2. Close the window a third time to the

point of resistance. The bounce-back
feature is now disabled and you can
close the window manually. The
window will go past the point of
resistance and you can close it fully.

See an authorized dealer as soon as
possible if the window does not close after
the third attempt.

Resetting the Bounce-Back Feature

WARNING

The bounce-back feature remains
turned off until you reset the
memory.

If you have disconnected the battery, you
must reset the bounce-back memory
separately for each window.

1.

Lift and hold the switch until the
window is fully closed.

2. Release the switch.

3. Lift the switch again for one more

second.

4. Press and hold the switch until the

window is fully open.

5. Release the switch.

6. Lift and hold the switch until the

window is fully closed.

7.

Open the window and then try to close
it automatically.

8. Reset and repeat the procedure if the

window does not close automatically.

Accessory Delay

 (If Equipped)

You can use the window switches for
several minutes after you switch the
ignition off or until you open either front
door.

GLOBAL OPENING

You can use the remote control to operate
the windows with the ignition off.

Note: To operate this feature, accessory
delay must not be active.

Opening the Windows

You can use the global opening feature to
open the windows only for a short time
after you unlock your vehicle by using the
remote control.

To use the global opening feature:
1.

Press and release the remote control
unlock button.

2. Press the remote control unlock button

again and hold it for approximately
three seconds. Release the control
when the windows begin to open.

3. Press the lock or unlock button on your

remote control to stop the window
opening function.

Note: Contact an authorized Ford dealer to
deactivate this feature.

EXTERIOR MIRRORS

Power Exterior Mirrors

WARNING

Do not adjust the mirrors when your
vehicle is moving. This could result
in the loss of control of your vehicle,

serious personal injury or death.

E70846

A

C

B

Left-hand mirror

A

Off

B

Right-hand mirror

C

E70847

Press the arrows to adjust the mirror.

Fold-Away Exterior Mirrors

Push the mirror toward the door window
glass. Make sure that you fully engage the
mirror in its support when returning it to its
original position.

Signal Indicator Mirrors

The outer portion of the appropriate mirror
housing blinks when you activate the turn
signal.

Heated Exterior Mirrors

 (If Equipped)

See Heated Windows and Mirrors (page
112).

Puddle Lamps

 (If Equipped)

The lamps on the bottom part of the mirror
housing light when you use your
transmitter to unlock the doors or when
you open a door.

Integrated Blind Spot Mirrors

 (If

Equipped)

WARNING

Objects in the blind spot mirror are
closer than they appear.

Blind spot mirrors have an integrated
convex mirror built into the upper outboard
corner of the exterior mirrors. They are
designed to increase your visibility along
the side of your vehicle.

Check the main mirror first before a lane
change, then check the blind spot mirror.
If no vehicles are present in the blind spot
mirror and the traffic in the adjacent lane
is at a safe distance, signal that you intend
to change lanes. Glance over your shoulder
to verify traffic is clear and carefully
change lanes.

A

B

C

E138665

The image of the approaching vehicle is
small and near the inboard edge of the
main mirror when it is at a distance. The
image becomes larger and begins to move
outboard across the main mirror as the
vehicle approaches (A). The image will
transition from the main mirror and begin
to appear in the blind spot mirror as the
vehicle approaches (B). The vehicle will
transition to your peripheral field of view
as it leaves the blind spot mirror (C).

Blind Spot Information System

 (If

Equipped)

See Blind Spot Information System
(page 179).

INTERIOR MIRROR

WARNING

Do not adjust the mirror when your
vehicle is moving.

Note: Do not clean the housing or glass of
any mirror with harsh abrasives, fuel or other
petroleum or ammonia-based cleaning
products.

You can adjust the interior mirror to your
preference. Some mirrors also have a
second pivot point. This lets you move the
mirror head up or down and from side to
side.

Pull the tab below the mirror toward you
to reduce glare at night.

Auto-Dimming Mirror

 (If Equipped)

Note: Do not block the sensors on the front
and back of the mirror. Mirror performance
may be affected. A rear center passenger or
raised rear center head restraint may also
block light from reaching the sensor.

The mirror will dim automatically to reduce
glare when bright lights are detected from
behind your vehicle. It will automatically
return to normal reflection when you select
reverse gear to make sure you have a clear
view when backing up.

SUN VISORS

Illuminated Vanity Mirror

 (If Equipped)

E162197

Lift the cover to switch the lamp on.

SUN SHADES

 (If Equipped)

WARNINGS

Do not let children play with the sun
shade or leave them unattended in
the vehicle. They may seriously hurt

themselves.

When closing the sun shade, you
should verify that it is free of
obstructions and make sure that

children and pets are not in the proximity
of the sunshade.

The control is located in the overhead
console.

The sun shade has a one-touch open and
close feature. To stop motion during
one-touch operation, press the control a
second time.

Opening and Closing the Sun
Shade

E138668

Fully press and release the front of the
control to open the sun shade.

Fully press and release the rear of the
control to close the sun shade.

Bounce-Back

The sun shade will stop automatically
while closing. It will reverse some distance
if there is an obstacle in the way.

Sun Shade Relearning

WARNING

The bounce-back function is not
active during this procedure. Make
sure that there are no obstacles in

the way of the moving sun shade.

Note: You must start the relearning process
within 30 seconds of switching the ignition
on.

In case the sun shade no longer opens or
closes properly, follow this relearning
procedure:

1.

Press the front of the control to the first
action point twice and release it within
two seconds.

2. Press the rear of the control to the first

action point twice and release it within
two seconds.
