Lincoln Navigator (2022 year). Manual in english - page 10

E327919

1. Adjust the seat backrest to an upright

driving or riding position.

2. Pivot the head restraint forward toward

your head to the preferred position.

After the head restraint reaches the
forward-most tilt position, pivot it forward
again to release it to the rearward, untilted
position.

Note: Do not attempt to force the head
restraint backward after it is tilted. Instead,
continue tilting it forward until the head
restraint releases to the upright position.

Power Head Restraints

 (If Equipped)

E222280

To raise the head restraint, lift the switch up.

To lower the head restraint, press the switch
down.

To move the head restraint forward, push
the switch forward.

To move the head restraint rearward, push
the switch rearward.

REMOVING THE HEAD RESTRAINT

1. Pull up the head restraint until it reaches

its highest position.

2. Press and hold the adjust and release

button and the unlock and remove
button.

3. Pull up the head restraint.

Note: You cannot remove head restraints
that have audio system speakers.

INSTALLING THE HEAD RESTRAINT

Align the steel stems into the guide sleeves
and push the head restraint down until it
locks.

168

Front Seats

MOVING THE SEAT BACKWARD AND
FORWARD

E348863

ADJUSTING THE SEAT CUSHION

E349631

Adjusting the Length of the Seat
Cushion

E221053

Press the top of the control to adjust the left
side of the cushion.

Press the bottom of the control to adjust the
right side of the cushion.

169

Front Seats

ADJUSTING THE SEAT BACKREST

WARNING: Do not place cargo or

any objects behind the seatback before
returning it to the original position.

WARNING: Do not adjust the driver

seat or seat backrest when your vehicle is
moving. This may result in sudden seat
movement, causing the loss of control of
your vehicle.

E348865

Adjusting the Upper Seat Backrest

E348864

170

Front Seats

ADJUSTING THE SEAT HEIGHT

E349633

ADJUSTING THE LUMBAR SUPPORT

E222308

MASSAGE SEATS

 (IF EQUIPPED)

MASSAGE SEAT LIMITATIONS

The engine must be running or the vehicle
must be in accessory mode to activate the
seats.

The passenger side massage is available if
the occupant meets the seat sensor weight
requirements.

Allow a few seconds for any selection to
activate. Selecting a different adjustment
cancels the current one in progress. When
the seat backrest and cushion are both
active, the massage alternates between
zones.

ADJUSTING THE MASSAGE SEAT
SETTINGS

E222219

Increase the massage intensity.

A

Select the massage feature.

B

Decrease the massage intensity.

C

On and off.

D

You can also adjust this feature through the
touchscreen.

171

Front Seats

HEATED SEATS

HEATED SEAT PRECAUTIONS

WARNING: Use caution when using

the heated seat if you are unable to feel
pain to your skin because of advanced
age, chronic illness, diabetes, spinal cord
injury, medication, alcohol use, exhaustion
or other physical conditions. The heated
seat could cause burns even at low
temperatures, especially if used for long
periods of time. Failure to follow this
instruction could result in personal injury.

WARNING: Do not poke sharp

objects into the seat cushion or seat
backrest. This could damage the heated
seat element and cause it to overheat.
Failure to follow this instruction could result
in personal injury.

WARNING: Do not place anything on

the seat that blocks the heat, for example
a seat cover or a cushion. This could cause
the seat to overheat. Failure to follow this
instruction could result in personal injury.

Do not:
•

Place heavy objects on the seat.

•

Operate the heated seat if water or any
other liquid spills on the seat. Allow the
seat to dry.

SWITCHING THE HEATED SEATS ON
AND OFF

The vehicle must be running to use this
feature.

E146322

Press the heated seat symbol to cycle
through the various heat settings and off.
More indicator lights indicate warmer
settings.

Note: The heated seats may remain on after
you remote start your vehicle, based on your
remote start settings. The heated seats may
also turn on when you start your vehicle if
they were on when you switched your
vehicle off.

Automatic Climate Controlled Seats

 (If

Equipped)

When you switch the auto setting on, the
climate controlled seats switch between the
heated seats and ventilated seats to match
your climate control setting.

172

Front Seats

VENTILATED SEATS

VENTILATED SEAT PRECAUTIONS

Do not:
•

Spill liquid on the front seats. This may
cause the air vent holes to become
blocked and not work properly.

•

Place cargo or objects under the seats.
They may block the air intake causing
the air vents to not work properly.

