Description

Voice command

Play Song ___

Play Audiobook ___

For USB audio only, you can say the name of an artist, album, or a genre to
browse by that selection. Your system must finish indexing before this option
is available. For example you can say "Browse The Beatles" or "Browse folk".

Browse ___

1

This option may not be available in all markets or may require a subscription.

Climate Voice Commands

You can control the temperature of the
vehicle using voice commands.

___ is a dynamic listing, meaning that for
climate voice commands it can be the
desired degrees for the temperature setting.

To adjust the temperature, say:

Description

Voice command

Adjust the temperature between 60–85°F (15.5–29.5°C).

Set Temperature ___

Phone Voice Commands

Pairing a Phone

You can use voice commands to connect
your Bluetooth enabled phone to the system.

391

MKZ Hybrid (CC9) Hybrid Electric Vehicle (HEV), Canada/United States of America, enUSA, Edition date: 201805, First-Printing

SYNC™ 3

To pair your phone, press the voice button and when prompted, say:

Description

Voice command

Follow the on-screen instructions to complete the pairing process.  See Settings (page 444).

Pair Phone

Making Calls

___ is a dynamic listing, meaning that for
phone voice commands it can be the name
of the contact you wish to call or the digits
you want to dial.

Press the voice button and say a command similar to the following:

Description

Voice command

Allows you to call a specific contact from your phonebook such as "Call Jenny".

Call ___

Allows you to call a specific contact from your phonebook at a specific location such as "Call
Jenny at Home".

Call ___ at ___

Allows you to dial a specific number such as “Dial 867-5309”.

Dial ___

Please make sure that you are saying the
contact name exactly as it appears in your
contact list.

392

MKZ Hybrid (CC9) Hybrid Electric Vehicle (HEV), Canada/United States of America, enUSA, Edition date: 201805, First-Printing

SYNC™ 3

Once you have provided the digits of the phone number, you can say the following commands:

Description

Voice Command

If you did not enter the full number with the first command, you can continue saying the number.

<0-9>

Tells SYNC 3 to make the phone call.

Dial

Tells SYNC 3 to erase the last block of digits you state.

Delete

Tells SYNC 3 to erase the entire number.

Clear

Text Message Voice Commands

To access text message options, press the voice button and say:

Description

Voice command

Listen to Message

You can say the number of the message you would like to hear.

Listen to text message ___

Reply to Message

393

MKZ Hybrid (CC9) Hybrid Electric Vehicle (HEV), Canada/United States of America, enUSA, Edition date: 201805, First-Printing

SYNC™ 3

Navigation Voice Commands

 (If Equipped)

Setting a Destination

You can use any of the following commands

to set a destination or find a point of interest.

___ is a dynamic listing, meaning that for
navigation voice commands it can be a POI
category or a major brand name, where
major brand name is a chain with more than
20 locations

You can find an address, a point of interest (POI), or search for points of interest by category:

Description

Voice command

Allows you to enter the address search functionality. You can also search for an address in a specific
state or province.

Find an Address

State the name of the POI category or major brand name you would like to search for such as "Find
restaurants".

Find a ___

Allows you to enter the POI search functionality.

Find a POI

Allows you to enter the intersection search functionality.

Find an Intersection

State the name of a POI category or major brand name you would like to search for.

Find the Nearest <POI Category>

Allows you to see a list of your previous destinations.

Show Previous Destinations

Allows you to see a list of your favorite destinations.

Show Favorites

Allows you to route to your home address.

Drive Home

Allows you to route to your work address.

Drive to Work

394

MKZ Hybrid (CC9) Hybrid Electric Vehicle (HEV), Canada/United States of America, enUSA, Edition date: 201805, First-Printing

SYNC™ 3

In addition, you can say these commands when a route is active:

Description

Voice command

Cancels the current route.

Cancel Route

Allows you to select an alternate route.

Detour

Repeats the last guidance prompt.

Repeat Instruction

Displays the active route.

Show Route

Displays the list of upcoming maneuvers.

Route Summary

Provides current location.

Where Am I

Allows you to zoom in on the map.

