Lincoln Nautilus (2022 year). Manual in english

Wi-Fi connected.

Vehicle data sharing on.

E335292

Vehicle data sharing off.

Vehicle location sharing on.

Vehicle data and vehicle location
sharing on.

Vehicle System Update

E327789

Vehicle system update available.

E327785

Vehicle system update requires
schedule.

E327786

Vehicle system update requires
consent.

E353217

Vehicle system update requires
Wi-Fi.

E327787

Vehicle system update schedule
reminder.

E327788

Vehicle system update not
successful.

E353218

Vehicle system update successful.

Wireless Accessory Charger

E353214

Wireless accessory charger active.

FEATURE BAR

The feature bar is located on the bottom of
the display and allows you to access vehicle
features.

E100027

Press to use the radio, a USB, a
media player or a Bluetooth®
device.

Press to make calls and access the
phonebook on your cell phone.

Press to use the navigation system.

E358432

Press to replace this button with a
shortcut to a feature or setting.

E353220

Press to search for and use
compatible apps on your iOS or
Android device.

E280315

Press to adjust system settings.

INFORMATION ON DEMAND
SCREEN

The information on demand screen displays
cards on the side of the display and allows
you to see information from different
features.

E353212

Press the button to view the next
card.

E353211

Press the button to view the
previous card.

438

Center Display Overview

-------------------------------------------------------------------------------------------------------------------------------------------------------------

WHAT IS VOICE INTERACTION

Voice Interaction allows you to control
vehicle features using conversational
requests.

SETTING THE WAKE WORD

E280315

Select the settings option on the
feature bar.

1. Press Lincoln Assistant.

2. Switch Listen for Wake Word on.

3. Press Preferred Wake Word.

4. Select a wake word.

BEGINNING A VOICE
INTERACTION

Say the selected wake word.

E142599

Press the voice interaction button
on the steering wheel.

VOICE INTERACTION EXAMPLES

General Examples

Result

Command

The system resets

the current voice

interaction.

Start Over.

The system ends the
current voice interac-

tion.

Cancel.

The system goes to

the next page.

Next Page.

The system goes to

the previous page.

Previous Page.

The system displays

a list of available

commands you can

use on the current

screen.

Help.

Entertainment Examples

Result

Command

The system plays the

selected music.

Play The Beatles.

The system shows

the selected music.

Show music by The

Beatles.

The system tunes

the radio to 101.9 FM.

Tune to FM 101.9.

The system tunes
the radio to Sirius

Channel 2.

Set the station to
Sirius Channel 2.

440

Voice Interaction

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Climate Examples

Result

Command

The system sets the

temperature to the

minimum.

Set the temperature

to low.

The system sets the
temperature to 72°F

(22°C).

Set the temperature

to 72°F (22°C).

Phone Examples

Result

Command

The system calls

Henry using your

connected device.

Call Henry.

The system dials the

selected phone

number.

Dial (phone number).

The system begins a

dictated text

message.

Send a text message

to Henry.

The system reads

Read my message

Result

Command

from Henry.

you the most recent

message from

Henry.

Apps Examples

Result

Command

The system prompts
you to say the name

of an app to start it

on the system.

Mobile Apps.

The system will list

all of the currently

available Mobile

Apps.

List Mobile Apps.

The system will

search and connect

to compatible apps

running on your

mobile device.

Find Mobile Apps

Navigation Examples

Result

Command

The system begins

guided navigation to

the address.

Say the address that

you're looking for,

like '125 Main Street,

New York'.

The system searches

for the requested

point of interest.

Where is ___

The system shows

directions to the

selected intersec-

tion.

Show me directions

to Oakwood

Boulevard and

Pelham Road.

The system ends

guided navigation to

the destination.

Cancel route.

441

Voice Interaction

-------------------------------------------------------------------------------------------------------------------------------------------------------------

PHONE PRECAUTIONS

WARNING: Driving while distracted

can result in loss of vehicle control, crash
and injury. We strongly recommend that
you use extreme caution when using any
device that may take your focus off the
road. Your primary responsibility is the safe
operation of your vehicle. We recommend
against the use of any hand-held device
while driving and encourage the use of
voice-operated systems when possible.
Make sure you are aware of all applicable
local laws that may affect the use of
electronic devices while driving.

CONNECTING YOUR PHONE

Go to the settings menu on your device and
switch Bluetooth® on.

Press the phone option on the
feature bar.

1. Press Add Phone.

Note: A prompt alerts you to search for your
vehicle on your cell phone.

2. Select your vehicle on your cell phone.

Note: A number appears on your cell phone
and on the touchscreen.

3. Confirm the number on your cell phone

matches the number on the touchscreen.

Note: The touchscreen indicates that you
have successfully paired your cell phone.

4. Download the phonebook from your cell

phone when you are prompted.

Note: If you pair more than one cell phone,
use the phone settings on the center display
to specify the primary phone. You can
change this setting at any time.

PHONE MENU

This menu becomes available after pairing
a phone.

Recent Call List

Display and select an entry from a list of
previous calls.