SWITCHING THE VENTILATED SEATS
ON AND OFF

The vehicle must be running to use this
feature.

E224689

Press this symbol on the climate controls or
the touchscreen to cycle through the various
ventilation settings and off. More indicator
lights indicate higher fan speeds.

Note: When you switch the climate control
fan speed and the ventilated seats to their
maximum settings, the ventilated seats
provide increased cooling.

If the engine falls below 350 RPM while the
ventilated seats are on, the feature turns
itself off unless the vehicle is in
Auto-Start-Stop mode. You may need to
reactivate the ventilated seats.

Note: The ventilated seats may remain on
after you remote start your vehicle, based
on your remote start settings. The ventilated
seats may also turn on when you start your
vehicle if they were on when you switched
your vehicle off.

173

Front Seats

MANUAL SEATS

HEAD RESTRAINT COMPONENTS

The second row outermost head restraints
are not adjustable or foldable.

E354503

The head restraints consist of:

An energy absorbing foam and
structure.

A

Two steel stems.

B

Guide sleeve unlock and remove
button.

C

Second Row Center Head Restraint

E138645

The head restraint consists of:

An energy absorbing foam and
structure.

A

Two steel stems.

B

Guide sleeve adjust and release
button.

C

Guide sleeve unlock and remove
button.

D

Third Row Head Restraints

The third row head restraints are
non-adjustable, but you may be able to fold
them.

E193964

The head restraints consist of:
•

A trimmed energy absorbing foam and
structure.

•

A fold button, if equipped.

174

Rear Seats

ADJUSTING THE HEAD RESTRAINT

For the second row center head restraint,
pull the head restraint up to raise it.

To lower the head restraint:

1. Press and hold the adjust and release

button.

2. Push the head restraint down.

To fold the second row outermost and third
row head restraints:

1. Press the fold button.

2. Pull the head restraint up to place it back

to the upright position.

REMOVING THE HEAD RESTRAINT

For the second row outermost head
restraints:

1. Pull the head restraint up until it reaches

its highest position.

2. Press and hold the guide sleeve unlock

and remove button.

3. Pull the head restraint up.

For the second row center head restraint:

1. Pull the head restraint up until it reaches

its highest position.

2. Press and hold guide sleeve adjust and

release button and the guide sleeve
unlock and remove button.

3. Pull the head restraint up.

INSTALLING THE HEAD RESTRAINT

Align the steel stems into the guide sleeves
and push the head restraint down until it
locks.

For the second row outermost head
restraints, make sure the fold button is facing
the outermost side of the seat.

MOVING THE SEAT BACKWARD AND
FORWARD

E247034

Lift the handle to move the second row
center seat forward or backward.

Note: Move the seat forward to keep a child
in a child restraint close to the front seat
occupants. Move the seat to the full
rearward position when it is occupied by
older children or adults, including children
in booster seats.

175

Rear Seats

ADJUSTING THE SEAT BACKREST

WARNING: Reclining the seatback

can cause an occupant to slide under the
seat's seatbelt, resulting in severe personal
injuries in the event of a crash.

E247681

For the second row outermost seats, the
release handle is on the outermost side of
the seat cushion. Lift it to adjust the seat
backrest to your preferred position.

FOLDING THE SEAT BACKREST

E246710

1. Locate the handle on the outermost side

of the seat cushion.

2. Pull up on the handle to fold the seat

backrest.

Note: Use caution when folding the seat
backrest to the flat position as the seat
moves forward when you lift the release
handle.

Folding the Second Row Center Seat

(If Equipped)

WARNING: To prevent possible

damage to the seat or seatbelts, make sure
that the seatbelts are not fastened before
folding the seatback.

E247331

The release handle is in the upper right seat
backrest. Pull the handle to release the
folding seat latch.

Note: Use the same release handle to
recline the seat backrest.

176

Rear Seats

UNFOLDING THE SEATS

WARNING: Do not place cargo or

any objects behind the seat backrest
before returning it to the original position.
Pull on the seat backrest to make sure that
it has fully latched after returning the seat
backrest to its original position. An
unlatched seat may become dangerous if
you stop suddenly or have a crash.

E246709

1. Lift the seat backrest toward the rear of

the vehicle.

2. Rotate the seat backrest until it engages,

locking it in the upright position.

ACCESSING THE THIRD ROW SEATS

WARNING: Do not drive your vehicle

with a seat that is unlatched or in the
folded position. Failure to follow this
instruction could result in personal injury
or death in the event of a sudden stop or
crash.

