SERVICING AND MAINTENANCE

Collapsible Spare Tire — If Equipped

The collapsible spare is for temporary emergency

use only. You can identify if your vehicle is

equipped with a collapsible spare by looking at the

spare tire description on the Tire and Loading

Information Placard located on the driver’s side

door opening or on the sidewall of the tire.
Collapsible spare tire description example:

165/80-17 101P.
Since this tire has limited tread life, the original

equipment tire should be repaired (or replaced)

and reinstalled on your vehicle at the first

opportunity.
Inflate collapsible tire only after the wheel is

properly installed to the vehicle. Inflate the

collapsible tire using the electric air pump before

lowering the vehicle.

Do not install a wheel cover or attempt to mount a

conventional tire on the collapsible spare wheel,

since the wheel is designed specifically for the

collapsible spare tire.

Full Size Spare — If Equipped

The full size spare is for temporary emergency use

only. This tire may look like the originally equipped

tire on the front or rear axle of your vehicle, but it is

not. This spare tire may have limited tread life.

When the tread is worn to the tread wear

indicators, the temporary use full size spare tire

needs to be replaced. Since it is not the same as

your original equipment tire, replace (or repair) the

original equipment tire and reinstall on the vehicle

at the first opportunity.

Limited Use Spare — If Equipped

The limited use spare tire is for temporary

emergency use only. This tire is identified by a label

located on the limited use spare wheel. This label

contains the driving limitations for this spare. This

tire may look like the original equipped tire on the

front or rear axle of your vehicle, but it is not.

Installation of this limited use spare tire affects

vehicle handling. Since it is not the same as your

original equipment tire, replace (or repair) the

original equipment tire and reinstall on the vehicle

at the first opportunity.

WARNING!

Compact and collapsible spares are for temporary

emergency use only. With these spares, do not

drive more than 50 mph (80 km/h). Temporary use

spares have limited tread life. When the tread is

worn to the tread wear indicators, the temporary

use spare tire needs to be replaced. Be sure to

follow the warnings, which apply to your spare.

Failure to do so could result in spare tire failure and

loss of vehicle control.

WARNING!

Compact and Collapsible spares are for temporary

emergency use only. With these spares, do not

drive more than 50 mph (80 km/h). Temporary use

spares have limited tread life. When the tread is

worn to the tread wear indicators, the temporary

use spare tire needs to be replaced. Be sure to

follow the warnings, which apply to your spare.

Failure to do so could result in spare tire failure and

loss of vehicle control.

WARNING!

Limited use spares are for emergency use only.

Installation of this limited use spare tire affects

vehicle handling. With this tire, do not drive

more than the speed listed on the limited use

spare wheel. Keep inflated to the cold tire

inflation pressures listed on your Tire and

Loading Information Placard located on the

driver’s side B-pillar or the rear edge of the

driver’s side door. Replace (or repair) the original

equipment tire at the first opportunity and

reinstall it on your vehicle. Failure to do so could

result in loss of vehicle control.

SERVICING AND MAINTENANCE

299

HEEL

RIM

ARE

All wheels and wheel trim, especially aluminum

and chrome plated wheels, should be cleaned

regularly using mild (neutral Ph) soap and water to

maintain their luster and to prevent corrosion.

Wash wheels with the same soap solution

recommended for the body of the vehicle and

remember to always wash when the surfaces are

not hot to the touch.
Your wheels are susceptible to deterioration

caused by salt, sodium chloride, magnesium

chloride, calcium chloride, etc., and other road

chemicals used to melt ice or control dust on dirt

roads. Use a soft cloth or sponge and mild soap to

wipe away promptly. Do not use harsh chemicals or

a stiff brush. They can damage the wheel’s

protective coating that helps keep them from

corroding and tarnishing.

When cleaning extremely dirty wheels including

excessive brake dust, care must be taken in the

selection of tire and wheel cleaning chemicals and

equipment to prevent damage to the wheels.

Mopar® Wheel Treatment or Mopar® Chrome

Cleaner or their equivalent is recommended or

select a non-abrasive, non-acidic cleaner for

aluminum or chrome wheels.

NOTE:

If you intend parking or storing your vehicle for an

extended period after cleaning the wheels with

wheel cleaner, drive your vehicle and apply the

brakes to remove the water droplets from the

brake components. This activity will remove the

red rust on the brake rotors and prevent vehicle

vibration when braking.
Dark Vapor Chrome, Black Satin Chrome, or Low

Gloss Clear Coat Wheels

CAUTION!

