SWITCHING REAR OCCUPANT
ALERT SYSTEM ON AND OFF

1. Press Settings on the touchscreen.
2. Press Vehicle.

3. Switch Rear Occupant Alert on or off.
Note: The default setting is on.

Note: Performing a master reset causes the
system to switch on again.

Semiannual Reminder

 (If Equipped)

When you switch the system off, a message
appears every six months as a reminder that
the system is off. You can switch the system
back on or leave it off.

REAR OCCUPANT ALERT SYSTEM
INDICATORS

E350472

Message

Check rear seats for occupants.

Displays when you switch your vehicle off
after the alert conditions are met.

The message displays for a short period of
time.  Press Close to acknowledge and
remove the message.

Note: Depending on your SYNC version, the
graphic may look different from what you
see here.

REAR OCCUPANT ALERT SYSTEM
AUDIBLE WARNINGS

Sounds when you switch your vehicle off
after the alert conditions are met.

The warning sounds for a short period of
time.

184

Rear Occupant Alert System

WHAT IS THE MEMORY FUNCTION

The driver seat memory function recalls the
position of these features:

•

Driver seat.

•

Power mirrors.

•

Power steering column.

•

Power adjustable foot pedals.

The passenger seat memory function recalls
the position of the passenger seat.

MEMORY FUNCTION
PRECAUTIONS

WARNING: Before activating the

memory seat, make sure that the area
immediately surrounding the seat is clear
of obstructions and that all occupants are
clear of moving parts.

WARNING: Do not use the memory

function when your vehicle is moving.

LOCATING THE MEMORY
FUNCTION BUTTONS

E222235

The memory control for the driver is on the
driver door.

The memory control for the passenger is on
the passenger door.

SAVING A PRESET POSITION

1. Adjust the memory features to your

preferred position.

2. Press and hold the preferred preset

button until you hear a single tone.

A confirmation message appears in the
information display.

You can save up to three preset memory
positions at any time.

To save a preset position for the passenger
door:

1. Adjust the passenger seat to your

preferred position.

2. Press and hold the preferred preset

button until you hear a single tone.

You can save up to three preset memory
positions at any time.

RECALLING A PRESET POSITION

Press and release a preset button.

185

Memory Function

Note: You can recall a preset memory
position when the ignition is off, or when you
place the transmission in park (P) or neutral
(N) if the ignition is on and the vehicle is not
moving.

Note: Pressing any of the preset buttons or
any memory feature control during a memory
recall cancels the operation.

You can also recall a preset memory position
by:
•

Pressing the unlock button on your
remote control if you linked it to a preset
position.

•

Unlocking the intelligent driver door
handle if a linked remote control is
present.

•

Recalling a personal profile in your SYNC
menu.

Using a linked remote control to recall your
memory position when the ignition is off
moves the seat and steering column to the
easy entry position.

To recalll a preset position on the passenger
door, press and release the preset button.
The passenger seat features move to the
position stored for that preset. You can recall
a passenger seat preset memory at any time.

Linking a Preset Position to Your
Remote Control or Passive Key

See Linking or Unlinking a Personal Profile
to a Remote Control (page 517).

186

Memory Function

WHAT IS THE GARAGE DOOR
OPENER

HomeLink Wireless Control System

E188211

The universal garage door opener replaces
the common hand-held garage door opener
with a three-button transmitter integrated
into the driver’s sun visor.

HOW DOES THE GARAGE DOOR
OPENER WORK

The system includes two primary features, a
garage door opener and a platform for
remote activation of devices within the home.
You can program garage doors as well as
entry gate operators, security systems, entry
door locks and home or office lighting.

Additional system information can be found
online at www.homelink.com or by calling
the toll-free help line at 1-800-355-3515.

Note: You can program a maximum of three
devices. To change or replace any of the
three devices after it has been initially
programmed, you must first erase the current
settings.  See Clearing the Garage Door
Opener (page 190).

GARAGE DOOR OPENER
PRECAUTIONS

WARNING: Do not use the system

with any garage door opener that does not
have the safety stop and reverse feature
as required by U.S. Federal Safety
Standards (this includes any garage door
opener manufactured before April 1, 1982).
A garage door opener which cannot detect
an object, signaling the door to stop and
reverse, does not meet current federal
safety standards. Using a garage door
opener without these features increases
the risk of serious injury or death.

Note: Make sure that the garage door and
security device are free from obstruction
when you are programming. Do not program
the system with your vehicle in the garage.

Note: Make sure you keep the original
remote control transmitter for use in other
vehicles as well as for future system
programming.

