4. Watch for the HomeLink

威 indicator to change flash

rates. When it changes, it is programmed. It may take up
to 30 seconds or longer in rare cases. The garage door
may open and close while you are programming.

5. Press and hold the programmed HomeLink

威 button

and observe the indicator light.

• If the indicator light stays on constantly, program-

ming is complete and the garage door/device
should activate when the HomeLink

威 button is

pressed.

• To program the two remaining HomeLink威 buttons,

repeat each step for each remaining button. DO
NOT erase the channels.

If you unplugged the garage door opener/device for
programming, plug it back in at this time.

Reprogramming A Single HomeLink

威 Button

To reprogram a channel that has been previously trained,
follow these steps:

1. Turn the ignition switch to the ON/RUN position.

2. Press and hold the desired HomeLink

威 button until

the indicator light begins to flash after 20 seconds. Do not
release the button.

3. Without

releasing

the

button

proceed

with

“Canadian/Gate Operator Programming” Step 2 and
follow all remaining steps.

Using HomeLink

姞

To operate, press and release the programmed
HomeLink

威 button. Activation will now occur for the

programmed device (i.e., garage door opener, gate opera-
tor, security system, entry door lock, home/office light-
ing, etc.,). The hand-held transmitter of the device may
also be used at any time.

172

UNDERSTANDING THE FEATURES OF YOUR VEHICLE

Security

It is advised to erase all channels before you sell or turn
in your vehicle.

To do this, press and hold the two outside buttons for
20 seconds until the red indicator flashes. Note that all
channels will be erased. Individual channels cannot be
erased.

The HomeLink

威 Universal Transceiver is disabled when

the Vehicle Security Alarm is active.

Troubleshooting Tips

If you are having trouble programming HomeLink

威, here

are some of the most common solutions:

• Replace the battery in the original hand-held transmit-

ter.

• Press the LEARN button on the Garage Door Opener

to complete the training for a Rolling Code.

• Did you unplug the device for programming and

remember to plug it back in?

If you have any problems, or require assistance, please
call toll-free 1–800–355–3515 or, on the Internet at
www.HomeLink.com for information or assistance.

UNDERSTANDING THE FEATURES OF YOUR VEHICLE

173

WARNING!

• Your motorized door or gate will open and close

while you are programming the universal trans-
ceiver. Do not program the transceiver if people,
pets or other objects are in the path of the door or
gate. Only use this transceiver with a garage door
opener that has a “stop and reverse” feature as
required by Federal safety standards. This includes
most garage door opener models manufactured
after 1982. Do not use a garage door opener without
these safety features. Call toll-free 1–800–355–3515
or, on the Internet at www.HomeLink.com for
safety information or assistance.

• Vehicle exhaust contains carbon monoxide, a dan-

gerous gas. Do not run your vehicle in the garage
while programming the transceiver. Exhaust gas
can cause serious injury or death.

General Information

This device complies with FCC rules Part 15 and Industry
Canada RSS-210. Operation is subject to the following
two conditions:

1. This device may not cause harmful interference.

2. This device must accept any interference that may be
received including interference that may cause undesired
operation.

NOTE:

• The transmitter has been tested and it complies with

FCC and IC rules. Changes or modifications not
expressly approved by the party responsible for com-
pliance could void the user’s authority to operate the
device.

• The term IC before the certification/registration num-

ber only signifies that Industry Canada technical
specifications were met.

174

UNDERSTANDING THE FEATURES OF YOUR VEHICLE

POWER SUNROOF — IF EQUIPPED

The power sunroof switch is located in the reading light.

WARNING!

• Never leave children in a vehicle with the key in

the ignition switch. Occupants, particularly unat-
tended children, can become entrapped by the
power sunroof while operating the power sunroof
switch. Such entrapment may result in serious
injury or death.

• In a collision, there is a greater risk of being

thrown from a vehicle with an open sunroof. You
could also be seriously injured or killed. Always
fasten your seat belt properly and make sure all
passengers are properly secured too.

• Do not allow small children to operate the sun-

roof. Never allow your fingers, other body parts, or
any object to project through the sunroof opening.
Injury may result.

Power Sunroof Switch

UNDERSTANDING THE FEATURES OF YOUR VEHICLE

175

Opening Sunroof — Express

Press the switch rearward and release it within one-half
second and the sunroof will open automatically from any
position. The sunroof will open fully and stop automati-
cally. This is called “Express Open”. During Express
Open operation, any movement of the sunroof switch
will stop the sunroof.