Avoid products or automatic car washes that use

acidic solutions or strong alkaline additives or

harsh brushes. Many aftermarket wheel

cleaners and automatic car washes may

damage the wheel's protective finish. Such

damage is not covered by the New Vehicle

Limited Warranty. Only car wash soap, Mopar®

Wheel Cleaner or equivalent is recommended.

CAUTION!

Do not use scouring pads, steel wool, a bristle

brush, metal polishes or oven cleaner. These

products may damage the wheel's protective

finish. Such damage is not covered by the New

Vehicle Limited Warranty. Only car wash soap,

Mopar® Wheel Cleaner or equivalent is

recommended.

CAUTION!

If your vehicle is equipped with these specialty

wheels, DO NOT USE wheel cleaners, abrasives,

or polishing compounds. They will permanently

damage this finish and such damage is not

covered by the New Vehicle Limited Warranty.

HAND WASH ONLY USING MILD SOAP AND

WATER WITH A SOFT CLOTH. Used on a regular

basis; this is all that is required to maintain

this finish.

300

SERVICING AND MAINTENANCE

NOW

RACTION

EVICES

Use of traction devices require sufficient tire-to-body clearance. Due to limited clearance, the following snow traction devices are recommended. Follow these

recommendations to guard against damage.



Snow traction device must be of proper size for the tire, as recommended by the snow traction device manufacturer.



No other tire sizes are recommended for use with the snow traction device.



Please follow the table for the recommended tire size, axle and snow traction device:

RWD

Trim Level

Axle

Tire/Wheel Size

Snow Traction Device

(maximum projection beyond

tire profile or equivalent)

SPECIAL SERVICE

Rear

P265/60R18

THULE XG-12 PRO or Equivalent

SXT

265/60R18
265/50R20

R/T

CITADEL

265/50R20

302

SERVICING AND MAINTENANCE

(Continued)

IRE

OTATION

ECOMMENDATIONS

The tires on the front and rear of your vehicle

operate at different loads and perform different

steering, handling, and braking functions. For

these reasons, they wear at unequal rates.
These effects can be reduced by timely rotation of

tires. The benefits of rotation are especially

worthwhile with aggressive tread designs such as

those on On/Off-Road type tires. Rotation will

increase tread life, help to maintain mud, snow,

and wet traction levels, and contribute to a

smooth, quiet ride.

For the proper maintenance intervals

page 256.

The reasons for any rapid or unusual wear should

be corrected prior to rotation being performed.
NOTE:

The Tire Pressure Monitor System will automati

cally locate the pressure values displayed in the

correct vehicle position following a tire rotation.
The suggested rotation method is the “rearward

cross” shown in the following diagram.

Tire Rotation (Rearward Cross)

CAUTION!

To avoid damage to your vehicle or tires, observe

the following precautions:



Because of restricted traction device clear

ance between tires and other suspension

components, it is important that only traction

devices in good condition are used. Broken

devices can cause serious damage. Stop the

vehicle immediately if noise occurs that could

indicate device breakage. Remove the

damaged parts of the device before

further use.



Install device as tightly as possible and then

retighten after driving about ½ mile (0.8 km).

Autosock traction devices do not require

retightening.



Do not exceed 30 mph (48 km/h).



Drive cautiously and avoid severe turns and

large bumps, especially with a loaded vehicle.



Do not drive for a prolonged period on dry

pavement.



Observe the traction device manufacturer’s

instructions on the method of installation,

operating speed, and conditions for use.

Always use the suggested operating speed of

the device manufacturer’s if it is less than

30 mph (48 km/h).



Do not use traction devices on a compact

spare tire.

CAUTION!

SERVICING AND MAINTENANCE

303

DEPARTMENT OF TRANSPORTATION

UNIFORM TIRE QUALITY GRADES

The following tire grading categories

were established by the National

Highway Traffic Safety Administration.

The specific grade rating assigned by the

tire's manufacturer in each category is

shown on the sidewall of the tires on

your vehicle.
All passenger vehicle tires must conform

to Federal safety requirements in

addition to these grades.

READWEAR

The Treadwear grade is a comparative

rating, based on the wear rate of the tire

when tested under controlled conditions

on a specified government test course.