Zoom in

Allows you to zoom out from the map.

Zoom out

395

MKZ Hybrid (CC9) Hybrid Electric Vehicle (HEV), Canada/United States of America, enUSA, Edition date: 201805, First-Printing

SYNC™ 3

Mobile App Voice Commands

 (If Equipped)

The following voice commands are always available:

Description

Voice command

SYNC 3 will prompt you to say the name of an app to start it on SYNC 3.

Mobile Apps

SYNC 3 will list all of the currently available Mobile Apps.

List Mobile Apps

SYNC 3 will search and connect to compatible app(s) running on your mobile device.

Find Mobile Apps

There are also voice commands that you can use when app(s) are connected to SYNC 3:

Description

Voice command

At any time, you can say the name of a mobile app to start the mobile app on SYNC 3.

Say the name of an app

SYNC 3 will list the available voice commands for the specified app if the app is running on SYNC 3.

Say the name of an app, followed
by help

SiriusXM Traffic and Travel Link Voice
Commands

 (If Equipped)

SiriusXM Traffic and Travel Link may not be
available in all markets. Activation and a
subscription are required.

396

MKZ Hybrid (CC9) Hybrid Electric Vehicle (HEV), Canada/United States of America, enUSA, Edition date: 201805, First-Printing

SYNC™ 3

You can say the following commands to access SiriusXM Traffic and Travel Link:

Description

Voice command

Displays a list of traffic incidents.

Show Traffic

Displays the current weather map.

Show Weather Map

Displays a list of fuel prices.

Show Fuel Prices

Displays the 5 day weather forecast.

Show 5 Day Forecast

Help

Voice Settings Commands

You can say the following commands to access the voice settings:

Description

Voice command

Allows you to enter the voice settings functionality.

Voice Settings

Sets standard prompting with longer prompts.

Interaction Mode Standard

Sets advanced prompting with shorter prompts.

Interaction Mode Advanced

Allows the system to confirm before making a phone call.

Call Confirmation On

397

MKZ Hybrid (CC9) Hybrid Electric Vehicle (HEV), Canada/United States of America, enUSA, Edition date: 201805, First-Printing

SYNC™ 3

Description

Voice command

The system does not confirm before placing a call.

Call Confirmation Off

The system displays a short list of available commands.

Voice Command Lists On

The system does not display the list of commands.

Voice Command Lists Off

You can use the volume control to adjust the
volume of the system voice prompts. While
prompt is active, adjust the volume control
up or down to your desired setting.

Note: Depending on the current climate
control settings, the fan speed may
automatically go down while issuing voice
commands or while making and receiving
phone calls via SYNC to reduce the amount
of background noise in the vehicle. The fan
speed will automatically return to normal
operation once the voice session ends. You
can adjust the fan speed during a voice
session, simply press the fan buttons (or turn
the fan knob) to increase or decrease the
fan speed to the setting you prefer.

To disable this automatic fan speed
reduction feature during voice sessions,
press and hold the climate control AC and
Recirculated air buttons simultaneously,
release and then increase fan speed within
2 seconds. To re-enable this feature, repeat
the above sequence.

ENTERTAINMENT

398

MKZ Hybrid (CC9) Hybrid Electric Vehicle (HEV), Canada/United States of America, enUSA, Edition date: 201805, First-Printing

SYNC™ 3

E242502

399

MKZ Hybrid (CC9) Hybrid Electric Vehicle (HEV), Canada/United States of America, enUSA, Edition date: 201805, First-Printing

SYNC™ 3

Message and description

Message

Sources

A

Direct Tune

B

Presets

C

Note: Your vehicle may allow you to save
presets from different audio sources on the
same page.

You can access these options using the
touchscreen or voice commands.

Sources

Press this button to select the source of
media you want to listen to.

Menu item

AM

FM

1

SIRIUS

1

CD

The name of the USB that is plugged in displays here.

USB

400

MKZ Hybrid (CC9) Hybrid Electric Vehicle (HEV), Canada/United States of America, enUSA, Edition date: 201805, First-Printing

SYNC™ 3

Menu item

Bluetooth Stereo

If you have SYNC 3 compatible apps on your connected smart phone, they display here as individual source selections.

