Trip 1 & 2

Provides trip odometer, trip average fuel
economy and trip timer.

Distance traveled on battery power only
with the engine off is shown in blue next
to total trip distance.

Info

In this mode, you can view
different vehicle system
information and perform a

system check.

Information

Displays a number of different system tutorials. Use the up/down
arrows to scroll through the tutorials. Then press OK to view.

Tutorial

MyKeys (Number of MyKeys programmed)

MyKey

MyKey Miles (km) (Distance traveled using a programmed MyKey)

Admin Keys (Number of admin keys)

All active warnings will display first if applicable. The system check
menu may appear different based upon equipment options and
current vehicle status. Use the up/down arrow buttons to scroll
through the list.

System Check

Settings

In this mode, you can configure
different driver setting choices.

Note: Some items are optional and may not appear.

Note: Some MyKey items will only appear if a MyKey is set.

Settings

Menu level 6

Menu level 5

Menu level 4

Menu level 3

Menu level 2

—

On or Off

Traction Ctrl

Driver Assist

—

On or Off

Blindspot

—

On or Off

Cross Traffic

—

On or Off

Rear Park Aid

—

Hold OK to
Reset

Tire Monitor

—

On or Off

Auto Engine
Off

Vehicle

Settings

On or Off

Auto Light
Rain

Lighting

On or Off

Daytime
Lights

Select time interval

Home Light

Auto or Last
Settings

Heater - A/C

Climate
Control

Remote Start

Auto or Off

Front Defrost

Auto or Off

Rear Defrost

Auto or Off

Driver Seat

Auto or Off

Passenger Seat

5, 10 or 15 minutes

Duration

On or Off

Quiet Start

Enable or Disable

System

—

Select
number of
years

Tire Mobility
Kit

—

Hold OK to
Create MyKey

Create MyKey

MyKey

—

Always On or
User Select-
able

Traction
Control

—

Choose
desired speed
or off

Max Speed

—

Choose
desired speed
or off

Speed
Warning

—

On or Off

Volume
Limiter

—

Hold OK to
Clear All
MyKeys

Clear MyKeys

Settings

—

Select the
desired
language

Language

Display

Select the desired units of measure

Distance

Units

Fahrenheit (°F) or Celsius (°C)

Temperature

—

On or Off

Brake Coach

—

On or Off

Battery
Display

—

On or Off

Regen Display

—

Hold OK to
Reset

Driving History

Right Information Display Controls

•

Press the up and down arrow buttons
to scroll through and highlight the
options within a menu.

•

Press the right arrow button to enter a
sub-menu.

•

Press the left arrow button to exit a
menu.

•

Press the OK button to choose and
confirm your selection.

Main menu

From the main menu bar on the right side
of the information display, you can choose
from the following categories:

Entertainment

See your SYNC information.

Navigation or Compass

See your SYNC information.

Phone

See your SYNC information.

Fuel Economy

Use the up or down arrow buttons to
choose between the following display
options.

Note: The information display will remember the menu level 2 state when you change the
individual key state from the RUN to the OFF position.

Fuel Economy

Menu level 5

Menu level 4

Menu level 3

Menu level 2

—

—

Help

Efficiency Leaves

—

5, 10 or 30 minutes

Duration

Fuel History
(Instantaneous Fuel
Economy + Fuel
Economy History + Avg
Fuel Economy)

—

—

Help

—

—

Help

Coach

Efficiency Leaves

Efficiency leaves indicate short term driving
efficiency measured over the last few
minutes. The more leaves and vines that
appear on the display, the better your fuel
economy. Leaves and vines will
occasionally appear and disappear to
indicate a change in your driving efficiency.

Fuel History

From left to right this view includes an
instantaneous fuel economy gauge,
historical fuel economy data and average
fuel economy. The historical data
represents an average over time intervals
of either 1, 2 or 6 minutes, with the leftmost
interval being the most recent. Shown at
the bottom of the view is the total time
duration for the 5 intervals. You can select
total duration in the options menu.
Intervals shown in grey color are from the
previous drive. The blue horizontal line
represents the average fuel economy value
shown to the right.

Note: Hold OK to reset fuel history and
average fuel economy.

Coach

This view provides a comparison of your
recent acceleration, braking and cruising
behavior, then recommends the most
efficient use of energy under present
conditions. The horizontal bars fill from left
to right with best behavior and appear blue
when at least half full. When the bars are
less than half full, the color is amber,
suggesting that you need a change in your
driving behavior to achieve better energy
efficiency.

Note: Fuel Economy will be impacted by
your use of brakes, accelerator and
accessories, as well as environmental
conditions such as hills and weather.

Note: Fuel economy is not always a
measure of appropriate driving behavior. For
example, when driving uphill and
maintaining an appropriate speed, your
instant fuel economy may not be good
(losing leaves) but the Coach may show a
blue bar for Acceleration and Cruising.

Common Displays

Both Average fuel economy and an
instantaneous fuel economy gauge are
included in Engage, Empower, MyView (if
selected) on the left information display.
They are also included in Fuel History on
the right information display.