For example, a tire graded 150 would

wear one and one-half times as well on

the government course as a tire graded

100. The relative performance of tires

depends upon the actual conditions of

their use, however, and may depart

significantly from the norm due to

variations in driving habits, service

practices, and differences in road

characteristics and climate.

RACTION

RADES

The Traction grades, from highest to

lowest, are AA, A, B, and C. These grades

represent the tire's ability to stop on wet

pavement, as measured under

controlled conditions on specified

government test surfaces of asphalt and

concrete. A tire marked C may have poor

traction performance.

EMPERATURE

RADES

The Temperature grades are A (the

highest), B, and C, representing the tire's

resistance to the generation of heat and

its ability to dissipate heat, when tested

under controlled conditions on a

specified indoor laboratory test wheel.
Sustained high temperature can cause

the material of the tire to degenerate

and reduce tire life, and excessive

temperature can lead to sudden tire

failure. The grade C corresponds to a

level of performance, which all

passenger vehicle tires must meet

under the Federal Motor Vehicle Safety

Standard No. 109. Grades B and A

represent higher levels of performance

on the laboratory test wheel, than the

minimum required by law.

WARNING!

The traction grade assigned to this tire is based

on straight-ahead braking traction tests, and

does not include acceleration, cornering,

hydroplaning, or peak traction characteristics.

WARNING!

The temperature grade for this tire is

established for a tire that is properly inflated and

not overloaded. Excessive speed, underinflation,

or excessive loading, either separately or in

combination, can cause heat buildup and

possible tire failure.

304

SERVICING AND MAINTENANCE

STORING THE VEHICLE

If you are storing your vehicle for more than three

weeks, we recommend that you take the following

steps to minimize the drain on your vehicle's battery:



Disconnect the negative cable from battery.



Any time you store your vehicle or keep it out of

service (i.e., vacation) for two weeks or more,

run the air conditioning system at idle for about

five minutes in the fresh air and high blower

setting. This will ensure adequate system lubri

cation to minimize the possibility of compressor

damage when the system is started again.

BODYWORK

ROTECTION

ROM

TMOSPHERIC

GENTS

Vehicle body care requirements vary according to

geographic locations and usage. Chemicals that

make roads passable in snow and ice and those

that are sprayed on trees and road surfaces during

other seasons are highly corrosive to the metal in

your vehicle. Outside parking, which exposes your

vehicle to airborne contaminants, road surfaces on

which the vehicle is operated, extreme hot or cold

weather and other extreme conditions will have an

adverse effect on paint, metal trim, and underbody

protection.

The following maintenance recommendations will

enable you to obtain maximum benefit from the

corrosion resistance built into your vehicle.

What Causes Corrosion?

Corrosion is the result of deterioration or removal

of paint and protective coatings from your vehicle.
The most common causes are:



Road salt, dirt and moisture accumulation.



Stone and gravel impact.



Insects, tree sap and tar.



Salt in the air near seacoast localities



Atmospheric fallout/industrial pollutants.

ODY

NDERBODY

AINTENANCE

Cleaning Headlights

Your vehicle is equipped with plastic headlights

and fog lights that are lighter and less susceptible

to stone breakage than glass headlights.
Plastic is not as scratch resistant as glass and

therefore different lens cleaning procedures must

be followed.
To minimize the possibility of scratching the lenses

and reducing light output, avoid wiping with a dry

cloth. To remove road dirt, wash with a mild soap

solution followed by rinsing.

Do not use abrasive cleaning components,

solvents, steel wool or other aggressive material to

clean the lenses.

RESERVING

ODYWORK

Washing



Wash your vehicle regularly. Always wash your

vehicle in the shade using Mopar® Car Wash, or

a mild car wash soap, and rinse the panels

completely with water.



If insects, tar, or other similar deposits have

accumulated on your vehicle, use Mopar®

Super Kleen Bug and Tar Remover to remove.



Use a high quality cleaner wax, such as Mopar®

Cleaner Wax to remove road film, stains and to

protect your paint finish. Use precautions to not

scratch the paint.



Avoid using abrasive compounds and power

buffing that may diminish the gloss or thin out

the paint finish.

CAUTION!



Do not use abrasive or strong cleaning mate

rials such as steel wool or scouring powder

that will scratch metal and painted surfaces.



Use of power washers exceeding 1,200 psi

(8,274 kPa) can result in damage or removal

of paint and decals.

SERVICING AND MAINTENANCE

305

Special Care



If you drive on salted or dusty roads or if you

drive near the ocean, hose off the undercarriage

at least once a month.



