Lincoln MKC (2019 year). Manual - part 7

Tachometer

A

Information display

B

Speedometer

C

Fuel gauge

D

Engine coolant temperature gauge

E

Information Display

Vehicle Settings and Personalization

See General Information (page 108).

Fuel Gauge

Note: The fuel gauge may vary slightly when
your vehicle is moving or on a gradient.

Switch the ignition on. The fuel gauge will
indicate approximately how much fuel is left
in the fuel tank. The arrow adjacent to the
fuel pump symbol indicates on which side of
your vehicle the fuel filler door is located.

The needle should move toward F when you
refuel your vehicle. If the needle points to E
after adding fuel, this indicates your vehicle
needs service soon.

After refueling some variability in needle
position is normal:

•

It may take a short time for the needle to
reach full after leaving the gas station.
This is normal and depends upon the
slope of pavement at the gas station.

•

The fuel amount dispensed into the tank
is a little less or more than the gauge
indicated. This is normal and depends
upon the slope of pavement at the gas
station.

•

If the gas station nozzle shuts off before
the tank is full, try a different gas pump
nozzle.

Low Fuel Level Reminder

A low fuel level reminder displays and
sounds when the distance to empty reaches
50 mi (80 km) to empty for MyKey, and at
35 mi (60 km), 25 mi (40 km), 10 mi (20 km)
and 0 mi (0 km) for all vehicle keys.

Engine Coolant Temperature Gauge

Indicates engine coolant temperature. At
normal operating temperature, the level
indicator will be in the normal range. If the
engine coolant temperature exceeds the
normal range, stop your vehicle as soon as
safely possible, switch off the engine and let
the engine cool.

WARNING

Never remove the coolant reservoir
cap when the engine is running or hot.

WARNING LAMPS AND
INDICATORS

The following warning lamps and indicators
alert you to a vehicle condition that may
become serious.  Some lamps illuminate
when you start your vehicle to make sure
they work.  If any lamps remain on after
starting your vehicle, refer to the respective
system warning lamp for further information.

103

MKC (TME) Canada/United States of America, enUSA, Edition date: 201802, First Printing

Instrument Cluster

Note: Some warning indicators appear in
the information display and operate the
same as a warning lamp but do not
illuminate when you start your vehicle.

Adaptive Cruise Control Indicator

 (If

Equipped)

E144524

It illuminates when you switch the
system on.

It illuminates white when the

system is in standby mode.  It illuminates
green when you set the adaptive cruise
speed.

See Using Adaptive Cruise Control (page
210).

Airbag Warning Lamp

E67017

If it does not illuminate when you
switch the ignition on, continues
to flash or remains on when the

engine is running, this indicates a
malfunction.  Have your vehicle checked as
soon as possible.

Anti-Lock Brake System Warning Lamp

If it illuminates when you are
driving, this indicates a
malfunction.  Your vehicle

continues to have normal braking without
the anti-lock brake system function.  Have
your vehicle checked as soon as possible.

Auto Hold Active

E197933

It illuminates when the system
holds your vehicle stationary.

Auto Hold Unavailable

E197934

It illuminates when the system is
on, but unavailable to hold your
vehicle stationary.

Automatic Headlamp High Beam
Indicator

 (If Equipped)

It illuminates when the system
automatically turns the headlamp
high beam on.

See Automatic High Beam Control (page
90).

Auto-Start-Stop Indicator

 (If Equipped)

It will illuminate to inform you when
the engine shuts down or in
conjunction with a message.

Battery

If it illuminates while driving, it
indicates a malfunction. Switch off
all unnecessary electrical

equipment and have the system checked by
an authorized dealer immediately.

Blind Spot Information System
Indicator

 (If Equipped)

E151262

It illuminates when you switch the
system off.

See Blind Spot Information

System (page 224).

104

MKC (TME) Canada/United States of America, enUSA, Edition date: 201802, First Printing

Instrument Cluster

Brake System Warning Lamp

WARNING

Driving your vehicle with the warning
lamp on is dangerous. A significant

decrease in braking performance may occur.
It may take you longer to stop your vehicle.
Have your vehicle checked as soon as
possible. Driving extended distances with
the parking brake engaged can cause brake
failure and the risk of personal injury.

Note: Indicators vary depending on region.

E270480

It illuminates when you engage the
parking brake and the ignition is
on.

If it illuminates when your vehicle
is moving, make sure the parking

brake is disengaged.  If the parking brake is
disengaged, this indicates low brake fluid
level or a brake system fault.  Have your
vehicle checked as soon as possible.