187

Garage Door Opener

Note: We recommend that upon the sale or
lease termination of your vehicle, you erase
the programmed function buttons for security
reasons.  See Clearing the Garage Door
Opener (page 190).

GARAGE DOOR OPENER
LIMITATIONS

Canadian radio-frequency laws require
transmitter signals to time-out (or quit) after
several seconds – which may not be long
enough for HomeLink to pick up the signal.

U.S. gate operators time-out in the same
manner.

Note: If programming a garage door opener
or gate operator, it is advised to unplug the
device during the “cycling” process to
prevent possible overheating.

PROGRAMMING THE GARAGE
DOOR OPENER TO YOUR HAND-
HELD TRANSMITTER

This process is to program your in-vehicle
HomeLink function button with your
hand-held transmitter.

Note: The programming steps below assume
you will be programming HomeLink that was
not previously programmed. If your
HomeLink was previously programmed, you
may need to erase your HomeLink buttons.
See Clearing the Garage Door Opener
(page 190).

E188212

1. With your vehicle parked outside of the

garage, switch your ignition to the on
position, but do not start your vehicle.

2. Press and release one of the three

HomeLink function buttons that you
would like to program.

3. Hold your hand-held garage door

transmitter 1–3 in (2–8 cm) away from the
HomeLink button you want to program.

4. Press and hold the hand-held transmitter

button you want to program while
watching the indicator light on HomeLink.
Continue to hold the hand-held button
until the HomeLink indicator light flashes
rapidly or is continuously on.

Note: You may need to use a different
method if you live in Canada or have
difficulties programming your gate operator
or garage door opener.  See Programming
the Garage Door Opener to Your Gate
Opener Motor (page 189).

5. Press and hold the HomeLink button you

programmed for two seconds, then
release. You may need to do this twice
to activate the door.

188

Garage Door Opener

Note: If the indicator light stays on, the
programming is complete.

Note: If the HomeLink indicator flashes
rapidly, repeat step 5.

Note: If your device still does not operate,
you must program your garage door.  See
Programming the Garage Door Opener to
Your Garage Door Opener Motor (page 189).

6. To program additional buttons, repeat

Steps 1 – 4.

PROGRAMMING THE GARAGE
DOOR OPENER TO YOUR GARAGE
DOOR OPENER MOTOR

E142659

1. Press the learn button on the garage

door opener motor, you have 30 seconds
to complete the next two steps.

2. Return to your vehicle.

E188212

3. Press and hold one of the three

HomeLink function buttons you want to
program for two seconds, then release.
Repeat this step. Depending on your
brand of garage door opener, you may
need to repeat this sequence a third time.

PROGRAMMING THE GARAGE
DOOR OPENER TO YOUR GATE
OPENER MOTOR

Gate Operator / Canadian
Programming

Canadian radio-frequency laws require
transmitter signals to “time-out” (or quit) after
several seconds of transmission – which may
not be long enough for HomeLink to pick up
the signal during programming. Similar to
this Canadian law, some U.S. gate operators
“time-out” in the same manner.

Note: If programming a garage door opener
or gate operator, it is advised to unplug the
device during the “cycling” process to
prevent possible overheating.

1. Press and release, every two seconds,

your hand-held transmitter until the
HomeLink indicator light changes to a
rapidly blinking or continuously on light.

2. Release the hand-held transmitter button.

189

Garage Door Opener

3. Press and hold the HomeLink function

button you want to program for two
seconds, then release. You may need to
do this twice to activate the door.

Note: If the indicator light stays on, the
programming is complete.

Note: If the HomeLink indicator flashes
rapidly, repeat Step 3.

Note: If your device still does not operate,
you must program your garage door.  See
Programming the Garage Door Opener to
Your Garage Door Opener Motor (page 189).

4. To program additional buttons, repeat

Steps 1 – 4.

CLEARING THE GARAGE DOOR
OPENER

E188213

1. Press and hold the outer two function

buttons simultaneously for approximately
10 seconds until the indicator light above
the buttons flashes rapidly.

2. When the indicator light flashes, release

the buttons.

Note: You cannot erase individual buttons.

REPROGRAMMING THE GARAGE
DOOR OPENER

To program a device to a previously trained
button, follow these steps:

1. Press and hold the desired button. Do

NOT release the button.

2. The indicator light begins to flash after

20 seconds. Without releasing the
button, follow programming steps.