Contacts

Display a smart search form to look up your
contacts. Use the List button to alphabetically
sort your contacts.

Favorites

Display the list of favorite contacts that are
set up on your phone.

Messaging

Displays the list of text messages to read,
listen to, or respond to.

Email

Displays the list of emails to read, listen to,
or respond to.

Phone List

Display the list of paired or connected
devices that you can select.

Note: Up to 12 devices can be stored.

442

Phone

-------------------------------------------------------------------------------------------------------------------------------------------------------------

MAKING AND RECEIVING A
PHONE CALL

Making Calls

To call a number in your contacts, select:

Action and Description

Menu Item

You can then select the
name of the contact you
want to call. Any numbers
stored for that contact
display along with any
stored contact photos. You
can then select the number
that you want to call. The
system begins the call.

Contacts

To call a number from your recent calls,
select:

Action and Description

Menu Item

You can then select an entry
that you want to call. The
system begins the call.

Recent Call
List

To call a number from your favorites, select:

Action and Description

Menu Item

You can then select an entry
that you want to call. The
system begins the call.

Favorites

To call a number that is not stored in your
phone, select:

Action and Description

Menu Item

Select the digits of the
number you wish to call.

Phone
Keypad

The system begins the call.

Call

Pressing the backspace button deletes the
last digit you typed.

Receiving Calls

During an incoming call, an audible tone
sounds. Caller information appears in the
display if it is available.

To accept the call, select:

Menu Item

Note: You can also accept the call by
pressing the phone button on the steering
wheel.

To reject the call, select:

Menu Item

Reject

Ignore the call by doing nothing. The system
logs it as a missed call.

During a Phone Call

During a phone call, the contacts name and
number display on the screen along with the
call duration.

The phone status items are also visible:

•

Signal Strength.

•

Battery.

444

Phone

-------------------------------------------------------------------------------------------------------------------------------------------------------------

CONNECTING A BLUETOOTH®
DEVICE

1. Make sure Bluetooth® is enabled on your

device.

2. Press Settings on the touchscreen.
3. Press Connectivity.

4. Press Bluetooth.

5. Press Add a Bluetooth Device.

Note: A prompt alerts you to search for your
vehicle on your device.

6. Select your vehicle on your device.

Note: A number appears on your device and
on the touchscreen.

7. Confirm that the number on your device

matches the number on the touchscreen.

Note: The touchscreen indicates that you
have successfully paired your device.

The Bluetooth® word mark and logos are
registered trademarks owned by Bluetooth
SIG, Inc. and any use of such marks by Ford
Motor Company is under license. Other
trademarks and trade names are those of
their respective owners.

PLAYING MEDIA USING
BLUETOOTH®

WARNING: Driving while distracted

Connect your device.

E100027

Press the audio button on the
feature bar.

Press Sources.

Press the Bluetooth® option.

Press to play a track. Press again
to pause the track.

Press to skip to the next track.

Press and hold to fast forward
through the track.

Press once to return to the
beginning of a track. Repeatedly
press to return to previous tracks.

Press and hold to fast rewind through the
track.

448

Bluetooth®

-------------------------------------------------------------------------------------------------------------------------------------------------------------

APP PRECAUTIONS

WARNING: Driving while distracted

APP REQUIREMENTS

When you start an app through the system
for the first time, you could be asked to grant
certain permissions. You can review and
change the permissions that you have
granted at any time when your vehicle is not
moving. We recommend that you check your
data plan before using your apps through

the system. Using them could result in
additional charges. We also recommend that
you check the app provider's terms and
conditions and privacy policy before using
their app. Make sure that you have an active
account for apps that you want to use
through the system. Some apps will work
with no setup. Others require you to
configure some personal settings before you
can use them.

ACCESSING APPS

Select the apps option on the
feature bar.

ENABLING APPS ON AN IOS
DEVICE

Select the apps option on the
feature bar.

1. Select Mobile Apps Help.

2. Follow the instructions to pair and

connect your device via Bluetooth® or
with a USB cable.

3. Start the apps on your device that you

want to use.

4. Select the app that you want to use on

the touchscreen.

Note: Some apps may run through Apple
CarPlay if it is enabled.

Note: Closing an app on your device will
close it on the touchscreen.

Note: For troubleshooting assistance select
Mobile Apps List under Mobile Apps Help.

ENABLING APPS ON AN ANDROID
DEVICE

Select the apps option on the
feature bar.

1. Select Mobile Apps Help.

2. Follow the instructions to pair and

connect your device via Bluetooth® or
with a USB cable.

3. Start the apps on your device that you

want to use.

4. Select Find Mobile Apps.

449

Apps

-------------------------------------------------------------------------------------------------------------------------------------------------------------

5. Select the app that you want to use on

the touchscreen.

Note: Some devices may lose the ability to
play music over USB when Mobile Apps are
enabled.

Note: Some apps may run through Android
Auto if it is enabled.

Note: Closing an app on your device will
close it on the touchscreen.

Note: For troubleshooting assistance select
Mobile Apps List under Mobile Apps Help.