Cruise Control Indicator

E71340

It illuminates when you switch the
system on.

See Using Cruise Control (page

209).

Direction Indicator

Illuminates when you turn the left
or right direction indicator or the
hazard warning flasher on. If the

indicators stay on or flash faster, check for a
burned out bulb.  See Changing a Bulb
(page 300).

Door Ajar

Displays when the ignition is on
and any door is not completely
closed.

Electric Park Brake

E146190

It will illuminate or flash when the
electric parking brake has a
malfunction.  See Electric Parking

Brake (page 187).

Engine Coolant Temperature Warning
Lamp

If it illuminates when your vehicle
is moving, this indicates that the
engine is overheating.  Stop your

vehicle as soon as it is safe to do so and
switch the engine off.  Have your vehicle
checked as soon as possible.

Fasten Seatbelt Warning Lamp

E71880

It illuminates and a chime sounds
until you fasten the seatbelts.

Front Fog Lamp Indicator

 (If Equipped)

It illuminates when you switch the
front fog lamps on.

105

MKC (TME) Canada/United States of America, enUSA, Edition date: 201802, First Printing

Instrument Cluster

Heads Up Display

 (If Equipped)

E156133

A red beam of lights will illuminate
on the windshield in certain
instances when using adaptive

cruise control or the collision warning system.
It will also illuminate momentarily when you
start your vehicle to make sure the display
works.

Headlamp High Beam Indicator

It illuminates when you switch the
headlamp high beam on.

Hood Ajar

E159324

Displays when the ignition is on
and the hood is not completely
closed.

Lane Keeping System Lamp

 (If Equipped)

E144813

It illuminates when the system
activates.

Low Fuel Level Warning Lamp

If it illuminates when you are
driving, refuel as soon as possible.

Low Tire Pressure Warning Lamp

It illuminates when your tire
pressure is low. If the lamp remains
on with the engine running or

when driving, check your tire pressure as
soon as possible.

It also illuminates momentarily when you
switch the ignition on to confirm the lamp is
functional. If it does not illuminate when you
switch the ignition on, or begins to flash at
any time, have the system checked by your
authorized dealer.

Low Washer Fluid Level Warning Lamp

E132353

It illuminates when the washer fluid
is low.

Oil Pressure Warning Lamp

It illuminates when you switch the
ignition on.

If it illuminates when the engine is

running this indicates a malfunction.  Stop
your vehicle as soon as it is safe to do so
and switch the engine off.  Check the engine
oil level.  If the oil level is sufficient, this
indicates a system malfunction.  Have your
vehicle checked as soon as possible.

See Engine Oil Check (page 289).

Parking Lamps

It will illuminate when you switch
the parking lamps on.

Powertrain Fault

Illuminates when the system has
detected a powertrain or an
all-wheel drive fault. Contact an

authorized dealer as soon as possible.

106

MKC (TME) Canada/United States of America, enUSA, Edition date: 201802, First Printing

Instrument Cluster

Service Engine Soon

If it illuminates when the engine is
running this indicates a
malfunction.  The On Board

Diagnostics system has detected a
malfunction of the vehicle emission control
system.

If it flashes, engine misfire may be occurring.
Increased exhaust gas temperatures could
damage the catalytic converter or other
vehicle components.  Drive in a moderate
fashion (avoid heavy acceleration and
deceleration) and have your vehicle
immediately serviced.

It illuminates when you switch the ignition
on prior to engine start to check the bulb and
to indicate whether your vehicle is ready for
Inspection and Maintenance (I/M) testing.

Normally, it illuminates until the engine is
cranked and automatically turns off if no
malfunctions are present. However, if after
15 seconds it flashes eight times, this
indicates that your vehicle is not ready for
Inspection and Maintenance (I/M) testing.

See Catalytic Converter (page 172).

Stability Control and Traction Control
Indicator

E138639

Flashes during operation.

If it does not illuminate when you
switch the ignition on, or remains

on when the engine is running, this indicates
a malfunction.  Have your vehicle checked
as soon as possible.

Note: The system automatically turns off if
there is a malfunction.

See Using Stability Control (page 196).   See
Using Traction Control (page 193).

Stability Control and Traction Control
Off Warning Lamp

E130458

It illuminates when you switch the
system off.

AUDIBLE WARNINGS AND
INDICATORS

Keyless Warning Alert

The horn will sound twice when you exit your
vehicle with the intelligent access key and
your vehicle is in RUN, indicating your vehicle
is still on.

Headlamps On Warning Chime

Sounds when you remove the key from the
ignition and open the driver's door and you
have left the headlamps or parking lamps
on.