It is important that the drain holes in the lower

edges of the doors, rocker panels, and trunk be

kept clear and open.



If you detect any stone chips or scratches in the

paint, touch them up immediately.



If your vehicle is damaged due to a collision or

similar cause that destroys the paint and protec

tive coating, have your vehicle repaired as soon

as possible.



If you carry special cargo such as chemicals,

fertilizers, de-icer salt, etc., be sure that such

materials are well packaged and sealed.



If a lot of driving is done on gravel roads,

consider mud or stone shields behind each

wheel.



Use Mopar® Touch Up Paint on scratches as

soon as possible. An authorized dealer has

touch up paint to match the color of your

vehicle.

INTERIORS

EATS

ABRIC

ARTS

Use Mopar® Total Clean to clean fabric upholstery

and carpeting.

Seat Belt Maintenance

Do not bleach, dye or clean the belts with chemical

solvents or abrasive cleaners. This will weaken the

fabric.
If the belts need cleaning, use a mild soap solution

or lukewarm water. Do not remove the belts from

the vehicle to wash them. Dry with a soft cloth.

Sun damage can also weaken the fabric. Replace

the belts if they appear frayed or worn or if the

buckles do not work properly.

WARNING!

Do not use volatile solvents for cleaning

purposes. Many are potentially flammable, and

if used in closed areas they may cause

respiratory harm.

WARNING!

A frayed or torn seat belt could rip apart in a

collision and leave you with no protection.

Inspect the seat belt system periodically,

checking for cuts, frays, or loose parts.

Damaged parts must be replaced immediately.

Do not disassemble or modify the seat belt

system. If your vehicle is involved in a collision,

or if you have questions regarding seat belt or

retractor conditions, take your vehicle to an

authorized FCA dealer or authorized FCA

Certified Collision Care Program facility for

inspection.

306

SERVICING AND MAINTENANCE

LASTIC

OATED

ARTS

Use Mopar® Total Clean to clean vinyl upholstery.

Cleaning Plastic Instrument Cluster

Lenses

The lenses in front of the instruments in this

vehicle are molded in clear plastic. When cleaning

the lenses, care must be taken to avoid scratching

the plastic.
Clean with a wet soft cloth. A mild soap solution

may be used, but do not use high alcohol content

or abrasive cleaners. If soap is used, wipe clean

with a clean damp cloth. Dry with a soft cloth.

EATHER

URFACES

Mopar® Total Clean is specifically recommended

for leather upholstery.
The leather upholstery can be best preserved by

regular cleaning with a damp soft cloth. Small

particles of dirt can act as an abrasive and damage

the leather upholstery and should be removed

promptly with a damp cloth. Stubborn soils can be

removed easily with a soft cloth and Mopar® Total

Clean. Care should be taken to avoid soaking your

leather upholstery with any liquid. Please do not

use polishes, oils, cleaning fluids, solvents,

detergents, or ammonia-based cleaners to clean

your leather upholstery.
NOTE:

If equipped with light colored leather, it tends to

show any foreign material, dirt, and fabric dye

transfer more so than darker colors. The leather is

designed for easy cleaning, and the manufacturer

recommends Mopar® total care leather cleaner

applied on a cloth to clean the leather seats as

needed.

LASS

URFACES

All glass surfaces should be cleaned on a regular

basis with Mopar® Glass Cleaner, or any

commercial household-type glass cleaner. Never

use an abrasive type cleaner. Use caution when

cleaning the inside rear window equipped with

electric defrosters or windows equipped with radio

antennas. Do not use scrapers or other sharp

instruments that may scratch the elements.
When cleaning the rearview mirror, spray cleaner

on the towel or cloth that you are using. Do not

spray cleaner directly on the mirror.

CAUTION!



Direct contact of air fresheners, insect repel

lents, suntan lotions, or hand sanitizers to the

plastic, painted, or decorated surfaces of the

interior may cause permanent damage. Wipe

away immediately.



Damage caused by these type of products

may not be covered by your New Vehicle

Limited Warranty.

CAUTION!

Do not use Alcohol and Alcohol-based and/or

Ketone based cleaning products to clean leather

upholstery, as damage to the upholstery may

result.

307

TECHNICAL SPECIFICATIONS

VEHICLE IDENTIFICATION NUMBER (VIN)

The VIN is found on a label located on the left front

corner of the instrument panel pad, visible from

outside of the vehicle through the windshield.