Apps

1

This feature may not be available in all markets and requires an active subscription.

AM/FM Radio

Tuning a Station

You can use the tune or seek controls on the
radio bezel to select a station.

To tune a station using the touchscreen,
select:

Menu item

Direct Tune

A pop up appears, allowing you to type in
the frequency of a station. You can only enter
a valid station for the source you are
currently listening to.

You can press the backspace button to
delete the previously entered number.

Once you have entered the station's call
numbers, you can select:

Action and description

Menu item

Press to begin
playing the station
you have entered.

Enter

Press to exit without
changing the station.

Cancel

Presets

To set a new preset, tune to the station and
then press and hold one of the memory
preset buttons. The audio mutes briefly while
the system saves the station and then
returns.

There are two preset banks available for AM
and three banks for FM. To access additional
presets, tap the preset button. The indicator
on the preset button shows which bank of
presets you are currently viewing.

SiriusXM® Satellite Radio (If Activated)

Note:  This feature may not be available in
all markets and requires an active
subscription.

E234451

401

MKZ Hybrid (CC9) Hybrid Electric Vehicle (HEV), Canada/United States of America, enUSA, Edition date: 201805, First-Printing

SYNC™ 3

SiriusXM satellite radio is a
subscription-based satellite radio service that
broadcasts a variety of music, sports, news,
weather, traffic and entertainment
programming. Your factory-installed SiriusXM
satellite radio system includes hardware and
a limited subscription term that begins on
the date of sale or lease of your vehicle. See
an authorized dealer for availability.

For more information on extended
subscription terms (a service fee is required),
the online media player and a list of SiriusXM
satellite radio channels, and other features,
please visit www.siriusxm.com in the United
States, www.siriusxm.ca in Canada, or call
SiriusXM at 1-888-539-7474.

Note: SiriusXM reserves the unrestricted
right to change, rearrange, add or delete
programming. This includes canceling,
moving or adding particular channels, and
its prices, at any time, with or without notice
to you. Ford Motor Company shall not be
responsible for any such programming
changes.

Note: This receiver includes the eCos
real-time operating system. eCos is
published under the eCos License.

The following buttons are available for SiriusXM:

Action and description

Menu item

Touch this button to see a list of available stations.

Browse

A pop-up appears, allowing you to type in the call numbers of a station.

Direct Tune

Once you enter the stations call numbers, you can select:

The system tunes to the station you select.

Enter

You exit the pop-up and the current station continues to play.

Cancel

You can press the backspace button to delete the previous number.

402

MKZ Hybrid (CC9) Hybrid Electric Vehicle (HEV), Canada/United States of America, enUSA, Edition date: 201805, First-Printing

SYNC™ 3

Action and description

Menu item

Replay audio on the current channel. You can replay approximately 45 minutes of audio as long as
you remain tuned to the current station. Changing stations erases the previous audio.

Replay

When you are in replay mode, you are not able to select a different
preset until you return to live audio. Pressing this button returns you
to the live broadcast.

Live

Save the current song, artist, or team as a favorite. The system alerts you when it plays again on
any channel.

ALERT

Selecting this button allows you to enable and edit alerts.  See Settings (page 444).

Memory Presets

To set a preset, tune to the station then press
and hold one of the memory preset buttons.
The audio mutes briefly while the system
saves the station and returns once the
station is stored.

There are three preset banks available for
SiriusXM. To access additional presets, tap
the preset button. The indicator on the preset
button shows which bank of presets you are
currently viewing.

Satellite Radio Electronic Serial Number
(ESN)

You need your ESN to activate, modify or
track your satellite radio account.  See
Settings (page 444).

403

MKZ Hybrid (CC9) Hybrid Electric Vehicle (HEV), Canada/United States of America, enUSA, Edition date: 201805, First-Printing

SYNC™ 3

SiriusXM Satellite Radio Reception Factors and Troubleshooting

Potential reception issues

For optimal reception performance, keep the antenna clear of snow and ice build-up and keep
luggage and other materials as far away from the antenna as possible.