WARNING: Check under the seat

cushion to make sure no cargo or objects
are under the seat cushion before
returning the seat cushion to its original
position, and that the seat cushion locks
into place. Failure to do so may prevent
the seat from operating properly in the
event of a crash, which could increase the
risk of serious injury.

WARNING: Do not place cargo or

any objects behind the seat backrest
before returning it to the original position.
Pull on the seat backrest to make sure that
it has fully latched after returning the seat
backrest to its original position. An
unlatched seat may become dangerous if
you stop suddenly or have a crash.

Note: You can move the outermost seats
forward to allow access to the third row
seats.

This feature allows for easier entry and exit
to and from the third row seat.

177

Rear Seats

E257686

1. Pull the lever on the top of the seat

backrest up.

2. Tilt the entire seat forward.

3. Slide the seat forward until it stops.

To return the seat to the seating position,
slide the seat rearward while pulling down
on the seat backrest until the latch fully
engages.

To move the seat further back, pull the lever
under the front of the seat and slide it
backward.

Note:  You must move the seat to the full
forward position before you move it
rearward. Otherwise, the seat may not slide
properly rearward.

Note: You can slide the outermost seats
forward when using a child restraint.

Adjusting the Second Row Outermost
Seats for Easy Exit

E246708

When exiting your vehicle from the third row
seats, pull the lever up on the upper corner
of the outermost seats. Then, push the seat
forward until it stops.

POWER SEATS

ADJUSTING THE HEAD RESTRAINT

The third row outermost head restraints are
fixed and cannot be removed.

E272543

178

Rear Seats

Press the button on the head restraint or the
button on the instrument panel to the left of
the steering wheel to fold the third row
outermost head restraints. Pull the head
restraint up to place it in the upright position.

Note: These head restraints fold when you
press the fold flat button.

ADJUSTING THE SEAT BACKREST

WARNING: Do not recline a rear seat

on which a child restraint is installed.
Failure to follow this instruction could
reduce the effectiveness of the child
restraint.

The third-row power recline buttons are on
the quarter trim panel on each side of the
vehicle.

E246706

Moves the seat backrest rearward.

A

Moves the seat backrest forward.

B

FOLDING THE SEAT BACKREST

The control buttons are on the left-hand rear
quarter trim panel and are accessible from
the liftgate area.

Second Row Bench Seats

E257920

179

Rear Seats

Second Row Captain Chairs

E246705

Folds the left-hand third-row seat.

A

Folds both third-row seats.

B

Folds the right-hand third-row seat.

C

Folds the left-hand second-row
seat.

D

Folds the second-row bench
center seat or both second-row
captain chair seats.

E

Folds the right-hand second-row
seat.

F

Note: The power fold seats operate for 10
minutes after you switch the ignition off. The
transmission must be in park (P) and the
liftgate, or liftgate glass must be open.
Similar to the battery saver feature, the
power rear seats disable 10 minutes after
you switch the ignition off.

Note: Be sure the third-row center head
restraint is in the lowered position before
you power the rear seats down. The
third-row outermost head restraints fold
automatically when you press the fold
button.

UNFOLDING THE SEAT BACKREST

To return the second-row seat backrest to
the original position, rotate the seat backrest
up until it latches in the upright position. The
seat backrest clicks when it is locked into
position.

To return the third-row seat backrest to the
original position, press the corresponding
control again.

Note: If the third row seat does not
completely fold or unfold, press and hold the
seat button until the seat folds and unfolds
twice.

If the power rear seat is disabled after 10
minutes, you can enable the seat by:
•

Opening any door.

•

Pressing the unlock button on the key
fob.

•

Pressing any keyless entry keypad
button.

•

Switching the ignition on.

Folding Down the Rear Seats to the
Load Floor

WARNING: To prevent possible

damage to the seat or seatbelts, make sure
that the seatbelts are not fastened before
folding the seatback.

180

Rear Seats

WARNING: Do not place cargo or

any objects behind the seatback before
returning it to the original position.

The third-row seats have obstacle detection
that prevents the seats from folding or
returning if they are obstructed.

MASSAGE SEATS

 (IF EQUIPPED)

MASSAGE SEAT LIMITATIONS

The engine must be running or the vehicle
must be in accessory mode to activate the
seats.

This feature is disabled when the child safety
locks are on.

Allow a few seconds for any selection to
activate. Selecting a different adjustment
cancels the current one in progress. When
the seat backrest and cushion are both
active, the massage alternates between
zones.