GARAGE DOOR OPENER RADIO
FREQUENCIES

FCC and RSS-210 Industry Canada
Compliance

WARNING: Changes or modifications

not expressively approved by the party
responsible for compliance could void the
user's authority to operate the equipment.
The term "IC:" before the radio certification
number only signifies that Industry Canada
technical specifications were met.

190

Garage Door Opener

This device complies with Part 15 of the FCC
Rules and with RSS-210 of Industry Canada.
Operation is subject to the following two
conditions: (1) this device may not cause
harmful interference, and (2) this device must
accept any interference received, including
interference that could cause undesired
operation.

This equipment complies with FCC radiation
exposure limits set forth for an uncontrolled
environment. End Users must follow the
specific operating instructions for satisfying
RF exposure compliance. This transmitter
must be at least 8 in (20 cm) from the user
and must not be co-located or operating in
conjunction with any other antenna or
transmitter.

191

Garage Door Opener

LOCATING THE USB PORTS

Data Transfer USB Ports

The USB ports could be in the following
locations:

•

On the lower instrument panel below the
climate control.

•

Inside the center console.

Note:  These USB ports can also charge
devices.

Note:  Not all USB ports in your vehicle have
data transfer capabilities.

Note:  We recommend using only USB-IF
certified cables and adapters. Non-certified
cables and adapters may not work.

Charge Only USB Ports

The USB ports could be in the following
locations:

•

On the lower instrument panel.

•

On the upper instrument panel.

•

Inside the media bin.

•

Inside the center console.

•

On the rear of the center console.

•

In the cargo area.

PLAYING MEDIA USING THE USB
PORT

WARNING: Driving while distracted

can result in loss of vehicle control, crash
and injury. We strongly recommend that
you use extreme caution when using any
device that may take your focus off the
road. Your primary responsibility is the safe
operation of your vehicle. We recommend
against the use of any hand-held device
while driving and encourage the use of
voice-operated systems when possible.
Make sure you are aware of all applicable
local laws that may affect the use of
electronic devices while driving.

Connect your device to the USB port.

E100027

Press the audio button on the
feature bar.

Select Sources.

Select the USB option.

Press the button to play a track.
Press the button again to pause
the track.

Press the button to skip to the next
track.

Press and hold the button to fast

forward through the track.

Press the button once to return to
the beginning of a track.
Repeatedly press the button to

return to previous tracks.

Press and hold the button to fast rewind.

CHARGING A DEVICE

Connect your device to the USB port.

192

USB Ports

Data Transfer USB Ports

You can charge your device through the data
transfer USB port when SYNC is on.

Charge Only USB Ports

You can charge your device through the
charge only USB port when the vehicle is in
accessory mode or when the vehicle is
running.

193

USB Ports

WHAT IS THE POWER OUTLET

The power outlet can power devices using
a 12 V outlet adapter.

POWER OUTLET PRECAUTIONS

WARNING: Do not plug optional

electrical accessories into the cigar lighter
socket. Incorrect use of the cigar lighter
can cause damage not covered by the
vehicle warranty, and can result in fire or
serious injury.

When you switch the vehicle on, you can use
the socket to power 12 V appliances with a
maximum current rating of 20 A. Do not use
the power point over the vehicle capacity of
12 V DC 240 W or a fuse could blow. Do not
plug in any device that supplies power to the
vehicle through the power points. This could
result in damage to vehicle systems. Do not
hang any accessory from the accessory plug.
Always keep the power point caps closed
when not in use. Do not insert objects other
than an accessory plug into the power point.

To prevent the battery from running out of
charge:
•

Do not use the power point longer than
necessary when the vehicle is off.

•

Do not leave devices plugged in
overnight or when you park your vehicle
for extended periods.

LOCATING THE POWER OUTLETS

Power outlets may be in the following
locations:
•

On the lower instrument panel.

•

Inside the center console.

•

On the front of the center console.

•

On the rear of the center console.

•

In the cargo area.

•

On the passenger side floor panel.

•

3rd row on the quarter trim panels.

194

Power Outlet - Vehicles With: 12V Power Outlet

WHAT IS THE POWER OUTLET

The power outlet is a socket that connects
an electrical device to your vehicle's power
supply.

POWER OUTLET PRECAUTIONS

WARNING: Do not keep electrical

devices plugged into the power outlet
whenever the device is not in use. The
outlet provides power when the vehicle is
on. Failure to follow this instruction could
result in personal injury.

WARNING: Do not use an extension

cord or connect multiple devices to the
power outlet. Doing so could result in
overloading the power outlet. Failure to
follow this instruction could result in fire,
personal injury or property damage.