Opening Sunroof — Manual Mode

To open the sunroof, press and hold the switch rearward
to full open. Any release of the switch will stop the
movement and the sunroof will remain in a partially
opened condition until the switch is pushed and held
rearward again.

Closing Sunroof — Express

Press the switch forward and release it within one-half
second and the sunroof will close automatically from any
position. The sunroof will close fully and stop automati-
cally. This is called “Express Close”. During Express

Close operation, any movement of the switch will stop
the sunroof.

Closing Sunroof — Manual Mode

To close the sunroof, press and hold the switch in the
forward position. Any release of the switch will stop the
movement and the sunroof will remain in a partially
closed condition until the switch is pushed and held
forward again.

Pinch Protect Feature

This feature will detect an obstruction in the opening of
the sunroof during Express Close operation. If an ob-
struction in the path of the sunroof is detected, the
sunroof will automatically retract. Remove the obstruc-
tion if this occurs. Next, press the switch forward and
release to Express Close.

NOTE:

Pinch protection is disabled while the switch is

pressed.

176

UNDERSTANDING THE FEATURES OF YOUR VEHICLE

Venting Sunroof — Express

Press and release the Vent button within one half second
and the sunroof will open to the vent position. This is
called “Express Vent”, and it will occur regardless of
sunroof position. During Express Vent operation, any
movement of the switch will stop the sunroof.

Sunshade Operation

The sunshade can be opened manually. However, the
sunshade will open automatically as the sunroof opens.

NOTE:

The sunshade cannot be closed if the sunroof is

open.

Wind Buffeting

Wind buffeting can be described as the perception of
pressure on the ears or a helicopter-type sound in the
ears. Your vehicle may exhibit wind buffeting with the
windows down, or the sunroof (if equipped) is in certain
open or partially open positions. This is a normal occur-
rence and can be minimized. If the buffeting occurs with

the rear windows open, open the front and rear windows
together to minimize the buffeting. If the buffeting occurs
with the sunroof open, adjust the sunroof opening to
minimize the buffeting or open any window.

Sunroof Maintenance

Use only a non-abrasive cleaner and a soft cloth to clean
the glass panel.

Ignition Off Operation

For vehicles not equipped with the Electronic Vehicle
Information Center (EVIC), the power sunroof switch
will remain active for 45 seconds after the ignition switch
is turned to the LOCK position. Opening either front
door will cancel this feature.

For vehicles equipped with the EVIC, the power sunroof
switch will remain active for up to approximately ten
minutes after the ignition switch is turned to the LOCK
position. Opening either front door will cancel this
feature. The time is programmable. Refer to “Electronic

UNDERSTANDING THE FEATURES OF YOUR VEHICLE

177

Vehicle Information Center (EVIC)/Personal Settings
(Customer-Programmable Features)” in “Understanding
Your Instrument Panel” for further information.

ELECTRICAL POWER OUTLETS

There is a standard 12 Volt (13 Amp) power outlet located
in the instrument panel for added convenience. This
power outlet can power cellular phones, electronics and
other low power devices.

Power is available when the ignition switch is in the ON
or ACC position. Insert the cigar lighter or accessory plug
into the outlet for use. To preserve the heating element,
do not hold the lighter in the heating position.

NOTE:

To ensure proper operation, a MOPAR

威 knob

and element must be used.

12 Volt Power Outlet

178

UNDERSTANDING THE FEATURES OF YOUR VEHICLE

CAUTION!

• Do not exceed the maximum power of 160 Watts

(13 Amps) at 12 Volts. If the 160 Watt (13 Amp)
power rating is exceeded the fuse protecting the
system will need to be replaced.

• Power outlets are designed for accessory plugs

only. Do not insert any other object in the power
outlets as this will damage the outlet and blow the
fuse. Improper use of the power outlet can cause
damage not covered by your New Vehicle Limited
Warranty.

WARNING!

To avoid serious injury or death:
• Only devices designed for use in this type of

outlet should be inserted into any 12 Volt outlet.

(Continued)

Power Outlet Fuse Location

UNDERSTANDING THE FEATURES OF YOUR VEHICLE

179

WARNING! (Continued)

• Do not touch with wet hands.

• Close the lid when not in use and while driving

the vehicle.

• If this outlet is mishandled, it may cause an

electric shock and failure.

CAUTION!

