Average Fuel Economy

Average Fuel Economy is continuously
averaged since the last reset. You can reset
your average fuel economy by pressing and
holding the OK button on the
corresponding steering wheel controls.

Note: Average fuel economy cannot be
reset in MyView.

Instantaneous Fuel Economy

If your instantaneous fuel economy is
greater than the maximum value
displayed, a + sign will be shown next to
the maximum scale number. When your
vehicle is operating on battery power only,
EV will display and the gauge fill will show
in blue.

INFORMATION MESSAGES

Note:  Depending on the vehicle options
equipped with your vehicle, not all of the
messages display or are available.  Certain
messages may be abbreviated or shortened
depending upon which cluster type you
have.

Press the OK button to acknowledge and
remove some messages from the
information display. Other messages are
be removed automatically after a short
time.

Certain messages need to be confirmed
before you can access the menus.

AdvanceTrac®

Action

Message

Displayed when the system has detected a condition that
requires service. Contact your authorized dealer as soon as
possible.

Service AdvanceTrac

Alarm

Action

Message

Displays when the alarm has been triggered due to unauthor-
ized entry.  See Anti-Theft Alarm (page 67).

Vehicle Alarm To Stop

Alarm, Start Vehicle.

Battery and Charging System (High Voltage)

Action

Message

Your vehicle is ready to drive.

Ready to Drive

Blind Spot Information and Cross Traffic Alert System

Action

Message

A fault with the system has occurred. Contact an authorized

dealer as soon as possible.

Blindspot System Fault

The system sensors are blocked.  See Blind Spot Informa-

tion System (page 170).

Blindspot Not Available

Sensor Blocked See

Manual

The system detects a vehicle.  See Blind Spot Information

System (page 170).

Vehicle Coming From X

The blind spot information system and cross traffic alert

system sensors are blocked.  See Blind Spot Information

System (page 170).

Cross Traffic Not Avail-

able Sensor Blocked See

Manual

A fault with the system has occurred. Contact an authorized

dealer as soon as possible.

Cross Traffic System

Fault

Doors

Action

Message

Displays when the door(s) listed is not completely closed and
the vehicle is moving.

X Door Ajar

Displays when the door(s) listed is not completely closed.

Displays when the liftgate is not completely closed.

Liftgate Ajar

Fuel

Action

Message

An early reminder of a low fuel condition.

Fuel Level Low

Displays if the fuel fill inlet is not properly closed.

Check Fuel Fill Inlet

Wait for up to 15 seconds while the fuel system depressurizes.

Fuel Door Opening

Action

Message

The fuel system has finished depressurizing and you can begin
to refuel.

Fuel Door Open

A reminder to close the fuel door.

Close Fuel Door

There is an error in attempting to refill your vehicle.

Refuel Error See Manual

Hill Start Assist

Action

Message

Displays when hill start assist is not available.  Contact your
authorized dealer.  See Hill Start Assist (page 154).

Hill Start Assist Not

Available

Keys and Intelligent Access

Action

Message

This message is displayed when there is a problem with your
vehicle’s starting system. See your authorized dealer for
service.

Starting System Fault

Displays to remind you that the key is in the luggage
compartment.

Key Inside vehicle

Displays if the key is not detected by the system.

Key Not Inside vehicle

Displayed if the key is not detected by the system.

No Key Detected

Displayed when the start/stop button is pressed to shut off
the engine and a Intelligent Access Key is not detected inside
the vehicle.

Restart Now or Key is

Needed

Displayed when the vehicle is in the Accessory ignition state.

Accessory Power is

Active

Displayed as a reminder to press the brake while starting the
vehicle.

To START Press Brake

Displayed as a reminder to apply the brake and push the start
button to start the vehicle.

Press Brake + Start

Button

Displayed as needed by the system for proper function.

Place Key in Backup

Location

Action

Message

Displayed during spare key programming, when an intelligent
access key is programmed to the system.

Key Programmed x Keys

Total

Displayed during spare key programming when the maximum
number of keys have been programmed.

Max Number of Keys

Learned

Displayed when an attempt is made to program a spare key
using two existing MyKeys.

Could Not Program

Integrated Key

Informs you that upon exiting your vehicle that the vehicle is
still on.

Vehicle is ON

Maintenance

Action

Message

Stop the vehicle as soon as safely possible, turn off the engine.
Check the oil level. If the warning stays on or continues to
come on with your engine running, contact your authorized
dealer as soon as possible.

Low Engine Oil Pressure

Displayed when the engine oil life remaining is 10% or less.

Change Engine Oil Soon

Displayed when the oil life left reaches 0%.

Oil Change Required

Indicates the brake fluid level is low and the brake system
should be inspected immediately.  See Brake Fluid Check
(page 221).

Brake Fluid Level Low

Displays when the brake system needs servicing. Stop the
vehicle in a safe place. Contact your authorized dealer.

Check Brake System

Displays when the engine coolant temperature is excessively
high.

Engine Coolant Over

Temperature

Displays when the motor coolant temperature is excessively
high.

Motor Coolant Over

Temperature

Displayed when the kit needs service. See your authorized
dealer.

Service Tire Mobility Kit

Informs the driver that the powertrain needs service due to a
powertrain malfunction.

See Manual