SWITCHING THE MASSAGE SEATS ON
AND OFF

You can adjust this feature through the rear
touchscreen.

HEATED SEATS

HEATED SEAT PRECAUTIONS

WARNING: Use caution when using

the heated seat if you are unable to feel
pain to your skin because of advanced
age, chronic illness, diabetes, spinal cord
injury, medication, alcohol use, exhaustion
or other physical conditions. The heated
seat could cause burns even at low
temperatures, especially if used for long
periods of time. Failure to follow this
instruction could result in personal injury.

WARNING: Do not poke sharp

objects into the seat cushion or seat
backrest. This could damage the heated
seat element and cause it to overheat.
Failure to follow this instruction could result
in personal injury.

WARNING: Do not place anything on

the seat that blocks the heat, for example
a seat cover or a cushion. This could cause
the seat to overheat. Failure to follow this
instruction could result in personal injury.

Do not:
•

Place heavy objects on the seat.

•

Operate the heated seat if water or any
other liquid spills on the seat. Allow the
seat to dry.

SWITCHING THE HEATED SEATS ON
AND OFF

The vehicle must be running to use this
feature.

181

Rear Seats

The rear seat heat controls are on the rear
of the center console.

E146322

Press the heated seat symbol to cycle
through the various heat settings and off.
More indicator lights indicate warmer
settings.

Note: The heated seats may remain on after
you remote start your vehicle, based on your
remote start settings. The heated seats may
also turn on when you start your vehicle if
they were on when you switched your
vehicle off.

Automatic Climate Controlled Seats

 (If

Equipped)

When you switch the auto setting on, the
climate controlled seats switch between the
heated seats and ventilated seats to match
your climate control setting.

VENTILATED SEATS

VENTILATED SEAT PRECAUTIONS

Do not:
•

Spill liquid on the seats. This may cause
the air vent holes to become blocked and
not work properly.

•

Place cargo or objects under the seats.
They may block the air intake causing
the air vents to not work properly.

SWITCHING THE VENTILATED SEATS
ON AND OFF

The vehicle must be running to use this
feature.

E224689

Press this symbol on the climate controls or
the rear touchscreen to cycle through the
various ventilation settings and off. More
indicator lights indicate higher fan speeds.

Note: When you switch the climate control
fan speed and the ventilated seats to their
maximum settings, the ventilated seats
provide increased cooling.

If the engine falls below 350 RPM while the
ventilated seats are on, the feature switches
itself off unless the vehicle is in
Auto-Start-Stop mode. You may need to
reactivate the ventilated seats.

Note: The ventilated seats may remain on
after you remote start your vehicle, based
on your remote start settings. The ventilated
seats may also switch on when you start
your vehicle if they were on when you
switched your vehicle off.

182

Rear Seats

WHAT IS THE REAR OCCUPANT
ALERT SYSTEM

The rear occupant alert system monitors
vehicle conditions and notifies you to check
for rear seat occupants when you switch the
ignition off.

HOW DOES THE REAR OCCUPANT
ALERT SYSTEM WORK

The system monitors when rear doors have
been opened and closed to indicate the
potential presence of an occupant in the rear
seat.

A message displays in the information and
entertainment display screen and an audible
warning sounds when you switch the ignition
off after any of the following conditions have
been met:
•

A rear door is opened or closed while
the ignition is on.

•

You switch the ignition on within 15
minutes of a rear door opening and
closing.

•

You switch the ignition on within 15
minutes of the alert having displayed or
sounded.

REAR OCCUPANT ALERT SYSTEM
PRECAUTIONS

WARNING: On hot days, the

temperature inside the vehicle can rise
very quickly. Exposure of people or animals
to these high temperatures for even a short
time can cause death or serious heat
related injuries, including brain damage.
Small children are particularly at risk.

WARNING: Do not leave children or

pets unattended in your vehicle. Failure to
follow this instruction could result in
personal injury or death.

REAR OCCUPANT ALERT SYSTEM
LIMITATIONS

The system does not detect the presence of
objects or passengers in the rear seat. It
monitors when rear doors are opened and
closed.

Note: It is possible to receive an alert when
there is no rear seat occupant, but alert
conditions are met.

Note: It is possible to receive no alert when
there is an occupant in the rear seat, if alert
conditions are not met. For example, if a rear
seat occupant does not enter the vehicle
through a rear door.

Note: The audible warning does not sound
when the front door is opened before you
switch the ignition off.

183

Rear Occupant Alert System