SWITCHING APPLE CARPLAY ON
AND OFF

Enabling Apple CarPlay with USB

1. Connect your device to a USB port.

2. Follow the instructions on your device

and the touchscreen.

Note: Selecting "Enable Wireless CarPlay"
on your device prepares the device for
wireless CarPlay when you re-enter the
vehicle.

Enabling Apple CarPlay with Wireless

1. Pair your device to Bluetooth®.
2. Follow the instructions on your device

and the touchscreen.

Disabling Apple CarPlay

E280315

Select the settings option on the
feature bar.

1. Press Phone List.

2. Select your device from the list.

3. Press Disable.

Re-Enabling Apple CarPlay

E280315

Select the settings option on the
feature bar.

1. Press Phone List.

2. Select your device from the list.

3. Press Connect to Apple CarPlay.

SWITCHING ANDROID AUTO ON
AND OFF

Enabling Android Auto with USB

(If

Equipped)

1. Connect your device to a USB port.

2. Follow the instructions on the

touchscreen.

Note: Certain features of the system are not
available when you are using Android Auto.

Enabling Android Auto with Wireless

1. Pair your device to Bluetooth®.

2. Follow the instructions on your device

and the touchscreen.

Note: Certain Android Devices do not
support Android Auto Wireless. Please check
your Android OS version for compatibility.

Disabling Android Auto

E280315

Select the settings option on the
feature bar.

1. Press Phone List.

450

Apps

-------------------------------------------------------------------------------------------------------------------------------------------------------------

HOW DO PERSONAL PROFILES
WORK

This feature allows you to create multiple
personal profiles enabling users to
personalize vehicle’s settings such as seats
and mirrors, as well as non-positional settings
like radio, navigation, driver assist system
settings. Positional settings are saved by
holding a memory seat button.
Non-positional settings are saved you
change a setting while a profile is active. You
can create one profile for each preset
memory seat button along with a guest
profile.

Recalling and Changing a Profile

You can recall a profile using the
touchscreen or the preset button you
selected when you created your profile. You
can also link a remote control and a mobile
device to your profile, which are used to
recall it.

ENABLING OR DISABLING
PERSONAL PROFILES

When you switch on the Personal Profiles
feature:
•

Unlocking a door with a remote control
or mobile device that is not linked to a
driver profile does not change the active
profile, but remains in the last known
profile. It does not change the positional
settings.

•

Pressing a memory seat button that is
not linked to a driver profile or saved to
a preset setting does not change the
active profile, but remains in the last
known profile. It does not change the
positional settings.

•

Pressing a memory seat button that is
not linked to a driver profile but is saved
to a preset setting does not change the
active profile, but remains in the last
known profile. It recalls the positional
settings that you saved to that memory
seat button.

When you switch off a Personal Profiles
feature:
•

Unlocking a door with a remote control
or mobile device does not recall any
non-positional settings but still recalls
positional settings from the driver profile
which the remote control or mobile
device is linked to.

•

Pressing a memory seat button that is
not linked to a driver profile or saved to
a preset setting does not change the
positional or non-positional settings.

•

Pressing a memory seat button that is
linked to a driver profile or has saved to
a preset setting recalls the positional
settings that you saved to that memory
seat button.

CREATING A PERSONAL PROFILE

Use the touchscreen to create a personal
profile.

1. Switch the vehicle on and leave the

vehicle in park (P).

2. Select the Personal Profiles button under

Settings.

452

Personal Profiles

-------------------------------------------------------------------------------------------------------------------------------------------------------------

3. Follow the instructions on the display.

LINKING OR UNLINKING A
PERSONAL PROFILE TO A REMOTE
CONTROL

You can save preset memory positions for
up to three remote controls by assigning a
remote control to a personal profile using
the touchscreen.

Use the touchscreen to link a remote control
to a personal profile.

1. Switch the vehicle on and leave the

vehicle in park (P).

2. Select the Personal Profiles button under

Settings.

3. Touch the arrow for the profile you wish

to link to a remote control.

4. Select remote control.

5. Follow the instructions on the display.

Note: If more than one linked remote control
is in range, the memory function moves to
the settings of the first key to initiate a
memory recall.

Note: The guest profile consists of existing
settings when there is no driver profile
created. After you create a driver profile, the
guest profile serves as an additional driver
profile.

Note: You cannot link a remote control to a
guest profile.

LINKING OR UNLINKING A
PERSONAL PROFILE TO A DEVICE

Use the touchscreen to link a mobile device
to a personal profile.

1. Switch the vehicle on and leave the

vehicle in park (P).

2. Select the Personal Profiles button under

Settings.

3. Touch the arrow for the profile you wish

to link to a mobile device.

4. Select mobile device.

5. Follow the instructions on the display.

Note: To successfully link a mobile device,
the mobile device must be in your vehicle,
and must have previously been setup as a
remote control for your vehicle.

Note: The guest profile consists of existing
settings when there is no driver profile
created. After you create a driver profile, the
guest profile serves as an additional driver
profile.

Note: You cannot link a personalized name
to a guest profile.

453

Personal Profiles

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Lincoln Nautilus (2022 year). Manual in english - page 27