Antenna obstructions

Hills, mountains, tall buildings, bridges, tunnels, freeway overpasses, parking garages, dense tree
foliage and thunderstorms can interfere with your reception.

Terrain

When you pass a ground-based broadcast-repeating tower, a stronger signal may overtake a
weaker one and the audio system may mute.

Station overload

Your display may show ACQUIRING... to indicate the interference and the audio system may mute.

Satellite radio signal interference

Troubleshooting tips

Action

Cause

Message

No action required.  This message should disap-
pear shortly.

Radio requires more than two seconds to produce
audio for the selected channel.

Acquiring Signal

If this message does not clear shortly, or with an
ignition key cycle, your receiver may have a fault.
See an authorized dealer for service.

There is an internal module or system failure
present.

Satellite antenna fault

SIRIUS system failure

Tune to another channel or choose another preset.

The channel is no longer available.

Invalid Channel

404

MKZ Hybrid (CC9) Hybrid Electric Vehicle (HEV), Canada/United States of America, enUSA, Edition date: 201805, First-Printing

SYNC™ 3

Troubleshooting tips

Action

Cause

Message

Contact SiriusXM at 1-888-539-7474 to subscribe
to the channel, or tune to another channel.

Your subscription does not include this channel.

Unsubscribed Channel

The signal is blocked. When you move into an
open area, the signal should return.

The signal is lost from the SiriusXM satellite or
SiriusXM tower to your vehicle antenna.

Satellite acquiring signal…

No action required.  The process may take up to
three minutes.

Update of channel programming in progress.

Updating…

Contact SiriusXM at 1-888-539-7474 to resolve
subscription issues.

Your satellite service is no longer available.

Questions? Call 1-888-539-7474

Use the channel guide to turn off the Lock or Skip
function on that station.

All the channels in the selected category are either
skipped or locked.

None found. Check channel guide.

No action required.

SiriusXM has updated the channels available for
your vehicle.

SIRIUS Subscription updated

HD Radio™ Information (If Available)

Note:  This feature may not be available in
all markets.

To activate HD radio, please see the Radio
Settings in the Settings Chapter.  See
Settings (page 444).

Note: HD Radio broadcasts are not available
in all markets.

405

MKZ Hybrid (CC9) Hybrid Electric Vehicle (HEV), Canada/United States of America, enUSA, Edition date: 201805, First-Printing

SYNC™ 3

HD Radio technology is the digital evolution
of analog AM/FM radio. Your system has a
special receiver that allows it to receive
digital broadcasts (where available) in
addition to the analog broadcasts, it already
receives. Digital broadcasts provide a better
sound quality than analog broadcasts with
free, crystal-clear audio and no static or
distortion. For more information, and a guide
to available stations and programming,
please visit:

Website

www.hdradio.com

When HD Radio is on and you tune to a
station broadcasting HD Radio technology,
you may notice the following indicators on
your screen:

E142616

The HD logo is grey when acquiring a digital
station, and then changes to orange when
digital audio is playing. When this logo is
available, you may also see Title and Artist
fields on-screen.

The multicast indicator appears in FM mode
(only) if the current station is broadcasting
multiple digital broadcasts. The highlighted
numbers signify available digital channels
where new or different content is available.
HD1 signifies the main programming status
and is available in analog and digital
broadcasts. Other multicast stations (HD2
through HD7) are only available digitally.

Note:  There is also an additional feature for
stations that have more than 1 HD multicast
(For example, HD1 or HD2). The HD logo and
Radio text appears as a button. Pressing this
button allows you cycle through all of the
HD stations on that specific frequency. For
example, if you are on 101.1 and it has HD1,
HD2, HD3, pressing the button repeatedly
causes the radio to cycle through the HD
stations in a cyclic increasing order.

406

MKZ Hybrid (CC9) Hybrid Electric Vehicle (HEV), Canada/United States of America, enUSA, Edition date: 201805, First-Printing

SYNC™ 3
