3. Carefully push the window down and

press firmly to latch securely.

Note: Be careful when opening or closing
the liftgate window in a garage or other
enclosed area to avoid damaging the glass.

Note:  Do not hang anything, for example a
bike rack, from the glass or liftgate.  This
could damage the liftgate and its
components.

Note:  Do not leave the liftgate window open
while driving. This could damage the liftgate
window and its components.

LIFTGATE – TROUBLESHOOTING

LIFTGATE – WARNING LAMPS

E162453

Illuminates when the liftgate is not
completely closed.

LIFTGATE – INFORMATION MESSAGES

Action

Message

The liftgate is not completely closed. Close the liftgate.

Liftgate Ajar

104

Liftgate

LIFTGATE – FREQUENTLY ASKED
QUESTIONS

Why won't my power liftgate function?

Make sure the transmission is in park
(P), ensure nothing is obstructing the
liftgate path and there is not excessive
weight on the liftgate. If there are
continued issues, the battery voltage
may be low or other system issues. See
an authorized dealer.

105

Liftgate

PASSIVE ANTI-THEFT SYSTEM

WHAT IS THE PASSIVE ANTI-THEFT
SYSTEM

The passive anti-theft system prevents
someone from starting the vehicle with an
incorrectly coded key.

Note: Do not leave a duplicate coded key
in your vehicle. Always take the keys and
lock all the doors when leaving your vehicle.

HOW DOES THE PASSIVE ANTI-THEFT
SYSTEM WORK

The passive anti-theft system arms when you
switch the ignition off.

It disarms when the ignition is switched on
with a correctly coded key.

Note: The system is not compatible with
non-Ford aftermarket remote start systems.

Note: Do not leave a duplicate coded key
in your vehicle. Always take the keys and
lock all doors when leaving your vehicle.

ANTI-THEFT ALARM SYSTEM

WHAT IS THE ANTI-THEFT ALARM
SYSTEM

The Anti-Theft Alarm System warns you of
an unauthorized entry to your vehicle.

HOW DOES THE ANTI-THEFT ALARM
SYSTEM WORK

When armed, the anti-theft alarm is triggered
in any of the following ways:
•

If someone opens a door, the tailgate or
the hood without a correctly coded key
or remote control.

•

If you turn the power on without a
correctly coded key.

•

If the interior sensors detect movement
inside your vehicle.

•

If the inclination sensors detect an
attempt to raise your vehicle.

•

If someone disconnects the vehicle
battery or the battery backup alarm.

•

If someone disconnects the trailer. See
Connecting a Trailer (page 345).

Any further attempts to carry out one of the
above, sounds the alarm again.

If the anti-theft alarm is triggered, the alarm
horn sounds for 30 seconds and the turn
signals flash for five minutes.

WHAT IS THE PERIMETER ALARM

The perimeter alarm is designed to detect
unauthorized access to your vehicle.

WHAT ARE THE INTERIOR SENSORS

The interior sensors are designed to detect
any movement inside your vehicle.

The interior sensors are in the overhead
console.

Note: Do not cover the interior sensors.

106

Security

WHAT ARE THE INCLINATION
SENSORS

The inclination sensor is designed to detect
an attempt to raise your vehicle, for example
to remove a wheel or to tow it away.

ARMING THE ANTI-THEFT ALARM
SYSTEM

The alarm is ready to arm when your vehicle
is switched off.

Lock your vehicle with your remote control
to arm the alarm.

DISARMING THE ANTI-THEFT ALARM
SYSTEM

Disarm the alarm by performing any of the
following actions:
•

Unlock the doors or luggage
compartment with the remote control.

•

Switch your vehicle on or start your
vehicle.

ANTI-THEFT ALARM SYSTEM
SETTINGS

WHAT ARE THE ALARM SECURITY
LEVELS

You can select two levels of alarm security,
all sensors and perimeter sensing.

All Sensors

All sensors is the standard setting.

In all sensors, all equipped sensors are on
when you arm the alarm.

Note: Do not arm the alarm with all sensors
if passengers, animals or other moving
objects are inside your vehicle.

Perimeter Sensing

In perimeter sensing, the interior sensors are
off when you arm the alarm.

All the other equipped sensors activate when
you arm the alarm in this mode.

SETTING THE ALARM SECURITY
LEVEL

1. Press Settings on the touchscreen.

2. Press Vehicle Settings.

3. Press Alarm System.

4. Press Motion Sensors.
5. Press a setting.

WHAT IS ASK ON EXIT

You can choose which level of security you
require after you switch the ignition off.

Note: If you do not choose a setting, the
system defaults to all sensors.

SWITCHING ASK ON EXIT ON AND
OFF

1. Press Settings on the touchscreen.

2. Press Vehicle Settings.

3. Press Alarm System.

4. Switch Ask on Exit on or off.

107

Security

SECURITY – TROUBLESHOOTING

SECURITY – INFORMATION MESSAGES

Action

Message

The system has not detected a correctly coded key.

No Key Detected

The system has malfunctioned. Have your vehicle checked as soon as possible.

