape button).

•

Press the OK button to choose and
confirm settings or messages.

•

Press the up and down arrow buttons
to scroll through and highlight the
options within a menu.

•

Press the right arrow button to enter a
sub-menu.

•

Press the left arrow button to exit a
menu.

Main Menu

From the main menu bar on the left side
of the information display, you can choose
from the following categories:

•

Trip 1 & 2.

•

Fuel Economy.

•

Driver Assist.

•

Settings.

Scroll up or down to highlight one of the
categories and then press the right arrow
key or OK to enter into that category. Press
the left arrow key as needed to exit back
to the main menu.

Trip 1 & 2

You can access the menu using the
information display control.

Note: Some options may appear slightly
different or not at all if the items are
optional.
