Ford E-450 (2018 year). Manual - part 11

ADJUSTING THE STEERING
WHEEL

WARNING

Do not adjust the steering wheel
when your vehicle is moving.

E161517

1

2

1.

Pull and hold the steering wheel
release lever.

2. Adjust the steering wheel to the

position you desire, then release the
lever.

VOICE CONTROL

 (If Equipped)

E193397

Press to select or deselect voice control.
See your SYNC information.

CRUISE CONTROL

 (If Equipped)

E161518

See Cruise Control (page 95).

WINDSHIELD WIPERS

Note: Fully defrost the windshield before
you switch the windshield wipers on.

Note: Make sure you switch the windshield
wipers off before entering a car wash.

Note:  If streaks or smears appear on the
windshield, clean the windshield and the
wiper blades.  If that does not resolve the
issue, install new wiper blades.

Note:  Do not operate the wipers on a dry
windshield.  This may scratch the glass,
damage the wiper blades or cause the wiper
motor to burn out.  Always use the
windshield washers before wiping a dry
windshield.

E207133

Rotate away from you for short
wipe interval.

Toward you for long-wipe
interval.

Use the rotary control to adjust the
intermittent wipe interval.

WINDSHIELD WASHERS

Note:  Do not operate the wipers on a dry
windshield.  This may scratch the glass,
damage the wiper blades or cause the wiper
motor to burn out.  Always use the
windshield washer before wiping a dry
windshield.

Note:  Do not operate the washers when
the washer reservoir is empty.  This may
cause the washer pump to overheat.

E207134

•

A brief press causes a single wipe
without washer fluid.

•

A brief press and hold causes the
wipers to swipe three times with
washer fluid.

•

A long press and hold turns on the
wipers and washer fluid for up to 10
seconds.

GENERAL INFORMATION

Condensation in the Exterior Front
Lamps and Rear Lamps

Exterior front lamps and rear lamps have
vents to accommodate normal changes
in air pressure.

Condensation can be a natural by-product
of this design. When moist air enters the
lamp assembly through the vents, there is
a possibility that condensation can occur
when the temperature is cold. When
normal condensation occurs, a fine mist
can form on the interior of the lens. The
fine mist eventually clears and exits
through the vents during normal operation.

Clearing time may take as long as 48 hours
under dry weather conditions.

Examples of acceptable condensation are:
•

The presence of a fine mist (no streaks,
drip marks or large droplets).

•

A fine mist covers less than 50% of the
lens.

Examples of unacceptable condensation
are:
•

A water puddle inside the lamp.

•

Streaks, drip marks or large droplets
present on the interior of the lens.

If you see any unacceptable condensation,
have your vehicle checked by an authorized
dealer.

LIGHTING CONTROL

E161456

A

B

C

P

Off.

A

Parking lamps, instrument panel
lamps, license plate lamps and
tail lamps.

B

Headlamps.

C

High Beams

E161457

Push the lever away from you to switch
the high beam on.

Push the lever forward again or pull the
lever toward you to switch the high beams
off.

Headlamp Flasher

E161458

Slightly pull the lever toward you and
release it to flash the headlamps.

INSTRUMENT LIGHTING
DIMMER

Note: If you disconnect the battery or it
becomes discharged, the dimmer switch
requires re-calibration. Rotate the dimmer
switch from the full dim position to the full
dome/on position to reset.

Note: Rotate to the full upright position,
past detent, to switch on the interior lamps.

E161459

Rotate up or down to adjust the intensity
of the panel lighting.

DAYTIME RUNNING LAMPS

 (If

Equipped)

WARNING

The daytime running lamps system
does not activate the rear lamps and
may not provide adequate lighting

during low visibility driving conditions.
Make sure you switch the headlamps on,
as appropriate, during all low visibility
conditions. Failure to do so may result in a
crash.

The system turns the lamps on in daylight
conditions.

To switch the system on, switch the
lighting control to the off, autolamp or
parking lamp position.

DIRECTION INDICATORS

E161460

Push the lever up or down to use the
direction indicators.

Note: Tap the lever up or down to make the
direction indicators flash three times to
indicate a lane change.