Windshield VIN Label Location

NOTE:

It is illegal to remove or alter the VIN.

BRAKE SYSTEM

Your vehicle is equipped with dual hydraulic brake

systems. If either of the two hydraulic systems

loses normal capability, the remaining system will

still function. However, there will be some loss of

overall braking effectiveness. You may notice

increased pedal travel during application, greater

pedal force required to slow or stop, and potential

activation of the Brake Warning Light.
In the event power assist is lost for any reason (i.e.,

repeated brake applications with the engine off)

the brakes will still function. However, the effort

required to brake the vehicle will be much greater

than that required with the power system

operating.

WHEEL AND TIRE TORQUE SPECIFICATIONS

Proper lug nut/bolt torque is very important to

ensure that the wheel is properly mounted to the

vehicle. Any time a wheel has been removed and

reinstalled on the vehicle, the lug nuts/bolts

should be torqued using a properly calibrated

torque wrench using a six sided (hex) deep wall

socket.

ORQUE

PECIFICATIONS

Base Model Vehicle

**Use only authorized dealer recommended lug

nuts/bolts and clean or remove any dirt or oil

before tightening.

Lug Nut/

Bolt Torque

**Lug Nut/

Bolt Size

Lug Nut/Bolt

Socket Size

130 Ft-Lb

(176 N·m)

M14 x 1.50

22 mm

308

TECHNICAL SPECIFICATIONS

Inspect the wheel mounting surface prior to

mounting the tire and remove any corrosion or

loose particles.

Wheel Mounting Surface

Tighten the lug nuts/bolts in a star pattern until

each nut/bolt has been tightened twice. Ensure

that the socket is fully engaged on the lug nut/bolt

(do not insert it half way).
NOTE:

If in doubt about the correct tightness, have them

checked with a torque wrench by an authorized

dealer or service station.

After 25 miles (40 km), check the lug nut/bolt

torque to be sure that all the lug nuts/bolts are

properly tightened.

Torque Patterns

FUEL REQUIREMENTS

While operating on gasoline with the required

octane number, hearing a light knocking sound

from the engine is not a cause for concern.

However, if the engine is heard making a heavy

knocking sound, see a dealer immediately. Use of

gasoline with a lower than recommended octane

number can cause engine failure and may void the

New Vehicle Limited Warranty.
Poor quality gasoline can cause problems such as

hard starting, stalling, and hesitations. If you

experience these symptoms, try another brand of

gasoline before considering service for the vehicle.

3.6L E

NGINE

Do not use E-85 flex fuel or ethanol blends greater

than 15% in this engine.

This engine is designed to meet all

emissions regulations and provide

optimum fuel economy and performance

when using high quality unleaded regular

gasoline having a posted octane number of 87 as

specified by the (R+M)/2 method. The use of

higher octane premium gasoline is not required, as

it will not provide any benefit over regular gasoline

in these engines.

WARNING!

To avoid the risk of forcing the vehicle off the

jack, do not tighten the lug nuts/bolts fully until

the vehicle has been lowered. Failure to follow

this warning may result in personal injury.

TECHNICAL SPECIFICATIONS

309

5.7L E

NGINE

Do not use E-85 flex fuel or ethanol blends greater

than 15% in this engine.

This engine is designed to meet all

emissions regulations and provide

satisfactory fuel economy and

performance when using high-quality

unleaded gasoline having an octane range of 87 to

89 as specified by the (R+M)/2 method. The use of

89 octane plus gasoline is recommended for

optimum performance and fuel economy.

EFORMULATED

ASOLINE

Many areas of the country require the use of

cleaner burning gasoline referred to as

“reformulated gasoline”. Reformulated gasoline

contains oxygenates and are specifically blended

to reduce vehicle emissions and improve air

quality.
The use of reformulated gasoline is recommended.

Properly blended reformulated gasoline will

provide improved performance and durability of

engine and fuel system components.

ATERIALS

DDED

UEL

Besides using unleaded gasoline with the proper

octane rating, gasolines that contain detergents,

corrosion and stability additives are

recommended. Using gasolines that have these

additives will help improve fuel economy, reduce

emissions, and maintain vehicle performance.