Parking Brake On Warning Chime

Sounds when you have left the parking brake
on and drive your vehicle. If the warning
chime remains on after you have released
the parking brake, have the system checked
by your authorized dealer immediately.

107

MKC (TME) Canada/United States of America, enUSA, Edition date: 201802, First Printing

Instrument Cluster

GENERAL INFORMATION

WARNING

Driving while distracted can result in
loss of vehicle control, crash and injury.

We strongly recommend that you use
extreme caution when using any device that
may take your focus off the road. Your
primary responsibility is the safe operation
of your vehicle. We recommend against the
use of any hand-held device while driving
and encourage the use of voice-operated
systems when possible. Make sure you are
aware of all applicable local laws that may
affect the use of electronic devices while
driving.

You can control various systems on your
vehicle using the information display controls
on the steering wheel.  The information
display shows the corresponding information.

Information Display Controls

E170369

•

Press the up and down arrow buttons to
scroll through and highlight the options
within a menu.

•

Press the right arrow button to enter a
sub-menu.

•

Press the left arrow button to exit a menu.

•

Press and hold the left arrow button at
any time to return to the main menu
display (escape button).

•

Press the OK button to choose and
confirm settings or messages.

E204495

This icon gives you the ability to
switch a feature on or off. A check
in the box indicates the feature is

enabled, and unchecked indicates the
feature is disabled.

Trip 1 & 2

Choose between the standard or enhanced
trip display.

Note: Some items are optional and may not appear.

108

MKC (TME) Canada/United States of America, enUSA, Edition date: 201802, First Printing

Information Displays

Trip 1 & 2

Normal or Towing

Distance to E

Average fuel economy

Trip timer

Press and hold OK to reset the currently displayed trip information.

•

Trip odometer — shows the accumulated trip distance.

•

Trip Timer— when you switch your vehicle off the timer stops and then restarts when you restart your vehicle.

•

Average fuel economy — shows the average fuel economy for a given trip.

Fuel Economy

Use the left or right arrow buttons to choose
the desired fuel economy display.

Fuel Economy

Instantaneous Fuel Economy

Auto StartStop

•

Instantaneous Fuel Economy: This display shows a visual graph of your instantaneous fuel economy.

•

Auto StartStop - Available Auto Start-Stop messaging will provide details about what is happening with your system.  See Information
Messages (page 113).

109

MKC (TME) Canada/United States of America, enUSA, Edition date: 201802, First Printing

Information Displays

Driver Assist

Use the up or down arrow buttons to choose
between the following display options.

Driver Assist

Traction Control

Blindspot

Sensitivity

Collision Warning

Cross Traffic

Adaptive or Normal

Cruise Control

On or Display

Driver Alert

Intelligent AWD

Mode

Lane Keeping Sys

Intensity

Front Park Aid

Rear Park Aid

Tire Pressure on demand screen

Tire Monitor

110

MKC (TME) Canada/United States of America, enUSA, Edition date: 201802, First Printing

Information Displays

Settings

In this mode, you can configure different
driver setting choices.

Note: Some items are optional and may not
appear.

Note: Some MyKey items will only appear if a MyKey is set.

Settings

Drive Control

Vehicle

DTE Calculation

Easy Entry/Exit

Auto Engine Off

Lighting

Locks

Mirror

Oil Life

Enable or Disable

Power Liftgate

Remote Start

Windows

Wipers

Create MyKey

MyKey

111

MKC (TME) Canada/United States of America, enUSA, Edition date: 201802, First Printing

Information Displays

Settings

911 Assist

Do Not Disturb

Traction Control

Max Speed

Speed Minder

Volume Limiter

Clear MyKeys

Distance Unit

Display

Temperature Unit

Tire Pressure

Language

Speedo in km/h

112

MKC (TME) Canada/United States of America, enUSA, Edition date: 201802, First Printing

Information Displays

INFORMATION MESSAGES

Note:  Depending on your vehicle options
and instrument cluster type, not all of the
messages will display or be available. The
information display may abbreviate or
shorten certain messages.

E145981

Press the OK button to acknowledge and
remove some messages from the information
display. The information display will
automatically remove other messages after
a short time.

You need to confirm certain messages
before you can access the menus.

Active Park

Action

Message

The system requires service due to a malfunction. Have the system checked by an authorized

dealer.

Active Park Fault

113

MKC (TME) Canada/United States of America, enUSA, Edition date: 201802, First Printing

Information Displays

Adaptive Cruise Control

Action

Message

A radar malfunction is preventing the adaptive cruise control from engaging.  See Using Adaptive

Cruise Control (page 210).