POWER OUTLET LIMITATIONS

You should not use the power outlet for
these types of electric devices:
•

Cathode ray tube type televisions.

•

Motor loads, such as vacuum cleaners,
electric saws or other electric power tools
and compressor-driven refrigerators.

•

Measuring devices which process precise
data, such as medical equipment or
measuring equipment.

•

Other appliances requiring an extremely
stable power supply, such as
microcomputer-controlled electric
blankets or touch sensor lamps.

Note: Some devices may exceed the power
rating on the device label when they are
initially plugged-in and may require you to
press the device power button more than
one time in order to allow a soft start. After
multiple attempts, if the device remains off,
please consider that your device may require
more than the available power.

Note: The power outlet provides full
available power when the vehicle is in park
(P). Power availability may be reduced when
the vehicle is in drive (D). If more than one
outlet is available in the vehicle, power is
divided between the outlets that are in use
at the same time.

LOCATING THE POWER OUTLETS

The power outlet is on the instrument panel
or the rear of the center console.

E353449

195

Power Outlet - Vehicles With: 110V Power Outlet

POWER OUTLET INDICATORS

The power outlet indicator illuminates to let
you know the status of the system.

Description

Indicator Status

When the indicator

light is on, the outlet

is providing power.

On

When the indicator

light is off, there is

no power to the

outlet.

Off

When the indicator

light is flashing, the

outlet is in a fault

mode.

Flashing

Fault mode

The power outlet temporarily turns off power
if the device exceeds the watt limit.

1. Unplug your device.

2. Switch your vehicle off to let the system

cool and reset the fault mode.

3. Switch your vehicle back on, but do not

plug your device back in.

4. With your vehicle on, make sure the

indicator light remains on.

5. Make sure your device does not exceed

the power limits and then plug in your
device.

Note: If a fault occurs again, your device
may exceed the capacity available from the
power outlet.

196

Power Outlet - Vehicles With: 110V Power Outlet

WHAT IS THE WIRELESS
ACCESSORY CHARGER

The wireless accessory charger allows you
to charge one compatible Qi wireless
charging device on the charging area.

WIRELESS ACCESSORY CHARGER
PRECAUTIONS

WARNING: Wireless charging

devices can affect the operation of
implanted medical devices, including
cardiac pacemakers. If you have any
implanted medical devices, we recommend
that you consult with your physician.

Keep the charging area clean and remove
foreign objects prior to charging a device.

Do not place items with a magnetic strip or
radio-frequency identification chip, for
example passports, parking tickets,
transportation passes or credit cards, near
the charging area when charging a device.
Damage could occur to the magnetic strip
or radio-frequency identification chip.

Do not place metal objects, for example
remote controls, coins and candy wrappers,
on or near the charging area when charging
a device. Metal objects may heat up and
degrade the charging performance, in
addition to causing interruptions in charging.

Charging could be interrupted, degraded, or
could stop if any of the following occur:

•

The system detects a foreign object.

•

The device is misaligned on the charging
area.

•

The device moves on the active charging
area when the vehicle is in motion.

•

The vehicle ambient temperature is too
high.

•

You attempt to charge a non-Qi
compatible device on the wireless
charger.

Note: During charging, the device and the
charger could heat up, this is normal. If the
battery gets hotter than usual, the device
may stop charging.

LOCATING THE WIRELESS
ACCESSORY CHARGER

E297549

The charging area is on the center
console or in the media bin below
the instrument panel.

CHARGING A WIRELESS DEVICE

Place the device on the center of the
charging surface with the charging side
down. The charging stops after your device
reaches a full charge.

You can use the charger when the vehicle
is in accessory mode, when the vehicle is
running, or when SYNC is on.

Displays on the status bar when
wireless charging is in progress.

197

Wireless Accessory Charger

Note: The charging performance may be
affected if your device is in a case. It may be
necessary to remove the case to wirelessly
charge your device.

Note: Software and firmware updates may
affect device compatibility, including the use
of unofficial software or firmware. You should
verify charging functionality with your
specific devices in-vehicle.

198

Wireless Accessory Charger

OVERHEAD STORAGE

OPENING THE OVERHEAD STORAGE
COMPARTMENT

E332434

Press near the rear edge of the door to open
it.

GLOVE COMPARTMENT

OPENING THE GLOVE
COMPARTMENT

E310218

Pull the latch to the left to open.

CENTER CONSOLE

OPENING THE CENTER CONSOLE

E355167

To open the center console storage
compartment, grab the handle and lift up.

199

Storage