Designated TOP TIER Detergent Gasoline

contains a higher level of detergents to

further aide in minimizing engine and

fuel system deposits. When available,

the usage of TOP TIER Detergent Gasoline is

recommended. Visit

www.toptiergas.com for a list

of TOP TIER Detergent Gasoline retailers.
Indiscriminate use of fuel system cleaning agents

should be avoided. Many of these materials

intended for gum and varnish removal may contain

active solvents or similar ingredients. These can

harm fuel system gasket and diaphragm materials.

ASOLINE

XYGENATE

LENDS

Some fuel suppliers blend unleaded gasoline with

oxygenates such as ethanol.

Problems that result from using gasoline

containing more than 15% ethanol (E-15) or

gasoline containing methanol are not the

responsibility of the manufacturer and may void

the New Vehicle Limited Warranty.

CAUTION!

DO NOT use E-85, gasoline containing methanol,

or gasoline containing more than 15% ethanol

(E-15). Use of these blends may result in starting

and drivability problems, damage critical fuel

system components, cause emissions to exceed

the applicable standard, and/or cause the

Malfunction Indicator Light to illuminate. Please

observe pump labels as they should clearly

communicate if a fuel contains greater than

15% ethanol (E-15).

310

TECHNICAL SPECIFICATIONS

(Continued)

E-85 I

-F

LEX

UEL

EHICLES

Non-Flex Fuel Vehicles (FFV) are compatible with

gasoline containing up to 15% ethanol (E-15). Use

of gasoline with higher ethanol content may void

the New Vehicle Limited Warranty.
If a Non-FFV vehicle is inadvertently fueled with

E-85 fuel, the engine will have some or all of these

symptoms:



Operate in a lean mode.



OBD II Malfunction Indicator Light on.



Poor engine performance.



Poor cold start and cold drivability.



Increased risk for fuel system component corro

sion.

CNG A

LP F

UEL

YSTEM

ODIFICATIONS

Modifications that allow the engine to run on

Compressed Natural Gas (CNG) or Liquid Propane

(LP) may result in damage to the engine,

emissions, and fuel system components. Problems

that result from running CNG or LP are not the

responsibility of the manufacturer and may void

the New Vehicle Limited Warranty.

ETHYLCYCLOPENTADIENYL

ANGANESE

RICARBONYL

(MMT) I

ASOLINE

MMT is a manganese-containing metallic additive

that is blended into some gasoline to increase

octane. Gasoline blended with MMT provides no

performance advantage beyond gasoline of the

same octane number without MMT. Gasoline

blended with MMT reduces spark plug life and

reduces emissions system performance in some

vehicles. The manufacturer recommends that

gasoline without MMT be used in your vehicle. The

MMT content of gasoline may not be indicated on

the gasoline pump; therefore, you should ask your

gasoline retailer whether the gasoline contains

MMT. MMT is prohibited in Federal and California

reformulated gasoline.

UEL

YSTEM

AUTIONS

NOTE:

Intentional tampering with the emissions control

system can result in civil penalties being assessed

against you.

CAUTION!

Follow these guidelines to maintain your

vehicle’s performance:



The use of leaded gasoline is prohibited by

Federal law. Using leaded gasoline can impair

engine performance and damage the emis

sions control system.



An out-of-tune engine or certain fuel or ignition

malfunctions can cause the catalytic

converter to overheat. If you notice a pungent

burning odor or some light smoke, your engine

may be out of tune or malfunctioning and may

require immediate service. Contact an autho

rized dealer for service assistance.



The use of fuel additives, which are now being

sold as octane enhancers, is not recom

mended. Most of these products contain high

concentrations of methanol. Fuel system

damage or vehicle performance problems

resulting from the use of such fuels or addi

tives is not the responsibility of the manufac

turer and may void or not be covered under

the New Vehicle Limited Warranty.

CAUTION!

TECHNICAL SPECIFICATIONS

311

FLUID CAPACITIES

Metric

Fuel (Approximate)
3.6L and 5.7L Engines

24.6 Gallons

93 Liters

Engine Oil With Filter
3.6L Engine

6 Quarts

5.6 Liters

5.7L Engine

7 Quarts

6.6 Liters

Cooling System *
3.6L Engine – Without Trailer Tow Package

10.4 Quarts

9.9 Liters

3.6L Engine – With Trailer Tow Package

11 Quarts

10.4 Liters

5.7L Engine – Without Trailer Tow Package

15.4 Quarts

14.6 Liters

5.7L Engine – With Trailer Tow Package

16 Quarts

15.2 Liters

* Includes heater and coolant recovery bottle filled to MAX level.