Adaptive Cruise Malfunction

A condition exists such that the adaptive cruise cannot function properly.  See Using Adaptive

Cruise Control (page 210).

Adaptive Cruise Not Available

You have a blocked sensor due to bad weather, ice, mud or water in front of the radar sensor.

You can typically clean the sensor to resolve.  See Using Adaptive Cruise Control (page 210).

Adaptive Cruise Not Available Sensor

Blocked See Manual

The system has disabled the automatic braking.

Normal Cruise Active Automatic Braking

Turned Off

A radar malfunction is preventing the adaptive cruise control from engaging.

Front Sensor Not Aligned

The adaptive cruise has reinstated controls to the driver.

Adaptive Cruise - Driver Resume Control

The vehicle speed is too slow to activate the adaptive cruise.

Adaptive Cruise Speed Too Low to

Activate

The adaptive cruise is automatically adjusting the gap distance and the driver needs to shift the

transmission into a lower gear.

Adaptive Cruise Shift Down

114

MKC (TME) Canada/United States of America, enUSA, Edition date: 201802, First Printing

Information Displays

AdvanceTrac™

Action

Message

The system detects a malfunction due to a blocked sensor.

Service AdvanceTrac

The status of the AdvanceTrac system after you switch it off.

AdvanceTrac Off

The status of the AdvanceTrac system after you switch it on.

AdvanceTrac On

Airbag

Action

Message

The system detects a malfunction due to a blocked sensor. Remove blockage.

Occupant Sensor BLOCKED Remove

Objects Near Passenger Seat

Alarm

Action

Message

Alarm triggered due to unauthorized entry.  See Anti-Theft Alarm (page 77).

Vehicle Alarm To Stop Alarm, Start Vehicle.

115

MKC (TME) Canada/United States of America, enUSA, Edition date: 201802, First Printing

Information Displays

All-Wheel Drive

Action

Message

The all-wheel drive system temporarily turns off to protect itself from overheating.

AWD Temporarily Disabled

The all-wheel drive system temporarily turns off to protect itself from overheating or if you are

using the temporary spare tire.

AWD OFF

The all-wheel drive system will resume normal function and clear this message after driving a

short distance with the road tire re-installed or after the system cools.

AWD Restored

The all-wheel drive system is not operating properly. If the warning stays on or continues to

come on, contact an authorized dealer as soon as possible.

AWD Malfunction Service Required

Automatic Engine Shutdown

Action

Message

The engine is getting ready to shut off.

Engine Shuts Off In {seconds to shut off:#0}

Seconds

The engine has shut off to help increase fuel economy.

Engine Shut Off For Fuel Economy

The engine is getting ready to shut off. You can press OK on the left steering wheel button to

override the shut down.

Engine Shuts Off in {seconds to shut off:#0}

Seconds Press Ok to Override

116

MKC (TME) Canada/United States of America, enUSA, Edition date: 201802, First Printing

Information Displays

Auto Start-Stop

Action

Message

The engine needs to be restarted, press the brake pedal to start.

Auto StartStop Press Brake to Start Engine

The engine needs to be restarted, press the brake pedal harder to start.

Auto StartStop Press Brake Harder to

Activate

The engine needs to be restarted, press any pedal to start.

Auto StartStop Press a Pedal to Start

Engine

Select neutral for the system to restart the engine.

Auto StartStop Select Neutral To Start

Engine

Select park for the system to restart the engine.

Auto StartStop Shift to P, then Restart

Engine

The system is not functioning. A manual restart is required.

Auto StartStop Manual Restart Required

Conditions are not met for the Auto StartStop system to function properly.

Auto StartStop Not Available

117

MKC (TME) Canada/United States of America, enUSA, Edition date: 201802, First Printing

Information Displays

Battery and Charging System

Action

Message

The charging system needs servicing. If the warning stays on or continues to come on, contact

an authorized dealer as soon as possible.

Check Charging System

The battery management system detects an extended low-voltage condition. Your vehicle will

disable various features to help preserve the battery. Turn off as many of the electrical loads as

soon as possible to improve system voltage. If the system voltage has recovered, the disabled

features will operate again as normal.

Low Battery Features Temporarily Turned

Off

The battery management system determines that the battery is at a low state of charge. Turn

your ignition off as soon as possible to protect the battery. This message will clear once you

restart your vehicle and the battery state of charge has recovered. Turning off unnecessary

electrical loads will allow faster battery state-of-charge recovery.

Turn Power Off To Save Battery

118

MKC (TME) Canada/United States of America, enUSA, Edition date: 201802, First Printing

Information Displays