Starting System Fault

Displays when the alarm has been triggered due to unauthorized entry.

Vehicle Alarm To Stop Alarm, Start
Vehicle.

Alarm Announcement

108

Security

SECURITY – FREQUENTLY ASKED
QUESTIONS

What should I do if there is any potential
alarm problem with my vehicle?

Take all remote controls to an
authorized dealer if there is any
potential alarm problem with your
vehicle.

What should I do if the vehicle is unable to
start with a correctly coded key?

Have your vehicle checked as soon as
possible.

109

Security

POWER RUNNING BOARD
PRECAUTIONS

WARNING: In extreme climates,

excessive ice buildup may occur, causing
the running boards not to deploy. Make
sure that the running boards have
deployed, and have finished moving before
attempting to step on them. The running
boards will resume normal function once
the blockage is cleared.

WARNING: Switch off the running

boards before jacking or placing any object
under your vehicle. Never place your hand
between the extended running board and
your vehicle. A moving running board may
cause injury.

Do not use the running boards, front and rear
hinge assemblies, running board motors, or
the running board underbody mounts to lift
your vehicle when jacking. Use proper
jacking points.

The running boards could move slower in
cold temperatures.

POWER RUNNING BOARD
SETTINGS

1. Press Features on the touchscreen.
2. Press Running Boards.

3. Press a setting.

Running Boards (Modes)

Off

The power running boards remain stowed,
regardless of door position.

Auto

The power running boards deploy when you
approach your vehicle with a remote control,
unlock the door or open the door.

The power running boards stow:
•

After a few seconds when you close the
doors.

•

If you unlock the door but do not open
it.

•

If you have switched Approach detection
on and do not open a door before the
Auto Timer setting expires.

Note: When you select this mode, an option
displays that allows you to select how long
the running boards stay deployed without
opening the door.

Out

The power running boards remain deployed,
regardless of door position.

Approach detection

When you switch Approach detection on
with Auto switched on, the running boards
deploy when you approach your vehicle with
a remote control.

DEPLOYING AND STOWING THE
POWER RUNNING BOARDS

The power running boards deploy when you
approach your vehicle with a remote control,
unlock the door or open the door.

110

Power Running Boards

The power running boards stow:
•

After a few seconds when you close the
doors.

•

If you unlock the door but do not open
it.

•

If you have switched Approach detection
on and do not open a door before the
Auto Timer setting expires.   See Power
Running Board Settings (page 110).

Note: The power running boards reverse
direction and move to the end of travel if
they encounter an object when moving.

POWER RUNNING BOARDS –
TROUBLESHOOTING

POWER RUNNING BOARDS –
FREQUENTLY ASKED QUESTIONS

Why is there unwanted noise coming from
my power running boards?

The power running board mechanism
could trap debris such as mud, dirt,
snow, ice and salt. If this happens, set
the running boards to the deployed
position. Then, wash the system, in
particular the front and rear hinge arms,
with a high-pressure car wash wand.

111

Power Running Boards

ADJUSTING THE STEERING WHEEL

WARNING: Do not adjust the steering

wheel when your vehicle is moving.

Note:  Make sure that you are sitting in the
correct position.   See Sitting in the Correct
Position (page 166).

E261582

Press the top or bottom of the control to
move the steering wheel up or down.

Press the front or rear of the control to move
the steering wheel in or out.

You can save and recall the steering wheel
position with the memory function. See
Recalling a Preset Position (page 185).

RESETTING THE STOPPING
POSITION

Note: The steering wheel stops when it
detects an obstruction. This sets a new
stopping position.

To reset the steering column to its normal
stopping position:

1. Confirm there is nothing obstructing the

motion of the steering column.

2. Press and hold the steering column

control until the steering column stops
moving.

3. Press the steering column control again.

Note: The steering column may start to move
again.

4. When the steering column stops,

continue holding the control for a few
seconds.

5. Repeat for each direction, as necessary.

HORN

E270945

Press on the center of the steering
wheel near the horn icon to
activate the horn.

SWITCHING THE HEATED
STEERING WHEEL ON AND OFF

To activate the heated steering
wheel, press the button on the
climate control unit.

On some vehicles, an indicator on the button
illuminates when the heated steering wheel
is on.

Note: A sensor regulates the temperature
of the steering wheel.

112

Steering Wheel

ADJUSTING THE PEDALS

WARNING: Do not use the pedal

adjustment controls when the vehicle is
moving. Failure to follow this instruction
could result in personal injury or death.

Your control is on the left-hand side of the
steering column or on the instrument panel.

E176213

Farther away from you.

A.

Closer to you.

B.

You can save and recall the pedal positions
with the memory feature.  See Memory
Function (page 185).

113

Adjustable Pedals

WIPERS

WIPER PRECAUTIONS

Do not operate the wipers on a dry
windshield. This could scratch the glass or
damage the wiper blades. Use the
windshield washers before wiping a dry
windshield.

Fully defrost the windshield before you
switch the windshield wipers on.