• Many accessories that can be plugged in draw

power from the vehicle’s battery, even when not in
use (i.e., cellular phones, etc.). Eventually, if
plugged in long enough, the vehicle’s battery will
discharge sufficiently to degrade battery life
and/or prevent the engine from starting.

(Continued)

CAUTION! (Continued)

• Accessories that draw higher power (i.e., coolers,

vacuum cleaners, lights, etc.) will degrade the
battery even more quickly. Only use these inter-
mittently and with great caution.

• After the use of high power draw accessories, or

long periods of the vehicle not being started (with
accessories still plugged in), the vehicle must be
driven a sufficient length of time to allow the
generator to recharge the vehicle’s battery.

POWER INVERTER — IF EQUIPPED

A 115 Volt (150 Watt) AC power inverter is located on the
rear of the center console for added convenience. This
outlet can power cellular phones, electronics and other
low power devices requiring power up to 150 Watts.
Certain high-end video games, such as Playstation3 and

180

UNDERSTANDING THE FEATURES OF YOUR VEHICLE

XBox360 will exceed this power limit, as will most power
tools.

The power inverter is designed with built-in overload
protection. If the power rating of 150 Watts is exceeded,
the power inverter will automatically shut down. Once
the electrical device has been removed from the outlet the
inverter should automatically reset. If the power rating
exceeds approximately 170 Watts, the power inverter
may have to be reset manually. To reset the inverter
manually, unplug the device and plug it in again.

NOTE:

To avoid overloading the circuit, check the

power ratings on electrical devices prior to using the
inverter.

WARNING!

To avoid serious injury or death:
• Do not use a three-prong adaptor.

• Do not insert any objects into the receptacles.

(Continued)

115 Volt Power Outlet

UNDERSTANDING THE FEATURES OF YOUR VEHICLE

181

WARNING! (Continued)

• Do not touch with wet hands.

• Close the lid when not in use.

• If this outlet is mishandled, it may cause an

electric shock and failure.

CAUTION!

• Many accessories that can be plugged in draw

(Continued)

CAUTION! (Continued)

• Accessories that draw higher power (i.e., coolers,

vacuum cleaners, lights, etc.) will degrade the
battery even more quickly. Only use these inter-
mittently and with great caution.

• After the use of high power draw accessories, or

long periods of the vehicle not being started (with
accessories still plugged in), the vehicle must be
driven a sufficient length of time to allow the
generator to recharge the vehicle’s battery.

182

UNDERSTANDING THE FEATURES OF YOUR VEHICLE

CUPHOLDERS

Your vehicle is equipped with four cupholders. There are
two cupholders located in the front.

There are two cupholders behind the center console for
rear passengers.

Front Cupholders

Rear Cupholders

UNDERSTANDING THE FEATURES OF YOUR VEHICLE

183

CONSOLE FEATURES

The floor console contains both an upper and lower
storage compartment.

To open the upper storage compartment, push inward on
the upper handle to unlatch the upper lid and lift the lid
open.

Upper Storage Compartment

184

UNDERSTANDING THE FEATURES OF YOUR VEHICLE

To open the lower storage compartment, lift upward on
the lower handle to unlatch the lower storage compart-
ment and lift the lid open.

WARNING!

Do not operate this vehicle with a console compart-
ment lid in the open position. Cellular phones, music
players, and other handheld electronic devices
should be stowed while driving. Use of these devices
while driving can cause an accident due to distrac-
tion, resulting in death or injury.

CARGO AREA FEATURES

Cargo Light/Removable Self-Recharging
Flashlight

The dual-function light is mounted in the headliner
above the cargo area to illuminate the cargo area, and
part of it snaps out of the bezel to serve as a flashlight
when needed. The flashlight features two bright LED
light bulbs and is powered by rechargeable lithium
batteries that recharge when snapped back into place for
convenience.

Lower Storage Compartment

UNDERSTANDING THE FEATURES OF YOUR VEHICLE

185

Cargo Cover

The cargo area trim panels include two notches for
mounting the available tonneau cover that accommo-
dates the reclining rear seat.

To install the Cargo Cover, insert either end of the cover
into one of the two notches located in the rear trim
panels. With one of the cover ends installed, push inward
on the opposite end and install it into the same notch
location of the rear trim panel.

Rear Trim Notches

UNDERSTANDING THE FEATURES OF YOUR VEHICLE

187

Dodge Caliber (2012 year). Manual - part 11