312

TECHNICAL SPECIFICATIONS

ENGINE FLUIDS AND LUBRICANTS

CHASSIS FLUIDS AND LUBRICANTS

Component

Fluid, Lubricant, or Genuine Part

Engine Coolant

We recommend using Mopar® Antifreeze/Coolant 10 Year/150,000 Mile (240,000 km) Formula OAT

(Organic Additive Technology) meeting the requirements of the manufacturer Material Standard

MS.90032.

Engine Oil – 3.6L & 5.7L Engine

We recommend using Mopar® SAE 0W-20 Full Synthetic Engine Oil which meets the requirements of

the manufacturer Material Standard MS-6395. Equivalent full synthetic SAE 0W-20 engine oil can be

used but must have the API Starburst trademark

page 263.

Engine Oil Filter

We recommend using a Mopar® Engine Oil Filter. If a Mopar® Engine Oil Filter is unavailable only use

filters that meet or exceed SAE/USCAR-36 Filter Performance Requirements.

Fuel Selection – 3.6L Engine

87 Octane (R+M)/2 Method , 0-15% Ethanol (Do not use E-85).

Fuel Selection – 5.7L Engine

89 Octane Recommended - 87 Octane Acceptable (R+M)/2 Method,

0-15% Ethanol (Do not use E-85).

Component

Fluid, Lubricant, or Genuine Part

Automatic Transmission

Use only Mopar® ZF 8 & 9 Speed ATF Automatic Transmission Fluid or equivalent. Failure to use the

correct fluid may affect the function or performance of your transmission.

Transfer Case

We recommend using Mopar® ATF+4 Automatic Transmission Fluid.

Axle Differential (Front-Rear) – Without Electronic

Limited-Slip Differential (ELSD)

We recommend using Mopar® GL-5 Synthetic Axle Lubricant SAE 75W-85.

Axle Differential (Rear) – With Electronic Limited-Slip

Differential (ELSD)

We recommend using Mopar® GL-5 Synthetic Axle Lubricant SAE 75W-85 with integrated friction

modifier.

Brake Master Cylinder

We recommend using Mopar® DOT 3 Brake Fluid, SAE J1703.

313

CUSTOMER ASSISTANCE

SUGGESTIONS FOR OBTAINING SERVICE

FOR YOUR VEHICLE

REPARE

PPOINTMENT

All work to be performed may not be covered by the

warranty. Discuss additional charges with the

service manager. Keep a maintenance log of your

vehicle's service history. This can often provide a

clue to the current problem.

REPARE

A L

IST

Make a written list of your vehicle's problems or the

specific work you want done. If you've had an

accident or work done that is not on your

maintenance log, let the service advisor know.

EASONABLE

ITH

EQUESTS

If you list a number of items and you must have

your vehicle by the end of the day, discuss the

situation with the service advisor and list the items

in order of priority. At many authorized dealers, you

may obtain a rental vehicle (additional charges

may apply). If you need a rental, it is advisable to

make these arrangements when you call for an

appointment.

IF YOU NEED ASSISTANCE

FCA US LLC and its authorized dealers are vitally

interested in your satisfaction. We want you to be

happy with our products and services.
Warranty service must be done by an authorized

dealer. We strongly recommend that you take the

vehicle to an authorized dealer. They know your

vehicle the best, and are most concerned that

you get prompt and high quality service.

FCA US LLC’s authorized dealers have the

facilities, factory-trained technicians, special tools,

and the latest information to ensure the vehicle is

fixed correctly and in a timely manner.
This is why you should always talk to an authorized

dealer’s service manager first. If for some reason

you are still not satisfied, talk to the general

manager or owner of the authorized dealer. They

want to know if you need assistance. If an

authorized dealer is unable to resolve the concern,

you may contact FCA US LLC's Customer

Assistance center.

Any communication to FCA US LLC’s customer

center should include the following information:



Owner's name and address



Owner's telephone number

(home, mobile, and office)



Authorized dealer name



Vehicle Identification Number (VIN)



Vehicle delivery date and mileage

FCA US LLC C

USTOMER

ENTER

P.O. Box 21–8004
Auburn Hills, MI 48321–8004
Phone: (800) 423-6343

FCA C

ANADA

. C

USTOMER

ENTER

P.O. Box 1621
Windsor, Ontario N9A 4H6
Phone: (800) 465-2001 English /

(800) 387-9983 French

Dodge Durango (2022 year). Manual in english - page 19