Switch the windshield wipers off before
entering a car wash.

SWITCHING WINDSHIELD WIPERS ON
AND OFF

E269410

Single wipe.

A

Intermittent wipe.

B

Normal wipe.

C

High-speed wipe.

D

E270969

Push the lever up or down to
operate the windshield wipers.

AUTOWIPERS

WHAT ARE AUTOWIPERS

Autowipers turns on and controls the speed
and frequency of the windshield wipers.

AUTOWIPERS SETTINGS

1. Press Settings on the touchscreen.
2. Press Vehicle Settings.

3. Press Wipers.

4. Switch Rain Sensing on or off.

Note: When you switch the feature off, the
wipers do not operate based on the rain
sensor. When you switch on the windshield
wipers to the intermittent wipe position with
the feature off, the wipers use the wipe
speed set by the rotary control.

114

Wipers and Washers

ADJUSTING THE SENSITIVITY OF THE
RAIN SENSOR

E330179

High sensitivity.

A

Low sensitivity.

B

Use the rotary control to set the sensitivity
of the rain sensor.

When you select high sensitivity, the wipers
operate when the sensor detects a small
amount of water on the windshield.

When you select low sensitivity, the wipers
operate when the sensor detects a large
amount of water on the windshield.

SWITCHING THE REAR WINDOW
WIPER ON AND OFF

E242324

Intermittent wipe.

A

Continuous wipe.

B

Rear window wiper off.

C

REVERSE WIPE

WHAT IS REVERSE WIPE

Reverse wipe turns on the rear window wiper
when you shift into reverse (R) and the
windshield wipers are on.

REVERSE WIPE SETTINGS

1. Press Settings on the touchscreen.

2. Press Vehicle Settings.

3. Press Wipers.

4. Switch Rear Wiper On (when in Reverse)

on or off.

115

Wipers and Washers

CHECKING THE WIPER BLADES

E142463

Run the tip of your fingers over the edge of
the blade to check for roughness.

REPLACING THE FRONT WIPER
BLADES

E165804

1. Pull the wiper blade and arm away from

the glass.

Note: Do not hold the wiper blade to lift the
wiper arm.

E327597

2

2. Lift the wiper blade primary locking clip.

E327598

3. Press the wiper blade secondary locking

clip.

116

Wipers and Washers

4. Remove the wiper blade.

Note: Make sure that the wiper arm does
not spring back against the glass when the
wiper blade is not attached.

5. To install, reverse the removal procedure.

Note: Make sure that the wiper blade locks
into place.

REPLACING THE REAR WIPER
BLADES

E271380

1. Lift the wiper arm.

Note: Do not hold the wiper blade to lift the
wiper arm.

2. Remove the wiper blade.

Note: Make sure that the wiper arm does
not spring back against the glass when the
wiper blade is not attached.

3. To install, reverse the removal procedure.

Note: Make sure that the wiper blade locks
into place.

WASHERS

WASHER PRECAUTIONS

WARNING: If you operate your

vehicle in temperatures below 41°F (5°C),
use washer fluid with antifreeze protection.
Failure to use washer fluid with antifreeze
protection in cold weather could result in
impaired windshield vision and increase
the risk of injury or accident.

Do not operate the washers when the
washer reservoir is empty. This could cause
the washer pump to overheat.

117

Wipers and Washers

Keep the outside of the windshield clean.
The rain sensor is very sensitive and the
wipers may operate if dirt, mist or insects hit
the windshield.

USING THE WINDSHIELD WASHER

E269412

E270967

Pull the lever toward you to
operate the windshield washer.

Note: A courtesy wipe occurs a short time
after the wipers stop to clear any remaining
washer fluid when switched on.  See
Switching the Courtesy Wipe On and Off
(page 118).

SWITCHING THE COURTESY WIPE ON
AND OFF

1. Press Settings on the touchscreen.
2. Press Vehicle Settings.

3. Press Wipers.

4. Switch Courtesy Wipe on or off.

USING THE REAR WINDOW WASHER

E269727

Push the lever away from you to operate the
rear window washer.

Note: A courtesy wipe occurs a short time
after the wipers stop to clear any remaining
washer fluid when switched on.  See
Switching the Courtesy Wipe On and Off
(page 118).

ADDING WASHER FLUID

E348204

WASHER FLUID SPECIFICATION

See Washer Fluid Specification (page 476).

118

Wipers and Washers

WIPERS AND WASHERS –
TROUBLESHOOTING

WIPERS AND WASHERS – WARNING
LAMPS

E132353

Illuminates when the windshield
washer fluid is low.

WIPERS AND WASHERS –
FREQUENTLY ASKED QUESTIONS

Why are there streaks and smears on the
windshield?

The wiper blades could be dirty, worn
or damaged. Check the wiper blades.
See Checking the Wiper Blades (page
116).  If the wiper blades are dirty, clean
them with washer fluid or water applied
with a soft sponge or cloth. If the wiper
blades are worn or damaged, install new
ones.  See Replacing the Front Wiper
Blades (page 116).

119

Wipers and Washers
